damage clockspring and/or require clockspring to be
readjusted.
NOTE: Clockspring is self-centering and will automatically lock in
the centered position when steering wheel is removed.
Adjustment is only required if centering position is
disturbed.
Removal
1) Before proceeding, see SERVICE PRECAUTIONS. Disable air
bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) Clockspring is located behind steering wheel. See Fig. 1.
Ensure front wheels are in straight-ahead position. Lock steering
wheel. Remove air bag module. See AIR BAG MODULE.
3) Remove steering wheel nut. Using appropriate steering
wheel puller, remove steering wheel. When steering wheel is removed,
self-centering clockspring will automatically lock in place. Remove
upper and lower steering column shrouds to gain access to clockspring
wiring.
4) Remove knee bolster (if equipped). Disconnect Yellow 2-wa\
y
clockspring harness connector between clockspring and instrument panel
wiring harness, at base of steering column. See Fig. 13. Remove
clockspring by releasing 2 tabs on side of clockspring. Clockspring
cannot be repaired and must be replaced if faulty.
Installation
1) Snap clockspring onto steering column. If clockspring
centering adjustment is disturbed, adjust clockspring before
installing steering wheel. See CLOCKSPRING CENTERING under
ADJUSTMENTS. Connect clockspring wiring connectors. Install steering
column covers. Install knee bolster (if removed).
2) Position steering wheel on steering column. Ensure flats
on steering wheel hub fit formations on inside of clockspring. Pull
clockspring, cruise control switch (if equipped) and horn wires
through lower large holes and upper small holes in steering wheel.
3) Install steering wheel retaining nut and tighten to 45 ft.
lbs. (61 N.m). Connect horn and cruise control wires (if equipped).
Connect clockspring wire to air bag module. To ensure complete
connector connection, latching arms must be visible on top of
connector housing. DO NOT connect negative battery cable at this time.
Go to SYSTEM OPERATION CHECK .
PASSENGER AIR BAG DISARM (PAD) SWITCH
Removal & Installation
1) Before proceeding, see SERVICE PRECAUTIONS. Disable air
bag system. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) If vehicle is equipped with automatic transmission, turn
ignition switch to UNLOCK position, set parking brake and place
transmission selector lever in LOW position. Tilt steering column to
lowest position (if equipped). Using trim stick, gently pry around
perimeter of cluster bezel and remove bezel.
3) Open glove box. Holding glove box door, push center of
glove box bin towards front of vehicle. Flex glove box bin far enough
so glove box stops will clear sides of instrument panel opening. Roll
glove box down until stop bumpers are beyond sides of instrument panel
opening. Release bin. Lift bottom of glove box upward to disengage
hinge hooks form hinge pins.
4) Reach through glove box opening to access and disconnect 2
passenger-side air bag disarm switch harness connectors. Connectors
are attached to bracket located on inboard glove box opening
reinforcement. See Fig. 4. Remove 3 screws retaining passenger-side
air bag disarm switch bezel to instrument panel.


AU TO T R AN S D IA G NO SIS - 4 2R E, 4 4R E, 4 6R E & 4 7R E

1999 D odge P ic ku p R 1500
1999 AUTOMATIC TRANSMISSIONS
Chrysler 42RE, 44RE, 46RE & 47RE Electronic Controls
MODEL IDENTIFICATION
Vehicle body codes are used throughout self-diagnostic tests.
See BODY CODE DESIGNATION table for model identification.
BODY CODE DESIGNATION









\









\









\









\









\









\









\







Model Body Code
Dodge
Dakota ........................................................ AN
Durango ....................................................... DN
Pickup ........................................................ BR
Ram Van/Wagon ................................................. AB
Jeep Grand Cherokee ............................................. WJ









