Page 3729 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
Repsol Elite Cosmos
X
Repsol YPF Lubricantes y Especialidades, S.A.,

Mostoles-Madrid, Spain

ROWE Synth RS 5W40 i
X
ROWE Mineralölwerk GmbH, Bubenheim, Germany

S-Tronic
X
Kuttenkeuler GmbH, Colo

Repsol Elite Cosmos
X
Repsol YPF Lubricantes y Especialidades, S.A.,

Mostoles-Madrid, Spain

ROWE Synth RS 5W40 i
X
ROWE Mineralölwerk GmbH, Bubenheim, Germany

S-Tronic
X
Kuttenkeuler GmbH, Cologne, Germany

Selenia Digitech
X
FL Italia s.p.a., Villastellone (Torino), Italy
Selenia Perform
X
FL Selenia s.p.a., Villastellone (Torino), Italy

Selenia WR 5W-40
X
FL Selenia s.p.a., Villastellone (Torino), Italy

Shell Helix Diesel Ultra
XX
Shell International Petroleum Co., London, England

Shell Helix Plus G-B025
X
Shell International Petroleum Co., London, England

Shell Helix Plus S
X
Shell International Petroleum Co., London, England

Shell Helix Ultra
XXX
Shell International Petroleum Co., London, England

Shell Helix Ultra AB
X
Shell International Petroleum Co., London, England

Statoil LazerWay 5W40
X
Statoil Lubricants, Stockholm, Sweden

Statoil LazerWay X
X
Statoil Lubricants, Stockholm, Sweden

swd Primus HDC
X
Swd Lubricants GmbH & Co. KG, Duisburg, Germany

swd Primus Ultra
X
Swd Lubricants GmbH & Co. KG, Duisburg, Germany

swd Primus VS
X
Swd Lubricants GmbH & Co. KG, Duisburg, Germany

Syncon High Performance Synthetic
X
ConocoPhillips International Inc., Singapore, Singapore

Synt 5W/40
X
Hunold Schmierstoffe GmbH, Eching, Germany

Synt-XL; SAE 5 W 40
X
Hubert Math. Müller Handelsgesellschaft mbH,

Eschweiler, Germany

Tamoil Sint Future Prestige (I)
X
Tamoil Petroli S.p.A., Milan, Italy

Tamoil Sint Future Racing
X
Tamoil Petroli S.p.A., Milan, Italy

Teboil Diamond Plus
X
Suomen Petrooli Oy, Hamina, Finland

Top Evolution
X
TOP OIL Products Company, Burlingame, CA, USA

Tor Hypersynth
X
De Oliebron B.V., Zwijndrecht, Netherlands

Total activa 9000
X
Total Lubrifiants, Paris, France

Total quartz 9000
X
Total Lubrifiants, Paris, France

Triathlon Sprint
X
Adolf Würth GmbH & Co. KG, Künzelsau, Germany

Ultra - Synth 4000
X
Profi-Tech chem. tech. Produkte GmbH, Gingen,

Germany

Ultrasyn Plus
X
Kuttenkeuler GmbH, Cologne, Germany

Unil Opal Opaljet 32 S
X
Unil S.A., Saumur, France

Unil Synth
X
Unil Germany GmbH, Stuttgart, Germany

Unimot Synth 9
X
GB Lubricants Limited, Gateshead, England

Unoil GX-7
X
Exxon Mobil Corporation, Fairfax, Virginia, USA

Valvoline Durablend MXL
X
The Valvoline Company, Dordrecht, Netherlands

Valvoline SynPower
X
The Valvoline Company, Dordrecht, Netherlands

Valvoline SynPower 0W-40
X
The Valvoline Company, Dordrecht, Netherlands

Valvoline SynPower 5W-40
X
The Valvoline Company, Dordrecht, Netherlands

Valvoline SynPro 5W-40
X
The Valvoline Company, Dordrecht, Netherlands

Valvoline SynPro motor oil
X
The Valvoline Company, Dordrecht, Netherlands

Veedol Powertron
X
Veedol International, Swindon, England

Veedol Syntron
X
Veedol International, Swindon, England

Wako's ex Synthe
X
Wako Chemical Co. Limited, Kanagawa / Japan

Westfalen Gigatron
X
Westfalen AG, Münster, Germany

Wintershall ViVA 1 LonglifeX
SRS Schmierstoff Vertrieb GmbH, Salzbergen, Germany

Wintershall ViVA 1 topsynth
X
SRS Schmierstoff Vertrieb GmbH, Salzbergen, Germany

