Use of various features for ride comfort, including air-conditioning and audio system.

Climate Control System...................... 5-4
Operating Tips ................................ 5-4
Vent Operation ............................... 5-5
Manual Type .................................. 5-7
Fully Automatic Type ................... 5-11

Before Using the Audio System ........ 5-15 Audio Control Switch .................. 5-15
AUX/USB .................................... 5-16
Antenna ........................................ 5-18

Audio Set
[Type A (non-touchscreen)] .............. 5-20 Power/Volume/Sound Controls .... 5-20
Clock ............................................ 5-22
Operating the Radio ..................... 5-24
How to use AUX mode ................ 5-26
How to use USB mode ................. 5-28
How to use iPod mode ................. 5-32
Error Indications .......................... 5-34
Bluetooth
® .................................... 5-35
Bluetooth® Preparation ................. 5-38
Available Language ...................... 5-48
Security Setting ............................ 5-49
Bluetooth
® Audio ......................... 5-50
Bluetooth® Hands-Free ................ 5-53
Voice Recognition ........................ 5-60
Voice Recognition Learning Function
(Speaker Enrollment) ................... 5-62
Troubleshooting ........................... 5-65
Audio Set
[Type B (touchscreen)] ...................... 5-69
Basic Operation Method .............. 5-69
Home screen ................................. 5-73
Volume/Display/
Sound Controls ............................. 5-74
Operating the Radio ..................... 5-76
Operating the Satellite Radio
* ...... 5-80
How to use AUX mode ................ 5-84
How to use USB mode ................. 5-85
Bluetooth
® .................................... 5-90
Bluetooth® Preparation ................. 5-94
Available Language ...................... 5-97
Bluetooth
® Audio ......................... 5-97
How to Use Pandora® ................. 5-102
How to Use Aha™ ....................... 5-105
How to Use Stitcher™ Radio ...... 5-109
Bluetooth® Hands-Free .............. 5-111
Voice Recognition ...................... 5-121
Settings ....................................... 5-124
Applications ............................... 5-126
Troubleshooting ......................... 5-127

Appendix .......................................... 5-132 Things You Need to Know ......... 5-132

CX-5_8FN1-EA-16L_Edition1.indb 12016/12/12 10:06:22

5–2*Some models.
Interior Equipment ......................... 5-138 Sunvisors .................................... 5-138
Interior Lights ............................ 5-139
Accessory Sockets ..................... 5-141
USB Power Outlet
* .................... 5-142
Cup Holder ................................. 5-143
Bottle Holder .............................. 5-144
Storage Compartments ............... 5-145
CX-5_8FN1-EA-16L_Edition1.indb 22016/12/12 10:06:22

5–3
MEMO
CX-5_8FN1-EA-16L_Edition1.indb 32016/12/12 10:06:22

5–4
Interior Features
Climate Control System
Operating Tips
  Operate the climate control system with
the engine running.
   To prevent the battery from being
discharged, do not leave the fan control
dial/switch on for a long period of time
with the ignition switched ON when the
engine is not running.
   Clear all obstructions such as leaves,
snow and ice from the hood and the air
inlet in the cowl grille to improve the
system effi ciency.
  Use the climate control system to defog
the windows and dehumidify the air.
   The recirculate mode should be used
when driving through tunnels or while in
a traffi c jam, or when you would like to
shut off outside air for quick cooling of
the interior.
   Use the outside air position for
ventilation or windshield defrosting.
   If the vehicle has been parked in direct
sunlight during hot weather, open the
windows to let warm air escape, then
run the climate control system.

   Run the air conditioner about 10 minutes
at least once a month to keep internal
parts lubricated.
   Have the air conditioner checked before
the weather gets hot. Lack of refrigerant
may make the air conditioner less
effi cient.
 The refrigerant speci fi cations are
indicated on a label attached to the
inside of the engine compartment. Check
the label before re fi lling the refrigerant.
If the wrong type of refrigerant is used,
it could result in a serious malfunction
of the air conditioner.
 For details, consult an Authorized Mazda Dealer.

