2017 MAZDA MODEL CX-5 Owners Manual (in English)

2–11
Essential Safety Equipment
Seats
*Some models.
Using remote handle *
1. (With rear seat warmer)
Turn the rear seat warmer switch off.
Refer to Seat Warmer on page 2-15 .
2. After checking that the rear seats are clear, open the liftgate and lower the
seatback you want to fold down using
the remote handle.
When folding the left side, operate the outer part of the remote handle.


WARNING
Always remove the child-restraint
system from the rear seat before
operating the remote handle for the
rear seat: Operating the remote handle while
a rear-facing child-restraint system
is in the rear seat is dangerous. It
could cause injury to a child seated in
the child-restraint system when the
seatback suddenly fl ips forward.

Make sure there is nobody in the rear
seat area before operating (pulling) the
remote handle: Not checking the rear seat area for
persons before folding the seatbacks
with the strap/remote handle is
dangerous. The rear seat area is
diffi cult to see from the rear of the
vehicle. Operating (pulling) the remote
handle without checking could cause
injury to a person when a seatback
suddenly fl ips forward.

CX-5_8FN1-EA-16L_Edition1.indb 112016/12/12 10:05:16

2–12
Essential Safety Equipment
Seats
*Some models.
CAUTION
 Before folding the seatbacks down with the remote handle, make sure there is
no cup in a rear cup holder. Folding the
seatbacks with the remote handle while
a cup is in the cup holder could soil or
damage the seat bottom and seatback.
 Be careful of the following when using the remote handle:
 On a downward slope, the seatback could fl ip forward faster than on a fl at
surface.
 On an upward slope, the seatback may not fold down. When the
seatbacks cannot be folded down
with the remote handle, pull the rear
seatback forward from inside the
vehicle.
 (Folding the left seatback)  Be careful when operating the remote
handle with the center seatback folded
down. If a person sitting in the right
rear seat places a hand on the center
seatback, it could be pinched by a
seatback or seat component causing
injury.


Using the lever
1. (With rear seat warmer)
Turn the rear seat warmer switch off.
Refer to Seat Warmer on page 2-15 .
2. Pull the lever and fold the seatback forward.


Folding only center seatback
Using remote handle
*
1. (With rear seat warmer)
Turn the rear seat warmer switch off.
Refer to Seat Warmer on page 2-15 .
2. If the center head restraint is in the position for use, store it.
3. After checking that the center seat is clear, open the liftgate and pull the
inside remote handle on the left side of
the liftgate compartment.


CX-5_8FN1-EA-16L_Edition1.indb 122016/12/12 10:05:16

2–13
Essential Safety Equipment
Seats
WARNING
Always remove the child-restraint
system from the rear seat before
operating the remote handle for the
rear seat: Operating the remote handle while
a rear-facing child-restraint system
is in the rear seat is dangerous. It
could cause injury to a child seated in
the child-restraint system when the
seatback suddenly fl ips forward.

Make sure there is nobody in the rear
seat area before operating (pulling) the
remote handle: Not checking the rear seat area for
persons before folding the seatbacks
with the strap/remote handle is
dangerous. The rear seat area is
diffi cult to see from the rear of the
vehicle. Operating (pulling) the remote
handle without checking could cause
injury to a person when a seatback
suddenly fl ips forward.

CAUTION
 Before folding the seatbacks down with the remote handle, make sure there is
no cup in a rear cup holder. Folding the
seatbacks with the remote handle while
a cup is in the cup holder could soil or
damage the seat bottom and seatback.
 Be careful of the following when using the remote handle:
 On a downward slope, the seatback could fl ip forward faster than on a fl at
surface.
 On an upward slope, the seatback may not fold down. When the
seatbacks cannot be folded down
with the remote handle, pull the rear
seatback forward from inside the
vehicle.


Using strap
1. (With rear seat warmer)
Turn the rear seat warmer switch off.
Refer to Seat Warmer on page 2-15 .
2. If the center head restraint is in the position for use, store it.
3. Pull the strap on the back of the seatback to fold the seatback forward.


CX-5_8FN1-EA-16L_Edition1.indb 132016/12/12 10:05:17

2–14
Essential Safety Equipment
Seats
To return the seatbacks to the upright
position
WARNING
Always make sure the seat belts are fully
pulled out from under the seatbacks: A seat belt caught under a seatback
after the seatback is returned to its
upright position is dangerous. In a
collision or sudden stop, the seat belt
cannot provide adequate protection.

When returning the seatback to its
upright position, make sure that it is
fi rmly locked and the red indication is
not visible: If the red indication is visible, the
seatback is not locked. If the vehicle is
driven without the seatback locked, it
could fold down suddenly and cause
an accident.

Locked
position
Unlocked
position
Red indicator

1. Make sure that the seat belt passes through the seat belt guide.

Seat belt guide

2. Press the seatback rearward and lock it in place. After returning the seatback
to its upright position, make sure it is
securely locked.

