When Driving
i-ACTIVSENSE
*Some models.
Traffi c Sign Recognition System (TSR) *
The Traf fi c Sign Recognition System (TSR) helps prevent the driver from overlook\
ing
traffi c signs, and provides support for safer driving by displaying traf fi c signs on the active
driving display which are recognized by the Forward Sensing Camera (FSC\
) or recorded in
the navigation system while the vehicle is driven.
The Traffi c Sign Recognition System (TSR) displays the speed limit, do not enter, and traf fi c
stop signs.
If the vehicle speed exceeds the speed limit sign indicated in the activ\
e driving display while
the vehicle is driven, the system noti fi es the driver using the indication in the active driving
display and a warning sound.
NOTE
   The Traffi c Sign Recognition System (TSR) is not supported in some countries or\
regions.
For information concerning the supported countries or regions, consult an Authorized
Mazda Dealer.
   The Traffi c Sign Recognition System (TSR) operates only if the navigation syste\
m SD card
(Mazda genuine) is inserted in the SD card slot. Consult an Authorized Mazda Dealer for
details.

Speed limit signs and do not enter signs

4040
Sign recognized
Sign displayed
Active driving display indication Active driving display indication

CX-5_8FN1-EA-16L_Edition1.indb 1052016/12/12 10:06:06

4–106
When Driving
i-ACTIVSENSE
Stop sign

40
Sign recognized and
displayed at same time
Active driving display indication

WARNING
Always check the traffi c signs visually while driving.
The Traffi c Sign Recognition System (TSR) helps prevent the driver from overlooking traffi c
signs and provides support for safer driving. Depending on the weather conditions or
problems with traffi c signs, a traffi c sign may not be recognized or a traffi c sign diff erent
from the actual traffi c sign may be displayed. Always make it your responsibility as a
driver to check the actual traffi c signs. Otherwise, it could result in an accident.

CX-5_8FN1-EA-16L_Edition1.indb 1062016/12/12 10:06:06

4–107
When Driving
i-ACTIVSENSE
NOTE
  The Traffi c Sign Recognition System (TSR) does not operate if there is a malfunction in
the Forward Sensing Camera (FSC).
   Under the following conditions, the Traf fi c Sign Recognition System (TSR) may not
operate normally.
   An object placed on the dashboard is re fl ected in the windshield and picked up by the
camera.
   Heavy luggage is loaded in the luggage compartment or on the rear seat and the
vehicle is tilted.
  The tire pressures are not adjusted to the speci fi ed pressure.   Tires other than standard tires are equipped.  The vehicle is driven on the ramp and surrounding area to or from a rest area or a
tollgate on a highway.
  When surrounding brightness suddenly changes such as when entering or exiting a
tunnel.
  The illumination of the headlights is weakened because of dirt or the op\
tical axis is
deviated.
  The windshield is dirty or foggy.  The windshield and camera are fogged (water droplets).  Strong light is directed at the front of the vehicle (such as backlight or high-beam
headlights of on-coming vehicles).
  The vehicle is making a sharp turn.  Strong light re fl ects off the road.   A traffi c sign is in a position which makes it dif fi cult to re fl ect the light from the
vehicle's headlights, such as when the vehicle is driven at night or in \
a tunnel.
   The vehicle is driven under weather conditions such as rain, fog, or sno\
w.  The stored map data for the navigation system is not current.  A traffi c sign is obscured by mud or snow.  A traffi c sign is concealed by trees or a vehicle.  A traffi c sign is partially shaded.  A traffi c sign is bent or warped.  A traffi c sign is too low or too high.  A traffi c sign is too bright or too dark (including electronic traf fi c signs).   A traffi c sign is too big or too small.  There is an object similar to the traf fi c sign being read (such as another traf fi c sign or
other signs resembling it).
   The Traffi c Sign Recognition System (TSR) does not operate if the active drivin\
g display
is set to non-display.
   The Traffi c Sign Recognition System (TSR) can be set to inoperable. Refer to Personalization Features on page 9-11 .
CX-5_8FN1-EA-16L_Edition1.indb 1072016/12/12 10:06:06

4–10 8
When Driving
i-ACTIVSENSE
Traffi c Sign Display Indication
The following traf fi c signs are displayed on the active driving display.
Speed limit signs


Do not enter signs


Stop signs


CX-5_8FN1-EA-16L_Edition1.indb 1082016/12/12 10:06:06

4–109
When Driving
i-ACTIVSENSE
NOTE
Speed limit signs   When the vehicle speed is about 1 km/h (0.6 mph) or faster, the speed limit sign is
displayed when any one of the following conditions are met.
  The Forward Sensing Camera (FSC) recognizes a speed limit sign as a sign targeted
for your vehicle and the vehicle passes it.
  The speed limit sign stored in the navigation system is read (if the Forward Sensing
Camera (FSC) does not recognize a speed limit sign).
  In the following cases, display of the speed limit sign stops.   The Forward Sensing Camera (FSC) recognizes the speed limit sign and the vehicle is
driven for a certain distance after passing the sign.
  Each sensor determines that the vehicle has changed direction of travel.  The Forward Sensing Camera (FSC) recognizes a new speed limit sign which differs
from the previous one (displays the new speed limit sign).
  The speed limit sign stored in the navigation system is not read within a certain period
of time (if the Forward Sensing Camera (FSC) does not recognize a speed limit sign,
the speed limit sign stored in the navigation system is displayed).
  The vehicle speed exceeds the displayed speed limit sign by 30 km/h (19\
mph) or more
after a certain period of time has elapsed since the speed limit sign wa\
s displayed.
(Except when there is information for the speed limit sign in the navigation system)


Do not enter signs   A do not enter sign is displayed when all of the following conditions are met.   The vehicle speed is about 60 km/h (37 mph) or slower.  The Forward Sensing Camera (FSC) recognizes a do not enter sign as a sign targeted
for your vehicle and the vehicle passes it.
  When the Forward Sensing Camera (FSC) recognizes the do not enter sign and a certain
period of time has elapsed since the vehicle passed the sign, display of\
the do not enter
sign stops.

