2017 MAZDA MODEL CX-5 Owners Manual (in English)

5–17
Interior Features
Before Using the Audio System
NOTE
  This mode may not be usable depending
on the portable audio device to be
connected.
  Before using the auxiliary jack/USB
port, refer to the instruction manual for
the portable audio device.
  Use a commercially-available, non-
impedance (3.5
) stereo mini plug for
connecting the portable audio unit to
the auxiliary jack. Before using the
auxiliary jack, read the manufacturer's
instructions for connecting a portable
audio unit to the auxiliary jack.
   To prevent discharging of the battery,
do not use the auxiliary input for long
periods with the engine off or idling.
  When connecting a device to the
auxiliary jack or USB port, noise may
occur depending on the connected
device. If the device is connected to the
vehicle's accessory socket, the noise can
be reduced by unplugging it from the
accessory socket.

How to connect USB port/Auxiliary jack
Type A


USB port Auxiliary jack

Type B


USB port Auxiliary jack

Connecting a device
1. Open the console lid.
2. If there is a cover on the auxiliary jack or USB port, remove the cover. (Type
A)
3. Connect the connector on the device to the USB port.

CX-5_8FN1-EA-16L_Edition1.indb 172016/12/12 10:06:27

5–18
Interior Features
Before Using the Audio System
Connecting with a connector cable
1. Open the console lid.
2. If there is a cover on the auxiliary jack or USB port, remove the cover. (Type
A)
3. Connect the device plug/connector cable to the auxiliary jack/USB port.
Pass the device plug/connector cable
through the notch in the console and
connect.

WARNING
Do not allow the connection plug cord
to get tangled with the shift lever
(manual )/selector lever (automatic ): Allowing the plug cord to become
tangled with the shift lever (manual )/
selector lever (automatic ) is dangerous
as it could interfere with driving,
resulting in an accident.

CAUTION
Do not place objects or apply force to
the auxiliary jack/USB port with the
plug connected.

NOTE
  Insert the plug into the auxiliary jack/
USB port securely.
  Insert or pull out the plug with the plug
perpendicular to the auxiliary jack/USB
port hole.
  Insert or remove the plug by holding its
base.

Antenna

Antenna

CX-5_8FN1-EA-16L_Edition1.indb 182016/12/12 10:06:27

5–19
MEMO
CX-5_8FN1-EA-16L_Edition1.indb 192016/12/12 10:06:28

5–20
Interior Features
Audio Set [Type A (non-touchscreen)]
Power/Volume/Sound Controls
Power/Volume/Audio control dialMenu button
Audio display
Power ON/OFF
Switch the ignition to ACC or ON. Press
the power/volume dial to turn the audio
system on. Press the power/volume dial
again to turn the audio system off.
Volume adjustment
To adjust the volume, turn the power/
volume dial. Turn the power/volume
dial clockwise to increase volume,
counterclockwise to decrease it.
Audio sound adjustment
1. Press the menu button ( ) to select
the function. The selected function will
be indicated. 2. Turn the audio control dial to adjust the
selected functions as follows:

Indication Setting value Turn
Counterclockwise Turn
Clockwise
ALC
(Automatic volume adjustment) Level
decrease Level
increase
BASS
(Low pitch sound) Decrease
bass Increase
bass
TREB
(Treble sound) Decrease
treble Increase
treble
FADE
(Front/back volume balance) Shift the
sound to
the front Shift the
sound to
the rear
BAL
(Left/right volume balance) Shift the
sound to
the left Shift the
sound to
the right
BEEP
(Audio operation sound) OFF ON
BT SETUP Select mode
12Hr
24Hr
(12 Hr/24 Hr time adjustment) 12Hr
(Flashing) 24Hr
(Flashing)

CX-5_8FN1-EA-16L_Edition1.indb 202016/12/12 10:06:28

5–21
Interior Features
Audio Set [Type A (non-touchscreen)]
NOTE
If not operated for several seconds, the
display returns to the previous display. To
reset bass, treble, fade, and balance, press
the menu button (
) for 2 seconds.
The unit will beep and “ CLEAR ” will be
displayed.