\









\









\









\









\









\









\







APPLICATION
TRANSMISSION APPLICATIONS








\









\









\









\









\









\









\







Application Transmission Model
Cab & Chassis
5.9L (Gasoline) ............................................. 46RE\
5.9L (Diesel) & 8.0L ........................................ 47RE\
Dakota & Durango
3.9L ........................................................ 42RE
5.2L ........................................................ 44RE
5.9L ........................................................ 46RE
Grand Cherokee
4.0L ........................................................ 42RE
Ram Pickup
3.9L ........................................................ 42RE
5.2L (RWD) .................................................. 42RE\
5.2L (4WD) .................................................. 46RE\
5.9L (Gasoline) ............................................. 46RE\
5.9L (Diesel) & 8.0L ........................................ 47RE\
Ram Van
5.2L (B3500) ................................................ 46RE\
5.9L ........................................................ 46RE
Ram Wagon (5.2L & 5.9L) ....................................... 46RE\









\









\









\









\









\









\









\







INTRODUCTION
The first step in diagnosing any driveability problem is
verifying the customer's complaint with a test drive under the
conditions the problem reportedly occurred. Before entering self-
diagnostics, perform a careful and complete visual inspection. Most
transmission control problems result from mechanical breakdowns or
poor electrical connections.
DESCRIPTION

The OD (Overdrive) OFF switch is located on instrument panel,\
to the right of steering column. The OD OFF switch controls overdrive
operation by delivering an input signal to PCM. The PCM uses this
signal for controlling operation of overdrive solenoid on the valve
body.
When overdrive switch is in the OFF position, OD light on
instrument panel will be illuminated and transmission will not upshift
into 4th gear for overdrive operation. When OD switch is in the ON
position, OD light on instrument panel will not be illuminated and
transmission will upshift into 4th gear for overdrive operation.
If OD switch is in the ON position, the TCC will lock-up when
transmission is in 4th gear with vehicle speed greater than 45 MPH. If
overdrive switch is in the OFF position, the TCC will lock-up when
transmission is in 3rd gear with vehicle speed greater than 35 MPH at
light throttle application.
THROTTLE POSITION (TP) SENSOR
The TP sensor delivers an input signal to the PCM to indicate
throttle position. The PCM uses this input signal for controlling TCC
operation, governor pressure and upshift into 4th gear for overdrive
operation.
TRANSMISSION FLUID TEMPERATURE SENSOR
NOTE: Transmission fluid temperature sensor may also be referred to
as transmission fluid temperature thermistor or transmission
fluid temperature sender.
Transmission fluid temperature sensor delivers an input
signal to the PCM to indicate transmission fluid temperature. The PCM
uses this input signal for controlling the TCC, overdrive operation
and governor pressure. Transmission fluid temperature sensor is
located on the valve body and is integral with governor pressure
sensor. See Fig. 1.
OUTPUT SHAFT SPEED SENSOR
NOTE: Output shaft speed sensor may also be referred to as
transmission shaft speed sensor or shaft speed sensor.
Output shaft speed sensor is located on overdrive unit
attached to rear of transmission. Output shaft speed sensor is mounted
above the lugs on park gear in the overdrive unit. Speed sensor input
signals are generated when lugs on park gear rotate past face of
sensor. Input signals are delivered to PCM. The PCM uses this input
signal for controlling transmission operation. The Vehicle Speed
Sensor (VSS) also serves as a back-up to the output shaft speed
sensor. The VSS signal is also an input to the PCM.
TROUBLE SHOOTING
* PLEASE READ THIS FIRST *
NOTE: For symptom trouble shooting, see appropriate AUTOMATIC
TRANSMISSION OVERHAUL article.
PRELIMINARY INSPECTION
Visually inspect all electrical wiring, looking for chafed,

