Page 1977 of 4133
GF82.15-P-2100-04GH
Function of headlamp cleaning system
telescopic nozzles
n
After the
HCS pump (M5/2)
has started to operate, pressure builds
up in the washing water line for approx. 1 second. Driven by the
water pressure, the nozzles first move telescopically into the cleaning
position. Then as a result of a further pressure rise, a valve at each
telescopic nozzle opens and an exactly metered quantity of washing
water is sprayed onto the headlamp lenses.
Swirl chambers are provided at the tips of the telescoping sections
and these ensure controlled propagation of the water jet, even when
traveling fast. After the cleaning process, the telescoping sections
are retracted back into the starting position with the aid of return
springs.
Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 1978 of 4133

AR82.15-P-6100GH
Remove/install telescoping nozzle for headlamp cleaning system
9.5.00
MODELS
163.113 /128 /154 /157 /172 /175 with CODE (600a) Headlamp cleaning system
MODEL
163.174
P82.15-2067-06
1
Water hose
2
Retaining clip
3
Screws
4
Cover
5
Telescopic nozzle
Remove/Install
1
Remove the front bumper
with visual enhancement package, code U49.
AR88.20-P-2000GI
As of VIN A289565, X754620.
AR88.20-P-2000GJ
2
Remove retaining clip (2) and water hose (1)
from telescopic nozzle
3
Unscrew screws (3) from mount of telescopic
nozzle
4
Remove cover (4) from telescopic nozzle
Risk of breakage!
Press telescopic nozzle upward to obtain
access to the retaining lugs for the cover from
above
5
Remove telescopic nozzle (5) together with
mount
6.1
Remove mount from telescoping nozzle
Only when the telescopic nozzle is
replaced.
7
Install in the reverse order
Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 1979 of 4133

AR88.30-P-2000-01GH
Remove brush guard
Modification notes
10.8.01
Value modified from 25 Nm to 49 Nm
Value modified in BA88.30-P-1003-01A for
model 163 up to 31.8.01
*BA88.30-P-1003-01A
Detachable body components, underride guard
Number
Designation
Model 163
up to
31.8.01
BA88.30-P-1002-01A
Nut, spacer tube on brush guard
Nm
86
BA88.30-P-1003-01A
Screw, mount on brush guard
Nm
49
BA88.30-P-1011-01A
Bolt, underride guard to brush guard
Nm
25
BA88.30-P-1015-01A
Nut, underride guard to bracket
Nm
49
BA88.30-P-1016-01A
Bolt, front section of underride guard to rear
section of underride guard
Nm
49
P88.30-2150-06
1.1
Remove screws (1) and nuts (2) from
underride guard (3) at bottom of vehicle
.
Only if available.
2
Remove screw for brush guard (4) from
inner mount at bottom (5)
3
Remove nut for spacer tube (6)
4
Remove spacer sleeve (7) from spacer
tube nut (6).
5
Remove brush guard (8) toward front.
Carefully move out brush guard so that
paint is not damaged.
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 1980 of 4133

AR88.20-P-2000GH
Remove/install front bumper
14.3.97
MODEL
163.113 /154 #A up to 289564,
163.113 #X up to 754619,
163.154 #X up to 716524,
163.136 /172 except CODE (U49) Styling package
P88.20-0375-09
1
Nut
2
Nuts
1a
Screw
Remove/Install
1.1
Remove brush guard together with underride
guard
If installed.
AR88.30-P-2000-01GH
*BA88.30-P-1002-01A
*BA88.30-P-1003-01A
*BA88.30-P-1011-01A
*BA88.30-P-1015-01A
*BA88.30-P-1016-01A
2
Unscrew nut (1)
Left and right at inside.
*BA88.20-P-1001-01B
3
Unscrew bolt (1a)
Left and right at inside.
*BA88.20-P-1002-01B
4
Remove front bumper grille.
Carefully remove front bumper grille so
that bumper grille and bumper grille mount
cannot be damaged.
Loosen retainers and pull to outside
Pulling hook
*140589023300
5.1
Remove outside temperature sensor from
front bumper.
If installed.
6
Unscrew nuts (2)
*BA88.20-P-1003-01B
7
Remove bumper toward front.
Do not damage paint.
8
Install in the reverse order
Detachable body components, underride guard
Number
Designation
Model 163
up to
31.8.01
BA88.30-P-1002-01A
Nut, spacer tube on brush guard
Nm
86
Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 1981 of 4133
BA88.30-P-1003-01A
Screw, mount on brush guard
Nm
49
BA88.30-P-1011-01A
Bolt, underride guard to brush guard
Nm
25
BA88.30-P-1015-01A
Nut, underride guard to bracket
Nm
49
BA88.30-P-1016-01A
Bolt, front section of underride guard to rear
section of underride guard
Nm
49
Bumper
Number
Designation
Model 163
BA88.20-P-1001-01B
Nut, front bumper on outer mount
Nm
8
BA88.20-P-1002-01B
Screw for front bumper on inner mount
Nm
1.5
BA88.20-P-1003-01B
Nut, front bumper on frame
Nm
8
Pulling hook
140 589 02 33 00
Copyright DaimlerChrysler AG 17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
Page 1982 of 4133

