* A /C -H EA TE R S YSTE M U NIF O RM IN SPEC TIO N G UID ELIN ES *

1 999 D odge P ic ku p R 1500
GENERAL INFORMATION
A/C-Heater System Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Heating, Ventilation and Air Conditioning
ACCUMULATORS
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AIR CONDITIONING FITTINGS
AIR CONDITIONING HOSES
AIR CONDITIONING METAL LINES, HOSES AND FITTING ASSEMBLIES
AIR CONTROL DOORS
AIR DAMS (EXTERNAL)
AIR DISTRIBUTION SYSTEM
BELTS
BLEND DOORS
BLOWER FANS (BLOWER WHEEL OR SQUIRREL CAGE)
BLOWER MOTORS
BLOWER RESISTORS
BLOWER SWITCHES
CABIN AIR FILTERS
CIRCUIT BREAKERS
COMPRESSOR CLUTCH ASSEMBLIES
COMPRESSORS
CONDENSER AIR SEALS
CONDENSER FAN MOTORS
CONDENSERS
CONNECTORS
CONTROL CABLES
CONTROL HEADS (FUNCTION SELECTORS)
CONTROL LINKAGES
CONTROL MODULES
COOLANT
COOLING FAN BLADES
COOLING FAN CLUTCHES
COOLING FAN MOTORS
EVAPORATOR DRAIN TUBES
EVAPORATOR PRESSURE REGULATORS (EPRS)
EVAPORATORS
EXPANSION VALVES
FUNCTION SELECTORS
FUSES, FUSIBLE LINKS AND CIRCUIT BREAKERS
FUSIBLE LINKS
GASKETS
HEATER CASES
HEATER CONTROL VALVES
HEATER CORES

Missing ................. C ........... Require replacement.
Noisy ................... 2 . Suggest repair or replacement.
Out of adjustment ....... B .......... (1) Require repair or
replacement.
Seized .................. A . Require repair or replacement.
( 1) - Follow OEM recommended adjustment procedures. Require
repair or replacement if out of specification.









\









\









\









\









\









\









\


CONTROL MODULES
NOTE: Includes, but not limited to: IRCM, Coolant Fan Control
Module (CFCM), AC Controller, Amplifier, Programmers,
Control Heads, Power Modules, etc.
CONTROL MODULE INSPECTION









\









\









\









\









\









\









\


Condition Code Procedure
Application incorrect ... B ............ Require replacement.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of hardware.
Attaching hardware
threads stripped
(threads missing) ...... A ... Require repair or replacement
of hardware.
Code set
(if applicable) ........ A .......... ( 1) Further inspection
required.
Connector broken ........ A .. Require repair or replacement.
Connector melted,
affecting performance .. A ........... ( 2) Require repair or
replacement.
Connector melted, not
affecting performance .. 2 ........... ( 2) Suggest repair or
replacement.
Connector missing ....... A ................. Require repair.
Contaminated ............ A ........... ( 3) Require repair or
replacement.
Inoperative ............. B ........... ( 4) Require repair or
replacement. Further
inspection required.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 2) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.

Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Refer to manufacturer's diagnostic trouble code
procedure and require repair or replacement of
affected component(s).
( 2) - Determine cause and correct prior to repair or
replacement of part.
( 3) - Determine source of contamination, such as engine coolant,
fuel, metal particles, or water. Require repair or
replacement. Check for accepted cleaning procedure.
( 4) - Inoperative includes intermittent operation or out of
OEM specification. Some components may be serviceable.









\









\









\









\









\









\









\


COOLANT
COOLANT INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Acidity (pH) incorrect .. 1 ........... Suggest correction or
replacement.
Contaminated ............ B ...... ( 1) Require replacement or
recycling. Further
inspection required.
Level incorrect ......... B .......... ( 2) Require filling to
proper level.
Maintenance intervals ... 3 ........ ( 3) Suggest replacement.
Mixture incorrect ....... B ........... Require correction or
replacement.
Type incorrect .......... B ............ Require replacement.
( 1) - Determine source of contamination and require correction
prior to coolant replacement.
( 2) - Determine source of incorrect level and suggest repair.
( 3) - The system should be drained and/or flushed and
refilled with correct coolant according to OEM
recommended service interval and procedures.









\









\









\









\









\









\









\


COOLING FAN BLADES
COOLING FAN BLADE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Application incorrect ... B ............ Require replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.

of hardware.
Binding ................. 2 .. Suggest repair or replacement.
Coolant leak ............ A .. Require repair or replacement.
Disconnected ............ A .. Require repair or replacement.
Malfunctioning .......... A ........... (1) Require repair or
replacement.
Missing ................. C ............ Require replacement.
Restricted .............. A .. Require repair or replacement.
Seized .................. A .. Require repair or replacement.
Vacuum leak ............. A .. Require repair or replacement.
( 1) - Includes inoperative, intermittent operation, or
failure to perform all functions.









\









\









\









\









\









\









\


HEATER CORES
HEATER CORE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Air flow obstruction .... A .. Require repair or replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A .. Require repair or replacement
of hardware.
Connection leaking ...... A .. Require repair or replacement.
Corroded ................ 1 .. Suggest repair or replacement.
Disconnected ............ A .. Require repair or replacement.
Fins damaged, affecting
performance ............ A .. Require repair or replacement.
Fins damaged, not
affecting performance .. .. ........ No service suggested or
required.
Internal restrictions,
affecting performance .. A .. Require repair or replacement.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.