stretched, cut or pinched wiring. Ensure electrical connectors fit
tightly and are not corroded. Check PCM, sensors and switches for
physical damage. Check engine coolant level. Check transmission fluid
level and condition.
SELF-DIAGNOSTIC SYSTEM
* PLEASE READ THIS FIRST *
NOTE: Only transaxle-related trouble codes are listed. For engine-
related DTC definitions, see TROUBLE CODE DEFINITIONS article
in APPLICATIONS & IDENTIFICATION. For engine-related DTC
diagnosis, see appropriate SELF-DIAGNOSTICS article in ENGINE
PERFORMANCE. Engine performance DTCs must be repaired first,
as engine performance and related component signals will
affect transaxle operation and diagnosis.
DIAGNOSTIC PROCEDURE
When performing vehicle diagnosis:
* Ensure transmission fluid level is correct and fluid is
neither contaminated or aerated.
* Ensure shift cable is properly adjusted. See appropriate
AUTOMATIC TRANSMISSION SERVICING article in TRANSMISSION
SERVICING.
* Ensure battery is fully charged.
* Perform visual inspection, ensuring all electrical
connections at transmission, PCM, TP sensor and output shaft
speed sensor are clean and properly installed.
* Retrieve DTCs. See RETRIEVING DIAGNOSTIC TROUBLE CODES.
* Repair DTCs in order displayed.
* Always perform test verification test after any repair
procedure is completed unless specified otherwise. See
appropriate verification test under DIAGNOSTIC TESTS.
NOTE: Self-diagnostic tests are written specifically for Chrysler's
Diagnostic Readout Box (DRB) scan tool. A generic scan tool
may be used, but may not be capable of performing all
necessary test functions.
TEST EQUIPMENT HOOK-UP
Generic Scan Tool & DVOM
Self-diagnostic tests are written specifically for Chrysler's
Diagnostic Readout Box (DRB) scan tool. The DRB has a built-in DVOM
function. A generic scan tool may be used, but may not be capable of
performing all necessary test functions. If DRB test procedures
require resistance or voltage to be measured using scan tool in
ohmmeter or voltmeter mode, connect DVOM ground lead to DLC connector
terminal No. 4 and positive lead to terminal specified in test
procedure.
DRB Scan Tool
Refer to DRB scan tool instructions to read and clear DTCs,
and when performing other scan tool functions. DRB scan tool is
grounded through DLC connector terminal No. 4. Only one volt/ohmmeter
test lead is required to measure voltage or resistance. See Fig. 2.
RETRIEVING DIAGNOSTIC TROUBLE CODES
NOTE: Manufacturer recommends using Chrysler's Diagnostic Readout

Box (DRB) scan tool with appropriate cartridge for system
diagnosis. Other after-market scan tools may be used for
system diagnosis. The following procedure is for DRB scan
tool usage. Use scan tool manufacturer's instruction for
operating scan tool.
NOTE: Ensure battery is fully charged before proceeding with test.
1) Ensure ignition is off. Connect DRB to Data Link Connector
(DLC) located under driver's side of instrument panel. Using scan
tool, display all Diagnostic Trouble Codes (DTCs). Identify DTCs once
retrieved. See DIAGNOSTIC TROUBLE CODES (DTC) & DRB MESSAGES table.
2) If scan tool will not power up, check for loose cable
connections or faulty cable. If cable connections and cable are okay,
check voltage at DLC terminal No. 16. Voltage should be at least 11
volts. If voltage is not as specified, check wiring circuit and
necessary fuses. See WIRING DIAGRAMS.
3) If scan tool displays an error message, RAM TEST FAILURE,
CARTRIDGE ERROR, KEY PAD TEST FAILURE, or LOW OR HIGH BATTERY, this
indicates a scan tool failure.
4) If DTCs are displayed, perform appropriate test(s). See
DIAGNOSTIC TROUBLE CODES (DTC) & DRB MESSAGES table. If no DTCs are
displayed, see TROUBLE SHOOTING in appropriate AUTOMATIC TRANSMISSION
OVERHAUL article.
DIAGNOSTIC TROUBLE CODES (DTC) & DRB MESSAGES