Wintershall ViVA 1 topsynth alpha
X
SRS Schmierstoff Vertrieb GmbH, Salzbergen, Germany

Wolf Masterlube Synflow DC
X
Wolf Oil Corporation N.V., Hemiksem, Belgium

Wolf Masterlube Synflow Plus
X
Wolf Oil Corporation N.V., Hemiksem, Belgium

Yacco VX 1000
X
Yacco SAF, Saint-Pierre-lès-Elbeuf, France
Yacco VX 600
X
Yacco SAF, Saint-Pierre-lès-Elbeuf, France

York 748
X
Ginouves Georges S.A., La Farlède, France

ZIC XQ
X
SK Corporation, Seoul, Rep. of Korea

Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 4

Page 3730 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
GF77.20-P-2003GH
Opening pop-up roof, function
19.2.97

MODEL
163 with CODE (414a) Electric glass sliding/pop-up roof

Function prerequisites

D
Voltage not too low or too high

D
Switch-on condi

GF77.20-P-2003GH
Opening pop-up roof, function
19.2.97

MODEL
163 with CODE (414a) Electric glass sliding/pop-up roof

Function prerequisites

D
Voltage not too low or too high

D
Switch-on conditions for convenience control fulfilled

D
Sliding/pop-up roof synchronized

Function

When
switch (SHD, S13/2)
is actuated continuously, circuit 30 is

switched through to the
sliding/pop-up roof (M12)
and the pop-up

roof opens.

The function "Open pop-up roof" is executed as long as

D
switch (SHD, S13/2)
is actuated and

D
the pop-up roof has not yet reached the end position and

D
lock-up is not recognized.

If the sliding/pop-up roof is desynchronized, it moves only in the pop-

up roof direction each time the
switch (SHD, S13/2)
is actuated. This
means that it is possible to move to the zero
position for synchronizing. After successful

synchronization
, the

sliding/pop-up roof can be controlled again without limitation.

Vehicles
up to 11.99:

The power for the
sliding/pop-up roof (M12)
is supplied via a

fuse directly to c. 30.

The power for the
switch (SR, S13/2)
is supplied via the

convenience relay (F1k14)
, which is actuated by the all-

activity module (AAM, N10).

Vehicles
as of 12.99:

The power for the
sliding/pop-up roof (M12)
is supplied via a

fuse directly to c. 30. The power for the
switch (SHD, S13/2) is

supplied via a lead to the
extended-activity module (EAM,

N10/1) , this power is switched through only when the switch-on

conditions for the convenience control are fulfilled and the EAM

is coded accordingly.

Closing sliding /pop-up roof, function

GF77.20-P-2002GH

Sliding /pop-up roof lock-up recognition,
function

GF77.20-P-3000GH

Sliding /pop-up roof position measurement,

function

GF77.20-P-3001GH

Synchronizing sliding /pop-up roof, function

GF77.20-P-3002GH

Convenience control

GF72.29-P-2002GH

All-activity module (AAM)
up to 11.99

GF54.21-P-4100GH

Extended-activity module, location/

purpose/design/function
as of 12.99

GF54.21-P-4107GK

Copyright DaimlerChrysler AG 04.08.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3731 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR88.70-P-9040GI
Remove/install outside rearview mirror paneling
27.2.01

MODEL
163.113 /154 /174 #A as of 289565,

163.113 /154 /174 #X as of 754620,

163.128 /157 /175

P88.70-2107-11

1
Mirro

Page 3732 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR88.70-P-9040GH
Removing and installing outside rearview mirror cover
12.2.97

MODEL
163.113 /136 /154 /172 /174 up to 31.8.01

P88.70-0255-06

1
Frame

2
Mirror housing paneling

3
Catches in m

Page 3733 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR88.70-P-9020GI
Remove/install mirror glass
24.4.01

MODEL
163.113 /154 /174 #A as of 289565,

163.113 /154 /174 #X as of 754620,

163.128 /157 /175

P88.70-2126-11

1
Locking mechanism

2
Mir

Page 3734 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
GF54.30-P-4104A
Outside temperature display, location/function
8.7.99

