MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR91.12-P-1110GH
Remove and install rear seat cushion frame
23.5.00

MODELS
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2205-01 P91.12-2206-01 P91.12-2257-01
P91.12-2258-0

AR91.12-P-1110GH
Remove and install rear seat cushion frame
23.5.00

MODELS
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2205-01 P91.12-2206-01 P91.12-2257-01
P91.12-2258-01 P91.12-2259-01

1
Retaining strap bolt

2
Rear seat cushion frame mounting

screws

3
Rear seat cushion frame

4
Screw
10

Clip

11
Cover

12
Rubber grommet

13
Handle locking device

5

Vertical adjustment handle

6
Vertical adjustment cable

7
Clip

8
Horizontal adjustment cable

9
Clip

Remove/install

1.1
Loosen Velcro lock in the left rear corner of
the rear seat cushion frame

Only 60% rear seat

2.1
Unscrew screw of retaining strap (1)

Only 60% rear seat

*BA91.12-P-1009-03A

Torx bit set

*000589011000

3
Remove paneling of horizontal adjustment

handle

Risk of breakage!

Unscrew screw and press paneling of

horizontal adjustment handle forwards in

order to unhook the retaining lugs.

4
Remove outer cover from rear seat

Do not remove the remaining covers.

AR91.12-P-1100GH

5
Remove curtain from the front and side of the

rear seat

6
Remove fold-down rear backrest

AR91.12-P-1720GI

7
Unhook the front of the rear seat covering on

both sides and at the back of the rear seat

cushion frame

8
Remove rear seat covering and rear seat

cushion from the rear seat cushion frame

Installation:
if a new rear seat cushion

frame is used for the 60% rear seat, the

center Velcro closure must be glued on.

9.1
Remove locking mechanism for automatic

front seat adjustment for easy entry to the rear

Only 40% rear seat for the 3rd seat row,

code 847.

AR91.12-P-1120GH

10
Detach cover (11) from vertical adjustment

handle (5)

11
Unscrew bolt (4) and detach vertical

adjustment handle (5) from rear seat cushion

frame

Press unlocking device and pull vertical

adjustment handle forwards. Observe

installed position of spring!

12
Unhook vertical adjustment cable (6) from

clips (7, 9)

Risk of breakage!

Clip (7) is concealed behind adhesive tape.

Installation:
glue on adhesive tape again

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3810 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
13
Unhook vertical adjustment cable (6) from

vertical adjustment handle (5)

14
Guide vertical adjustment cable (6) through

grommet (12)

Installation:
If a new rear seat cushion

frame is

Page 3811 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR91.12-P-1730GI
Remove and install locking mechanism for folding rear seat backrest
5.5.99

MODELS
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2133-06

1
Rear backrest r

Page 3812 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
Torx bit set

000 589 01 10 00

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2

Page 3813 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR91.12-P-1720GI
Remove/install tilting rear seat
3.5.99

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2128-09

1
Cushion below arm rest

2
Bolts
7

Center seat be

AR91.12-P-1720GI
Remove/install tilting rear seat
3.5.99

MODEL
163.136 /154 /172 as of 1.9.99,

163.113 /128 /157 /174 /175

P91.12-2128-09

1
Cushion below arm rest

2
Bolts
7

Center seat belt

8
Seat belt bolt

9
Rear seat cushion

10
Belt end fitting

3

Covers

4
Bolts

5
Bolts

6
Backrest

Remove, Install

1
Remove headrests

See Operating Instructions

2
Remove rear cargo space floor flaps

See Operating Instructions

3
Fold other bench down into the footwell

See Operating Instructions

4.1
Remove cushion (1) from underneath arm rest

Applies to 60% seat bench only.

Unscrew 2 bolts on the bottom of the rear

side, and turn upholstery upwards, in order to

detach locating tab at the rear.

5
Remove screws (2) for covering (3)

6
Remove covers (3) from backrest fitting

7
Remove screws (4) on backrest fitting

60 % bench: Fold backrest down, in order

to gain access to the screws on inside of the

backrest fitting.

Torx bit set

*000589011000

*BA91.12-P-1006-03A

8
Fold bench seat into footwell

Rear seat backrest remains erect.

9
Remove screw (5) on backrest bracket

Pull handle forward.

Torx bit set

*000589011000

*BA91.12-P-1006-03A

10
Remove rear seat backrest (6) from bench

Put rear seat backrest down in the load

compartment.

11.1
Detach seat upholstery from back of rear seat

cushion (9)

Applies to 60% seat bench only.

12.1
Carefully lift seat upholstery upwards and

remove seat belt screw (8) on belt end fitting

(10) on the rear seat bench frame

Take care not to damage seat upholstery.

Applies to 60% seat bench only.

Torx bit set

*000589011000

*BA91.40-P-1001-01D

13.1
Remove buckle connector from seat frame

and withdraw from retaining clamp

Only 60 % bench seat in combination with

rear side airbag (left and right), code 293. In

order to avoid fault codes, turn ignition key to

the "0" position.

Copyright DaimlerChrysler AG 14.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3814 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
14.1
Remove belt end fitting (10) together with

buckle through the rear seat cushion (9)

Do not damage seat cover!

Applies to 60% seat bench only.

15
Install in the reverse order

Rear sea

Page 3815 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR91.40-P-2000GHRemove/install seat belts for third row of seats
12.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /175 with CODE (847) 3rd seat row

P91.40-0361-06

1
Screw

2
Seat belt guide brack

Page 3816 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR91.40-P-1515GH
Remove/install belt buckle (front seat)
5.3.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P91.40-0372-11

1
Front seat

2
Front seat seat belt buckle

3
Internal Torx dri
