Page 1489 of 1691
all models, remove transmission-to-cylinder block bolts. Slide
transmission rearward from dowels on cylinder block.
10) Install "C" clamp on edge of transmission housing to hold
torque converter in place. Lower transmission and remove transmission
from vehicle.
Fig. 1: Locating Crankshaft Position Sensor (2.5L)
Courtesy of Chrysler Corp.
Fig. 2: Locating Crankshaft Position Sensor (3.9L, 5.2L & 5.9L
Gasoline)
Page 1490 of 1691

Courtesy of Chrysler Corp.
Installation
1) To install, reverse removal procedure. Ensure torque
converter is fully seated in transmission by measuring distance from
cylinder block surface on transmission housing to front edge on torque
converter bolt lug on front of torque converter. Distance should be .
50" (12.7 mm) if torque converter is fully seated.
CAUTION: Proper length torque converter bolts must be used. If
replacing any torque converter bolts, ensure proper length
bolt is used.
2) Tighten bolt/nuts to specification. See TORQUE
SPECIFICATIONS. Ensure reference mark on torque converter and
flexplate, and drive shaft flanges are aligned. Adjust shift cable or
linkage, throttle valve cable and transfer case shift linkage if
necessary. See AUTOMATIC TRANSMISSION - TRUCKS & RWD VANS article.
3) Use NEW "O" ring when installing dipstick tube. Before
installing oil cooler lines on transmission, ensure all fittings are
clean. Install oil cooler line into quick-disconnect fitting. Push oil
cooler line inward until a click is heard. Pull on oil cooler line to
ensure oil cooler line is locked in place. Fill transmission with
Mopar ATF Plus Type 7176.
RAM PICKUP
Removal
1) Disconnect negative battery cable. Raise and support
vehicle. Disconnect and remove necessary skid plates and exhaust
components for transmission removal. Remove engine-to-transmission
struts (if equipped). These struts are located between front of
transmission and engine.
2) Ensure area around transmission oil cooler lines fitting
are clean. Disengage retainer on quick-disconnect cooler line fitting.
Pull cooler line from transmission oil cooler. Remove starter.
CAUTION: On 3.9L, 5.2L and 5.9L gasoline models, crankshaft position
sensor must be removed from transmission housing before
removing transmission to prevent damage to crankshaft
position sensor.
3) On 3.9L, 5.2L and 5.9L gasoline models, disconnect
electrical connector for crankshaft position sensor. Crankshaft
position sensor is mounted on passenger's side of transmission
housing. See Fig. 2.
4) Remove crankshaft position sensor bolts. Remove crankshaft
position sensor from transmission housing. Remove dipstick, dipstick
tube and "O" ring from transmission.
5) Remove torque converter cover. Place reference mark on
flexplate and torque converter for installation reference. Rotate
crankshaft clockwise and remove torque converter bolts.
6) Place reference mark on drive shaft flanges for
installation reference. Remove drive shaft from transmission. On 4WD
models, disconnect drive shaft from transfer case. Disconnect shift
rod for transfer case from transfer case shift lever.
7) On all models, disconnect necessary control cables, wiring
harnesses, and shift linkage from transmission. Support rear of engine
with jack stand. Using transmission jack, slightly raise transmission
to release pressure from rear mount and rear crossmember.
8) Remove bolts securing rear support and rear mount to
transmission and rear crossmember. Raise transmission slightly. Slide
exhaust hanger arm from bracket on rear support. Remove rear support
Page 1491 of 1691

and rear mount.
9) Remove rear crossmember located below the transmission. On
4WD models, disconnect electrical connectors from transfer case. On
all models, remove transmission-to-cylinder block bolts. Slide
transmission rearward from dowels on cylinder block.
10) Install "C" clamp on edge of transmission housing to hold
torque converter in place. Lower transmission and remove transmission
from vehicle.
Installation
1) To install, reverse removal procedure. Ensure torque
converter is fully seated in transmission by measuring distance from
cylinder block surface on transmission housing to front edge on torque
converter bolt lug on front of torque converter. Distance should be .
50" (12.7 mm) if torque converter is fully seated.
CAUTION: Proper length torque converter bolts must be used. If
replacing any torque converter bolts, consult parts
department to ensure proper length bolt is used.