MODEL
129

MODEL
140 as of 1.6.96

MODEL
170

MODEL
163, 202 with CODE (240a) Outside temperature display

MODEL
202 a

GF54.30-P-4104A
Outside temperature display, location/function
8.7.99

MODEL
129

MODEL
140 as of 1.6.96

MODEL
170

MODEL
163, 202 with CODE (240a) Outside temperature display

MODEL
202 as of 1.8.96

MODEL
168

MODEL
208 up to 31.7.99,

210 as of 1.6.96 up to 30.6.99

To display the temperature, the
outside temperature indicator

A1p4
requires:

D
the outside temperature

D
the speed signal

D
the engine running time

and
D
the coolant temperature (model 129, and model 140 as of
1.6.96, model 170, model 202 as of 08/96 and model 163,

model 168, model 210)

The outside temperature is determined by the outside temperature

indicator temperature sensor B14. The temperature sensor is

installed at the front left of the vehicle under the bumper and

connected to the instrument cluster A1 via the 21 or 25-pin

connector, coding part A terminal 1 and 2.

The speed signal, engine running time and engine temperature are

determined internally by the instrument cluster A1.

Since the outside temperature display depends on the speed, engine

running time and coolant temperature, high temperatures (influenced

by the heat generated by the engine, for example) are not displayed

when the vehicle is stationary or moving slowly.
Function, model 202 until 08/95

When the ignition is switched on and off and at speeds below approx.

20 km/h, the last temperature measured is stored and displayed.

If the measured outside temperature drops below the stored value,

the current measured temperature is displayed.

If the outside temperature rises above the stored value, the current

measured outside temperature is displayed only after the following

delays:

D
When the engine is not running, the current outside

temperature is only displayed after 6 times the engine running

time. For example, if the preceding running time was 5 minutes,

the current temperature is not displayed until after 30 minutes.
The maximum delay, however, is 1 hour.

Up to 09.94

D
At vehicle speeds between 20-60 km/h, outside temperatures

are displayed after a delay of approx. 5 min.

D
At vehicle speeds over 60 km/h, outside temperatures are

displayed after a delay of approx. 2 minutes.

As of 09.94

D
At vehicle speeds between 20-45 km/h, outside temperatures

are displayed after a delay of approx. 3 min.

D
At vehicle speeds over 45 km/h, outside temperatures are

displayed after a delay of approx. 1.5 min.

Function

Model 129, model 140 as of 1.6.96, model 170, model 202 as of

08/96, model 163, model 168, model 208 and model 210

D
When the ignition is turned on or off

and with an engine temperature < 60°C

the current temperature is always stored and displayed.

D
When the ignition is turned off

and with an engine temperature < 60°C

the temperature last measured is stored and displayed.

D
When the ignition is turned on

and when an engine temperature < 60(C

The stored temperature is displayed.
If the measured outside temperature drops below the stored value,

the current measured temperature is displayed.

If the outside temperature rises above the stored value, the current

measured outside temperature is displayed only after the following

delays:

D
When the engine is not running, the current outside

temperature is only displayed after 6 times the engine running

time. For example, if the preceding running time was 5 minutes,

the current temperature is not displayed until after 30 minutes.
The maximum delay, however, is 1 hour.

D
At vehicle speeds between 20-45 km/h, outside temperatures

are displayed after a delay of approx. 3 minutes.

D
At vehicle speeds above 45 km/h, outside temperatures are

displayed after a delay of approx. 1.5 minutes.

Copyright DaimlerChrysler AG 05.06.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 3735 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR77.20-P-0001GH
Removing and installing switch for pop-up/sliding roof
29.4.97

MODEL
163 with CODE (414a) Electric glass pop-up/sliding roof

P77.20-0449-11

1
Overhead control panel

2
Screw

Page 3736 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR82.20-P-1100GH
Remove/install front overhead control panel
27.5.97

MODEL
163.113 /128 /136 /154 /157 /172 /174 /175

P68.00-0650-06

1
Garage door opener flap

2
Overhead control panel

3
Cove

Load next 8 pages

Page: < prev 1-10 ... 3697-3704 3705-3712 3713-3720 3721-3728 3729-3736 3737-3744 3745-3752 3753-3760 3761-3768 ... 4136 next >

garage door opener windshield wipers roof rack inflation pressure winter tyres headlight bulb
