2017 MAZDA MODEL CX-5 Owners Manual (in English)

6–5
Maintenance and Care
Scheduled Maintenance
Schedule 1
U.S.A. and Puerto Rico residents - Engine oil fl exible maintenance interval
Use when the maintenance monitor for “Oil Change” is set to “Flexible”. For details,
see maintenance monitor. (page 6-16 )
Maintenance Interval Number of months or kilometers (miles), whichever comes
fi rst.
Months 12 24 36 48 60 72 84 96
×1000 km 12 24 36 48 60 72 84 96
×1000 miles 7.5 15 22.5 30 37.5 45 52.5 60
Spark plugs Replace every 120,000 km (75,000 miles).
Air fi lter Replace when any equivalent timing of replacing engine oil.
(Max interval: 36 months or 60,000 km (37,500 miles))
Drive belts I I
Engine oil & fi lter
*1 Replace when wrench indicator light is ON. (Max interval:
12 months or 12,000 km (7,500 miles))
Engine coolant
*2 Replace at
fi rst 192,000 km (120,000 miles) or 10 years;
after that, every 96,000 km (60,000 miles) or 5 years.
Fuel lines and hoses
*3 I I I I
Hoses and tubes for emission
*3 I I
Brake lines, hoses and connections I I I I
Disc brakes I I I I I I I I
Tire (Rotation) Rotate when any equivalent timing of replacing engine oil.
(Max interval: 12,000 km (7,500 miles))
Steering operation and linkages I I I I
Front and rear suspension, ball joints and wheel
bearing axial play I
I I I
Rear differential oil
*4
Transfer oil *4
Driveshaft dust boots I I I I
Bolts and nuts on chassis and body T T T T
Exhaust system and heat shields I
Emergency fl at tire repair kit (if installed)
*5 Inspect annually.
Cabin air fi lter Replace when any equivalent timing of replacing engine oil.
(Max interval: 24 months or 48,000 km (30,000 miles))
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fi ll up, or replace if necessary.
C: Clean
T: Tighten
CX-5_8FN1-EA-16L_Edition1.indb 52016/12/12 10:07:05

6–6
Maintenance and Care
Scheduled Maintenance
Remarks:
*1 The engine oil and fi lter must be changed at least once a year or within 12,000 km (7,500 mi\
les) since last
engine oil and fi lter change. Reset the engine oil data whenever replacing the engine oil\
regardless of the
message/wrench indicator light display.
*2 Use of FL-22 is recommended when replacing engine coolant. Using engine \
coolant other than FL-22 may cause serious damage to the engine and cooling system.
*3 According to state/provincial and federal regulations, failure to perfor\
m maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or mileage/kilometer period to ensure long-term reliabi\
lity.
*4 If this component has been submerged in water, the oil should be replaced.
*5 Check the tire repair fl uid expiration date every year when performing the periodic maintenance.\
Replace the
tire repair fl uid bottle with new one before the expiration date.


Schedule 2
U.S.A. and Puerto Rico residents - Severe driving conditions maintenance interval
Maintenance Interval Number of months or kilometers (miles), whichever comes
fi rst.
Months 6 12 18 24 30 36 42 48 54 60 66 72
×1000 km 8 16 24 32 40 48 56 64 72 80 88 96
×1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
Spark plugs Replace every 120,000 km (75,000 miles).
Air fi lter
*1 Replace when any equivalent timing of replacing engine oil.
(Max interval: 36 months or 60,000 km (37,500 miles))
Drive belts I I
Engine oil & fi lter Flexible
*2
Replace when wrench indicator light is ON. (Max interval: 12
months or 12,000 km (7,500 miles))
Fixed R R R R R R R R R R R R
Engine coolant
*3 Replace at
fi rst 192,000 km (120,000 miles) or 10 years;
after that, every 96,000 km (60,000 miles) or 5 years.
Engine coolant level I I I I I I I I I I I I
Fuel lines and hoses
*4 I I I
Hoses and tubes for emission
*4 I
Function of all lights I I I I I I I I I I I I
Brake lines, hoses and connections I I I
Brake and clutch fl uid level I I I I I I I I I I I I
Disc brakes I I I I I I
Tire (Rotation) Rotate when any equivalent timing of replacing engine oil.
(Max interval: 8,000 km (5,000 miles))
Tire in fl ation pressure and tire wear I I I I I I I I I I I I
Steering operation and linkages I I I
Front and rear suspension, ball joints and wheel
bearing axial play I
I I
Rear differential oil
*5
CX-5_8FN1-EA-16L_Edition1.indb 62016/12/12 10:07:05

