Page 12 of 1691

DODGE RAM 1999 Service Repair Manual
A/C C O M PR ESSO R R EFR IG ER AN T O IL C HEC KIN G

1999 D odge P ic ku p R 1500
1999 GENERAL SERVICING
A/C Compressor Refrigerant Oil Checking
All Models

A/C C O M PR ESSO R R EFR IG ER AN T O IL C HEC KIN G

1999 D odge P ic ku p R 1500
1999 GENERAL SERVICING
A/C Compressor Refrigerant Oil Checking
All Models
* PLEASE READ THIS FIRST *
NOTE: For compressor applications, see COMPRESSOR APPLICATIONS &
BODY DESIGNATIONS. DO NOT exceed A/C system refrigerant oil
capacity when servicing system. See CAPACITIES.
BODY DESIGNATIONS
BODY DESIGNATIONS (CHRYSLER CORP. CARS)\
\
\
\
\
\
\

Model ( 1) Body Designation
Avenger & Sebring Coupe ................................ "FJ22" Body
Breeze, Cirrus & Stratus ................................. "JA" Body
Concorde, Intrepid, LHS & 300M ........................... "LH" Body
Neon ..................................................... "PL" Body
Sebring Convertible ...................................... "JX" Body
( 1) - Body codes are determined by fifth character of VIN code.
\
\
\
\
\
\
\

BODY DESIGNATIONS (CHRYSLER CORP. LIGHT TRUCKS & VANS)\
\
\
\
\
\
\

Model Body Designation
Caravan, Town & Country, & Voyager ..................... "NS" Series
Dakota ................................................. "AN" Series
Durango ................................................ "DN" Series
Ram Pickup .......................................... "BR/BE" Series
Ram Van/Wagon .......................................... "AB" Series
\
\
\
\
\
\
\

BODY DESIGNATIONS (FORD MOTOR CO. LIGHT TRUCKS & VANS)\
\
\
\
\
\
\

Model Body Designation
Explorer & Mountaineer .................................. "U" Series
Pickup .................................................. "F" Series
Ranger .................................................. "R" Series
Van ..................................................... "E" Series
\
\
\
\
\
\
\

BODY DESIGNATIONS (GENERAL MOTORS CARS)\
\
\
\
\
\
\

Model ( 1) Body Designation
Alero, Cutlass, Grand Am & Malibu ......................... "N" Body
Aurora & Riviera .......................................... "G" Body
Bonneville, Eighty Eight, LeSabre & LSS ................... "H" Body
Camaro & Firebird ......................................... "F" Body
Catera .................................................... "V" Body
Cavalier & Sunfire ........................................ "J" Body
Century, Grand Prix, Intrigue, Lumina, Monte Carlo &
Regal .................................................... "W" Body

Page 13 of 1691

DODGE RAM 1999 Service Repair Manual DeVille & Seville ......................................... "K" Body
Corvette .................................................. "Y" Body
Eldorado ................................................

DeVille & Seville ......................................... "K" Body
Corvette .................................................. "Y" Body
Eldorado .................................................. "E" Body
Metro ..................................................... "M" Body
Park Avenue ............................................... "C" Body
Prizm ..................................................... "S" Body
Saturn .................................................... "Z" Body
(1) - Body codes are determined by fourth character of VIN code.
\
\
\
\
\
\
\

BODY DESIGNATIONS (GENERAL MOTORS LIGHT TRUCKS & VANS)\
\
\
\
\
\
\

Model ( 1) Body Designation
Astro & Safari
2WD ................................................... "M" Series
4WD ................................................... "L" Series
Blazer, Bravada, Envoy, Jimmy, Pickup & Sonoma
2WD ................................................... "S" Series
4WD ................................................... "T" Series
Commercial Chassis & Motorhome .......................... "P" Series
Escalade, Pickup, Sierra, Silverado, Suburban, Tahoe & Yukon
2WD ................................................... "C" Series
4WD ................................................... "K" Series
Express & Savana ........................................ "G" Series
Tracker ................................................. "J" Series
Montana, Silhouette & Venture ........................... "U" Series
( 1) - Series codes are determined by fifth character of VIN code.
\
\
\
\
\
\
\