AR88.20-P-2200GH
Remove/install rear bumper
6.4.99
MODEL
163.113 #A up to 289564,
163.154 #X up to 754619,
163.154 #A up to 289564,
163.136 /172
P88.20-0372-09
A
Covers
C
Screws
B
Nuts
Remove/install
1.1
Disconnect antenna connector of E-call
emergency call system
Only with emergency call system E-Call,
code 349.
Connector is located behind side flap of right
C-pillar paneling at jack mounting point.
2
Remove covers (A)
Do not damage paint. Do not break off
clips.
Installation wedge
*115589035900
3
Unscrew mounting nuts (B) from bumper
*BA88.20-P-1004-01B
4
Unscrew screws (C)
*BA88.20-P-1005-01B
5.1
Remove nut from rear mud guard
Only if present
*BA88.30-P-1004-01A
6
Remove bumper toward rear
Do not damage paint.
Installation:
Align bumper at tailgate and
at taillamps
7.1
Remove rubber seal for E-call emergency call
system antenna from body at right
Only with emergency call system E-Call,
code 349.
8
Install in the reverse order
Bumper
Number
Designation
Model 163
BA88.20-P-1004-01B
Nut, rear bumper to frame
Nm
8
BA88.20-P-1005-01BScrews, rear bumper on frame
Nm
8
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1
Page 1983 of 4133
Number
Designation
Model 163
up to
31.8.01
Model 163
as of
1.9.01
BA88.30-P-1004-01A
Nut for retaining strap on mud guard on vehicle
underbody
Nm
66
Long wedge
115 589 03 59 00
Copyright DaimlerChrysler AG 20.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
Page 1984 of 4133

AR88.20-P-2200GI
Remove/install rear bumper
11.4.97
MODEL
163.113 #A up to 289564,
163.113 #X up to 754619,
163.154 #A up to 289564,
163.154 #X up to 716524,
163.136 /172 with CODE (849) Spare wheel carrier/spare wheel
P88.20-0369-09
A
Nuts
B
Nut
E
Nuts
C
Screws
D
Spare wheel carrier consoles
Remove/Install
1.1
Disconnect antenna connector of E-call
emergency call system
Only with emergency call system E-Call,
code 349.
Connector is located behind side flap of right
C-pillar paneling at jack mounting point.
2
Unscrew nuts (A)
On vehicle underbody behind cross
member
3
Unscrew nut (B)
On vehicle underbody behind cross
member
4
Unscrew bolts from spare wheel carrier
console
Do not damage bolt thread
Bolts fastened with nuts (A) can be driven
out from the rear of the cross member.
5
Remove spare wheel carrier consoles (D)
6
Remove 3 panels from bumper
Do not damage paint. Do not break off
clips.
Long wedge
*115589035900
7
Unscrew bolts (C) from bumper
*BA88.20-P-1007-01B
8
Unscrew nuts (E) from bumper
*BA88.20-P-1006-01B
9.1
Remove nut from rear mud guard
Only if present
*BA88.30-P-1004-01A
10
Remove bumper
Do not damage paintwork on vehicle and
bumper.
Completely turn spare wheel carrier to
rear (maximum clearance for bumper). Pull
bumper to rear and then lift out upward
between spare wheel carrier and vehicle.
Installation:
Align bumper at tailgate and
at taillamps
