horizontally, and clamp straightedge to yoke in a horizontal plane.
Repeat procedure with drive pinion flange. Ensure flange/yokes are
horizontal by checking angle of straightedge using a machinist spirit
level.
4) Measure distance "X" at each side. See Fig. 9. If
measurements are not within 1/16" (1.6 mm) of each other, transmission\
flange is horizontally misaligned.
5) Measure distance "Y" (edge of straightedge to axle shaft
center line) at each side. If measurements are not within 1/8" (3.2
mm) of each other, axle housing is misaligned. Measure distance "W" at
each side. If measurements are not within 1/16" (1.6 mm) of each
other, pinion flange is horizontally misaligned.
ADJUSTING HORIZONTAL ALIGNMENT
NOTE: Excessive difference in measurements may indicate frame
damage. DO NOT attempt to use following correction procedure
if more than slight horizontal misalignment exists.
Minor adjustment of drive shaft horizontal alignment may be
made by loosening axle housing "U" bolts and moving either side of
axle housing forward or backward. If frame is not bent, slight axle
movement should make "W" measurements equal. See Fig. 9.
REMOVAL & INSTALLATION
CENTER BEARING SUPPORT ASSEMBLY
Removal
1) With transmission in neutral and parking brake off, raise
vehicle. Scribe alignment marks on all flange/yokes and slip joints to
be disassembled or disconnected. Remove drive shaft from pinion
flange/yoke.
2) Slide rear drive shaft slip joint from front drive shaft
splines. See Fig. 10. Support drive shaft(s) while removing center
bearing support bracket mounting bolts. Pull to remove front drive
shaft slip joint from transmission extension housing shaft.
Fig. 10: Identifying Center Bearing Support Assembly Components
Courtesy of Chrysler Corp.
CAUTION: DO NOT clamp drive shaft tube or slip joint tube in a vise.
Clamp only forged portion of each yoke in vise. To avoid

distorting yoke, DO NOT overtighten vise jaws.
Disassembly
1) Clamp front drive shaft in a soft-jaw vise. If required,
disassemble "U" joint from yoke to access yoke-to-drive shaft
retaining bolt. Scribe mark yoke or slip joint to drive shaft for
reassembly reference. Slide yoke or slip joint off shaft splines.
2) Remove and retain center bearing support bracket and
retainer. (Service replacement assembly may not come with these items.
) Remove rubber insulator from bearing housing. See Fig. 10.
3) Bend slinger away from center bearing to provide clearance
for bearing puller. Using bearing puller, remove center bearing from
drive shaft. On some applications, outer bearing cover/cage and balls
must be removed to attach puller to bearing race.
Reassembly & Installation
Install NEW slinger to shaft. Install/press bearing onto
shaft using appropriate tool or tube until bearing is seated to shaft
shoulder. To complete installation, reverse disassembly and removal
procedures. Ensure support bracket angle adjustment shims are
reinstalled (if removed).
OVERHAUL
NOTE: Manufacturer recommends replacing "U" joint(s) whenever "U"
joint is disassembled from yoke. ALWAYS replace complete "U"
joint whenever extreme external lubrication leakage or
bearing cap damage exists.
Before disassembly, mark flange/yoke to drive shaft for
reassembly reference, and remove "U" joint lube fitting(s). If joints
are rusted or corroded, apply penetrating oil before pressing bearing
caps out of yoke or off "U" joint trunnion pin.
SINGLE CARDAN "U" JOINTS
Other than adding grease, "U" joint assembly items are not
individually serviceable or repairable. If needle bearings, seals,
spider, or bearing caps are found to be defective, damaged or
excessively worn, complete "U" joint must be replaced.
NOTE: Saturate bearing caps and yokes with penetrating oil before
removal.
Removal
Raise and support vehicle. Remove drive shaft. Remove inner
or outer type bearing cap retainer clips. See Fig. 11. Press bearing
caps from yokes. Remove bearings, seals and spider from yoke bore, and
discard.
Cleaning
Clean yoke bores using solvent and wire brush or crocus
cloth. Remove rust, corrosion and foreign matter from yoke bores.
Installation
1) Apply multipurpose lubricant (NLGI grade 2 EP) to yoke
bores and into needle bearings of each bearing cap. Position spider in
yoke bores.
2) Install seals onto spider trunnions or bearing caps.
Lightly tap bearing caps into yoke bore far enough to retain spider in
place.

