  When the ignition is switched OFF, the
system status before it was turned off is
maintained. For example, if the ignition
is switched OFF with the lane-keep
system operable, the system will be
operable when the ignition is switched
ON the next time.
  In the following cases, the Lane-keep
Assist System (LAS) & Lane Departure
Warning System (LDWS) is canceled
automatically and the Lane-keep
Assist System (LAS) & Lane Departure
Warning System (LDWS) OFF indicator
light turns on. Have your vehicle
inspected at an Authorized Mazda
Dealer.
  There is a malfunction in the power
steering.
  There is a malfunction in the TSC.  There is a malfunction in the
Forward Sensing Camera (FSC).


When the Lane-keep Assist System
(LAS) & Lane Departure Warning System
(LDWS) is turned off, the vehicle lane line
indication in the multi-information display
and the active driving display turn off.
CX-5_8FN1-EA-16L_Edition1.indb 1452016/12/12 10:06:15

4–14 6
When Driving
i-ACTIVSENSE
Lane Departure Warning
If the system determines that the vehicle may deviate from its lane, the\
lane departure
warning (beep sound, rumble sound *1 , or steering wheel vibration) is activated and the
direction in which the system determines that the vehicle may deviate is\
indicated in the
multi-information display and the active driving display.
If the system determines that the vehicle may deviate from its lane, the\
color of the lane line
on the side being detected by the system changes from white to amber, and fl ashes.

Multi-information Display Active Driving Display

CX-5_8FN1-EA-16L_Edition1.indb 1462016/12/12 10:06:15

4–147
When Driving
i-ACTIVSENSE
NOTE
  If you have set the lane departure warning sound to the beep sound/rumble sound *1
setting, the warning sound may not be heard depending on the surrounding noise
conditions.
   If you have set the lane departure warning system to the steering wheel vibrations setting,
the vibration may not be felt depending on the road surface conditions.
  When the setting for the steering operation assist is changed to operati\
onal, the warnings
can be set to activate/not activate. (When the setting for the steering\
operation assist is
changed to non-operational, the warnings cannot be set to not activate.)\
 Refer to Setting Change (Personalization Features) on page 9-11 .  The Lane-keep Assist System (LAS) & Lane Departure Warning System (LDWS) can be
changed to the following settings regardless of whether the steering operation assist has
been set to operational/non-operational. Always check the setting status when driving the
vehicle and make setting changes if necessary.
 Refer to Setting Change (Personalization Features) on page 9-11 .   Steering wheel vibration: Strong/weak  Warning sound volume  Types of warnings (steering wheel vibration/beep sound/rumble sound *1 )

*1 A rumble strip is a series of grooves in the road pavement surface positioned at speci fi c
intervals, and when the vehicle passes over it a vibration and rumble so\
und is produced
which alerts the driver that the vehicle is departing from the lane.
The rumble sound is a reproduction of the sound which occurs when a vehicle passes over a rumble strip.


Rumble
Groove

CX-5_8FN1-EA-16L_Edition1.indb 1472016/12/12 10:06:15

4–14 8
When Driving
i-ACTIVSENSE
*Some models.
Smart City Brake Support (SCBS) *
The Smart City Brake Support (SCBS) system alerts the driver of a possible collision using
an indication in the display and a warning sound when the Forward Sensin\
g Camera (FSC)
detects a vehicle ahead and determines that a collision with a vehicle a\
head is unavoidable
while the vehicle is being driven at a vehicle speed of about 4 to 80 km\
/h (2 to 50 mph).
In addition, the system reduces damage in the event of a collision by op\
erating the brake
control (Smart City Brake Support (SCBS) brake) when the system dete\
rmines that a
collision is unavoidable while the vehicle is being driven at a vehicle \
speed of about 4 to
30 km/h (2 to 18 mph). It may also be possible to avoid a collision if\
the relative speed
between your vehicle and the vehicle in front of you is less than about \
20 km/h (12 mph).
In addition, when the driver depresses the brake pedal while the system \
is in the operation
range at about 4 to 30 km/h (2 to 18 mph), the brakes are applied fi rmly and quickly to
assist. (Brake Assist (Smart City Brake Support (SCBS) brake assist))


Forward Sensing
Camera (FSC)

CX-5_8FN1-EA-16L_Edition1.indb 1482016/12/12 10:06:16

4–149
When Driving
i-ACTIVSENSE
WARNING
Do not rely completely on the Smart City Brake Support (SCBS) system:  The Smart City Brake Support (SCBS) system is only designed to reduce damage in the event of a collision. Over reliance on the system leading to the accelerator pedal or
brake pedal being mistakenly operated could result in an accident.
 The Smart City Brake Support (SCBS) is a system which operates in response to a vehicle ahead. The system may not be able to detect or react to 2-wheeled vehicles or
pedestrians.

