D - A D JU STM EN TS - C NG & G ASO LIN E

1999 D odge P ic ku p R 1500
1999 ENGINE PERFORMANCE
CHRY - On-Vehicle Adjustments - Trucks & RWD Vans - CNG & Gas
Dakota, Durango, Ram Pickup, Ram Van, Ram Wagon
ENGINE MECHANICAL
Before performing any on-vehicle adjustments to fuel or
ignition systems, ensure engine mechanical condition is okay.
VALVE CLEARANCE
NOTE: All engines use hydraulic lifters. No adjustments are
required.
IGNITION TIMING
On all models, ignition timing is controlled by Powertrain
Control Module (PCM). Ignition timing is nonadjustable. DO NOT attempt\
to adjust ignition timing by rotating distributor.
NOTE: On Dakota 3.9L, 5.2L and 5.9L, Durango, Ram Pickup, Ram Van
and Ram Wagon, if distributor is rotated, fuel system
synchronization will be changed. If distributor is removed or
rotated, check fuel system synchronization. See procedures
under FUEL SYSTEM SYNCHRONIZATION under FUEL SYSTEM.
FUEL SYSTEM
FUEL SYSTEM SYNCHRONIZATION
NOTE: Fuel system synchronization is controlled by position of the
distributor. Rotating distributor WILL NOT change ignition
timing, but will change fuel system synchronization. Fuel
system synchronization should be checked anytime distributor
is removed or rotated.
Dakota 3.9L, 5.2L & 5.9L, Durango, Ram Pickup, Ram Van & Ram
Wagon
1) Connect scan tool to Data Link Connector (DLC). DLC is
located below driver's side of instrument panel, near steering column.
See Fig. 1 , 2 or 3.
2) Using scan tool manufacturer's instructions, access SET
SYNC display on scan tool. Following scan tool displays, start engine.
Warm engine to normal operating temperature. Vehicle must be in closed
loop. With engine idling, if scan tool displays IN RANGE along with
0
, this indicates correct distributor location. The degree reading
displayed on scan tool indicates the fuel synchronization, not
ignition timing.
3) If scan tool display is correct, shut engine off. Remove
scan tool. If scan tool does not display IN RANGE along with 0
, go to
next step.
4) If scan tool displays a plus (+) or minus (-) sign next\
to
the degree number, and/or the degree number displayed is not zero,
loosen but DO NOT remove distributor hold-down bolt.
5) Rotate distributor until scan tool displays IN RANGE.
Continue to rotate distributor until a reading as close as possible to

2) Disconnect vacuum line at PCV valve located in valve
cover. Install .185" fixed orifice Air Metering Fitting (6714) into
disconnected vacuum line in place of PCV valve.
3) Disconnect purge vacuum hose from passenger's side front
corner of throttle body, next to MAP sensor. Place cap on vacuum hose
fitting on throttle body.
4) Connect scan tool to Data Link Connector (DLC) located
below driver's side of instrument panel, near steering column. See
Fig. 1, 2 or 3.
5) Start engine and warm engine to normal operating
temperature. Using scan tool manufacturer's instructions, select
SYSTEM TEST and then access the MINIMUM AIRFLOW display on scan tool.
When accessed, scan tool will count down to stabilize idle RPM and
display minimum airflow idle RPM. Minimum airflow idle RPM should be
500-900 RPM.
6) Shut engine off. If minimum airflow idle RPM is correct,
throttle body is okay. Go to next step. If minimum airflow idle RPM is
not within specification, using approved cleaner, clean throttle body
and recheck minimum airflow idle RPM. If correct minimum airflow idle
RPM cannot be obtained, replace throttle body. Go to next step.
7) Remove air metering fitting. Reinstall vacuum hoses as
necessary. Reinstall air duct on throttle body. Remove scan tool.
Ram Pickup 8.0L
Throttle body minimum airflow cannot be checked on this
application.
THROTTLE POSITION SENSOR
NOTE: Throttle Position (TP) sensor is nonadjustable. Use following\
procedure to check TP sensor calibration. For complete
testing of TP sensor and wiring circuit, see SELF-DIAGNOSTICS
- JEEP, TRUCKS & RWD VANS article.
