1999 DODGE RAM Service Repair Manual

fitting and fuel lines are clean. Note location of release tab and
pull tab on disconnect fitting. See Fig. 6.
CAUTION: Release tab must be pressed downward before removing pull tab
or pull tab will be damaged.
2) Press release tab downward. Use screwdriver to pry pull
tab upward until pull tab separates from disconnect fitting. Remove
disconnect fitting from fuel line. Inspect components for damage. If
disconnect fitting is damaged, entire assembly must be replaced, as
only pull tab can be replaced.
3) To install, ensure fuel line and disconnect fitting are
clean. Lubricate fuel line and disconnect fitting with engine oil.
Install disconnect fitting on fuel line until disconnect fitting
bottoms on fuel line.
4) Install NEW pull tab until pull tab locks in disconnect
fitting. DO NOT reuse old pull tab. Pull on fuel line and disconnect
fitting to ensure components are properly locked together. Reconnect
negative battery cables. Start engine and check for leaks.
Removal & Installation (Dual Tab)
1) Disconnect negative battery cables. Ensure disconnect
fitting and fuel lines are clean. Note location of tabs on disconnect
fitting. See Fig. 6.
2) Squeeze both tabs against disconnect fitting. Pull
disconnect fitting from fuel line. The plastic retainer will remain on
the fuel system component being serviced. The "O" rings and spacer
will remain in the disconnect fitting.
3) Inspect components for damage. If disconnect fitting is
damaged, entire assembly must be replaced. The only component that may
be replaced is the plastic retainer. If plastic retainer must be
removed from fuel system component, carefully release the plastic
retainer from the fuel system component using 2 screwdrivers. Inspect
plastic retainer for cracks or damage. Replace plastic retainer if
defective.
4) To install, ensure fuel line and disconnect fitting are
clean. Lubricate fuel line and disconnect fitting with engine oil.
Install disconnect fitting on fuel line until click sound is heard.
5) Pull on fuel line and disconnect fitting to ensure
components are properly locked together. Reconnect negative battery
cables. Start engine and check for leaks.
Removal & Installation (Plastic Retainer Ring)
1) Disconnect negative battery cables. Ensure disconnect
fitting and fuel lines are clean. Note location of plastic retainer
ring on disconnect fitting. See Fig. 6.
NOTE: Plastic retainer ring must be pressed evenly into disconnect
fitting. If plastic retainer is not even, it will be
difficult to remove disconnect fitting from fuel line.
2) Firmly push disconnect fitting toward the fuel line while
pushing plastic retainer ring evenly into disconnect fitting. With
plastic retainer ring fully depressed, pull disconnect fitting from
fuel line.
3) Inspect components for damage. If disconnect fitting is
damaged, entire assembly must be replaced.
4) To install, ensure fuel line and disconnect fitting are
clean. Lubricate fuel line and disconnect fitting with engine oil.
Install disconnect fitting on fuel line until click sound is heard.
5) Pull on fuel line and disconnect fitting to ensure
components are properly locked together. Reconnect negative battery
cables. Start engine and check for leaks.