BODY DESIGNATIONS (JEEP LIGHT TRUCKS)\
\
\
\
\
\
\

Model ( 1) Body Designation
Cherokee ............................................... "XJ" Series
Grand Cherokee ......................................... "WJ" Series
Wrangler ............................................... "TJ" Series
( 1) - Series codes are determined by fifth character of VIN code.
\
\
\
\
\
\
\

COMPRESSOR APPLICATIONS
COMPRESSOR APPLICATIONS (CARS)\
\
\
\
\
\
\

Application Compressor
Chrysler Corp.
Avenger & Sebring Coupe
2.0L (DOHC) ........................ Nippondenso 10PA17C 10-Cyl.\
2.5L (SOHC) .............................. Sanden MSC90-C Scroll\
Breeze, Cirrus & Stratus .................... Sanden TRS-90 Scroll
Concorde, Intrepid, LHS & 300M ........ Nippondenso 10PA17 10-Cyl.
Neon .................................. Nippondenso 10PA17 10-Cyl.
Sebring Convertible ......................... Sanden TRS-90 Scroll
Ford Motor Co.
Except Taurus 3.4L SHO ........................ Ford FS-10 10-Cyl.
Taurus 3.4L SHO .................................... Sanden Scroll
General Motors ( 1)
"C" Body ...................................... Harrison V5 5-Cyl.

Page 14 of 1691

DODGE RAM 1999 Service Repair Manual "E" Body ................................. Harrison HD6/HT6 6-Cyl.
"F" Body
3.8L Engine ................................. Harrison V5 5-Cyl.
5.7L Engine ..............................

"E" Body ................................. Harrison HD6/HT6 6-Cyl.
"F" Body
3.8L Engine ................................. Harrison V5 5-Cyl.
5.7L Engine ................................. Harrison V7 7-Cyl.
"G" Body
Aurora ................................. Harrison HD6/HT6 6-Cyl.
Riviera ..................................... Harrison V5 5-Cyl.
"H" Body ...................................... Harrison V5 5-Cyl.
"J" Body ...................................... Harrison V5 5-Cyl.
"K" Body ................................. Harrison HD6/HT6 6-Cyl.
"M" Body ..................................... Nippondenso 10-Cyl.
"N" Body ...................................... Harrison V5 5-Cyl.
"S" Body ...................................... Harrison V5 5-Cyl.
"V" Body ...................................... Harrison V5 5-Cyl.
"W" Body ...................................... Harrison V5 5-Cyl.
"Y" Body ...................................... Harrison V7 7-Cyl.
"Z" Body ....................................... Zexel Rotary Vane
(1) - Body codes are determined by fourth character of VIN code.
\
\
\
\
\
\
\