Stop sign   A stop sign is displayed when all of the following conditions are met:   The vehicle speed is about 30 km/h (19 mph) or slower.  The Forward Sensing Camera (FSC) recognizes a stop sign as a sign targeted for your
vehicle.
  When a certain period of time has elapsed since the stop sign was displa\
yed, display of
the stop sign stops.

CX-5_8FN1-EA-16L_Edition1.indb 1092016/12/12 10:06:07

4–110
When Driving
i-ACTIVSENSE
Excessive Speed Warning
If the vehicle speed exceeds the speed limit sign displayed in the activ\
e driving display,
the area around the speed limit sign fl ashes three times in amber and the warning sound is
activated three times at the same time. If the vehicle speed continues t\
o exceed the displayed
speed limit sign, the indication stops fl ashing and remains on. Check the surrounding
conditions and adjust the vehicle speed to the legal speed using the app\
ropriate operation
such as depressing the brake pedal.

While 60 mph is displayed
50 mph is displayed
Active driving display indication
Active driving display indication

The excessive speed warning is initially set to inoperable. If you want \
to activate the
excessive speed warning, change the setting in the personalization featu\
res. In addition, the
warning pattern and the warning activation timing differ depending on the setting contents.
Refer to Personalization Features on page 9-11 .
Warning pattern
   Off: The excessive speed warning is not activated.  Visual: The area around the speed limit sign displayed in the display fl ashes three times
in amber, and if the vehicle speed continues to exceed the displayed speed limit\
sign, the
indication stops fl ashing and remains on.
   Audio & Visual: The area around the speed limit sign displayed in the display fl ashes
three times in amber and the warning sound is activated three times at t\
he same time. If
the vehicle speed continues to exceed the displayed speed limit sign, th\
e indication stops
fl ashing and remains on.

CX-5_8FN1-EA-16L_Edition1.indb 1102016/12/12 10:06:07

4–111
When Driving
i-ACTIVSENSE
Warning activation timing   0: If the vehicle speed exceeds the speed limit sign displayed in the displ\
ay, the
excessive speed warning is activated.
  5: If the vehicle speed exceeds the speed limit sign displayed in the displ\
ay by 5 km/h
(3 mph), the excessive speed warning is activated.
  10: If the vehicle speed exceeds the speed limit sign displayed in the displ\
ay by
10 km/h (6.2 mph), the excessive speed warning is activated.

NOTE
  In the following cases, the excessive speed warning stops operating.   The vehicle speed is less than the speed of the displayed speed limit si\
gn. (If the
activation timing for the excessive speed warning is changed in the pers\
onalization
features, the excessive speed warning stops operating when the vehicle speed i\
s less
than the changed vehicle speed.
  A speed limit sign indication has been updated and the vehicle speed is l\
ower than the
updated indication.
  Display of the speed limit sign stops.   The warning indication is displayed at the same time the excessive speed\
warning sound
is activated if the vehicle speed exceeds the speed indicated on the spe\
ed limit sign.
 Refer to Warning Sound is Activated on page 7-39 .  If the Forward Sensing Camera (FSC) incorrectly recognizes the actual speed limit sign
at a lower speed, the excessive speed alarm is activated even if the veh\
icle is driven at the
legal speed.

CX-5_8FN1-EA-16L_Edition1.indb 1112016/12/12 10:06:07

4–112
When Driving
i-ACTIVSENSE
*Some models.
Distance Recognition Support System (DRSS) *
The Distance Recognition Support System (DRSS) measures the distance between your
vehicle and a vehicle ahead using a radar sensor (front) while the veh\
icle speed is about
30 km/h (19 mph) or faster, and if your vehicle approaches a vehicle ahead more closely
than what is appropriate for maintaining distance between the vehicles a\
ccording to the
vehicle speed, a notifi cation in the active driving display is indicated to advise you to keep \
a
safe distance from the vehicle ahead.
WARNING
Do not rely completely on the Distance Recognition Support System (DRSS) and always
drive carefully: The Distance Recognition Support System (DRSS) provides advice for safer driving and
notifi es the driver of a recommended, safer distance to maintain with a vehicle ahead.
The ability to detect a vehicle ahead is limited depending on the type of vehicle ahead,
the weather conditions, and the traffi c conditions. Therefore, if the accelerator and brake
pedals are not operated correctly it could lead to an accident. Always verify the safety of
the surrounding area and depress the brake pedal or accelerator pedal while keeping a
safer distance from vehicles ahead or on-coming vehicles.

NOTE
  The Distance Recognition Support System (DRSS) operates when all of th\
e following
conditions are met:
  The ignition is switched ON.  The Distance Recognition Support System (DRSS) is on.  The selector lever is in a position other than reverse (R).  The vehicle speed is 30 km/h or faster (19 mph or faster).   The objects which activate the system are 4-wheeled vehicles.  The Distance Recognition Support System (DRSS) may also operate in the\
presence of
motorcycles and bicycles.
  The Distance Recognition Support System (DRSS) system may not operate \
normally
under the following conditions:
  The Dynamic Stability Control (DSC) has a malfunction.  The vehicle ahead is traveling at an extremely slow speed.   The system does not operate with the following objects:   Vehicles approaching in the opposite direction.  Stationary objects (stopped vehicles, obstructions)