2) Tighten bolt/nuts to specification. See TORQUE
SPECIFICATIONS. Ensure reference mark on torque converter and
flexplate, and drive shaft flanges are aligned. Adjust shift linkage,
throttle valve cable and transfer case shift linkage if necessary. See
AUTOMATIC TRANSMISSION - TRUCKS & RWD VANS article.
3) Use NEW "O" ring when installing dipstick tube. Before
installing oil cooler lines on transmission, ensure all fittings are
clean. Install oil cooler line into quick-disconnect fitting. Push oil
cooler line inward until a click is heard. Pull on oil cooler line to
ensure oil cooler line is locked in place. Fill transmission with
Mopar ATF Plus Type 7176.
RAM VAN/WAGON
Removal
1) Disconnect negative battery cable. Raise and support
vehicle. Remove engine-to-transmission struts. These struts are
located between front of transmission and engine.
2) Remove starter and oil cooler line bracket. Ensure area
around transmission oil cooler lines fitting are clean. Disengage
retainer on quick-disconnect cooler line fitting. Pull cooler line
from transmission oil cooler.
CAUTION: Crankshaft position sensor must be removed from transmission
housing before removing transmission to prevent damage to
crankshaft position sensor.
3) Disconnect electrical connector for crankshaft position
sensor. Crankshaft position sensor is mounted on passenger's side of
transmission housing. See Fig. 2.
4) Remove crankshaft position sensor bolts. Remove crankshaft
position sensor from transmission housing. Remove dipstick, dipstick
tube and "O" ring from transmission.
5) Remove torque converter cover. Place reference mark on
flexplate and torque converter for installation reference. Rotate
crankshaft clockwise and remove torque converter bolts.
6) Place reference mark on drive shaft yokes for installation
reference. Remove drive shaft from transmission. Disconnect necessary
wiring harnesses and control cables from transmission. Support rear of
engine with hoist. Using transmission jack, slightly raise
transmission to release pressure from rear mount and crossmember.
7) Remove rear mount-to-rear crossmember bolts. Remove bolts
and rear crossmember located below the transmission. Remove engine oil
Page 1492 of 1691

filter (if necessary). Remove transmission-to-cylinder block bolts.
Slide transmission rearward from dowels on cylinder block.
8) Install "C" clamp on edge of transmission housing to hold
torque converter in place. Lower transmission and remove transmission
from vehicle.
Installation
1) To install, reverse removal procedure. Ensure torque
converter is fully seated in transmission by measuring distance from
cylinder block surface on transmission housing to front edge on torque
converter bolt lug on front of torque converter. Distance should be .
50" (12.7 mm) if torque converter is fully seated.
CAUTION: Proper length torque converter bolts must be used. If
replacing any torque converter bolts, ensure proper length
bolt is used.
2) Ensure proper length torque converter bolts are used in
accordance with torque converter diameter and number of torque
converter bolt lugs on front of torque converter. See TORQUE CONVERTER
BOLT APPLICATION table.
TORQUE CONVERTER BOLT APPLICATION
\
\
\
\
\
\
\
Torque Converter Diameter Bolt Length
In. (mm)\
9.50" (241.0 mm) 3-Bolt Lug Torque Converter ............ .46 (11.7\
)
9.50" (241.0 mm) 4-Bolt Lug Torque Converter ............ .52 (13.2\
)
10.00" (254.0 mm) 4-Bolt Lug Torque Converter ........... .52 (13.2\
)
10.75" (273.0 mm) 4-Bolt Lug Torque Converter ........... .44 (11.2\
)
\
\
\
\
\
\
\
3) Tighten bolt/nuts to specification. See TORQUE
SPECIFICATIONS. Ensure reference mark on torque converter and
flexplate, and drive shaft yokes are aligned. Adjust shift cable and
throttle valve cable if necessary. See AUTOMATIC TRANSMISSION - TRUCKS
& RWD VANS article.
4) Use NEW "O" ring when installing dipstick tube. Before
installing oil cooler lines on transmission, ensure all fittings are
clean. Install oil cooler line into quick-disconnect fitting. Push oil
cooler line inward until a click is heard. Pull on oil cooler line to
ensure oil cooler line is locked in place. Fill transmission with
Mopar ATF Plus Type 7176.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS (DAKOTA & DURANGO) \
\
\
\
\
\
\
Application Ft. Lbs.