6–7
Maintenance and Care
Scheduled Maintenance
Maintenance Interval Number of months or kilometers (miles), whichever comes
fi rst.
Months 6 12 18 24 30 36 42 48 54 60 66 72
×1000 km 8 16 24 32 40 48 56 64 72 80 88 96
×1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
Transfer oil
*5
Driveshaft dust boots I I I
Bolts and nuts on chassis and body T T T
Exhaust system and heat shields Inspect every 72,000 km (45,000 miles) or 5 years.
All locks and hinges L L L L L L L L L L L L
Washer fl uid level I I I I I I I I I I I I
Emergency fl at tire repair kit (if installed)
*6 Inspect annually.
Cabin air fi lter Replace when any equivalent timing of replacing engine oil.
(Max interval:24 months or 48,000 km (30,000 miles))
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fi ll up, or replace if necessary.
R: Replace
L: Lubricate
T: Tighten
Remarks:
*1 If the vehicle is operated in very dusty or sandy areas, clean and if ne\
cessary, replace the air fi lter more often
than the recommended intervals.
*2 Engine oil fl exible maintenance is available for U.S.A. and Puerto Rico residents who\
se vehicle is operated
mainly where none of the following conditions apply.
 Extended periods of idling or low-speed operation such as police car, taxi or driving school car
 Driving in dusty conditions If any do apply, follow fi xed maintenance.
The engine oil and fi lter must be changed at least once a year or within 12,000 km (7,500 mi\
les) since last
engine oil and fi lter change. Reset the engine oil data whenever replacing the engine oil\
regardless of the
message/wrench indicator light display.
*3 Use of FL-22 is recommended when replacing engine coolant. Using engine \
coolant other than FL-22 may cause serious damage to the engine and cooling system.
*4 According to state/provincial and federal regulations, failure to perfor\
m maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or mileage/kilometer period to ensure long-term reliabi\
lity.
*5 If this component has been submerged in water, the oil should be replaced.
*6 Check the tire repair fl uid expiration date every year when performing the periodic maintenance.\
Replace the
tire repair fl uid bottle with new one before the expiration date.




CX-5_8FN1-EA-16L_Edition1.indb 72016/12/12 10:07:05

6–8
Maintenance and Care
Scheduled Maintenance
Canada residents
Maintenance Interval Number of months or kilometers (miles), whichever comes
fi rst.
Months 6 12 18 24 30 36 42 48 54 60 66 72
×1000 km 8 16 24 32 40 48 56 64 72 80 88 96
×1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
Air fi lter I I I I I I I I I I I I
Replace every 56,000 km (35,000 miles) or 3 years.
Spark plugs Replace every 120,000 km (75,000 miles).
Drive belts I I
Engine oil & fi lter R R R R R R R R R R R R
Engine coolant
*1 Replace at
fi rst 192,000 km (120,000 miles) or 10 years;
after that, every 96,000 km (60,000 miles) or 5 years.
Engine coolant level I I I I I I I I I I I I
Fuel lines and hoses
*2 I I I
Hoses and tubes for emission
*2 I
Function of all lights I I I I I I I I I I I I
Brake lines, hoses and connections I I I
Brake and clutch fl uid level I I I I I I I I I I I I
Disc brakes Inspect every 24,000 km (15,000 miles) or 1 years.
Tire (Rotation) Rotate every 8,000 km (5,000 miles).
Tire in fl ation pressure and tire wear I I I I I I I I I I I I
Steering operation and linkages I I I
Front and rear suspension, ball joints and wheel
bearing axial play I
I I
Rear differential oil
*3
Transfer oil *3
Driveshaft dust boots I I I
Bolts and nuts on chassis and body T T T
Exhaust system and heat shields Inspect every 72,000 km (45,000 miles) or 5 years.
All locks and hinges L L L L L L L L L L L L
Washer fl uid level I I I I I I I I I I I I
Emergency fl at tire repair kit (if installed)
*4 Inspect annually.
Cabin air fi lter Replace every 48,000 km (30,000 miles) or 2 years.
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fi ll up, or replace if necessary.
R: Replace
L: Lubricate
T: Tighten
CX-5_8FN1-EA-16L_Edition1.indb 82016/12/12 10:07:05

6–9
Maintenance and Care
Scheduled Maintenance
Remarks:
*1 Use of FL-22 is recommended when replacing engine coolant. Using engine \
coolant other than FL-22 may cause serious damage to the engine and cooling system.
*2 According to state/provincial and federal regulations, failure to perfor\
m maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or mileage/kilometer period to ensure long-term reliabi\
lity.
*3 If this component has been submerged in water, the oil should be replaced.
*4 Check the tire repair fl uid expiration date every year when performing the periodic maintenance.\
Replace the
tire repair fl uid bottle with new one before the expiration date.