Type A

Label

Type B

Label

CX-5_8FN1-EA-16L_Edition1.indb 42016/12/12 10:06:22

5–5
Interior Features
Climate Control System
*Some models.
Vent Operation
Adjusting the Vents
Directing airfl ow
To adjust the direction of air fl ow, move the
adjustment knob.
NOTE
   When using the air conditioner under
humid ambient temperature conditions,
the system may blow fog from the vents.
This is not a sign of trouble but a result
of humid air being suddenly cooled.
  The air vents can be fully opened and
closed by operating the dial.

Side Vents

Knob
DialOpen
Close
Center Vents

Knob

Rear Vents
*

KnobDial Close
Open

CX-5_8FN1-EA-16L_Edition1.indb 52016/12/12 10:06:22

5–6
Interior Features
Climate Control System
Selecting the Airfl ow Mode

Dashboard Vents
Dashboard and Floor Vents
Floor Vents Defroster and Floor Vents
Defroster Vents
* With rear vents
CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:06:23

5–7
Interior Features
Climate Control System
Manual Type
A/C switchAir intake selector switch Rear window defogger switchMode selector dial
Fan control dial
Temperature control dial
Control Switches
Temperature control dial
This dial controls temperature. Turn it
clockwise for hot and counterclockwise
for cold.
NOTE
When the mode is set to , or a
position in between them with the fan
control dial in a position other than 0 and
the temperature control dial in the
maximum cold position, the air intake
selector switches to the recirculated air
position and the A/C turns on
automatically.
If A/C is not desired, press the A/C switch
to turn it off.

Fan control dial
This dial allows variable fan speeds.
The fan has seven speeds.
Mode selector dial
Turn the mode selector dial to select
airfl ow mode (page 5-6 ).
NOTE
  The mode selector dial can be set at the
intermediate positions (
) between
each mode. Set the dial to an
intermediate position if you want to split
the airfl ow between the two modes.
  For example, when the mode selector
dial is at the
position between the
and
positions, airfl ow from the fl oor
vent is less than that of the
position.
A/C switch
Press the A/C switch to turn the air
conditioner on. The indicator light on the
switch will illuminate when the fan control
dial is in any position except OFF.

Press the switch once again to turn the air
conditioner off.
NOTE
The air conditioner may not function when
the outside temperature approaches 0 °C
(32 °F).

CX-5_8FN1-EA-16L_Edition1.indb 72016/12/12 10:06:23

5–8
Interior Features
Climate Control System
Air intake selector
This switch controls the source of air
entering the vehicle.

Outside or recirculated air positions can be
selected. Press the switch to select outside/
recirculated air positions.
Recirculated air position (indicator light
illuminated)
Outside air is shut off. Use this position
when going through tunnels, driving in
congested traffi c (high engine exhaust
areas) or when quick cooling is desired.
Outside air position (indicator light
turned off)
Outside air is allowed to enter the
cabin. Use this mode for ventilation or
windshield defrosting.
WARNING
Do not use the position in cold or
rainy weather: Using the
position in cold or rainy
weather is dangerous as it will cause
the windows to fog up. Your vision will
be hampered, which could lead to a
serious accident.

Rear window defogger switch
Press the rear window defogger switch to
defrost the rear window.
Refer to Rear Window Defogger on page
4-62 .
Heating
1. Set the mode selector dial to the
position.
2. Set the air intake selector to the outside air position (indicator light turns off).
3. Set the temperature control dial to the hot position.
4. Set the fan control dial to the desired speed.
5. If dehumidifi ed heating is desired, turn
on the air conditioner.

NOTE
   If the windshield fogs up easily, set the
mode selector dial to the
position.  If cooler air is desired at face level, set
the mode selector dial at the
position
and adjust the temperature control dial
to maintain maximum comfort.
   The air to the fl oor is warmer than air
to the face (except when the temperature
control dial is set at the extreme hot or
cold position).

Cooling
1. Set the mode selector dial to the
position.
2. Set the temperature control dial to the cold position.
3. Set the fan control dial to the desired speed.
4. Turn on the air conditioner by pressing the A/C switch.
5. After cooling begins, adjust the fan control dial and temperature control
dial as needed to maintain maximum
comfort.

CX-5_8FN1-EA-16L_Edition1.indb 82016/12/12 10:06:23