Crankshaft Position Sensor Bolt/Nut
2.5L ..................................................... 14 (19)\
3.9L, 5.2L & 5.9L ............................................ ( 1)
Front Drive Shaft Universal Joint Strap-To-Transfer
Case Flange Bolt ......................................... 20 (27)\
Rear Crossmember Bolt ...................................... 50 (68)\
Rear Drive Shaft Center Bearing-To-Crossmember Bolt ........ 50 (68)\
Rear Drive Shaft Universal Joint Strap-To-Rear
Axle Flange Bolt ......................................... 14 (19)\
Starter Bolt
2.5L ..................................................... 33 (45)\
Page 1493 of 1691

3.9L, 5.2L & 5.9L ........................................ 50 (68)\
Torque Converter Bolt ...................................... 23 (31)\
Transmission-To-Cylinder Block Bolt ............................ (2)
( 1) - Tighten bolts to 70 INCH lbs. (7.9 N.m).
( 2) - Information is not available from manufacturer.
\
\
\
\
\
\
\
TORQUE SPECIFICATIONS (RAM VAN/WAGON) \
\
\
\
\
\
\
Application Ft. Lbs.
Drive Shaft Universal Joint Strap-To-Rear
Axle Flange Bolt ......................................... 14 (19)\
Engine-To-Transmission Strut Bolt
Bolt At Cylinder Block ............................. 20-40 (27-54)\
Bolt At Transmission ............................... 35-65 (47-88)\
Rear Crossmember Bolt ...................................... 50 (68)\
Starter Bolt/Nut ........................................... 50 (68)\
Torque Converter Bolt ( 1)
9.50" (241.0 mm) 3-Bolt Lug Torque Converter ............. 40 (54\
)
9.50" (241.0 mm) 4-Bolt Lug Torque Converter ............. 55 (75\
)
10.00" (254.0 mm) 4-Bolt Lug Torque Converter ............ 55 (75\
)
10.75" (273.0 mm) 4-Bolt Lug Torque Converter ............ 23 (31\
)
Transmission-To-Cylinder Block Bolt
Large Bolt ......................................... 35-65 (47-88)\
Small Bolt ......................................... 20-40 (27-54)\
INCH Lbs. (N.m)
Crankshaft Position Sensor Bolt ........................... 70 (7.9)\
( 1) - Bolt torque is determined by diameter of torque converter and
number of torque converter bolt lugs on front of torque
converter.
\
\
\
\
\
\
\
TORQUE SPECIFICATIONS (RAM PICKUP) \
\
\
\
\
\
\
Application Ft. Lbs.
Front Drive Shaft-To-Front Axle Flange Bolt ................ 14 (19)\
Front Drive Shaft Flange-To-Transfer Case Flange Bolt ...... 65 (88)\
Rear Crossmember Bolt ...................................... 50 (68)\
Rear Drive Shaft Center Bearing-To-Crossmember Bolt ........ 50 (68)\
Rear Drive Shaft Universal Joint Strap-To-Rear
Axle Flange Bolt
Dana Axle ............................................... 22 (30)\
9 1/4" Axle ............................................. 14 (19)\
Starter Bolt
5.9L Diesel .............................................. 32 (43)\
All Others ............................................... 50 (68)\
Torque Converter Bolt ( 1)
10.75" (273.0 mm) Torque Converter ....................... 23 (31\
)
12.20" (273.0 mm) Torque Converter ....................... 35 (47\
)
Transmission-To-Cylinder Block Bolt ............................ ( 2)
INCH Lbs. (N.m)
Crankshaft Position Sensor Bolt
3.9L, 5.2L & 5.9L Gasoline .............................. 70 (7.9)\
( 1) - Bolt torque is determined by diameter of torque converter.
