2017 MAZDA MODEL CX-5 Owners Manual (in English)

7–27
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


(Red)
Brake Pedal
Operation Demand Warning Light
*
When only fl ashing
Flashes if there is the possibility of the vehicle not being held in the\
stopped position by the
AUTOHOLD function, such as on steep slopes. Depress and hold your foot on t\
he brake
pedal.
When fl ashing and beep sound is activated at the same time
The warning light fl ashes and the beep sound is activated for about fi ve seconds if there is
a problem with the system. If the warning light fl ashes and the warning sound is activated,
immediately depress the brake pedal and stop using the AUTOHOLD function then contact
an Authorized Mazda Dealer.
WARNING
Immediately depress the brake pedal if the warning light fl ashes and the beep sound is
activated while using the AUTOHOLD function: Because the AUTOHOLD function is canceled forcibly, the vehicle may move
unexpectedly and result in an accident.


Check Engine Light If this light illuminates while driving, the vehicle may have a problem.\
It is important to
note the driving conditions when the light illuminated and consult an Authorized Mazda
Dealer.
The check engine light may illuminate in the following cases:
 The fuel tank level being very low or approaching empty.
 The engine's electrical system has a problem.
 The emission control system has a problem.
 The fuel- fi ller cap is missing or not tightened securely.
If the check engine light remains on, or it fl ashes continuously , do not drive at high speeds
and consult an Authorized Mazda Dealer as soon as possible.


Automatic
Transaxle Warning
Indication/Warning Light
* The indication/light illuminates when the transaxle has a problem.
CAUTION
If the automatic transaxle warning indication/light illuminates, the transaxle has
an electrical problem. Continuing to drive your Mazda in this condition could cause
damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible.


AWD Warning Indication
*
“4WD System Malfunction” is displayed
The indication is displayed under the following conditions. The system may have a
malfunction. Have the vehicle checked at an Authorized Mazda Dealer.
 When there is a malfunction in the AWD system.
 When there is a large difference between the tire size of the front and rear wheels.
“4WD System High Load” is displayed
The indication is displayed under the following conditions. Park the veh\
icle in a safe place
and check that the warning indication light turns off, and then drive the vehicle. Contact an
Authorized Mazda Dealer if the indication is continuously displayed.
 When the differential oil temperature is excessively high.
 When there is a large difference between the front and rear wheel rotation, such as when
trying to remove the vehicle from mud.
CX-5_8FN1-EA-16L_Edition1.indb 272016/12/12 10:07:25

7–28
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


AWD Warning Light
*
When the light is turned on
The light turns on under the following conditions. The system may have a malfunction.
Have the vehicle checked at an Authorized Mazda Dealer.
 When there is a malfunction in the AWD system.
 When there is a large difference between the tire size of the front and rear wheels.
When the light is fl ashing
Park the vehicle in a safe place. After a few moments, if the warning light stops fl ashing,
you can resume driving. If the light does not stop fl ashing, contact an Authorized Mazda
Dealer.
 When the differential oil temperature is excessively high.
 When there is a large difference between the front and rear wheel rotation, such as when
trying to remove the vehicle from mud.

(Turns on)
TCS/DSC Indicator Light If the light stays on, the TCS, DSC or the brake assist system may have a malfunction and
they may not operate correctly. Take your vehicle to an Authorized Mazda Dealer.


Air Bag/Front Seat Belt Pretensioner System Warning Light A system malfunction is indicated if the warning light constantly
fl ashes, constantly
illuminates or does not illuminate at all when the ignition is switched \
ON. If any of these
occur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate
in an accident. WARNING
Never tamper with the air bag/pretensioner systems and always have an Authorized
Mazda Dealer perform all servicing and repairs: Self-servicing or tampering with the systems is dangerous. An air bag/pretensioner
could accidentally activate or become disabled causing serious injury or death.