CAUTION: DO NOT clamp drive shaft tube or slip joint tube in a vise.
Clamp only forged portion of each yoke in vise. To avoid
distorting yoke, DO NOT overtighten vise jaws.
3) Using vise or press, push bearing caps into yoke bores,
keeping spider aligned in center of bearing caps. Using socket with
diameter slightly smaller than bearing cap, continue pressing caps
inward until retainer clips can be installed. Install inner or outer
type bearing cap retainer clips.
4) Install lube fitting, and lube "U" joint. Install drive
shaft. Tighten "U" joint clamp bolts to 14 ft. lbs. (19 N.m). Lower
vehicle.
Fig. 11: Exploded View Of Single Cardan "U" Joint
Courtesy of Chrysler Corp.
DOUBLE CARDAN CONSTANT VELOCITY (CV) JOINT (4WD)
NOTE: Other than adding grease, "U" joint assembly items are not
individually serviceable or repairable. If needle bearings,
seals, spider, or bearing caps are found to be defective,
damaged or excessively worn, complete "U" joint assembly must
be replaced.
CAUTION: DO NOT allow pinion flange end of front drive shaft to hang
free or bend at sharp angle from CV joint.
Removal & Disassembly (Dakota & Ram Pickup)
1) Mark drive shaft yoke-to-front pinion flange position and
transfer case flange-to-CV joint flange position for installation
reference. Remove CV joint flange-to-transfer case flange bolts first,
then remove pinion flange bolts. Remove front drive shaft from
vehicle. DO NOT bend shaft at sharp angle from CV joint.
2) Mark CV joint components for reassembly reference. Remove
all inner or outer type bearing cap retaining clips. See Fig. 12.
3) Set joint in arbor press or vise and place a socket on
upper bearing cap. Partially press one bearing cap from outer side of

link yoke enough to grasp bearing cap with vise jaws. Remove grease
fittings that interfere with removal.
4) Grasp protruding bearing in vise jaws. Tap link yoke with
mallet and drift to dislodge bearing cap from yoke.
5) Flip assembly and repeat steps 3 and 4 to remove opposite
bearing cap. Remove cross centering kit assembly and spring.
6) Press remaining bearing caps out other end of link yoke to
complete disassembly.
Reassembly & Installation
1) Clean dirt and rust from all contact areas. Apply
multipurpose lubricant (NLGI grade 2 EP) to yoke bores and into needle\
bearings of each bearing cap. Lube center socket yoke and needle
bearings. See Fig. 12.
2) Position spider in drive shaft yoke bore. Reassemble
components in reverse order of disassembly, ensuring reference marks
align. Install drive shaft in vehicle, and tighten flange bolts to
specification. See TORQUE SPECIFICATIONS table.
Installation
1) Before installing drive shaft, clean mating flange, and
inspect machined surface for scratches, nicks and burrs. Support drive
shaft during installation to prevent bending shaft at sharp angle to
CV joint and causing damage to "U" joints.
2) Aligning reference marks, install CV joint flange to
transfer case flange first, then install shaft to pinion flange.
Attach 2 clamps to pinion flange, and tighten attaching bolts to
specification. Install and tighten 4 bolts to CV joint at transfer
case flange.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS








\









\









\









\









\









\









\








Application Ft. Lbs. (N.m)\
Center Bearing Support Bracket-To-Upper Bracket Bolts ...... 50 (68)\
Center Bearing Upper Bracket-To-Frame Bolts ................ 50 (68)\
Spring "U" Bolt Nuts
Dakota
2WD ..................................................... 65 (88)\
4WD ................................................... 110 (149)\
Ram Pickup ............................................. 110 (149)\
Ram Van/Wagon
B150 & B250 ............................................. 45 (61)\
B350 .................................................. 110 (149)\
Transfer Case Flange-To-CV Joint Flange Bolts
Dakota ................................................... 20 (27)\
Ram Pickup ............................................... 65 (88)\
"U" Joint Clamp-To-Pinion Flange Bolts
1/4" ..................................................... 14 (19)\
5/16" .................................................... 25 (34)\
Wheel Lug Nuts
Dakota .......................................... 85-115 (115-156)\
Ram Pickup
5-Lug .................................................. 95 (129)\
8-Lug (Single Wheel) .................................. 135 (183\
)
8-Lug (Dual Wheel) .................................... 145 (196\
)
Ram Van/Wagon
5-Lug .......................................... 80-110 (108-149)\
8-Lug ......................................... 120-150 (163-203)\









\









\









\









\









\









\









\








Fig. 12: Double Cardan Constant Velocity (CV) "U" Joint (Dakota &
Ram Pickup)
Courtesy of Chrysler Corp.