Dakota, Ram Pickup, Ram Van & Ram Wagon
1) Remove components for access to electrical connector at TP
sensor mounted on throttle body. With electrical connector installed
on TP sensor, turn ignition on with engine off. DO NOT start engine.
2) Using digital volt-ohmmeter, measure voltage at center
terminal on electrical connector for TP sensor with throttle valve
closed (idle position). Voltage should be greater than .35 volt, but
less than .90 volt.
3) Slowly open throttle to full throttle and note voltage
reading. Voltage should smoothly increase to less than 4.50 volts.
Replace TP sensor if voltage is not within specification.

as the malfunction is detected. A stored code indicates there was an
active code present at some time. However, the code currently may not
be present as an active code, although another active code could be.
When a trouble code occurs, the AIR BAG warning light
illuminates for 12 seconds minimum (even if problem existed for less
than 12 seconds). Code is stored, along with time in minutes it was
active, and number of times ignition has been cycled since problem was
detected.
When and if malfunction ceases to exist, an ignition cycle
count will be initiated for that code. If ignition cycle count reaches
100 without a reoccurrence of the same malfunction, DTC is erased and
that ignition cycle counter is reset to zero. If malfunction reoccurs
before count reaches 100, ignition cycle counter will be reset and DTC
will continue to be a stored code.
If a particular code is not active while performing
diagnostic test for that code, code diagnostic test may not locate the
source of the problem. In this case, stored code can only indicate an
area of system to inspect.
If no obvious problems are found, erase stored codes, and
with ignition on, wiggle wiring harness and connectors. Recheck for
codes periodically as you work through system. This procedure may
uncover a difficult problem to locate.
PRETEST INSPECTION & DIAGNOSTIC PROCEDURE
Following precautions and procedures must be followed:
* Always follow air bag service precautions to avoid air bag
deployment and possible personal injury. Refer to procedure
under See SERVICE PRECAUTIONS.
* After component replacement, ensure proper system operation.
See SYSTEM OPERATION CHECK .
* When testing voltage or continuity at ACM, use terminal side
(not wire end) of connector. DO NOT probe wire through
insulation.
* Always check if any TECH SERVICE BULLETINS (TSBs) apply to
vehicle.
* When using diagnostic charts, DO NOT skip any steps in chart
or incorrect diagnosis may result. Always perform
SYSTEM OPERATION CHECK after repairs are made.
* Always use most current DRB diagnostic program cartridge
available to prevent erroneous codes or test results.
* When using diagnostic charts, use DRB voltmeter unless
instructed to use an external voltmeter. Never use a test
light in place of a voltmeter.
* When performing electrical tests, prevent accidental
shorting of terminals. Such shorts can damage fuses or
components and may cause a second code (message) to be
set, making diagnosis of original problem more difficult.
* Vehicle must have a fully-charged battery and functional
charging system.
* Each time a connector is disconnected, inspect it to ensure
it is in good condition. Always focus on circuit being
tested. Dirt, water and corrosion, are most common problems
in connectors.
* Always disconnect DRB after use.
* Always disconnect DRB before charging battery.
USING DRB
1) Refer to DRB user guide for instructions and assistance
with reading trouble codes and other DRB functions. Under normal
operation DRB will display one of only 2 error messages: User-

Requested WARM boot or User-Requested COLD boot. If DRB should display
any other error message, record entire display and contact
manufacturer.
2) If DRB does not power-up, check for loose cable
connections or a bad cable. Check vehicle battery voltage (data link
connector terminal No. 16). A minimum of 11 volts is required to
adequately power DRB.
3) If all connections are proper between DRB and vehicle or
other devices, and vehicle battery is fully charged, an inoperative
DRB may be result of faulty cable or vehicle wiring.
ENTERING ON-BOARD DIAGNOSTICS
1) Before entering on-board diagnostics, refer to
PRETEST INSPECTION & DIAGNOSTIC PROCEDURE . Connect DRB to data link
connector. Data link connector (DLC) is located under left side of
instrument panel, left of steering column.