\









\









\









\









\









\









\







DTC DRB-III Scan Tool Message
P0711 .................. TRANS TEMP SENSOR, NO TEMP RISE AFTER START
P0712 ............................. TRANS TEMP SENSOR VOLTAGE TO LOW
P0713 ............................ TRANS TEMP SENSOR VOLTAGE TO HIGH
P0720 ..................... LOW OUTPUT SPEED SENSOR RPM ABOVE 15 MPH
P0740 .................... TORQ CONVERTER CLU, NO RPM DROP AT LOCKUP
P0743 ........ TORQUE CONVERTER CLUTCH SOLENOID/TRANS RELAY CIRCUITS
P0748 ........... GOVERNOR PRESSURE SOL CONTROL/TRANS RELAY CIRCUITS
P0751 ....................... OD SWITCH PRESSED (LO) MORE THAN 5 MIN\
P0753 ................ TRANS 3-4 SHIFT SOLENOID/TRANS RELAY CIRCUITS
P0783 ....................... 3-4 SHIFT SOL, NO RPM DROP @ 3-4 SHIFT
P1740 (1) .......................... TCC OR O/D SOLENOID PERFORMANCE
P1756 .................... GOV PRESS NOT EQUAL TO TARGET @ 15-20 PSI
P1757 ...................... GOV PRES ABOVE 3 PSI IN GEAR WITH 0 MPH
P1762 .................... GOV PRESS SEN OFFSET VOLTS TO LOW OR HIGH
P1763 ....................... GOVERNOR PRESSURE SENSOR VOLTS TO HIGH
P1763B ...................... GOVERNOR PRESSURE SENSOR VOLTS TO HIGH
P1764 ........................ GOVERNOR PRESSURE SENSOR VOLTS TO LOW
P1765 ..................... TRANS 12 VOLT SUPPLY RELAY CNTRL CIRCUIT
P1899 .......................... P/N SWITCH STUCK IN PARK OR ON GEAR
( 1) - BR body only.









\









\









\









\









\









\









\







CLEARING DIAGNOSTIC TROUBLE CODES
After repairs have been performed, clear DTCs from PCM memory
using scan tool, following scan tool manufacturer's instructions.
NOTE: If malfunction is no longer present after DTC is stored in
PCM memory, the PCM will erase DTC after ignition has been
cycled at least 50 times. DTC may be cleared by using scan
tool. Follow scan tool manufacturer's instructions. DTCs may
also be cleared by disconnecting negative battery cable for a
period of time, but other vehicle control modules may also be

2) If any DTCs listed are present, perform appropriate
test(s). See TORQUE CONVERTOR CLUTCH (TCC) TESTS table. If no DTCs a\
re
present, go to next step.
TORQUE CONVERTOR CLUTCH (TCC) TESTS









\









\









\









\









\









\









\







DTC DTC Message
P0122 (1) ................. THROTTLE POSITION SENSOR VOLTAGE TOO LOW
P0123 ( 1) ................ THROTTLE POSITION SENSOR VOLTAGE TOO HIGH
P1696 ( 1) .......................... PCM FAILURE EEPROM WRITE DENIED
P0743 ........ TORQUE CONVERTOR CLUTCH SOLENOID/TRANS RELAY CIRCUITS
( 2) ........................................................ MISFIRE
P0320 ( 1) ......................... NO CRANK REFERENCE SIGNAL AT PCM
( 1) - See appropriate SELF-DIAGNOSTICS article in ENGINE PERFORMANCE.
( 2) - Perform appropriate misfire DTC test. See appropriate
SELF-DIAGNOSTICS article in ENGINE PERFORMANCE.









\









\









\









\









\









\









\







3) Check transmission fluid for proper level and for any
debris. Fill or repair transmission as necessary. If fluid level and
condition are okay, go to next step.
4) Start engine. Using scan tool, perform TCC SYSTEM TEST. If
vehicle does not stall, go to step 9). If vehicle stalls, go to next
step.
5) Using scan tool, perform GOV and 3-4 SHIFT VALVE SYSTEM
TEST. Select 4th gear. If vehicle stalls, go to next step. If vehicle
does not stall, go to step 7).
6) Turn ignition off. Replace TCC solenoid. Using scan tool,
perform GOV and 3-4 SHIFT VALVE SYSTEM TEST. Select 4th gear. If
vehicle stalls, problem in internal. Check for blocked passage. If
vehicle does not stall, testing is complete.
7) Turn ignition off. Remove oil pump and inspect reaction
shaft, input shaft and input seal. Repair transmission as necessary.
See appropriate AUTOMATIC TRANSMISSION OVERHAUL article. If
transmission is okay, go to next step.
8) Inspect all related wiring and connectors. Repair as
necessary. If wiring and connectors are okay, see INACTIVE DTC
CONDITION under SELF-DIAGNOSTIC SYSTEM. Testing is complete.
9) Turn ignition off. Connect a pressure gauge to
transmission cooler OUT port. Start engine. Using scan tool, perform
TCC SYSTEM TEST. If pressure increases when TCC is actuated, go to
next step. If pressure does not increase, repair leaks or blockage in
hydraulic circuit, or repair valve body as necessary.
10) Turn engine off. Remove oil pump and inspect reaction
shaft, input shaft and input seal. Repair transmission as necessary.
See appropriate AUTOMATIC TRANSMISSION OVERHAUL article. If
transmission is okay, there are no other potential causes remaining.
TCC is assumed to be defective. Replace torque converter.
DTC P0743: TORQUE CONV CLUTCH SOLENOID/TRANS RELAY CKT
NOTE: To test transmission temperature sensor, engine and
transmission temperature must be less than 85F (29C).
Circuit Description
Circuit is monitored continuously while key is on. Code sets
if voltage detected on Torque Converter Clutch (TCC) at the Powertrain\
Control Module (PCM) does not match desired voltage.
Possible Causes

