2017 MAZDA MODEL CX-5 Owners Manual (in English)

5–97
Interior Features
Audio Set [Type B (touchscreen)]
Available Language
The Bluetooth ® Hands-Free System
applies to the following languages:
   English  Spanish  French
Refer to Settings on page 5-124 .
Bluetooth ® Audio
Applicable Bluetooth ® specifi cation
(Recommended)
Ver. 1.1/1.2/2.0
EDR/2.1 EDR/3.0
(conformity)
Response profi le
  A2DP (Advanced Audio Distribution
Profi le) Ver. 1.0/1.2
  AVRCP (Audio/Video Remote Control
Profi le) Ver. 1.0/1.3/1.4


A2DP is a profi le which transmits only
audio to the Bluetooth
® unit. If your
Bluetooth ® audio device corresponds
only to A2DP, but not AVRCP, you
cannot operate it using the control panel
of the vehicle's audio system. In this
case, only the operations on the mobile
device are available the same as when a
portable audio device for a non-compliant
Bluetooth
® device is connected to the
AUX terminal.

CX-5_8FN1-EA-16L_Edition1.indb 972016/12/12 10:06:48

5–98
Interior Features
Audio Set [Type B (touchscreen)]
Function A2DP AVRCP
Ve r. 1.0 Ve r.
1.3 Ve r.
1.4
Playback X X X X
Pause X X X X
File (Track)
up/down — X X X
Reverse — — X X
Fast-forward — — X X
Text display — — X X
Repeat — —
Depends on
device Depends
on
device
Shuffl e — — Depends
on
device Depends
on
device
Scan — — Depends
on
device Depends
on
device
Folder up/
down — — — Depends
on
device
X: Available
—: Not available

NOTE
   The battery consumption of Bluetooth ®
audio devices increases while
Bluetooth
® is connected.   If a general mobile phone device is
USB connected during music playback
over the Bluetooth
® connection, the
Bluetooth ® connection is disconnected.
For this reason, you cannot have music
playback over a Bluetooth
® connection
and music playback using a USB
connection at the same time.
   The system may not operate normally
depending on the Bluetooth ® audio
device.

CX-5_8FN1-EA-16L_Edition1.indb 982016/12/12 10:06:48

5–99
Interior Features
Audio Set [Type B (touchscreen)]
Switching to Bluetooth ® audio mode
To listen to music or voice audio recorded to a Bluetooth ® audio device, switch to the
Bluetooth ® audio mode to operate the audio device using the audio system control p\
anel.
Any Bluetooth ® audio device must be paired to the vehicle's Bluetooth ® unit before it can be
used.
Refer to Bluetooth
® Preparation on page 5-94 .
1. Turn on the Bluetooth ® audio device's power.
2. Switch the ignition to ACC or ON.
3. Select the
icon on the home screen to display the Entertainment screen.
4. When
is selected, switches to the Bluetooth ® audio mode to begin playback.
NOTE
   If Bluetooth ® audio is used after using Pandora ® , Aha™ or Stitcher™ radio, the
application on the mobile device has to be closed fi rst.
   If the Bluetooth ® audio device does not begin playback, select the icon.  If the mode is switched from Bluetooth ® audio mode to another mode (radio mode), audio
playback from the Bluetooth ® audio device stops.
CX-5_8FN1-EA-16L_Edition1.indb 992016/12/12 10:06:48

5–10 0
Interior Features
Audio Set [Type B (touchscreen)]
Playback
To listen to a Bluetooth ® audio device over the vehicle's speaker system, switch the mode to
Bluetooth ® audio mode. (Refer to “Switching to Bluetooth ® audio mode”)
After switching to the Bluetooth ® audio mode, the following icons are displayed in the
lower part of the display. Icons which can be used differ depending on the version of the
Bluetooth
® audio device which you are currently using.

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

(AVRCP Ver. 1.4 only)
Displays the top level folder/
fi le list.
Select the folder which you want to select.
The fi les in the selected folder are displayed.
Select the fi le you want to play.

(AVRCP Ver. 1.3 or higher)
Replays the song currently being played repeatedly.
When selected again, the songs in the folder are played repeatedly.
Select it again to cancel.
Icons change when the song is repeated or the folder is repeated.