CX-5_8FN1-EA-16L_Edition1.indb 92016/12/12 10:07:05

6–10
Maintenance and Care
Scheduled Maintenance
Scheduled Maintenance (Mexico)
Follow Schedule 1 if the vehicle is operated mainly where none of the fo\
llowing conditions
(severe driving conditions) apply.
  Repeated short-distance driving  Driving in dusty conditions  Driving with extended use of brakes  Driving in areas where salt or other corrosive materials are used  Driving on rough or muddy roads  Extended periods of idling or low-speed operation  Driving for long periods in cold temperatures or extremely humid climate\
s  Driving in extremely hot conditions  Driving in mountainous conditions continually
If any do apply, follow Schedule 2.
NOTE
For maintenance guidelines beyond the kilometers/months listed, follow t\
he maintenance
intervals provided in the Scheduled Maintenance Tables.

Schedule 1
Maintenance Interval Number of months or kilometers, whichever comes fi
rst
Months 6 12 18 24 30 36 42 48 54 60 66 72
×1000 km 10 20 30 40 50 60 70 80 90
100 110 120
ENGINE
Drive belts I I I
Engine oil & fi lter R R R R R R R R R R R R
COOLING SYSTEM
Cooling system I I I
Engine coolant
*1 Replace at
fi rst 200,000 km or 10 years; after that, every
100,000 km or 5 years
FUEL SYSTEM
Air fi lter R R R R R R
Fuel lines and hoses I
*2 I *2 I
Hoses and tubes for emission I
*2 I *2 I
Fuel fi lter Replace every 60,000 km
IGNITION SYSTEM
Spark plugs I I I I I I I I I I I I
Replace every 120,000 km
CX-5_8FN1-EA-16L_Edition1.indb 102016/12/12 10:07:05

6–11
Maintenance and Care
Scheduled Maintenance
Maintenance Interval Number of months or kilometers, whichever comes fi
rst
Months 6 12 18 24 30 36 42 48 54 60 66 72
×1000 km 10 20 30 40 50 60 70 80 90
100 110 120
CHASSIS and BODY
Brake lines, hoses and connections I I I I I I
Brake and clutch fl uid level I I I I I I I I I
Brake fl uid R R R
Disc brakes I I I I I I I I I I I I
Tire (Rotation) Rotate every 10,000 km
Tire in fl ation pressure and tire wear I I I I I I I I I I I I
Steering operation and linkages I I I I I I I I I I I I
Front and rear suspension, ball joints and wheel
bearing axial play I I I I I I
Rear differential oil
*3
Transfer oil *3
Driveshaft dust boots I I I I I I
Bolts and nuts on chassis and body T T T T T T
Exhaust system and heat shields I I I I I I
All locks and hinges L L L L L L L L L L L L
Washer fl uid level I I I I I I I I I I I I
Emergency fl at tire repair kit (if installed)
*4 Inspect annually.
AIR CONDITIONER SYSTEM
Cabin air fi lter R R R
Chart symbols:
I: Inspect: Inspect and clean, repair, adjust, fi ll up, or replace if necessary.
R: Replace
L: Lubricate
T: Tighten
Remarks:
*1 Use of FL-22 is recommended when replacing engine coolant. Using engine \
coolant other than FL-22 may cause serious damage to the engine and cooling system.
*2 According to state/provincial and federal regulations, failure to perfor\
m maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the
recommended time or kilometer period to ensure long-term reliability.
*3 If this component has been submerged in water, the oil should be replaced.
*4 Check the tire repair fl uid expiration date every year when performing the periodic maintenance.\
Replace the
tire repair fl uid bottle with new one before the expiration date.


CX-5_8FN1-EA-16L_Edition1.indb 112016/12/12 10:07:05

6–12
Maintenance and Care
Scheduled Maintenance
Schedule 2
Maintenance Interval Number of months or kilometers, whichever comes fi
rst
Months 3 6 9 12 15 18 21 24 27 30 33 36
×1000 km 5 10 15 20 25 30 35 40 45 50 55 60
ENGINE
Drive belts I
Engine oil & fi lter R R R R R R R R R R R R
COOLING SYSTEM
Cooling system I
Engine coolant
*1 Replace at
fi rst 200,000 km or 10 years; after that, every
100,000 km or 5 years
Engine coolant level I I I I I I I I I I I I
FUEL SYSTEM
Air fi lter C R C R C R
Fuel lines and hoses I
*2
Hoses and tubes for emission I
*2
Fuel fi lter Replace every 60,000 km
IGNITION SYSTEM
Spark plugs I I I I I I
Replace every 120,000 km
ELECTRICAL SYSTEM
Function of all lights I I I I I I I I I I I I
CX-5_8FN1-EA-16L_Edition1.indb 122016/12/12 10:07:06