ALC (Automatic volume adjustment)
The automatic level control (ALC)
changes the audio volume automatically
according to the vehicle speed. The faster
the vehicle speed, the higher the volume
increases. ALC has ALC OFF and ALC
LEVEL 1 to 7 modes. At ALC LEVEL 7,
the amount that the volume can increase
is at the maximum. Select the mode
according to the driving conditions.
BEEP (Audio operation sound)
The setting for the operation sound when
pressing and holding a button can be
changed. The initial setting is ON. Set to
OFF to mute the operation sound.
BT SETUP mode
Music and other audio such as voice data
recorded on portable audio devices and
mobile phones available on the market
which are equipped with the Bluetooth
®
transmission function can be listened to
via wireless transmission over the vehicle's
speakers. Using the BT SETUP mode,
these devices can be programmed to the
Bluetooth
® unit or changed (page 5-38 ).
12Hr
24Hr (12 Hr/24 Hr time
adjustment)
Rotating the audio control dial switches
the display between 12 and 24-hour clock
time (page 5-22 ).
CX-5_8FN1-EA-16L_Edition1.indb 212016/12/12 10:06:28

5–22
Interior Features
Audio Set [Type A (non-touchscreen)]
Clock
Audio display
Audio control dial
Hour/Minute set switch:00 button
Menu button
Clock button
Setting the time
The clock can be set at any time when the
ignition is switched to ACC or ON.

1. To adjust the time, press the clock
button (
) for about 2 seconds until
a beep is heard.
2. The clock's current time will fl ash.
Time adjustment
 To adjust the time, press the hour/ minute set button (
, ) while the
clock's current time is fl ashing.
 The hours advance while the hour set
button (
) is pressed. The minutes
advance while the minute set button
(
) is pressed.
3. Press the clock button ( ) again to
start the clock.

Time resetting
1. Press the clock button ( ) for about
2 seconds until a beep is heard.
2. Press the :00 button ( 1 ).
3. When the button is pressed, the time will be reset as follows:
(Example)
12:01—12:29→12:00
12:30—12:59→1:00

NOTE
   When the :00 button ( 1 ) is pressed, the
seconds will start at “ 00 ”.
  Switching between 12 and 24-hour
clock time:
 Press the menu button ( ) several
times until 12 and 24-hour clock time
are displayed. Turn the audio control
dial in either direction, select the
desired clock setting while the preferred
clock time is fl ashing.

CX-5_8FN1-EA-16L_Edition1.indb 222016/12/12 10:06:28

5–23
MEMO
CX-5_8FN1-EA-16L_Edition1.indb 232016/12/12 10:06:29

5–24
Interior Features
Audio Set [Type A (non-touchscreen)]
Operating the Radio
Band selector buttonChannel preset
buttons
Scan button Auto memory button
Tuning button Audio display

Radio ON
Press a band selector button ( ) to
turn the radio on.
Band selection
Successively pressing the band selector
button (
) switches the bands as
follows: FM1→FM2→AM.

The selected mode will be indicated.
NOTE
If the FM broadcast signal becomes weak,
reception automatically changes from
STEREO to MONO for reduced noise.

Tuning
The radio has the following tuning
methods: Manual, Seek, Scan, Preset
channel, and Auto memory tuning. The
easiest way to tune stations is to set them
on preset channels.
Manual tuning
Select the station by pressing the tuning
button (
, ) lightly.
Seek tuning
Automatic search for radio stations starts
when the tuning button (
, ) is pressed
until a beep sound is heard. The search
stops when a station is found.
NOTE
If you continue to press and hold the
button, the frequency will continue
changing without stopping.

CX-5_8FN1-EA-16L_Edition1.indb 242016/12/12 10:06:29