(AVRCP Ver. 1.3 or higher)
Plays songs in the folder in random order.
When selected again, the songs on the device are played in random order.
Select it again to cancel.
Icons change during folder shuf
fl e or device shuf fl e.

Scans the titles in a folder and plays the beginning of each song to aid\
in
fi nding a desired
song.
When selected again, the beginning of each song on the device is played.\
When selected again, the operation is canceled and the song currently be\
ing played
continues.

Returns to the beginning of the previous song.
Long-press to fast reverse. It stops when you remove your hand from the \
icon or the
commander knob.

Plays the Bluetooth
® audio. When selected again, playback is temporarily stopped.

Advances to the beginning of the next song.
Long-press to fast forward. It stops when you remove your hand from the \
icon or the
commander knob.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-74 .

CX-5_8FN1-EA-16L_Edition1.indb 1002016/12/12 10:06:48

5–101
Interior Features
Audio Set [Type B (touchscreen)]
Bluetooth ® Audio Device
Information Display
If a Bluetooth ® audio device is connected,
the following information is displayed in
the center display.

AVRCP
Ver. lower than 1.3 AVRCP
Ver. 1.3 AVRCP
Ver. 1.4 or higher
Device name X X X
Remaining
battery
charge of
device X X X
Song name — X X
Artist name — X X
Album name — X X
Playback
time — X X
Genre name — X X
Album art
image — — —
X: Available
—: Not available

NOTE
Some information may not display
depending on the device, and if the
information cannot be displayed,
“Unknown - - -” is indicated.

CX-5_8FN1-EA-16L_Edition1.indb 1012016/12/12 10:06:49

5–102
Interior Features
Audio Set [Type B (touchscreen)]
How to Use Pandora ®
What is Pandora ® ?
Pandora ®*1 is free personalized Internet radio. Simply enter a favorite artist, tr\
ack, genre,
and Pandora ® will create a personalized station that plays their music and more like\
it.
Rate songs by giving thumbs-up and thumbs-down feedback to further re fi ne your station,
discover new music and help Pandora
® play only music you like.
*1 Pandora ® , the Pandora ® logo, and the Pandora ® trade dress are trademarks or registered
trademarks of Pandora Media, Inc., used with permission.

NOTE
To operate Pandora ® from your Bluetooth ® device, perform the following in advance:    Create Pandora ® account on the Web.  Create Pandora ® station using Pandora ® application.  Install Pandora ® application on your device.
CX-5_8FN1-EA-16L_Edition1.indb 1022016/12/12 10:06:49

5–103
Interior Features
Audio Set [Type B (touchscreen)]
Playback
Select the icon on the home screen to display the Entertainment screen. When is
selected, the following icons are indicated in the bottom part of the ce\
nter display.

Icon Function

Displays the Entertainment menu. Use to switch to a different audio source.

Displays the station list.
Use to switch to other stations.

Thumbs-Down

Press the icon to tell Pandora ® not to play this track.

Thumbs-Up

Press the icon to tell Pandora ® “you like this track” and it helps to bring in more tracks
like it to your station.

Bookmarking
Bookmarks the song or artist currently being played.

Plays the track. When selected again, playback is temporarily stopped.

Goes to the next song.

Displays sound settings to adjust audio quality level.
Refer to Volume/Display/Sound Controls on page 5-74 .

NOTE
 
 The skip function may not be available depending on the device.  The number of skips is limited by Pandora ® .
  If the icon is selected when the skip song function is running, the next song \
is skipped.
CX-5_8FN1-EA-16L_Edition1.indb 1032016/12/12 10:06:49

5–104
Interior Features
Audio Set [Type B (touchscreen)]
Selection from station list
Selection can be made from a programmed
radio station list.

1. Select the icon.
2. Select the desired radio station.

NOTE
When is selected, songs randomly
selected from the radio station list are
played.

Selecting the sort method
The displayed order of the station list can
be changed.

1. Select the icon.
2. Select
.
3. Select
to display in the order
starting from the newly created station.
4. Select
to display in alphabetical
order.

NOTE
The displayed order of cannot be
changed.

Bookmarking
You can bookmark song or artist to check
out later on the Web.

1. Select the icon.
2. Select
to bookmark the
song.
3. Select
to bookmark the
artist.