FUEL LINE BLEEDING
NOTE: Fuel line bleeding is necessary if fuel injection pump is
replaced, fuel filter/water separator is not filled with
diesel fuel before installing or vehicle ran out off fuel.
Bleed high-pressure fuel lines if connections are loosened or
replaced. If engine has not been operated for an extended
time, bleed fuel lines before next initial engine start-up.
WARNING: DO NOT bleed fuel lines on a hot engine, as high exhaust
temperatures may cause a fire. Carefully bleed fuel lines, as
fuel is under extremely high pressure and could penetrate
skin. Use safety goggles and protective clothing when
bleeding fuel lines.
1) Loosen banjo bolt holding low-pressure fuel supply line to
side of fuel injection pump. Wrap a towel around banjo fitting to
catch fuel. Crank engine quickly and release key before engine starts.
This will operate fuel transfer pump for about 25 seconds.
2) If fuel is not present at fuel supply line after 25
seconds, turn ignition off. Repeat engine crank procedure until fuel
is present at fuel supply line. Tighten banjo bolt at fuel supply line
to specification. See TORQUE SPECIFICATIONS.
CAUTION: Ensure parking brake is applied and transmission is in
Neutral before bleeding fuel injection pump or high-pressure
fuel lines. DO NOT operate starter for more than 30 seconds
when bleeding fuel injection pump or high-pressure fuel
lines. Allow 2-minute intervals between starter operations.
3) To bleed air from fuel injection pump, ensure parking
brake is applied and transmission is in Neutral, as engine may start
when operating starter to bleed air from fuel injection pump. Operate
starter for 30 seconds to bleed any trapped air in fuel injection
pump.
4) To bleed high-pressure fuel lines, ensure parking brake is
applied and transmission is in Neutral, as engine may start when
operating starter to bleed high-pressure fuel lines. Loosen high-
pressure fuel line nut at fuel injector.
5) Operate starter until steady fuel flow exists at high-
pressure fuel line. Tighten high-pressure fuel line nut to
specification. See TORQUE SPECIFICATIONS. Start engine. Repeat
procedure on each high-pressure fuel line until engine operates
smoothly.
FUEL FILTER/WATER SEPARATOR & WATER-IN-FUEL SENSOR
NOTE: Vehicle also contains an in-tank fuel filter located on
bottom of fuel tank module. For servicing procedure, see FUEL
TANK MODULE & IN-TANK FUEL FILTER under FUEL SYSTEM.
NOTE: When fuel filter/water separator is being replaced,
manufacturer recommends cleaning the pre-filter. See FUEL
HEATER under FUEL SYSTEM for servicing of pre-filter.
Removal
1) Ensure engine is off. Place drain pan below drain tube at
fuel filter/water separator. See Fig. 3. Rotate handle on drain valve
forward, toward front of vehicle to DRAIN position. Drain valve is
located near top of fuel filter/water separator. See Fig. 3. Once fuel
is drained from fuel filter/water separator, rotate handle on drain
valve back to CLOSE position.

2) Disconnect drain tube from drain valve. Disconnect
electrical connector for Water-In-Fuel (WIF) sensor at bottom of fuel
filter/water separator. See Fig. 3.
3) Support canister for fuel filter/water separator and
remove canister nut from top of filter mounting head. See Fig. 3.
Remove canister with fuel filter/water separator and seal ring from
filter mounting head. Remove fuel filter/water separator from
canister.
4) Remove "O" ring from top of shaft inside the canister.
Remove bolts and drain valve from canister (if necessary).
5) Check the 2 probes inside the canister on end of WIF
sensor for contamination. Clean probes if contaminated. If
contamination cannot be removed from the probes, replace WIF sensor.
If replacing WIF sensor, remove WIF sensor and "O" ring from canister.
6) Fuel heater is located inside fuel filter housing. Heater
mounting plate, heating element, temperature sensor, and wiring
harness are serviced as an assembly. Disconnect heater electrical
connector from engine wiring harness near upper rear part of filter.
7) Disconnect electrical connector at end of 2-wire harness
before attempting to pass harness through filter header. Remove clip
retaining wires to connector. Remove wires from connector. Remove 3
fuel heater screws. Press on heater sealing grommet to remove heater
from filter canister header. Pass wire through hole in filter header.
Remove fuel heater.
Installation
1) Ensure inside of canister is clean. Using NEW "O" ring,
install WIF sensor on canister (if removed). Tighten WIF sensor to
specification. See TORQUE SPECIFICATIONS.
2) Install drain valve on canister (if removed). Tighten
drain valve-to-canister bolts to specification. See TORQUE
SPECIFICATIONS.
3) Install NEW "O" ring on shaft inside canister. Coat "O"
ring with diesel fuel. Install NEW fuel filter/water separator and NEW
seal ring in canister. Coat seal ring with diesel fuel.
NOTE: Canister for fuel filter/water separator should be filled
with diesel fuel before installing. If canister cannot be
filled with diesel fuel, low-pressure fuel lines must be bled
after installation.
CAUTION: When installing canister on filter mounting head, ensure tab
areas on outside of canister align with tabs on filter
mounting head. This must be done to prevent damage to
canister and filter mounting head.
4) Fill canister for fuel filter/water separator with diesel
fuel. Install canister with fuel filter/water separator on filter
mounting head. Ensure canister fully engages with filter mounting head
and tab areas on outside of canister align with tabs on filter
mounting head.
5) Install and tighten canister nut to specification. See
TORQUE SPECIFICATIONS.
6) To install remaining components, reverse removal
procedure. If canister was not filled with diesel fuel, bleed low-
pressure fuel lines before starting engine. See FUEL LINE BLEEDING
under FUEL SYSTEM. Start engine and check for fuel leaks.
FUEL TANK MODULE & IN-TANK FUEL FILTER
NOTE: In-tank fuel filter is located on bottom of fuel tank module
which also contains the fuel gauge sending unit. Fuel tank
module is mounted on top of fuel tank.