(Flashing)
Tire Pressure
Monitoring System Warning Light
* If the tire pressure monitoring system has a malfunction, the tire press\
ure warning light
fl
ashes. Have your vehicle checked by an Authorized Mazda Dealer as soon as possible.
WARNING
If the tire pressure monitoring system warning light illuminates or fl ashes, or the tire
pressure warning beep sound is heard, decrease vehicle speed immediately and avoid
sudden maneuvering and braking:
If the tire pressure monitoring system warning light illuminates or fl ashes, or the tire
pressure warning beep sound is heard, it is dangerous to drive the vehicle at high
speeds, or perform sudden maneuvering or braking. Vehicle drivability could worsen
and result in an accident.
To determine if you have a slow leak or a fl at, pull over to a safe position where you can
check the visual condition of the tire and determine if you have enough air to proceed
to a place where air may be added and the system monitored again by an Authorized
Mazda Dealer or a tire repair station.

Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Have the problem taken care of as soon as possible before it develops into a more
serious situation that could lead to tire failure and a dangerous accident.
CX-5_8FN1-EA-16L_Edition1.indb 282016/12/12 10:07:25

7–29
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


(Amber)
KEY Warning Indication
* “Keyless System Malfunction” is displayed
This message is displayed if the advanced keyless entry & push button st\
art system has a
problem.
Contact an Authorized Mazda Dealer.
CAUTION
If the message is indicated, or the push button start indicator light (amber) fl ashes, the
engine may not start. If the engine cannot be started, try starting it using the emergency
operation for starting the engine, and have the vehicle inspected at an Authorized
Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-10 .
“Ignition is On” is displayed
This message is displayed when the driver's door is opened without switc\
hing the ignition
off.
“Key Not Detected” is displayed
This message is displayed when any of the following operations is perfor\
med with the key
out of the operational range or placed in areas inside the cabin where i\
t is dif fi cult for the
key to be detected.
 The push button start is pressed with the ignition switched off
 The ignition is switched on
 All doors are closed without switching the ignition off

(Red)
(Illuminate)
KEY Warning Light
* If any malfunction occurs in the keyless entry system, it illuminates co\
ntinuously.
CAUTION
If the key warning indicator light illuminates or the push button start indicator light
(amber) fl ashes, the engine may not start. If the engine cannot be started, try starting it
using the emergency operation for starting the engine, and have the vehicle inspected
at an Authorized Mazda Dealer as soon as possible.
Refer to Emergency Operation for Starting the Engine on page 4-10 .


(Amber)
High Beam Control System (HBC)
Warning Indication/ Warning Light
* The light remains turned on if there is a problem with the system. Have \
your vehicle
inspected at an Authorized Mazda Dealer.
NOTE
If the windshield area in front of the Forward Sensing Camera (FSC) is fogged or
obstructed, the light turns on temporarily. If the light remains turned on, there may be a
problem with the system.


Blind Spot
Monitoring (BSM)
Warning Indication
* This light illuminates if there is a malfunction in the Blind Spot Monit\
oring (BSM). Have
your vehicle inspected by an Authorized Mazda Dealer.
NOTE
If the vehicle is driven on a road with less traf
fi c and few vehicles that the radar sensors
can detect, the system may pause. However, it does not indicate a malfunction.
CX-5_8FN1-EA-16L_Edition1.indb 292016/12/12 10:07:26

7–30
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning


Blind Spot
Monitoring (BSM) OFF Indicator Light
* A problem in the system may be indicated under the following conditions.
Have your vehicle inspected at an Authorized Mazda Dealer.
 The light does not turn on when the ignition is switched ON.
 The light remains on even when the Blind Spot Monitoring (BSM) system \
can be operated.
 It turns on while driving the vehicle.
NOTE
If the vehicle is driven on a road with less traf fi c and few vehicles that the radar sensors
can detect, the system may pause (The Blind Spot Monitoring (BSM) OFF\
indicator light in
the instrument cluster illuminates). However, it does not indicate a malfunction.


(Amber)
Mazda Radar
Cruise Control with Stop & Go function (MRCC with Stop & Go function)
Warning Indication
* The message is displayed when the system has a malfunction. Have your ve\
hicle inspected
at an Authorized Mazda Dealer.


