Page 2585 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
WH58.30-Z-1001-06A
6 mm socket hexagon on flexible shaft for hose clamps with worm drive
Hazet

Güldenwerther

Bahnhofstrasse 25-28

D-42857 Remscheid

426-6

WH58.30-Z-1002-06A
7 mm hexagon sock

Page 2586 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR80.20-P-4004GH
Removing, installing fuel filler flap central locking motor
12.3.97

MODEL
163

P80.20-0478-06

1
Fuel filler flap

2
Outer screws

3
Inner screws

4
Fuel filler fitting

5

Page 2587 of 4133

Page 2588 of 4133

Page 2589 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AP47.20-P-0780BB
Replace fuel filter
2.3.99

ENGINE
611.960 in MODEL 202.133 /134 /193 /194

ENGINE
611.961 in MODEL 210.006 /007 /206 /606

ENGINE
612.961 in MODEL 210.016 /216 /616

ENGINE

AP47.20-P-0780BB
Replace fuel filter
2.3.99

ENGINE
611.960 in MODEL 202.133 /134 /193 /194

ENGINE
611.961 in MODEL 210.006 /007 /206 /606

ENGINE
612.961 in MODEL 210.016 /216 /616

ENGINE
612.963 in MODEL 163.113

ENGINE
613.961 in MODEL 210.026 /226

ENGINE
613.960 in MODEL 220.026 /126

P47.20-0289-01

Shown on engine 611.960

70
Fuel filter housing

70/1
Fuel filter input

70/2
Fuel filter output

70/3
Threaded ring

70/4
Cap

70/5
Seal

70/6
Filter element

P07.16-2101-01

Shown on engine 612.961

70/1
Fuel line input

70/2
Fuel line output

70/3
Threaded ring

70/4
Cap

70/5
Seal

70/6
Filter element

70/7
Fuel return line

70/8
Fuel feed line

Remove/install and replacing

Danger!
Risk of death.
Death may result if vehicle

slips or topples from the lifting platform.
Align vehicle between the columns of the

lifting platform and position the four support

plates
at the lifting platform support points

specified by the vehicle manufacturer.

AS00.00-Z-0010-01A

Danger!
Risk of explosion
from fuel igniting,
risk of

poisoning
from inhaling and swallowing fuel

as well as
risk of injury
to eyes and skin

from contact with fuel.
No fire, sparks, naked flames or smoking.

Pour fuels only into suitable and appropriately

marked containers.

Wear protective clothing when handling fuel.

AS47.00-Z-0001-01A

1
Remove trim panel of charge air distribution

pipe

2
Disconnect fuel return line (70/7) and fuel

feed line (70/8 )

3
Unscrew threaded ring (70/3) and remove

together with cover (70/4).

If the fuel filter housing is soiled inside,
it must be removed and cleaned (against
separate order):

#
f

Remove/install fuel full-flow filter

AR47.20-P-1070HB

4
Replace filter insert (70/6)

After inserting the filter element

Fill fuel filter housing with fuel.

5
Replace sealing ring (70/5)

6
Mount threaded ring with cover so that the

groove latches at the fuel filter housing

Tighten threaded ring by hand.

7
Mount fuel return line (70/7) and fuel feed line

(70/8 )

8
Install trim panel of charge air distribution pipe

*BA01.20-P-1003-01A

Danger!
Risk of accident.
Accidents may result if the

vehicle starts off unintentionally with the

engine running.
Risk of injury.
Crushing and

burn injuries may result while working on

engine during when it is being started or when

it is in operation.
Secure vehicle to prevent it from moving.
Wear closed and snug-fitting work clothes.

Do not grasp hot or rotating parts.

AS00.00-Z-0005-01A

9
Run engine and inspect fuel filter for leaks

Crankcase ventilation, cylinder head cover

Copyright DaimlerChrysler AG 28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 2590 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
Number
Designation
Engine

611.960/

961/962
Engine

612.961/

962/967
Engine

612.963
Engine

613.960/

961

BA01.20-P-1003-01A
Screw attaching cover panel to charge air

distribution pipe
Nm

Page 2591 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
AR47.20-P-1070M
Removing and installing fuel full-flow filter
24.8.99

ENGINE
612.963 in MODEL 163.113

P47.20-2043-06

1
Fuel feed line

2
Fuel return flow line

3
Fuel cooler

4
Bolts of fuel

AR47.20-P-1070M
Removing and installing fuel full-flow filter
24.8.99

ENGINE
612.963 in MODEL 163.113

P47.20-2043-06

1
Fuel feed line

2
Fuel return flow line

3
Fuel cooler

4
Bolts of fuel cooler

70
Fuel full-flow filter

Operation no. of operation texts or standard texts and flat rates
Sector

Op. no.
Operation text

P
075560
REMOVING AND INSTALLING FUEL FULL-FLOW FILTER

P
075563
REPLACING FUEL FULL-FLOW FILTER

P
075564
REPLACING FUEL FULL-FLOW FILTER (AFTER INSPECTING)

Removing, installing

Danger!

Risk of injury
from fingers being
jammed or

bruised
when removing or installing and

aligning hood, doors, trunk lid/tailgate or

sliding roof
Ensure that no parts of your body or limbs are

within the operating range when moving such

components.

AS00.00-Z-0011-01A

Danger!

Risk of explosion
as a result of fuel vapors

igniting.
Risk of poisoning
as a result of

inhaling fuel vapors.
Risk of injury
as a

result of fuel coming into contact with skin

and eyes.
No fire, naked flame or smoking.

Pour fuels only into suitable and appropriate

marked containers.

Wear protective clothing when handling fuel.

AS47.00-Z-0001-01A

1
Open hood and raise to vertical position

Have assistant secure hood.

AR88.40-P-1000GI

2
Remove trim panel of charge air distribution

pipe

AR01.20-P-5014-02B

*BA01.20-P-1002-01A
*BA01.20-P-1003-01A

3
Disconnect fuel lines (1, 2) at fuel full-flow

filter (70)

Collect fuel which flows out.

Pay attention to use of locking arm. See:
#

Disconnecting and connecting fuel lines at

engine.

AR47.25-P-1000-01A

4
Take off fuel cooler (3)

Take off only the bolts (4) and raise fuel

cooler slightly.

5
Remove fuel full-flow filter (70)

Collect fuel which flows out.

Installation:
If the fuel full-flow filter has been

drained, it must be filled with fuel after being

installed and before starting the engine to

ensure engine starts properly.

*BA47.20-P-1001-02A

6
Install in the reverse order

Copyright DaimlerChrysler AG 28.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 1

Page 2592 of 4133

MERCEDES-BENZ ML350 1997 Complete Repair Manual
Danger!

Risk of accident
as a result of vehicle

starting off when engine running.
Risk of

injury as a result of bruises and burns if you

insert your hands into engine when it is being