COMPRESSOR APPLICATIONS (LIGHT TRUCKS & VANS)\
\
\
\
\
\
\

Application Compressor
Chrysler Corp.
Dakota & Ram Pickup ........................ Sanden SD-7H15 7-Cyl.
Durango .................................... Sanden SD-7H15 7-Cyl.
Caravan, Town & Country, & Voyager .... Nippondenso 10PA17 10-Cyl.
Ram Van/Wagon ............................... Sanden TR-105 Scroll
Ford Motor Co.
"E" Series Van ................................ Ford FS-10 10-Cyl.
Expedition & Navigator ........................ Ford FS-10 10-Cyl.
Explorer & Mountaineer ........................ Ford FS-10 10-Cyl.
"F" Series Pickup
Except Super Duty ........................... Ford FS-10 10-Cyl.
Super Duty ............................... Sanden SD-7H15 7 Cyl.
Ranger ........................................ Ford FS-10 10-Cyl.
Villager ........................................... FS-10 10-Cyl.
Windstar ...................................... Ford FS-10 10-Cyl.
General Motors ( 1)
"C" & "K" Series ......................... Harrison HD6/HT6 6-Cyl.
"G" Series .................................... Harrison V5 5-Cyl.
"J" Series ................................... Nippondenso 10-Cyl.
"L" & "M" Series ......................... Harrison HD6/HT6 6-Cyl.
"P" Series ............................... Harrison HD6/HT6 6-Cyl.
"S" & "T" Series
2.2L ........................................ Harrison V7 7-Cyl.
4.3L ................................... Harrison HD6/HT6 6-Cyl.
"U" Series .................................... Harrison V5 5-Cyl.
Jeep
Cherokee ................................... Sanden SD-7H15 7-Cyl.
Grand Cherokee ........................ Nippondenso 10PA17 10-Cyl.
Wrangler ................................... Sanden SD-7H15 7-Cyl.
( 1) - Series codes are determined by fifth character of VIN code.
\
\
\
\
\
\
\

CAPACITIES
NOTE: Always refer to underhood A/C specification label in engine
compartment or A/C compressor label while servicing A/C

Page 15 of 1691

DODGE RAM 1999 Service Repair Manual system. If A/C specification label and specifications in this
article differ, use underhood label specifications.
REFRIGERANT OIL & R-134a REFRIGERANT CAPACITY (CARS)
��

system. If A/C specification label and specifications in this
article differ, use underhood label specifications.
REFRIGERANT OIL & R-134a REFRIGERANT CAPACITY (CARS)
\
\
\
\
\
\
\

Application ( 1) Oil Oz. Refrigerant Oz.
Chrysler Corp.
Avenger & Sebring Coupe
2.0L (DOHC) ...................... 2.7-4.1 ......... 24.7-26.1\
2.5L (SOHC) ...................... 5.7-6.4 ......... 24.7-26.1\
Breeze, Cirrus & Stratus ............. 5.0 ................ 20.0
Concorde, Intrepid, LHS & 300M ....... 5.0 ................ 28.0
Neon ................................. 6.8 ................ 28.0
Sebring Convertible .................. 5.0 ................ 20.0
Ford Motor Co.
Continental .......................... 7.0 ................ 34.0
Contour, Cougar & Mystique ........... ( 1) ................. ( 1)
Crown Victoria & Grand Marquis ....... 7.0 ................ 38.0
Escort, Coupe & Tracer ............... 7.0 ................ 28.0
Mustang .............................. 7.0 ................ 34.0
Sable & Taurus ....................... 7.0 ................ 34.0
Town Car ............................. 7.0 ................ 38.0
General Motors
"C" Body ............................. 9.0 ................ 32.0
"E" & "K" Bodies ................ ( 1) 8.0-9.0 ............. 32.0
"F" Body ............................. 9.0 ................ 24.0
"G" Body
With HD6/HT6 Compressor ............ 8.0 ................ 32.0
With V5 Compressor ................. 9.0 ................ 32.0
"H" Body ............................. 9.0 ................ 32.0
"J" Body ............................. 9.0 ................ 24.0
"M" Body ............................. 3.4 ........... 19.0-21.0
"N" Body ............................. 9.0 ................. ( 2)
"S" Body ......................... ( 3) 4.1 ........... 22.9-26.5
"V" Body ............................. 9.0 ................ 33.5
"W" Body ............................. 9.0 ................ 30.0
"Y" Body ............................. 9.0 ................ 24.0
"Z" Body ............................. 5.0 ................ 24.0
( 1) - Total system capacity, unless otherwise noted. Refer to
underhood A/C specification label in engine compartment for
specified oil type.
( 2) - Refrigerant capacity for Alero and Grand Am is 36.0 ounces.
Refrigerant capacity for Cutlass and Malibu is 28.0 ounces.
( 3) - Compressor oil capacity.
\
\
\
\
\
\
\