NOTE: Read active DTCs with PAD switch in both ON and OFF
positions. Always turn ignition off before changing PAD
switch positions,
2) Turn ignition switch to ON position. Exit vehicle with
DRB. Using DRB, read and record active Diagnostic Trouble Code (DTC)
data. Read and record stored DTC data. If any DTCs (fault messages)
exist, perform appropriate test.
3) If PAD switch OFF indicator fails to illuminate when in
the OFF position, go to PAD SWITCH INDICATOR PROBLEMS . If PAD switch
OFF indicator illuminates when switch is in ON position or key
cylinder does not operate, replace PAD switch.
4) Air Bag Control Module (ACM) may report any of the
following DTCs or fault messages. If the following active or stored
codes are reported by DRB, replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
* ACM OUTPUT DRIVER CIRCUIT OPEN
* ACM ACCELEROMETER
* ACM INTERNAL DIAGNOSTIC CODE #1
* WARNING LAMP DRIVER ERROR
* FIRING CAPACITOR LOW
* LOGIC CAPACITOR LOW
* SAFING SENSOR SHORTED
If the following active codes are reported by DRB, go to the
appropriate procedure under DIAGNOSTIC TESTS.
* CLUSTER MESSAGE MISMATCH
* DRIVER SQUIB CIRCUIT OPEN
* DRIVER SQUIB CIRCUIT SHORTED
* DRIVER SQUIB CIRCUIT SHORTED TO BATTERY
* DRIVER SQUIB CIRCUIT SHORTED TO GROUND
* LOSS OF IGNITION RUN ONLY
* LOSS OF IGNITION RUN/START
* NO CLUSTER CCD MESSAGE
* NO CCD COMMUNICATION
* MISSING OR INVALID VIN
* PASSENGER SQUIB CIRCUIT OPEN
* PASSENGER SQUIB CIRCUIT SHORTED
* PASSENGER SQUIB CIRCUIT SHORTED TO BATTERY
* PASSENGER SQUIB CIRCUIT SHORTED TO GROUND
* SCTM FAILURE
* SCTM MESSAGE MISMATCH
* VIN MESSAGE MISMATCH

NOTE: All active codes must be resolved before diagnosing store
codes.
1) Raise and support vehicle. Start engine and let idle with
transmission in PARK position. Wiggle wiring harness and connectors of
air bag system and rotate steering wheel from stop to stop.
2) Visually inspect related wire harness connectors. Look for
broken, bent, pushed out, spread, corroded or contaminated terminals.
Also, look for chafed, pierced, pinched or partially broken wires.
3) Check for trouble codes as you work through system. If
stored trouble code becomes active, perform appropriate diagnostic
test. If stored code is reproducible, repair or replace wiring
harness, harness connector or terminals or replace component as
necessary.
CLUSTER MESSAGE MISMATCH
NOTE: Perform AIR BAG VERIFICATION TEST after
all repairs. Each time a connector is disconnected, inspect
it to ensure it is in good condition. Always focus on circuit
being tested. Dirt, water and corrosion, are most common
problems in connectors. Due to manufacturer changes in wire
colors, use terminal identification whenever possible.
1) If AIR BAG warning light is on, go to next step. If AIR
BAG warning light is not on, go to step 5).
2) Using DRB, select PASSIVE RESTRAINTS, AIRBAG and MONITOR
DISPLAY. Read WARNING LAMP STATUS. If DRB does not display MIC LAMP
STATUS ON, replace instrument cluster. If DRB displays MIC LAMP STATUS
ON, go to next step.
3) If DRB displays ACM LAMP REQUEST: ON, go to next step. If
DRB does not display ACM LAMP REQUEST: ON, replace instrument cluster.
4) If there are no potential causes for this DTC remaining,
ACM is assumed to be defective. Replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
NOTE: If AIR BAG warning light is defective, instrument cluster
will flash seat belt light for 30 seconds starting 10 seconds
after bulb check stops.
5) Using DRB, read air bag control module active codes
(messages). If CLUSTER MISMATCH is only active message, go to next
step. If other messages are present, go to appropriate diagnostic test
to continue diagnosis.
