2017 MAZDA MODEL CX-5 Owners Manual (in English)

5–41
Interior Features
Audio Set [Type A (non-touchscreen)]
(Music player)
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Select music player”
5. Prompt: “Please say the name of the device you would like to select.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C). Which
device please?”
6. Say: [Beep] “XXXXX... (Ex. Device B)”
7. Prompt: “XXXXX... (Ex. Device B). Is this correct?”
8. Say: [Beep] “Yes” or “No”
9. If “Yes”, go to Step 10. If “No”, the procedure returns to Step 5.
10. Prompt: “XXXXX... (Ex. Device B) selected.”

NOTE
  When the selected device connection is
completed, the
or symbol is
displayed.
   Some Bluetooth ® audio devices need a
certain amount of time before the
or
symbol is displayed.
   Device (Music player) selection can
also be done by operating the panel
button.

Deleting a device (Bluetooth ®
Hands-Free)
Registered devices (Mobile phone) can be
deleted individually or collectively.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button
with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Pairing options”
5. Prompt: “Select one of the following: Pair, Edit, Delete, List, or Set Pairing
Code.”
NOTE
A registered device (Mobile phone) can be
deleted using the registration list.

6. Say: [Beep] “Delete”
7. Prompt: “Please say the name of the device you would like to delete.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device
B), XXXXX... (Ex. device C), or all.
Which device please?”
8. Say: [Beep] “X” (Say the number of the device to be deleted.)
NOTE
Say “All” to delete all devices (Mobile
phone).

9. Prompt: “Deleting XXXXX... (Ex. device B...) (Registered device tag). Is
this correct?”
10. Say: [Beep] “Yes”
CX-5_8FN1-EA-16L_Edition1.indb 412016/12/12 10:06:32

5–42
Interior Features
Audio Set [Type A (non-touchscreen)]
11. Prompt: “Deleted”
Registered device editing (Bluetooth ® Hands-Free)
1. Press the pick-up button or talk button
with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Pairing options”
5. Prompt: “Select one of the following: Pair, Edit, Delete, List, or Set Pairing
Code.”
6. Say: [Beep] “Edit”
7. Prompt: “Please say the name of the device you would like to edit. Available
devices are XXXXX... (Ex. device A),
XXXXX... (Ex. device B), XXXXX...
(Ex. device C). Which device please?”
8. Say: [Beep] “X” (Say the number of the device to be edited.)
9. Prompt: “New name please?”
10. Say: [Beep] “XXXXX... (Ex. Device C)” (Speak a “device tag” an arbitrary
name for the device.)
11. Prompt: “XXXXX... (Ex. device C) (Device tag), is this correct?”
12. Say: [Beep] “Yes”
13. Prompt: “New name saved.”

Bluetooth ® Audio Preparation
Bluetooth ® audio device set-up
Bluetooth
® audio pairing, changes,
deletions, and display of paired device
information can be performed.

1. The mode changes as follows each time the menu button (
) is pressed.
Select “ BT SETUP ”.


*
*

* Depending on the mode selected, the indication changes.
CX-5_8FN1-EA-16L_Edition1.indb 422016/12/12 10:06:33

5–43
Interior Features
Audio Set [Type A (non-touchscreen)]
2. Turn the audio control dial and select a desired mode.



Display Mode Function
PAIR
DEVICE Pairing mode Bluetooth ® audio
device pairing
LINK
CHANGE Link change
mode Changing link to
Bluetooth
® audio
device
PAIR
DELETE Pairing
deletion
mode Deleting link to
Bluetooth
® audio
device
DEVICE
INFO Device
information
display mode Displaying vehicle's
Bluetooth
® unit
information

3. Press the audio control dial to
determine the mode.

Bluetooth ® audio device pairing
(Bluetooth ® Audio)
Any Bluetooth ® audio device must be
paired to the vehicle's Bluetooth ® unit
before it can be listened to over the
vehicle's speakers.
A maximum of seven devices including
Bluetooth
® audio devices and hands-
free mobile phones can be paired to one
vehicle.
NOTE
   If a Bluetooth ® device has already been
paired to the vehicle as a hands-free
mobile phone, it does not need to be
paired again when using the device as
a Bluetooth
® audio device. Conversely,
it does not need to be paired again as
a hands-free mobile phone if it has
already been paired as a Bluetooth
®
audio device.
   Device registration can also be done
using voice recognition.

