NOTE: Clutch release bearing is packed with grease. DO NOT use
cleaning solvent to clean release bearing.
Removal
1) Remove transmission and clutch housing. See TRANSMISSION
(DAKOTA) or TRANSMISSION (RAM PICKUP). Disconnect release bearing fr\
om
fork, and remove bearing. See Fig. 11. Remove release fork.
2) Inspect bearing. Bearing should turn smoothly under a
light thrust load. Inspect release fork and fork ball pivot for
distortion and wear.
Installation
1) Lubricate crankshaft pilot bearing, input shaft splines,
bearing retainer slide surface, fork pivot and release fork pivot
surface with high-temperature bearing grease.
2) Install release fork and release bearing. Ensure fork and
bearing are properly secured. Install transmission and clutch housing.
Fig. 11: Exploded View Of RWD Clutch Release Bearing Assembly
Courtesy of Chrysler Corp.
CLUTCH MASTER CYLINDER
Removal
1) Disconnect clutch pedal interlock switch wires. Remove
locating clip from clutch master cylinder mounting bracket. Remove
retaining clip, flat washer and wave washer that attach clutch master
cylinder push rod to clutch pedal. Slide clutch master cylinder push
rod off pedal pin. Ensure cap on clutch master cylinder reservoir is
tight.
2) Remove clutch fluid reservoir. Rotate clutch master
cylinder 45 degrees counterclockwise to unlock it. Remove cylinder
from dash panel. Remove clutch master cylinder rubber seal from dash
panel.
Installation
Lubricate cylinder seal with liquid soap to ease
installation. Seat seal in dash and around cylinder. To install,
reverse removal procedure.

FLUID TYPE
Use SAE 80W-90 or 90W hypoid gear lubricant with MIL-L-2105-C
and API GL-5 ratings.
TROUBLE SHOOTING
NOTE: See appropriate table in TROUBLE SHOOTING article in GENERAL
INFORMATION.
REMOVAL & INSTALLATION
AXLE SHAFT & HUB BEARING
Removal
1) Raise and support vehicle. Remove wheel. Remove brake
caliper with hose attached, and secure aside. DO NOT allow brake
caliper to hang by brake hose. Remove brake rotor. Remove ABS wheel
speed sensor (if equipped). Remove grease cap from center of front
hub. Remove cotter pin from end of axle shaft. Remove axle nut and
washer.
2) Remove hub/bearing assembly-to-knuckle bolts. Remove
hub/bearing assembly from steering knuckle and axle shaft. Remove
brake dust shield. To remove right (passenger-side) axle shaft,
carefully pull axle shaft from axle housing.
NOTE: Left axle shaft will disengage from collar located on
intermediate axle shaft.
3) To remove left (driver's side) axle shaft, disconnect
electrical connector and vacuum hoses at vacuum shift motor. Remove
bolts, vacuum shift motor and gasket. Carefully pull axle shaft from
axle housing and collar on intermediate axle shaft.
Installation
1) Install NEW oil seal on axle shaft with seal lip facing
toward splines on differential end of axle shaft. Coat seal lip with
wheel bearing grease.
2) Install right axle shaft into axle housing. Ensure axle
shaft engages with side gears in differential.
3) To install left axle shaft, ensure collar is engaged with
splines on intermediate axle shaft. Install left axle shaft into axle
housing. Ensure axle shaft engages with splines on collar. Install
vacuum shift motor, ensuring fork on vacuum shift motor engages groove
on collar. Install and tighten bolts to specification. See TORQUE
SPECIFICATIONS table.
4) To complete installation, reverse removal procedure. Apply
silicone rubber sealant to edge of grease cap before installing.
Tighten bolts/nuts to specification. See TORQUE SPECIFICATIONS table.
DRIVE SHAFT
Removal
1) Raise and support vehicle. Ensure transmission and
transfer selector levers case are in Neutral. Reference mark drive
shaft and pinion flange for reassembly reference.
2) Remove bolts and "U" joint straps at pinion flange. Remove
center carrier bearing bolts (if equipped). Remove drive shaft.
CAUTION: The "U" joint components are not serviceable. Replace
complete assembly. DO NOT reuse.