Page 1494 of 1691

TR AN SM IS SIO N S ER VIC IN G - A /T
1999 D odge P ic ku p R 1500
1998-99 TRANSMISSION SERVICING
CHRY - Automatic Transmission - Trucks & RWD Vans
Dakota, Durango, Ram Pickup, Ram Van/Wagon
APPLICATION
AUTOMATIC TRANSMISSION/TRANSAXLE APPLICATIONS \
\
\
\
\
\
\
Model Designation
Dakota & Durango
3.9L ........................................................ 42RE
5.2L ........................................................ 44RE
5.9L ........................................................ 46RE
Ram Pickup
3.9L ................................................. 42RE & 46RE
5.2L & 5.9L (Gasoline) ...................................... 46RE\
5.9L Diesel & 8.0L .......................................... 47RE
Ram Van/Wagon
3.9L ........................................................ 32RH
5.2L ........................................................ 36RH
5.2L & 5.9L ................................................. 46RE
\
\
\
\
\
\
\
TRANSFER CASE APPLICATIONS \
\
\
\
\
\
\
Model Designation
Dakota & Durango
3.9L ....................................................... NV231
5.2L .............................................. NV231HD Or NV242
5.9L ....................................................... NV242HD
Ram Pickup
1500 ..................................................... NV231HD
2500 & 3500
5.9L Diesel & 8.0L ...................................... NV241HD
All Others ................................................ NV241
\
\
\
\
\
\
\
OIL PAN GASKET IDENTIFICATION
Fig. 1: Identifying Oil Pan Gasket (32RH, 42RE & 44RE)
Page 1495 of 1691
Fig. 2: Identifying Oil Pan Gasket (36RH, 46RE & 47RE)
LUBRICATION
SERVICE INTERVALS
Transmission
Check transmission fluid level when performing other
underhood services. Under normal service conditions or severe service
conditions change transmission fluid, adjust bands and replace
transmission filter at specified interval. See TRANSMISSION SERVICING
INTERVALS table. Severe service conditions are conditions such as long
periods of engine idling, trailer towing, off-highway operation, snow
removal, or operating in dusty or excessively hot conditions.
TRANSMISSION SERVICING INTERVALS
\
\
\
\
\
\
\
Application Months Miles
Dakota & Durango
Normal Service ........................ 30 .............. 37,500
Severe Service ........................ ( 1) ............. 12,000
Page 1496 of 1691

Ram Pickup
Gasoline Models
Light-Duty (2)
Normal Service ..................... 30 .............. 37,500
Severe Service ..................... ( 1) ............. 12,000
Medium-Duty & Heavy-Duty
Normal Service ..................... 24 .............. 24,000
Severe Service ..................... ( 1) ............. 12,000
Diesel Models
Normal Service ....................... 24 .............. 24,000
Severe Service ....................... ( 1) ............. 12,000
Ram Van/Wagon
Normal Service ........................ ( 3) ................ ( 3)
Severe Service ........................ ( 1) ............. 12,000
( 1) - Monthly interval is not available from manufacturer.
( 2) - Light-duty applies to all 1500 models and 2500 models except
5.9L diesel or 8.0L engines. Medium-duty applies to 2500 and
3500 California models with 8.0L engine. Heavy-duty applies to
2500 and 3500 Federal models with 8.0L engine and all 3500
models with 5.9L gasoline engine.
( 3) - Normal service interval is not available from manufacturer.
\
\
\
\
\
\
\
Transfer Case
Check transfer case fluid level when performing other
underhood services. Under normal service conditions or severe service
conditions change transfer case fluid at specified interval. See
TRANSFER CASE SERVICING INTERVALS table. Severe service conditions are
conditions such as long periods of engine idling, trailer towing, off-
highway operation, snow removal, or operating in dusty or excessively
hot conditions.
TRANSFER CASE SERVICING INTERVALS
\
\
\
\
\
\
\
Application Months Miles
Dakota
Normal Service ....................... 30 ............... 37,500
Severe Service ....................... ( 1) .............. 36,000
Ram Pickup
Gasoline Models
Light-Duty ( 2)
Normal Service .................... 30 ............... 37,500
Severe Service .................... ( 1) .............. 36,000
Medium-Duty & Heavy-Duty
Normal Service .................... 36 ............... 36,000
Severe Service .................... ( 1) .............. 36,000
Diesel Models
Normal Service ...................... 36 ............... 36,000
Severe Service ...................... ( 1) .............. 36,000
( 1) - Monthly interval is not available from manufacturer.
( 2) - Light-duty applies to all 1500 models and 2500 models except
5.9L diesel or 8.0L engines. Medium-duty applies to 2500 and
3500 California models with 8.0L engine. Heavy-duty applies to
2500 and 3500 Federal models with 8.0L engine and all 3500
models with 5.9L gasoline engine.
\
\
\
\
\
\
\
Power Take-Off (PTO) Adapter (Ram Pickup 2WD 2500 & 3500)
Check PTO adapter fluid level when performing other underhood
services. Service interval is not available from manufacturer.