6) If seat belt warning light flashes for 30 seconds after
bulb check is complete, replace instrument cluster. If seat belt
warning light does not flashes for 30 seconds after bulb check is
complete, go to next step.
7) Using DRB, select PASSIVE RESTRAINTS, AIRBAG and MONITOR
DISPLAY. Read WARNING LAMP STATUS. If DRB displays ACM LAMP REQUEST:
OFF, go to next step. If DRB does not display ACM LAMP REQUEST: OFF,
replace instrument cluster.
8) If DRB displays MIC LAMP REQUEST: OFF, go to next step. If
DRB does not display MIC LAMP REQUEST: OFF, replace instrument
cluster.
9) If there are no potential causes for this DTC remaining,
ACM is assumed to be defective. Replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
DRIVER SQUIB CIRCUIT OPEN
NOTE: Perform AIR BAG VERIFICATION TEST after
all repairs. Each time a connector is disconnected, inspect

it to ensure it is in good condition. Always focus on circuit
being tested. Dirt, water and corrosion, are most common
problems in connectors. Due to manufacturer changes in wire
colors, use terminal identification whenever possible.
1) Disconnect battery and wait 2 minutes before proceeding.
Disconnect driver-side air bag module squib connector. Connect a
jumper wire between driver-side air bag (squib) 2-pin connector
terminal No. 1 (Black/Light Blue wire) and terminal No. 2 (Dark
Green/Light Blue wire). Turn ignition on (engine off). Reconnect
battery. Using DRB, read active codes. If DRB displays DRIVER SQUIB
CIRCUIT SHORTED, replace driver-side air bag module. If not, go to
next step.
2) Disconnect clockspring 2-pin connector. Connect a jumper
wire between clockspring 2-pin connector terminals No. 1 (Black/Light
Blue wire) and No. 2 (Dark Green/Light Blue wire). Using DRB, read
active codes. If DRB displays DRIVER SQUIB CIRCUIT SHORTED, replace
clockspring. If not, go to next step.
3) Disconnect battery and wait 2 minutes before proceeding.
Remove jumper wires. Disconnect ACM connector. ACM is located under
instrument panel, on transmission tunnel. Using an ohmmeter, check
resistance between ACM connector terminal No. 6 (Dark Green/Light Blue
wire) and clockspring 2-pin connector terminal No. 2 (Dark Green/Light\
Blue wire). If resistance is less than 5 ohms, go to next step. If
resistance is more than 5 ohms, repair open or high resistance in Dark
Green/Light Blue wire.
4) Check resistance between ACM connector terminal No. 5
(Black/Light Blue wire) and clockspring 2-pin connector terminal No. 1\
(Black/Light Blue wire). If resistance is less than 5 ohms, go to next\
step. If resistance is more than 5 ohms, repair open or high
resistance in Black/Light Blue wire.
5) If there are no potential causes for this DTC remaining,
ACM is assumed to be defective. Replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
DRIVER SQUIB CIRCUIT SHORTED
NOTE: Perform AIR BAG VERIFICATION TEST after
all repairs. Each time a connector is disconnected, inspect
it to ensure it is in good condition. Always focus on circuit
being tested. Dirt, water and corrosion, are most common
problems in connectors. Due to manufacturer changes in wire
colors, use terminal identification whenever possible.
1) Disconnect battery and wait 2 minutes before proceeding.
Ensure driver-side air bag module connector is completely connected
before disconnecting it. If driver-side air bag module connector is
not completely connected, reconnect it. If driver-side air bag
connector is completely connected, go to next step.
2) Disconnect driver-side air bag module. Turn ignition on
(engine off). Reconnect battery. Using DRB, read active codes. If DRB
displays DRIVER SQUIB CIRCUIT OPEN, replace driver-side air bag
module. If not, go to next step.
3) Disconnect clockspring 2-pin connector. Using DRB, read
active codes. If DRB displays DRIVER SQUIB CIRCUIT OPEN, replace
clockspring. If not, go to next step.