(Amber)
Lane-keep Assist System (LAS) & Lane Departure
Warning System
(LDWS) Warning Indication
* The message is displayed when the system has a malfunction. Have your ve\
hicle inspected
at an Authorized Mazda Dealer.
The system does not operate when the warning message is displayed.
CAUTION

Always use tires for all wheels that are of the specifi ed size, and the same manufacture,
brand, and tread pattern. In addition, do not use tires with signifi cantly diff erent wear
patterns on the same vehicle. If such improper tires are used, the system may not operate
normally.
 When an emergency spare tire is used, the system may not operate normally.


LED Headlight Warning Light This light illuminates if there is a malfunction in the LED headlight. H\
ave your vehicle
inspected by an Authorized Mazda Dealer.

CX-5_8FN1-EA-16L_Edition1.indb 302016/12/12 10:07:26

7–31
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Taking Action
Take the appropriate action and verify that the warning light turns off.

Signal Warning Action to be taken


(Turns on)
Tire Pressure Monitoring System Warning Light
* When the warning light illuminates, and
the warning beep sound is heard when tire
pressure is too low in one or more tires.
WARNING
If the tire pressure monitoring system
warning light illuminates or fl
ashes,
or the tire pressure warning beep
sound is heard, decrease vehicle
speed immediately and avoid sudden
maneuvering and braking:
If the tire pressure monitoring system
warning light illuminates or fl ashes,
or the tire pressure warning beep
sound is heard, it is dangerous to
drive the vehicle at high speeds, or
perform sudden maneuvering or
braking. Vehicle drivability could
worsen and result in an accident.
To determine if you have a slow leak
or a fl at, pull over to a safe position
where you can check the visual
condition of the tire and determine
if you have enough air to proceed to
a place where air may be added and
the system monitored again by an
Authorized Mazda Dealer or a tire
repair station.

Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is
dangerous, even if you know why
it is illuminated. Have the problem
taken care of as soon as possible
before it develops into a more serious
situation that could lead to tire
failure and a dangerous accident. Inspect the tires and adjust to the speci
fi ed
infl ation pressure (page 6-39 ).
CAUTION
When replacing/repairing the tires or wheels
or both, have the work done by an Authorized
Mazda Dealer, or the tire pressure sensors may
be damaged.
NOTE

Perform tire pressure adjustment when the tires are
cold. Tire pressure will vary according to the tire
temperature, therefore let the vehicle stand for
1 hour or only drive it 1.6 km (1 mile) or less
before adjusting the tire pressures. When pressure
is adjusted on hot tires to the cold in fl ation
pressure, the TPMS warning light/beep may turn
on after the tires cool and pressure drops below
specifi cation.
Also, an illuminated TPMS warning light, resulting
from the tire air pressure dropping due to cold
ambient temperature, may turn off if the ambient
temperature rises. In this case, it will also be
necessary to adjust the tire air pressures. If the
TPMS warning light illuminates due to a drop in
tire air pressure, make sure to check and adjust the
tire air pressures.
 After adjusting the tire air pressures, it may require
some time for the TPMS warning light to turn off. If
the TPMS warning light remains illuminated, drive
the vehicle at a speed of at least 25 km/h (16 mph)
for 10 minutes, and then verify that it turns off.
 Tires lose air naturally over time and the TPMS
cannot tell if the tires are getting too soft over time
or you have a fl at. However, when you fi nd one low
tire in a set of four-that is an indication of trouble;
you should have someone drive the vehicle slowly
forward so you can inspect any low tire for cuts
and any metal objects sticking through tread or
sidewall. Put a few drops of water in the valve stem
to see if it bubbles indicating a bad valve. Leaks
need to be addressed by more than simply re fi lling
the trouble tire as leaks are dangerous — take it
to an Authorized Mazda Dealer which has all the
equipment to fi x tires, TPMS systems and order the
best replacement tire for your vehicle.
If the warning light illuminates again even after the tire pressures are adjusted, there may be a tire
puncture.
CX-5_8FN1-EA-16L_Edition1.indb 312016/12/12 10:07:27

7–32
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning Action to be taken


(Amber)
Smart Brake Support/ Smart City Brake
Support (SBS/SCBS) Warning Indication/ Warning Light
* The light turns on if the windshield or
the radar sensor are dirty, or there is a
malfunction in the system. Verify the reason why the warning light is
illuminated on the center display.
If the reason why the warning light is
illuminated is due to a dirty windshield,
clean the windshield.
If the warning light is illuminated because
of a dirty radar sensor, clean the front
emblem.
For any other reasons, have the vehicle
inspected at an Authorized Mazda Dealer.