replace PCM and see INACTIVE DTC CONDITION under SELF-DIAGNOSTIC
SYSTEM. Testing is complete.
DTC P0783: 3-4 SHIFT SOL, NO RPM DROP @ 3-4 SHIFT
Circuit Description
Circuit is monitored continuously while key is on and engine
running. Code sets if expected RPM drop does not occur within 4
seconds of requested gear change by PCM. Test must fail 3 times to set
code.
Possible Causes
* Transmission mechanically defective.
* TPS codes set.
* Transmission 3-4 solenoid wiring harness defective.
* Transmission fluid burnt or oil pan has excessive debris.
Diagnostic Procedures
1) Using scan tool, read DTCs. On all bodies except AB and WJ
bodies, go to next step. On AB and WJ bodies, if DTC SPECIFIC GOOD
TRIPS counter is not displayed or displayed count is not "0", go to
step 6). If DTC SPECIFIC GOOD TRIPS counter is displayed and displayed
count is "0", indicating DTC still exists, go to next step.
2) If any DTCs listed are present, perform appropriate
test(s). See 3-4 SHIFT SOLENOID TESTS table. If no DTCs are present,
go to next step.
3-4 SHIFT SOLENOID TESTS









\









\









\









\









\









\









\







DTC Message Test
NO CAM SIGNAL AT PCM ..................................... ( 1) P0340
P/N SWITCH STUCK IN PARK OR IN GEAR .......................... P1899
Any Throttle Position Sensor (TPS) DTC ......................... ( 1)
TORQUE CONVERTOR CLUTCH SOLENOID/TRANS RELAY CIRCUITS ........ P0743
TRANS 12-VOLT SUPPLY RELAY CNTRL CIRCUIT ..................... P1765
TRANS 3-4 SHIFT SOLENOID/TRANS RELAY CIRCUITS ................ P0753
( 1) - See appropriate SELF-DIAGNOSTICS article in ENGINE PERFORMANCE.









\









\









\









\









\









\









\







3) Check transmission fluid for proper level and for any
debris. Fill or repair transmission as necessary. If fluid level and
condition are okay, go to next step.
4) Connect a 0-300 psi (0-21 kg/cm
) pressure gauge to
transmission Overdrive (O/D) clutch pressure test port. Connect a
second 0-300 psi (0-21 kg/cm
) pressure gauge to transmission governor
pressure test port. See appropriate AUTOMATIC TRANSMISSION OVERHAUL
article. Ensure engine and transmission are at normal operating
temperature. With an assistant, test drive vehicle. Using scan tool,
select GOV and 3-4 SHIFT VALVE SYSTEM TEST. Select 4th gear while
monitoring pressure gauge. Governor pressure should rise to greater
than 20 psi (1.4 kg/cm
) and O/D pressure should rise to greater than
40 psi (2.8 kg/cm). If pressures are as specified, go to next step.
If pressures are not as specified, go to step 8).
5) Using wiring diagram as a guide, inspect wiring and
connectors. Repair wiring harness as necessary. If wiring and
connectors are okay, go to next step.
6) Using scan tool, erase DTCs. Start engine. Road test
vehicle at 0-55 MPH with a constant 20 percent throttle. Repeat road
test 4 times. Note if DTC P0783 resets. If DTC P0783 resets, repair
wiring harness as necessary. If DTC P0783 does not reset, go to next