Concerning the operation of a Bluetooth ®
audio device itself, refer to its instruction
manual.
Some Bluetooth
® audio devices have PIN
codes (four digits). Refer to the audio
device's instruction manual because the
pairing procedure differs depending on
whether it has a PIN code or not.
Pairing a Bluetooth
® audio device which
has a four-digit PIN code
1. Using the audio control dial, select the pairing mode “ PAIR DEVICE ”
in the “ BT SETUP ” mode. (Refer to
“Bluetooth
® audio device set-up” for
details.)
2. Press the audio control dial to determine the mode. After “ ENTER
PIN ” is displayed on the audio display
for three seconds, “ PIN 0000 ” is
displayed and the PIN code can be
input.
CX-5_8FN1-EA-16L_Edition1.indb 432016/12/12 10:06:33

5–44
Interior Features
Audio Set [Type A (non-touchscreen)]
3. Input the PIN code of your Bluetooth ®
audio device by pressing channel preset
buttons 1 to 4 while “ PIN 0000 ” is
displayed.
Press channel preset button 1 to input the fi rst digit, 2 for the second, 3 for the
third, and 4 for the forth. For example,
if the PIN code were “4213” press
channel preset button 1 four times
(1, 2, 3, 4), button 2 twice (1, 2), button
3 once (1), and button 4 three times
(1, 2, 3). If the “ PIN 0000 ” display
disappears before fi nishing the PIN
code input, repeat the procedure from
Step 1.
NOTE
Some devices accept only a particular
pairing code (Usually, “0000” or
“1234”).
If pairing cannot be completed, refer to the
owner's manual of your mobile device, and
try those numbers if necessary.

4. Press the audio control dial while the input PIN code is displayed.
“ PAIRING ” fl ashes on the audio
display.
5. Operate the Bluetooth
® audio device
and set it to the pairing mode while
“ PAIRING ” is fl ashing.
6. When the pairing is completed,
and
“ PAIR SUCCESS ” are displayed after
about 10-30 seconds, after which
“ PAIR SUCCESS ” continues to be
displayed for three seconds, and then
the unit returns to the normal display.
NOTE
   Some Bluetooth ® audio devices need a
certain amount of time before the

symbol is displayed.
   If the pairing failed, “ Err ” fl ashes for
three seconds.
   Pairing cannot be performed while
the vehicle is moving. If you attempt
to perform pairing while the vehicle is
moving, “ PAIR DISABLE ” is displayed.
  If seven Bluetooth ® audio devices have
already been paired to the vehicle,
pairing cannot be performed and
“ MEMORY FULL ” is displayed. Delete
one paired device to pair another one.

Pairing a Bluetooth ® audio device which
does not have a four-digit PIN code
1. Using the audio control dial, select the pairing mode “ PAIR DEVICE ”
in the “ BT SETUP ” mode. (Refer to
“Bluetooth
® audio set up” for details.)
2. Press the audio control dial to determine the mode. After “ ENTER
PIN ” is displayed on the audio display
for three seconds, “ PIN 0000 ” is
displayed and the PIN code can be
input.
3. Press the audio control dial while “ PIN 0000 ” is displayed. “ PAIRING ” fl ashes
on the audio display.
4. Operate the Bluetooth
® audio device
and set it to the pairing mode while
“ PAIRING ” is fl ashing.
5. As the Bluetooth
® audio device
requires a PIN code, input “0000”.
6. When the pairing is completed,
and
“ PAIR SUCCESS ” are displayed after
about 10-30 seconds, after which
“ PAIR SUCCESS ” continues to be
displayed for three seconds, and then
the unit returns to the normal display.
CX-5_8FN1-EA-16L_Edition1.indb 442016/12/12 10:06:33

5–45
Interior Features
Audio Set [Type A (non-touchscreen)]
NOTE
  If pairing cannot be completed, try
“1234” instead. Refer to the owner's
manual of your mobile device for the
right PIN code.
  Some Bluetooth ® audio devices need a
certain amount of time before the

symbol is displayed.
   If the pairing failed, “ Err ” fl ashes for
three seconds.
   Pairing cannot be performed while
the vehicle is moving. If you attempt
to perform pairing while the vehicle is
moving, “ PAIR DISABLE ” is displayed.
  If seven Bluetooth ® audio devices have
already been paired to the vehicle,
pairing cannot be performed and
“ MEMORY FULL ” is displayed. Delete
one paired device to pair another one.

Device selection (Bluetooth ® Audio)
If several devices have been paired, the
Bluetooth ® unit links the device last
paired. If you would like to link a different
paired device, it is necessary to change the
link. The order of device priority after the
link has been changed is maintained even
when the ignition is switched off.

1. Using the audio control dial, select the link change mode “ LINK CHANGE ”
in the “ BT SETUP ” mode. (Refer to
“Bluetooth
® audio device set-up” for
details.)
2. Press the audio control dial to determine the mode.
3. The name of the currently linked Bluetooth
® audio device is displayed.
If no Bluetooth ® audio device is
currently linked, the name of the fi rst
device among the paired devices is
displayed. 4. Turn the audio control dial to select the
name of the device you would like to
link.


Device name 1
Device name 2
Device name 3
Device name 4
Device name 5
Device name 6
Device name 7

5. Press the audio control dial to select the device you would like to link. The

symbol disappears, and “ PAIRING ”
fl ashes in the audio display.
NOTE
When “ GO BACK ” is selected and the
audio control dial is pressed, the display
returns to “ LINK CHANGE ”.