Low Fuel Warning
Indication/Warning Light
The light turns on when the remaining fuel
is about 9.0 L (2.3 US gal, 1.9 Imp gal).
NOTE
The light illumination timing may
vary because fuel inside the fuel tank
moves around according to the driving
conditions and the vehicle posture.
Add fuel.


Check Fuel Cap Warning
Indication/Warning Light If the check fuel cap warning light
illuminates while driving, the fuel-
fi ller
cap may not be installed properly. Stop the engine and reinstall the fuel-
fi ller
cap.
Refer to Fuel-Filler Cap on page 3-34
CX-5_8FN1-EA-16L_Edition1.indb 322016/12/12 10:07:27

7–33
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
Signal Warning Action to be taken


Seat Belt Warning Light
Except Mexico
The seat belt warning light turns on if the driver
or front passenger's seat is occupied and the seat
belt is not fastened with the ignition switched
ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's seat
is occupied) and the vehicle is driven at a speed
faster than about 20 km/h (12 mph), the warning
light fl ashes. After a short time, the warning
light stops fl ashing, but remains illuminated.
NOTE

The warning light fl ashes for about 6 seconds
if the driver's seat belt is not fastened when the
ignition is switched ON.
 To allow the front passenger occupant
classifi cation sensor to function properly, do
not place and sit on an additional seat cushion
on the front passenger's seat. The sensor may
not function properly because the additional
seat cushion could cause sensor interference.
 If a small child is seated on the front
passenger's seat, the warning light may not
operate.
Mexico
The seat belt warning light turns on if the driver
or front passenger's seat is occupied and the seat
belt is not fastened with the ignition switched
ON.
If the driver or front passenger's seat belt is
unfastened (only when the front passenger's seat
is occupied) and the vehicle is driven at a speed
faster than about 20 km/h (12 mph), the warning
light fl ashes. After a short time, the warning
light stops fl ashing, but remains illuminated. If
a seat belt remains unfastened, the warning light
fl ashes again for a given period of time.
NOTE

Placing heavy items on the front passenger's
seat may cause the front passenger's seat belt
warning function to operate depending on the
weight of the item.
 To allow the front passenger seat weight sensor
to function properly, do not place and sit on an
additional seat cushion on the front passenger's
seat. The sensor may not function properly
because the additional seat cushion could
cause sensor interference.
 If a small child is seated on the front
passenger's seat, the warning light may not
operate.
Fasten the seat belts.
CX-5_8FN1-EA-16L_Edition1.indb 332016/12/12 10:07:27

7–34
If Trouble Arises
Warning/Indicator Lights and Warning Sounds
*Some models.
Signal Warning Action to be taken


Low Washer Fluid Level Warning Indication/Warning Light
* This warning light indicates that little
washer fl
uid remains. Add washer
fl uid (page 6-27 ).

Door-Ajar/Liftgate-Ajar Warning Indication/ Warning Light The light turns on if any door/liftgate is
not closed securely.
Close the door/liftgate securely.


KEY Warning Indication/Warning Light
*
Take the appropriate action and verify that the warning light turns off.

Signal Cause Action to be taken


(White)
KEY Warning Indication The key battery is dead.
Replace the key battery (page 6-36 ).


(Red)
(Flashing)
KEY Warning Light The key battery is dead.
Replace the key battery (page 6-36 ).
The key is not within the operation range. Bring the key into the operation range
(page 3-8 ).
The key is placed in areas inside the
cabin where it is dif
fi cult for the key to be
detected.
A key from another manufacturer similar to
the key is in the operation range. Take the key from another manufacturer
similar to the key out of the operation
range.
Without the ignition switched off, the key is
taken out of the cabin, and then all the doors
are closed. Bring the key back into the cabin.

CX-5_8FN1-EA-16L_Edition1.indb 342016/12/12 10:07:27