Installation
To install, reverse removal procedure using NEW "U" joint
straps and bolts. Ensure all reference marks are aligned. Tighten
bolts to specification. See TORQUE SPECIFICATIONS table.
PINION FLANGE & OIL SEAL
Removal
1) Raise and support vehicle. Reference mark drive shaft and
pinion flange on differential for reassembly. Remove bolts and "U"
joint straps at pinion flange on differential. Disconnect drive shaft
from differential, and support it aside.
2) Using INCH-lb. torque wrench, measure amount of force
required to rotate pinion. This is pinion bearing preload. Record
pinion bearing preload for reassembly reference.
3) Remove pinion nut and washer from pinion. Scribe reference
mark on pinion flange and pinion for reassembly. Using Holder (C-3281)\
and appropriate flange remover, remove pinion flange from pinion.
Remove oil seal from axle housing.
Installation
1) Ensure oil seal surface in axle housing is clean. Coat lip
of oil seal with gear lube. Using appropriate oil seal installer and
handle, install oil seal.
2) Install pinion flange on pinion with reference mark
aligned. Press pinion flange onto pinion. Install washer and pinion
nut. Tighten pinion nut while rotating pinion, ensuring bearings are
properly seated. Tighten nut until preload measured before disassembly
is achieved. DO NOT exceed maximum torque specification. See TORQUE
SPECIFICATIONS table.
3) To install remaining components, reverse removal procedure
using NEW "U" joint straps and bolts. Ensure all reference marks are
aligned. Tighten bolts to specification. See TORQUE SPECIFICATIONS
table. Check lubricant level and add if necessary.
AXLE HOUSING ASSEMBLY
NOTE: Removing axle housing assembly is not necessary unless axle
housing is damaged. Differential carrier and components can
be serviced by removing differential assembly from axle
housing.
Removal
1) Raise and support vehicle. Remove front wheels. Reference
mark drive shaft to pinion flange for reassembly. Remove bolts and "U"
joint straps at pinion flange. Remove drive shaft, and support aside.
Remove brake calipers, and support aside with wire. DO NOT allow
calipers to hang from brake hoses.
2) Disconnect ABS sensor harness connectors (if equipped).
Disconnect drag link and tie rod from steering knuckles. Disconnect
shock absorber from axle housing. Disconnect stabilizer bar links at
spring brackets.
3) Disconnect electrical connector and vacuum hoses at vacuum
shift motor. Support axle housing assembly with floor jack. Remove
bolts from upper and lower suspension arms. Lower axle housing
assembly from vehicle and remove.
Installation
To install, reverse removal procedure. Ensure reference marks
on drive shaft and pinion flange align. Tighten suspension arms with
vehicle at normal operating height. Tighten bolt/nuts to
specification. See TORQUE SPECIFICATIONS table. Check axle fluid level

bearing preload is checked before disassembly, as previous
pinion bearing preload will be used during reassembly.
Removal
1) Raise and support vehicle. Scribe reference mark on drive
shaft-to-pinion flange on differential for reassembly reference.
Remove bolts and "U" joint straps at pinion flange on differential.
Disconnect drive shaft from differential.
2) Remove rear wheels and brake drums to prevent any drag
that may affect pinion bearing preload reading. Using INCH-lb. torque
wrench, measure amount of force required to rotate pinion. This is
pinion bearing preload. Record pinion bearing preload for reassembly
reference.
3) Using Holder (6719), hold pinion flange. Remove pinion nu\
t
and washer. Scribe reference mark on pinion flange-to-pinion for
reassembly reference. Using appropriate puller, remove pinion flange
from pinion. Remove oil seal from axle housing.
Installation
1) Ensure oil seal surface in axle housing is clean. Coat lip
of oil seal with gear lube. Install oil seal using appropriate seal
installer. Drive oil seal into axle housing until oil seal installer
contacts axle housing.
2) Install pinion flange on pinion with reference mark
aligned. Using appropriate pinion flange installer, install pinion
flange on pinion.
CAUTION: Washer must be installed on pinion with convex side of washer
facing outward (away from pinion).
3) Install washer on pinion with convex side of washer facing
outward (away from pinion). Install NEW pinion nut. Tighten pinion nut\
to 210 ft. lbs. (285 N.m). Rotate pinion several times to seat pinion
bearings.
CAUTION: DO NOT overtighten or loosen then retighten pinion nut when
adjusting pinion bearing preload. If pinion nut is over
tightened, collapsible spacer on pinion must be replaced. See
OVERHAUL.
4) Using INCH-lb. torque wrench, measure pinion bearing
preload. Tighten pinion nut in small increments until original pinion
bearing preload is obtained.
5) To install remaining components, reverse removal procedure
using NEW "U" joint straps and bolts. Ensure all reference marks are
aligned. Tighten bolts to specification. See TORQUE SPECIFICATIONS.
Check lubricant level and add if necessary.
AXLE HOUSING ASSEMBLY
NOTE: It is not necessary to remove axle housing assembly, unless
axle housing is damaged. Differential carrier and components
can be serviced by removing differential assembly from axle
housing.
Removal
1) Raise and support vehicle. Block brake pedal in upward
position so brake pedal cannot be depressed, as brakelines must be
disconnected.
2) Remove rear wheels. DO NOT remove brake drums. Disconnect
brakelines at wheel cylinders. Cap brakelines to prevent fluid loss.
Disconnect axle housing vent hose.
3) Remove brake tee fitting bolt, and disengage brakelines

Back-Up Lamp Switch On left side of transmission.
Brake Pressure Switch On combination valve.
Clutch Pedal Position Switch On clutch master cylinder
pushrod.
Low Washer Fluid Level Switch On side of washer fluid
reservoir.
Park Brake Switch On park brake mechanism.
Park/Neutral Position Switch
(A/T) On left side of transmission.
Seat Belt Switch Above left rear speaker.