REFRIGERANT OIL & R-134a REFRIGERANT CAPACITY (LIGHT TRUCKS & VANS)\
\
\
\
\
\
\

Application ( 1) Oil Oz. Refrigerant Oz.
Chrysler Corp.
Caravan, Town & Country, & Voyager
Without Rear Unit ................... 9.0 ............... 34.0
With Rear Unit ..................... 13.4 ............... 44.0
Dakota ................................ 8.1 ............... 28.0
Durango
Without Rear Unit ................... 5.5 ............... 28.0
With Rear Unit ...................... 8.0 ............... 30.0
Ram Pickup ............................ 8.1 ............... 30.0
Ram Van/Wagon
Without Rear Unit ................... 8.0 ............... 34.0

Page 16 of 1691

DODGE RAM 1999 Service Repair Manual With Rear Unit ..................... 10.0 ............... 46.0
Ford Motor Co.
"E" Series
With Rear Unit ..................... 13.0 ............... 64.0
Without Rear Unit .......

With Rear Unit ..................... 10.0 ............... 46.0
Ford Motor Co.
"E" Series
With Rear Unit ..................... 13.0 ............... 64.0
Without Rear Unit ................... 9.0 ............... 44.0
Expedition & Navigator ................ (2) ................ ( 2)
Explorer & Mountaineer ................ 7.0 ............... 30.0
F150/F250 Pickup ...................... 9.0 ............... 32.0
F250HD/F350 Pickup .................... 9.0 ............... 32.0
Ranger ................................ 7.0 ............... 30.0
Villager
With Rear Unit ..................... 11.0 ............... 56.0
Without Rear Unit ................... 7.0 ............... 32.0
Windstar
With Rear Unit ..................... 13.0 ............... 56.0
Without Rear Unit ................... 9.0 ............... 44.0
General Motors
"C" & "K" Series
Pickup & Sierra ..................... 8.0 ............... 32.0
Crew Cab & Utility .................. 8.0 ............... 36.0
Suburban, Tahoe & Yukon
With Rear Unit ..................... 11.0 ............... 64.0
Without Rear Unit ................... 8.0 ............... 36.0
"G" Series
With Rear Unit ..................... 11.0 ............... 78.0
Without Rear Unit ................... 8.0 ............... 48.0
"J" Series ............................ 3.4 ............... 21.0
"L" & "M" Series
With Rear Unit ..................... 11.0 ............... 48.0
Without Rear Unit ................... 8.0 ............... 32.0
"P" Series ............................ 8.0 ................ ( 2)
"S" & "T" Series
2.2L ................................ 9.0 .......... 30.0-32.0
4.3L ................................ 8.0 .......... 30.0-32.0
"U" Series
With Rear Unit ..................... 11.0 ............... 46.0
Without Rear Unit ................... 8.0 ............... 32.0
Jeep
Cherokee .............................. 8.1 ............... 20.0
Grand Cherokee ........................ 5.8 ............... 24.0
Wrangler .............................. 8.1 ............... 20.0
( 1) - Total system capacity, unless otherwise noted. Refer to
underhood A/C specification label in engine compartment for
specified oil type.
( 2) - Refrigerant oil and/or refrigerant capacity not available from
manufacturer. Refer to underhood A/C specification label in
engine compartment.
\
\
\
\
\
\
\

REFRIGERANT OILS
* PLEASE READ THIS FIRST *
NOTE: Use ONLY the specified oil for the A/C system or compressor.
Always check the underhood A/C specification label or A/C
compressor label before adding refrigerant oil to A/C
compressor/system.
NOTE: For compressor applications, see COMPRESSOR APPLICATIONS &
BODY DESIGNATIONS. DO NOT exceed A/C system refrigerant oil
capacity when servicing system. See CAPACITIES.

Load next 8 pages

Page: < prev 1-8 9-16 17-24 25-32 33-40 41-48 ... 1696 next >

fuel cap release check oil remote control oil mirror diagram