CX-5_8FN1-EA-16L_Edition1.indb 142016/12/12 10:05:17

2–15
Essential Safety Equipment
Seats
*Some models.
Rear Seat Recline
WARNING
After adjusting the seatback, make
sure that it is fi rmly locked and the red
indication is not visible by attempting to
lightly move the seatback forward and
back: If the red indication is visible, the
seatback is not locked. If the vehicle
is driven with the seatback unlocked,
it may move unexpectedly and the
seating posture of the occupant
becomes unstable, resulting in an
accident.


Locked
position
Unlocked
position
Red indicator

CAUTION
When adjusting the seatback, always
support the seatback with your hand.
If the seatback is not supported by your
hand, it will move suddenly and could
cause injury.

NOTE
When you adjust the left seatback, the
center seatback moves at the same time.

The left and right seatbacks of the rear seat
can be adjusted separately.
Recline the seatback with the lever pulled
up.


Seat Warmer *
The rear seats are electrically heated. The
ignition must be switched ON.
Press the seat warmer switch while the
ignition is switched ON to operate the seat
warmer. The indicator lights turn on to
indicate that the seat warmer is operating.
The mode changes as follows each time
the seat warmer switch is pressed.
When using the seat warmer, fold the
armrest forward.
Refer to Armrest on page 2-17 .

OFF
High
Mid
Low

CX-5_8FN1-EA-16L_Edition1.indb 152016/12/12 10:05:17

2–16
Essential Safety Equipment
Seats
WARNING
Be careful when using the seat warmer: The heat from the seat warmer may be
too hot for some people, as indicated
as follows, and could cause a low-
temperature burn.
 Infants, small children, elderly people, and physically challenged
people
 People with delicate skin People who are excessively fatigued People who are intoxicated People who have taken sleep-inducing medicine such as sleeping
pills or cold medicine

Do not use the seat warmer with
anything having high moisture-
retention ability such as a blanket or
cushion on the seat: The seat may be heated excessively
and cause a low-temperature burn.

Do not use the seat warmer even when
taking a short nap in the vehicle: The seat may be heated excessively
and cause a low-temperature burn.

Do not place heavy objects with sharp
projections on the seat, or insert
needles or pins into it: This could cause the seat to become
excessively heated and result in injury
from a minor burn.

CAUTION
 Before folding a rear seatback, make sure that the rear seat warmer switch is
off . If a rear seatback is folded while the
rear seat warmer is in operation, it may
heat the seat excessively and damage
the seat surface.
 Do not use organic solvents to clean the seat. It may damage the seat surface
and the heater.

NOTE
   Use the seat warmer when the engine
is running. Leaving the seat warmer
on for long periods with the engine not
running could cause the battery power
to be depleted.
  When the engine is stopped while
the seat warmers are operating and
then the ignition is switched ON, the
seat warmers will not turn back on
automatically. In addition, the seat
warmer operation stops automatically
after the seat warmers have operated
for about 90 minutes.
 To turn the seat warmer back on, press the switch.
  The temperature of the seat warmer
cannot be adjusted beyond High, Mid
and Low because the seat warmer is
controlled by a thermostat.

CX-5_8FN1-EA-16L_Edition1.indb 162016/12/12 10:05:17

2–17
Essential Safety Equipment
Seats
*Some models.
Armrest *
The rear armrest in the center of the rear
seatback can be used (no occupant in the
center seat) or placed upright.


WARNING
Never put your hands and fi ngers
around the moving parts of the seat and
armrest: Putting your hands and fi ngers around
the moving parts of the seat and
armrest is dangerous as they could get
injured.

Head Restraints
Your vehicle is equipped with head
restraints on all outboard seats and the
rear center seat. The head restraints are
intended to help protect you and the
passengers from neck injury.
WARNING
Always drive with the head restraints
installed when seats a re being used and
make sure they are properly adjusted.
In addition, always raise the head
restraints on all rear seat when they are
being used: Driving with the head restraints
adjusted too low or removed is
dangerous. With no support behind
your head, your neck could be seriously
injured in a collision.

Height Adjustment
Adjust the head restraint so that the center
is even with the top of the passenger's ears.



To raise a head restraint, pull it up to the
desired position.
To lower the head restraint, press the stop-
catch release, then push the head restraint
down.
CX-5_8FN1-EA-16L_Edition1.indb 172016/12/12 10:05:18

2–18
Essential Safety Equipment
Seats
Front outboard seat


Rear outboard seat

Except Mexico


Mexico


Rear center seat



Removal/Installation
To remove the head restraint, pull it up
while pressing the stop-catch.
To install the head restraint, insert the legs
into the holes while pressing the stop-
catch.
WARNING
Always drive with the head restraints
installed when seats a re being used and
make sure they are properly installed: Driving with the head restraints not
installed is dangerous. With no support
behind your head, your neck could be
seriously injured in a collision.

After installing a head restraint, try
lifting it to make sure that it does not
pull out: Driving with an unsecured head
restraint is dangerous as the
eff ectiveness of the head restraint will
be compromised which could cause it
to unexpectedly detach from the seat.

CX-5_8FN1-EA-16L_Edition1.indb 182016/12/12 10:05:18