CAUTION
In the following cases, turn the system off to prevent a mis-operation:  The vehicle is being towed or when towing another vehicle. The vehicle is on a chassis roller. When driving on rough roads such as in areas of dense grass or off -road.
Refer to Stopping the Smart City Brake Support (SCBS) system Operation on page 4-152
on how to turn off the Smart City Brake Support (SCBS) system.

CX-5_8FN1-EA-16L_Edition1.indb 1492016/12/12 10:06:16

4–150
When Driving
i-ACTIVSENSE
NOTE
  The Smart City Brake Support (SCBS) system will operate under the foll\
owing conditions.   The engine is running.  The Smart Brake Support/Smart City Brake Support (SBS/SCBS) system war\
ning
indication/warning light (amber) does not illuminate.
  (Rear-end collision warning)  The vehicle speed is about 4 to 80 km/h (2 to 50 mph).  (Brake control (Smart City Brake Support (SCBS) brake))  The vehicle speed is about 4 to 30 km/h (2 to 18 mph).  The Smart City Brake Support (SCBS) system is not turned off.   Under the following conditions, the Smart City Brake Support (SCBS) sy\
stem may not
operate normally:
  The Smart City Brake Support (SCBS) system will not operate if the dri\
ver is
deliberately performing driving operations (accelerator pedal and steer\
ing wheel).
  If there is the possibility of partial contact with a vehicle ahead.  The vehicle is driven on a slippery road surface such as wet roads or icy or snow-
bound roads.
  The braking performance is adversely affected due to cold temperatures or wet brakes.  The vehicle is driven at the same speed as the vehicle ahead.  The accelerator pedal is depressed.  The brake pedal is depressed.  The steering wheel is being operated.  The selector lever is being operated.   In the following cases, the Forward Sensing Camera (FSC) determines that there is a
vehicle ahead and the Smart City Brake Support (SCBS) may operate.
  Objects on the road at the entrance to a curve.  Vehicles passing in the opposite lane while making a curve.  Metal objects, bumps, or protruding objects on the road.  When passing through a toll gate.  When passing through low gates, narrow gates, car washing machines, or tunnels.  If you suddenly come close to a vehicle ahead.  2-wheeled vehicles, pedestrians, animals or standing trees.  Vehicle is driven with some of the tires having signi fi cant wear.

CX-5_8FN1-EA-16L_Edition1.indb 1502016/12/12 10:06:16

4–151
When Driving
i-ACTIVSENSE
Smart City Brake Support (SCBS) Indicator Light (Red)
If the Smart City Brake Support (SCBS) is
operating, the indicator light (red) fl ashes.



Collision Warning
If there is the possibility of a collision
with a vehicle ahead, the beep sounds
continuously and a warning is indicated in
the multi-information display or the active
driving display.

Multi-information Display
Active Driving Display

NOTE
The operation distance and volume of the
collision warning can be changed. Refer to
Personalization Features on page 9-11 .

Automatic Brake Operation
Display
“Smart City Brake Support Activated” is
indicated in the multi-information display
after the SCBS brakes or the brake assist
(SCBS brake assist) is operated.


NOTE
  The collision warning beep sounds
intermittently while the SCBS brake
or brake assist (SCBS brake assist) is
operating.
  If the vehicle is stopped by the SCBS
operation and the brake pedal is not
depressed, the warning beep sounds
one time after about 2 seconds and the
SCBS brake is automatically released.

CX-5_8FN1-EA-16L_Edition1.indb 1512016/12/12 10:06:16

4–152
When Driving
i-ACTIVSENSE
Stopping the Smart City Brake Support (SCBS) System Operation
The Smart City Brake Support (SCBS)
system can be temporarily deactivated.
Refer to Personalization Features on page
9-11 .
When the Smart City Brake Support
(SCBS) system is turned off, the Smart
City Brake Support (SCBS) OFF indicator
light turns on.



When the engine is restarted, the system
becomes operational.