Removal
1) Raise and support vehicle. Disconnect negative battery
cables. Drain fuel tank. Remove fuel tank filler tube bolts from body.
Support fuel tank with transmission jack. Remove fuel tank straps and
heat shields (if equipped).
2) Slightly lower fuel tank for access to fuel lines and
electrical connector at fuel tank module. Disconnect electrical
connector and fuel lines at fuel tank module. See Fig. 7. Use proper
procedure when disconnecting fuel lines. See FUEL LINE DISCONNECT
FITTINGS under FUEL SYSTEM.
NOTE: Information for servicing of in-tank fuel filter is not
available from manufacturer. If necessary to service in-tank
fuel filter, consult parts department to verify if filter may
be replace without replacing fuel tank module.
3) Note direction of fuel line connections on fuel tank
module for installation reference. Using Spanner Wrench (6856),
unscrew plastic fuel tank module lock nut from fuel tank. Remove fuel
tank module and gasket from fuel tank. Inspect in-tank fuel filter for
damage.
Installation
1) Using NEW gasket, install fuel tank module in fuel tank.
Install plastic fuel tank module lock nut finger tight. DO NOT tighten
plastic fuel tank module lock nut at this time.
2) Position fuel tank module so fuel line connections and
electric connection are facing toward driver's side of vehicle. This
must be done to prevent float on fuel gauge sending unit from
contacting fuel tank.
3) Once fuel tank module is properly positioned, tighten
plastic fuel tank module lock nut to specification. See TORQUE
SPECIFICATIONS.
4) Install fuel lines on fuel tank module using proper
procedure. See FUEL LINE DISCONNECT FITTINGS under FUEL SYSTEM.
Install electrical connector on fuel tank module. Reinstall fuel tank.
Tighten fuel tank strap nuts to specification. See TORQUE
SPECIFICATIONS. Reconnect negative battery cables.
Fig. 7: Locating Fuel Tank Module & Fuel Tank Rollover Valve
Courtesy of Chrysler Corp.
FUEL INJECTOR DRAIN LINE ASSEMBLY

Removal
1) Remove nameplate located above rocker lever covers. Remove
fuel injector drain line-to-fuel injector banjo bolt and seal washer
from each fuel injector. Plug all fuel openings.
2) Remove fuel injector drain line assembly retaining clamp
at rear of intake manifold. Remove fuel injector drain line bolt with
seal washers at filter mounting head. See Fig. 3. Remove fuel injector
drain line assembly.
Installation
To install, reverse removal procedure using NEW seal washers.
Tighten bolts to specification. See TORQUE SPECIFICATIONS.
FUEL HEATER
Removal & Installation
Fuel heater is located in FUEL FILTER/WATER SEPARATOR &
WATER-IN-FUEL SENSOR. See FUEL FILTER/WATER SEPARATOR & WATER-IN-FUEL
SENSOR.
FUEL INJECTOR
Removal
1) Disconnect negative battery cables. Each fuel injector is
connected to each high-pressure fuel line with a steel connector line.
Steel connector is positioned into cylinder head and sealed with "O"
ring. See Fig. 8. If removing injector at cylinder No. 1 or No. 2,
remove intake manifold air heater assembly. If removing injector at
cylinder No. 5, remove engine lifting bracket. Ensure area around fuel
injector and high-pressure fuel line is clean. Disconnect high-
pressure fuel line at fuel injector. DO NOT bend any high-pressure
fuel line to gain access to fuel injector. It may be necessary to
remove high-pressure fuel lines from fuel injection pump for access to
fuel injector.
2) If removing high-pressure fuel lines from fuel injection
pump, mark high-pressure fuel line location for installation
reference. Remove valve cover. Thread Fuel Injector Connector Tube
Remover (8324) onto end of injector connector tube. Remove and discard\
old "O" ring from injector connector tube.
3) Remove fuel injector hold down clamp bolt at front end of
clamp. DO NOT loosen or remove shouldered bolt at rear of clamp.
Remove injector clamp by sliding it from shoulders on rear clamp bolt.
Thread rod from fuel injector remover into top of fuel injector.
Tighten nut to remove fuel injector from cylinder head. Remove and
discard "O" ring and copper sealing washer.
Fig. 8: Removing Fuel Injector
Courtesy of Chrysler Corp.
Installation
1) Clean fuel injector bore on cylinder head with wire brush.