4) Turn ignition off, disconnect battery and wait 2 minutes
before proceeding. Disconnect passenger-side air bag module connector.
Using an ohmmeter, check resistance between clockspring 2-pin
connector terminal No. 1 (Black/Light Blue wire) and passenger-side
air bag 2-pin connector terminal "A" (Black/Yellow wire). If
resistance is less than 5 ohms, repair short between Black/Light Blue
wire and Black/Yellow wire. If resistance is more than 5 ohms, go to

next step.
5) Using an ohmmeter, check resistance between clockspring 2-
pin connector terminals No. 1 (Black/Light Blue wire) and No. 2 (Dark\
Green/Light Blue wire). If resistance is less than 5 ohms, repair
short between Dark Green/Light Blue wire and Black/Light Blue wire. If
resistance is more than 5 ohms, go to next step.
6) If there are no potential causes for this DTC remaining,
ACM is assumed to be defective. Replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
DRIVER SQUIB CIRCUIT SHORTED TO BATTERY
NOTE: Perform AIR BAG VERIFICATION TEST after
all repairs. Each time a connector is disconnected, inspect
it to ensure it is in good condition. Always focus on circuit
being tested. Dirt, water and corrosion, are most common
problems in connectors. Due to manufacturer changes in wire
colors, use terminal identification whenever possible.
1) Disconnect battery and wait 2 minutes before proceeding.
Disconnect driver-side air bag module. Turn ignition on and reconnect
battery. Using DRB, read active codes. If DRB does not display DRIVER
SQUIB CIRCUIT SHORTED TO VOLTAGE, replace driver-side air bag module.
If DRB displays DRIVER SQUIB CIRCUIT SHORTED TO VOLTAGE, go to next
step.
2) Disconnect clockspring 2-pin connector. Using DRB, read
active codes. If DRB does not display DRIVER SQUIB CIRCUIT SHORTED TO
VOLTAGE, replace clockspring. If DRB displays DRIVER SQUIB CIRCUIT
SHORTED TO VOLTAGE, go to next step.
3) Disconnect battery and wait 2 minutes before proceeding.
Disconnect ACM 23-pin connector. Using a voltmeter, check voltage
between ground and clockspring connector terminals No. 1 (Black/Light
Blue wire) and No. 2 (Dark Green/Light Blue wire). If voltage is more\
than 5 volts on either circuit, repair short to voltage in Dark
Green/Light Blue wire or Black/Light Blue wire. If voltage is less
than 5 volts on either circuit, go to next step.
4) If there are no potential causes for this DTC remaining,
ACM is assumed to be defective. Replace ACM. See
AIR BAG CONTROL MODULE (ACM) under REMOVAL & INSTALLATION.
DRIVER SQUIB CIRCUIT SHORTED TO GROUND
NOTE: Perform AIR BAG VERIFICATION TEST after
all repairs. Each time a connector is disconnected, inspect
it to ensure it is in good condition. Always focus on circuit
being tested. Dirt, water and corrosion, are most common
problems in connectors. Due to manufacturer changes in wire
colors, use terminal identification whenever possible.
1) Disconnect battery and wait 2 minutes before proceeding.
Disconnect driver-side air bag module. Turn ignition on (engine off)
and reconnect battery. Using DRB, read active codes. If DRB does not
display DRIVER SQUIB CIRCUIT SHORTED TO GROUND, replace driver-side
air bag module. If DRB displays DRIVER SQUIB CIRCUIT SHORTED TO
GROUND, go to next step.
2) Disconnect clockspring 2-pin connector. Using DRB, read
active codes. If DRB does not display DRIVER SQUIB CIRCUIT SHORTED TO
GROUND, replace clockspring. If DRB displays DRIVER SQUIB CIRCUIT
SHORTED TO GROUND, go to next step.
3) Disconnect battery and wait 2 minutes before proceeding.
Disconnect ACM 23-pin connector. Using an ohmmeter, check resistance
between ground and clockspring connector terminals No. 1 (Black/Light
Blue wire) and No. 2 (Dark Green/Light Blue wire). If resistance is