\









\









\









\









\









\









\


HEATER HOSES
HEATER HOSE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Application incorrect ... B ............ Require replacement.
Connected incorrectly ... A ................. Require repair.
Corroded, not reusable .. 1 ............ Suggest replacement.
Cracked ................. A .. Require repair or replacement.
Hard (brittle) .......... 1 .. Suggest repair or replacement.
Inner fabric (webbing)
damaged ................ A ............ Require replacement.
Insufficient clamping
force, allowing hose to
leak ................... A .. Require repair or replacement.
Leaking ................. A .. Require repair or replacement.
Maintenance intervals ... 3 ............ Suggest replacement.

assembly towards right side of vehicle and remove rear A/C-heater
assembly.
5) To install, reverse removal procedure. Ensure all wiring
and hoses are clear and not pinched. Tighten bolts and nuts to
specification. See TORQUE SPECIFICATIONS .
Removal (Ram Pickup - Front)
1) Disconnect negative battery cable. Drain cooling system.
In engine compartment, remove coolant hoses from heater core tubes.
Remove coolant overflow bottle.
2) Discharge A/C system, using approved refrigerant
recovery/recycling equipment. Disconnect refrigerant lines from
evaporator and plug or cover all openings in A/C system. Remove
instrument panel. See INSTRUMENT PANEL. Remove Powertrain Control
Module (PCM) and position aside. DO NOT disconnect 60-pin connector
from PCM.
3) Remove attaching nuts from studs on engine compartment
side of dash panel. Remove defrost duct. Disconnect electrical
connectors. Remove attaching nuts from studs in passenger compartment
side of dash panel. Remove A/C-heater assembly from vehicle. See
Fig. 5 .
4) Place A/C-heater assembly upside-down on work bench.
Remove screw securing floor duct to bottom of A/C-heater assembly and
slide floor duct off of center heat duct adapter. Unsnap center heat
duct adapter from bottom of A/C-heater assembly housing. Remove screw
hidden behind adapter. Remove remaining screws and separate A/C-heater
assembly.
Installation
Ensure mode door pivot pins are properly inserted in holes.
To complete installation, reverse removal procedure.
A/C-HEATER CONTROL PANEL R & I
Removal & Installation (Dakota & Durango)
1) Disconnect negative battery cable. On models equipped with
A/T, unlock ignition switch. Set parking brake and place gear selector
lever in "L" position. If equipped, set tilt steering column in lowest
position.
2) On all models, carefully pry bezel away from instrument
panel to disengage clips. Unplug connectors from cigarette lighter and
auxiliary power outlet. Disconnect fog light switch (if equipped).
Remove A/C-heater control panel screws.
3) Pull control panel outward enough to disconnect wiring
connector, vacuum harness, and temperature control cable. Remove A/C-
heater control panel. To install, reverse removal procedure. Adjust
temperature control cable. See TEMPERATURE CONTROL CABLE ADJUSTMENT .
Removal & Installation (Ram Pickup)
1) Disconnect negative battery cable. Reach under driver's
side of instrument panel, near transmission tunnel and unplug A/C-
heater control panel to A/C-heater assembly vacuum harness connector.
Disconnect vacuum harness from center air duct.
2) On models equipped with A/T, unlock ignition switch. Set
parking brake and place gear selector lever in "L" position. If
equipped, set tilt steering column in lowest position.
3) On all models, remove screw securing cluster bezel to
instrument panel. See Fig. 6. Carefully pry bezel away from instrument
panel to disengage clips. Unplug connectors from cigarette lighter and
auxiliary power outlet.
4) Remove 4 screws attaching A/C-heater control panel. Pull
control panel outward enough to disconnect wiring connector, vacuum
harness and temperature control cable. Remove A/C-heater control

test system. Ensure A/C system is operating properly.
Orifice Tube Replacement Kit (Villager)
1) Discharge A/C system, using approved refrigerant
recovery/recycling equipment. Drain engine coolant to a level below
thermostat. Remove upper radiator hose and bracket to gain access to
condenser end of liquid line. Remove condenser-to-evaporator liquid
line from vehicle.
2) Locate orifice tube in metal portion of liquid line, at
indentation. See Fig. 20. Make a 4" (102 mm) index line on liquid line
with indentation at the midpoint. Cut a 2.5" (63.5 mm) section from
liquid line with indentation in the middle, at least 1" (25.4 mm) from\
start of closest bend. Clean out liquid line to remove contaminants.
3) Lubricate orifice tube replacement kit compression nuts
and rings with refrigerant oil and install on liquid line. See Fig. 21
. Ensure flow direction arrow points toward evaporator. Ensure index
line on liquid line is properly aligned for installation. Tighten
compression nuts to 65-70 ft. lbs. (88-95 N.m).
4) To complete installation, reverse removal procedure.
Lubricate "O" rings with refrigerant oil. Evacuate, charge and leak
test system. Ensure A/C system is operating properly.
Fig. 20: Locating Orifice Tube (Continental & Mustang Shown; Villager
Is Similar)
Courtesy of ford motor co.