6. If the link to the desired device is
successful, the
symbol is displayed
again, together with “ LINK
CHANGED ”. “ LINK CHANGED ” is
displayed for three seconds, then it
returns to the normal display.
CX-5_8FN1-EA-16L_Edition1.indb 452016/12/12 10:06:33

5–46
Interior Features
Audio Set [Type A (non-touchscreen)]
NOTE
  Some Bluetooth ® audio devices need a
certain amount of time before the
symbol is displayed.   If a hands-free type mobile phone has
been the most recently paired device,
the Bluetooth
® unit links this device.
If you would like to use a Bluetooth ®
audio type device which has been
previously paired to the Bluetooth
® unit,
the link must be changed to this device.
   If an error occurs while trying to link
a device, “ Err ” fl ashes in the audio
display for three seconds, and the
display returns to “ LINK CHANGE ”.
If this occurs, check the pairing status
of the Bluetooth
® audio device and the
location of the device in the vehicle
(not in the luggage compartment or a
metal-type box), and then try the link
operation again.
   Device selection can also be done using
voice recognition.

How to confi rm the device currently
linked
Switch to the link-change mode. (Refer to
“Changing the link to a Bluetooth
® audio
device”)
The device name displayed fi rst is the
device which is currently linked.
Deleting a device (Bluetooth ®
Audio)
1. Using the audio control dial, select the
pairing delete mode “ PAIR DELETE ”
in the “ BT SETUP ” mode. (Refer to
“Bluetooth
® audio device set-up” for
details.)
2. Press the audio control dial to determine the mode.
3. The name of the fi rst device among the
paired devices is displayed.
4. Rotate the audio control dial and select the name of the paired device you
would like to delete.


Device name 1
Device name 2
Device name 3
Device name 4
Device name 5
Device name 6
Device name 7

NOTE
Only the names of paired devices can be
displayed. If only one device is paired,
only the name for this device is displayed.

5. If a selection other than “ GO BACK ” is made and the audio control dial is
pressed, “ SURE ? NO ” is displayed.
CX-5_8FN1-EA-16L_Edition1.indb 462016/12/12 10:06:33

5–47
Interior Features
Audio Set [Type A (non-touchscreen)]
6. Rotate the audio control dial clockwise and switch the display to “ SURE ?
YES ”.
NOTE
The display changes as follows depending
on whether the audio control dial is
rotated clockwise or counterclockwise.
-Clockwise: “ SURE ? YES ” displayed
-Counterclockwise: “ SURE ? NO ”
displayed

7. Press the audio control dial to delete the selected device.
NOTE
Select “ GO BACK ” and press the audio
control dial to return to the “ PAIR
DELETE ” display.

8. “ PAIR DELETED ” is displayed for three seconds after the deletion is
completed, and then it returns to the
normal display.
NOTE
If an error occurs while trying to delete
the paired device, “ Err ” fl ashes in the
display for three seconds and the display
returns to “ LINK DELETE ”.

Bluetooth ® audio device
information display
1. Using the audio control dial, select the
pair device information display mode
“ DEVICE INFO ” in the “ BT SETUP ”
mode. (Refer to “Bluetooth
® audio
device set-up” for details.)
2. Press the audio control dial to determine the mode.
3. The name of the Bluetooth
® unit device
is displayed.
4. Rotate the audio control dial to select the information for the Bluetooth
® unit
which you would like to view.


Device nameBT address

NOTE
When “ GO BACK ” is selected and the
audio control dial is pressed, the display
returns to “ DEVICE INFO ”.

CX-5_8FN1-EA-16L_Edition1.indb 472016/12/12 10:06:34

5–48
Interior Features
Audio Set [Type A (non-touchscreen)]
Available Language
The available languages are English,
Spanish, and Canadian French. If the
language setting is changed, all of the
voice guidance and voice input commands
are done in the selected language.
NOTE
  If the language setting is changed,
device registration is maintained.
  Phonebook records are not cleared,
but each language has a separate
phonebook. Therefore, entries created in
one language will need to be re-entered
in the phonebook of the new language.
  Do these steps before you start driving.
These less used functions are too
distracting to undertake while driving
until you are fully familiar with the
system.

(Method 1)
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Language”
5. Prompt: “Select a language: English, French, or Spanish.”
6. Say: [Beep] “French” (Speak the desired language: “English”, “French”
or “Spanish”)
NOTE
Other language settings can also be made
while in the current setting by saying
the name of the language in the native
pronunciation.

7. Prompt: “French (Desired language) selected. Is this correct?”
8. Say: [Beep] “Yes”
9. Prompt: “French (Desired language) selected” (Spoken in the newly selected
language).

(Method 2)
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “French” (Say the desired language: “English”, “French” or
“Spanish”). (Change the desired
language by saying the language
name.)
NOTE
Other language settings can also be made
while in the current setting by saying
the name of the language in the native
pronunciation.

3. Prompt: “Would you like to change the language to French (Desired
language)?”
4. Say: [Beep] “Yes”
5. Prompt: “Please wait. Switching to French phonebook. French selected”
(Spoken in the newly selected
language).

CX-5_8FN1-EA-16L_Edition1.indb 482016/12/12 10:06:34