Apply light coat of engine oil on NEW .060" (1.5 mm) thick Copper
sealing washer. Install NEW Copper sealing washer on spray tip of fuel
injector. Engine oil is used to aid holding sealing washer in place.
Install new "O" ring on fuel injector. Apply small amount of engine
oil to "O" ring.
2) Ensure fuel inlet hole on side of fuel injector is
positioned toward injector connector tube. Install injector into
cylinder head bore using care not to allow injector tip to touch sides
of bore. Press fuel injector into cylinder head with finger pressure
only. Install fuel injector hold down clamp into shouldered bolt while
aligning slot in top of injector into groove in bottom of clamp.
Tighten opposite clamp bolt to specification. See TORQUE
SPECIFICATIONS.
3) Apply small amount of clean engine oil to NEW "O" ring.
Install "O" ring to fuel injector connector tube. Using finger
pressure only, press injector connector tube into cylinder head.
Connect and tighten high pressure fuel lines to specification. See
TORQUE SPECIFICATIONS.
NOTE: Fuel line fitting torque is important. Mating surfaces will
not seal if fuel line fitting is under or over-torqued.
4) To install remaining components, reverse removal
procedure. Tighten bolts to specification. See TORQUE SPECIFICATIONS.
Bleed high-pressure fuel lines. See FUEL LINE BLEEDING under FUEL
SYSTEM.
FUEL INJECTION PUMP
CAUTION: High-pressure fuel lines must be clamped securely and routed
so they do not contact each other or any other components. DO
NOT weld or substitute high-pressure fuel lines. High
-pressure lines are same length and proper high-pressure fuel
line must be installed in specified area for proper engine
operation.
Removal
1) Disconnect negative battery cables. Clean fuel lines at
cylinder head and injection pump. Clean fuel injection pump and fuel
lines at side of pump. Disconnect 9-pin electrical connector at Fuel
Pump Control Module (FPCM). Place a rag around overflow valve to catch\
excess fuel. Remove overflow valve and disconnect fuel return line.
Remove banjo bolts and fuel supply line at side of injection pump and
top of fuel filter housing.
2) Remove all high pressure fuel lines, intake air tube,
accelerator pedal position sensor, air intake housing, engine oil
dipstick tube, wiring clips, electrical connectors at intake heaters,
and engine lifting bracket. Unscrew plastic access cap at front gear
cover. Remove injection pump gear-to-injection pump shaft nut and
washer.
3) Engine may be rotated by removing dust plug from
transmission adapter plate and installing Engine Barring Tool (Snap-On
SP371) in transmission adapter plate. See Fig. 9. Rotate engine until
keyway is at 12 o'clock position.

Fig. 9: Rotating Engine
Courtesy of Chrysler Corp.
CAUTION: Engine must be rotated until keyway is at 12 o'clock position
to prevent pump/gear keyway from falling into gear housing.
If gear retainer nut, washer or key drops into gear housing,
cover may have to be removed to retrieve them before engine
start.
4) Using gear puller, separate injection pump gear from
injection pump shaft. See Fig. 11. DO NOT pull fuel injection pump
drive gear too far forward or timing gear cover may be damaged.
5) Remove 3 lower fuel injection pump-to-lower mounting
bracket bolts. Loosen 2 engine bracket bolts. See Fig. 10. Remove 4
fuel injection pump-to-gear housing nuts. Remove fuel injection pump.
Use care not to scratch or damage shaft of fuel injection pump during
removal.

Fig. 10: Removing Lower Pump Bracket & Mounting Bolts
Courtesy of Chrysler Corp.
Fig. 11: Removing Fuel Injection Pump Drive Gear
Courtesy of Chrysler Corp.
NOTE: Before installing fuel injection pump, ensure shaft on fuel
injection pump is properly positioned for proper fuel
