Maintenance and Care
Scheduled Maintenance
Maintenance Interval Number of months or kilometers, whichever comes fi
rst
Months 3 6 9 12 15 18 21 24 27 30 33 36
×1000 km 5 10 15 20 25 30 35 40 45 50 55 60
CHASSIS and BODY
Brake lines, hoses and connections I I I
Brake and clutch fl uid level I I I I I
Brake fl uid R
Disc brakes I I I I I I
Tire (Rotation) Rotate every 10,000 km
Tire in fl ation pressure and tire wear I I I I I I
Steering operation and linkages I I I I I I
Front and rear suspension, ball joints and wheel
bearing axial play I
I I
Rear differential oil
*3
Transfer oil *3
Driveshaft dust boots I I I
Bolts and nuts on chassis and body T T T
Exhaust system and heat shields I I I
All locks and hinges L L L L L L
Washer fl uid level I I I I I I
Emergency fl at tire repair kit (if installed)
*4 Inspect annually.
AIR CONDITIONER SYSTEM
Cabin air fi lter R R R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fi ll up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
Remarks:
*1 Use of FL-22 is recommended when replacing engine coolant. Using engine \
coolant other than FL-22 may cause serious damage to the engine and cooling system.
*2 According to state/provincial and federal regulations, failure to perfor\
m maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or kilometer period to ensure long-term reliability.
*3 If this component has been submerged in water, the oil should be replaced.
*4 Check the tire repair fl uid expiration date every year when performing the periodic maintenance.\
Replace the
tire repair fl uid bottle with new one before the expiration date.




CX-5_8FN1-EA-16L_Edition1.indb 132016/12/12 10:07:06

6–14
Maintenance and Care
Scheduled Maintenance
(Cont.)
Maintenance Interval Number of months or kilometers, whichever comes fi
rst
Months 39 42 45 48 51 54 57 60 63 66 69 72
×1000 km 65 70 75 80 85 90 95
100 105 110 115 120
ENGINE
Drive belts I I
Engine oil & fi lter R R R R R R R R R R R R
COOLING SYSTEM
Cooling system I I
Engine coolant
*1 Replace at
fi rst 200,000 km or 10 years; after that, every
100,000 km or 5 years
Engine coolant level I I I I I I I I I I I I
FUEL SYSTEM
Air fi lter C R C R C R
Fuel lines and hoses I
*2 I
Hoses and tubes for emission I
*2 I
Fuel fi lter Replace every 60,000 km
IGNITION SYSTEM
Spark plugs I I I I I I
Replace every 120,000 km
ELECTRICAL SYSTEM
Function of all lights I I I I I I I I I I I I
CX-5_8FN1-EA-16L_Edition1.indb 142016/12/12 10:07:06

6–15
Maintenance and Care
Scheduled Maintenance
Maintenance Interval Number of months or kilometers, whichever comes fi
rst
Months 39 42 45 48 51 54 57 60 63 66 69 72
×1000 km 65 70 75 80 85 90 95
100 105 110 115 120
CHASSIS and BODY
Brake lines, hoses and connections I I I
Brake and clutch fl uid level I I I I
Brake fl uid R R
Disc brakes I I I I I I
Tire (Rotation) Rotate every 10,000 km
Tire in fl ation pressure and tire wear I I I I I I
Steering operation and linkages I I I I I I
Front and rear suspension, ball joints and wheel
bearing axial play I
I I
Rear differential oil
*3
Transfer oil *3
Driveshaft dust boots I I I
Bolts and nuts on chassis and body T T T
Exhaust system and heat shields I I I
All locks and hinges L L L L L L
Washer fl uid level I I I I I I
Emergency fl at tire repair kit (if installed)
*4 Inspect annually.
AIR CONDITIONER SYSTEM
Cabin air fi lter R R R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fi ll up, or replace if necessary.
R: Replace
L: Lubricate
C: Clean
T: Tighten
Remarks:
*1 Use of FL-22 is recommended when replacing engine coolant. Using engine \
coolant other than FL-22 may cause serious damage to the engine and cooling system.
*2 According to state/provincial and federal regulations, failure to perfor\
m maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or kilometer period to ensure long-term reliability.
*3 If this component has been submerged in water, the oil should be replaced.
*4 Check the tire repair fl uid expiration date every year when performing the periodic maintenance.\
Replace the
tire repair fl uid bottle with new one before the expiration date.


CX-5_8FN1-EA-16L_Edition1.indb 152016/12/12 10:07:06

6–16
Maintenance and Care
Scheduled Maintenance
Maintenance Monitor
Maintenance Monitor (Type A)
Based on the engine operating conditions, the onboard computer in your v\
ehicle calculates
the remaining oil life in the United States and Puerto Rico. The wrench indicator light in the
instrument cluster will be illuminated when remaining oil life becomes l\
ess than 1,000 km
(600 mile), or remaining days are less than 15 (whichever comes fi rst).
The system must be reset whenever replacing the engine oil.
Reset method
Press and hold the dashboard illumination knob with the ignition switche\
d off, then switch
it on. Keep pressing the dashboard illumination knob for more than 5 sec\
onds. The master
warning light will fl ash for a few seconds when the reset is completed.

Dashboard illumination knob

Maintenance Monitor (Type B)
1. Select the icon on the home screen to display the “Applications” screen.
2. Select “Vehicle Status Monitor”.
3. Select “Maintenance” to display the maintenance list screen.
4. Switch the tab and select the setting item you want to change.

CX-5_8FN1-EA-16L_Edition1.indb 162016/12/12 10:07:06

6–17
Maintenance and Care
Scheduled Maintenance
You can customize settings in the setup display as follows:
Tab Item Explanation
Scheduled Setting
Notifi cation can be switched on/off.
Time (months) Displays the time or distance until maintenance is due.
Select this item to set the maintenance period.
The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining distance is less than
1,000 km or 600 mile, or the remaining number of days is less than
15 (whichever comes
fi rst).
Distance (km or mile)
Reset Resets the time and distance to the initial values.
Once the system turns on, it needs to be reset whenever carrying
out maintenance.
Tire Rotation Setting
Notifi cation can be switched on/off.
Distance (km or mile) Displays the distance until tire rotation is due.
Select this item to set the tire rotation distance.
The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining distance is less than 1,000 km
or 600 mile.
Reset Resets the remaining distance to the initial value.
Once the system turns on, it needs to be reset whenever rotating
the tires.
Oil Change Setting Interval
Oil replacement period can be selected from the
fl exible setting or
fi xed setting, or it can be set to non-display.
The fl exible setting is available only in the United States and
Puerto Rico. Once engine oil fl exible maintenance is selected,
the vehicle calculates the remaining oil life based on the engine
operating conditions. The vehicle lets you know when an oil
change is due by illuminating the wrench indicator light in the
instrument cluster. Mazda Genuine 0W-20 oil and Castrol
® 0W-20
oil are required to achieve optimum performance.
Distance (km or mile)
(Displays only in fi xed
setting) Displays the distance until the oil replacement is due.
Select this item to set the oil replacement distance.
The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining distance is less than 1,000 km
or 600 mile.
Oil life (km or mile)
(Displays only in fl exible
setting) Displays the engine oil life until the oil replacement is due.
The wrench indication/indicator light in the instrument cluster will
be illuminated when the remaining oil life distance is less than
1,000 km or 600 mile.
Reset In
fl exible setting: Resets the remaining oil life to 100 %.
In fi xed setting: Resets the remaining distance to the initial value.
Once the Flexible Oil Maintenance Setting is selected, the system
must be reset whenever replacing the engine oil.

CX-5_8FN1-EA-16L_Edition1.indb 172016/12/12 10:07:06

6–18
Maintenance and Care
Owner Maintenance
Owner Maintenance Precautions
The owner or a qualifi ed service technician should make these vehicle inspections at the
indicated intervals to ensure safe and dependable operation.

Bring any problem to the attention of an Authorized Mazda Dealer or quali fi ed service
technician as soon as possible.
When Refueling
   Brake and clutch fl uid level (page 6-27 )   Engine coolant level (page 6-25 )  Engine oil level (page 6-25 )  Washer fl uid level (page 6-27 )
At Least Monthly
   Tire in fl ation pressures (page 6-39 )
At Least Twice a Year (For Example, Every Spring and Fall)
You can do the following scheduled maintenance items if you have some mec\
hanical ability
and a few basic tools and if you closely follow the directions in this m\
anual.
   Engine coolant (page 6-25 )  Engine oil (page 6-23 )

Improper or incomplete service may result in problems. This section gives instructions only
for items that are easy to perform.

As explained in the Introduction (page 6-2 ), several procedures can be done only by a
qualifi ed service technician with special tools.

Improper owner maintenance during the warranty period may affect warranty coverage.
Refer to Introduction (page 6-2 ) for owner's responsibility in protecting your investment.
For details, read the separate Mazda Warranty statement provided with the vehicle. If you
are unsure about any servicing or maintenance procedure, have it done by\
an Authorized
Mazda Dealer.

There are strict environmental laws regarding the disposal of waste oil \
and fl uids. Please
dispose of your waste properly and with due regard to the environment.

We recommend that you entrust the oil and fl uid changes of your vehicle to an Authorized
Mazda Dealer.
CX-5_8FN1-EA-16L_Edition1.indb 182016/12/12 10:07:06

6–19
Maintenance and Care
Owner Maintenance
WARNING
Do not perform maintenance work if you lack suffi cient knowledge and experience
or the proper tools and equipment to do the work. Have maintenance work done by a
qualifi ed technician:
Performing maintenance work on a vehicle is dangerous if not done properly. You can be
seriously injured while performing some maintenance procedures.

If you must run the engine while working under the hood, make certain that you
remove all jewelry (especially rings, bracelets, watches, and necklaces) and all
neckties, scarves, and similar lo ose clothing before getting near the engine or cooling
fan which may turn on unexpectedly: Working under the hood with the engine running is dangerous. It becomes even more
dangerous when you wear jewelry or loose clothing.
Either can become entangled in moving parts and result in injury.


Pull over to a safe location, then switch the ignition off and make sure the fan is not
running before attempting to work near the cooling fan: Working near the cooling fan when it is running is dangerous. The fan could continue
running indefi nitely even if the engine has stopped and the engine compartment
temperature is high. You could be hit by the fan and seriously injured.

Do not leave items in the engine compartment: After you have fi nished checking or doing servicing in the engine compartment, do not
forget and leave items such as tools or rags in the engine compartment.
Tools or other items left in the engine compartment could cause engine damage or a fi re
leading to an unexpected accident.

CX-5_8FN1-EA-16L_Edition1.indb 192016/12/12 10:07:06

6–20
Maintenance and Care
Owner Maintenance
Hood
WARNING
Always check that the hood is closed
and securely locked: A hood that is not closed and securely
locked is dangerous as it could fl y open
while the vehicle is moving and block
the driver's vision which could result in
a serious accident.

Opening the Hood
1. With the vehicle parked, pull the release handle to unlock the hood.


Release handle
2. Insert your hand into the hood opening, slide the latch lever to the right, and lift
up the hood.


Lever
3. Grasp the support rod in the padded
area and secure it in the support rod
hole indicated by the arrow to hold the
hood open.


Pad Support rod

CX-5_8FN1-EA-16L_Edition1.indb 202016/12/12 10:07:07
