2017 MAZDA MODEL CX-5 Owners Manual (in English)

5–33
Interior Features
Audio Set [Type A (non-touchscreen)]
Track search
Press the track up button (
) once to skip
forward to the beginning of the next track.
Press the track down button (
) within a
few seconds (depends on iPod software
version) after playback begins to track
down to the beginning of the previous
track.
Press the track down button (
) after a
few seconds (depends on iPod software
version) have elapsed to start playback
from the beginning of the current track.
Category search
Press the category down button ( 5 ) to
select the previous category and press the
category up button ( 6 ) to select the next
category.
NOTE
The types of categories include Playlist,
Artist, Album, Song, Podcast, Genre,
Composer, and Audio book.

List search
Press the list down button (
) to select the
previous list and press the list up button
(
) to select the next list.
NOTE
When the selected category is Song or
Audio book, there is no list.

Music scan
This function scans the titles in a list
currently being played and plays
10 seconds of each song to aid you in
fi nding a song you want to listen to.
Press and hold the scan button (
)
during playback to start the scan play
operation (the track number will fl ash).
Press and hold the scan button (
)
again to cancel scan playback.
NOTE
If the unit is left in scan, normal playback
will resume where scan was selected.

Repeat playback
1. Press the repeat button ( 1 ) during playback to play the current track
repeatedly. “ TRACK RPT ” is displayed
(
is displayed next to RPT at the
bottom of the display area).
2. Press the button again to cancel the repeat playback.

Random playback
Tracks are randomly selected and played.
Song random
1. Press the random button ( 2 ) during playback to play the tracks in the list
randomly. “ SONG RDM ” is displayed
(
is displayed next to RDM at the
bottom of the display area).
2. To cancel the random playback, press the button again after 3 seconds.

Album random
1. Press the random button ( 2 ) during playback, and then press the button
again within 3 seconds to play the
tracks in the iPod randomly. “ ALBUM
RDM ” is displayed (
is displayed
next to RDM at the bottom of the
display area).
2. Press the button again to cancel the random playback.

NOTE
The track number being played randomly
is in the order of the iPod shuf fl e table.

CX-5_8FN1-EA-16L_Edition1.indb 332016/12/12 10:06:31

5–34
Interior Features
Audio Set [Type A (non-touchscreen)]
Switching the display
The information displayed on the audio
display changes as follows each time the
text button ( 3 ) is pressed during playback.

Button Information displayed
on audio display

File number/Elapsed
time
File number
Category name Artist name
Album name Song name

NOTE
   The information (artist name, music
name) is displayed only when the iPod
has information which can be displayed.
  This unit cannot display some
characters. Characters which cannot be
displayed are indicated by an asterisk
(
).
Display scroll
13 characters can be displayed at one time.
To display the rest of the characters of a
long title, press and hold the text button
( 3 ). The display scrolls the next
13 characters. Press and hold the text
button ( 3 ) again after the last 13 characters
have been displayed to return to the
beginning of the title.
NOTE
The number of characters which can be
displayed is restricted.

Error Indications
If you see an error indication on the
display, take appropriate action according
to the following methods. If you cannot
clear the error indication, take the vehicle
to an Authorized Mazda Dealer.
CHECK USB
When the message “ CHECK USB ” is
displayed, it indicates that there is some
error in the USB device. Verify that the
content recorded in the USB device has
MP3/WMA/AAC fi les and re-connect
correctly.
CHECK iPod
If the message “ CHECK iPod ” is
displayed, it indicates that there is a
malfunction in the iPod. Verify that the
content recorded in the iPod has playable
fi les and connect correctly.
CX-5_8FN1-EA-16L_Edition1.indb 342016/12/12 10:06:31

5–35
Interior Features
Audio Set [Type A (non-touchscreen)]
Bluetooth ®
Introduction
Bluetooth ® Hands-Free outline
When a Bluetooth
® device (mobile phone) is connected to the vehicle's Bluetooth ® unit, a
call can be made or received by pressing the talk button, pick-up button\
, or hang-up button
on the audio remote control switch. For example, even if a device (mobi\
le phone) is in your
coat pocket, a call can be made without taking the device (mobile phone\
) out and operating
it directly.
Bluetooth
® audio outline
When a portable audio unit equipped with the Bluetooth
® communication function is paired
to the vehicle, you can listen to music stored on the paired portable au\
dio device from the
vehicle's speakers. It is not necessary to connect the portable audio de\
vice to the vehicle's
external input terminal. After programming, operate the vehicle audio control panel to play/
stop the audio.

NOTE
   For your safety, a device can be paired only when the vehicle is parked. If the vehicle
starts to move, the pairing procedure will end. Park the vehicle in a safe place before
pairing.
  The communication range of a Bluetooth ® equipped device is about 10 meters (32 ft) or
less.
   Basic audio operation is available using voice commands even if Bluetoot\
h ® is not
connected.

CX-5_8FN1-EA-16L_Edition1.indb 352016/12/12 10:06:31

5–36
Interior Features
Audio Set [Type A (non-touchscreen)]
CAUTION
Some Bluetooth ® mobile devices are not compatible with the vehicle. Consult an
Authorized Mazda Dealer, Mazda's call center or Web support center for information
regarding Bluetooth
® mobile device compatibility:

 U.S.A. Phone: 800-430-0153 Web: www.mazdausa.com/mazdaconnect Canada Phone: 800-430-0153 Web: www.mazdahandsfree.ca  Mexico Center of Attention to Client (CAC) Phone: 01-800-01-MAZDA Web: www.mazdamexico.com.mx
Applicable Bluetooth ® specifi cation (Recommended)
Ver. 2.0
CX-5_8FN1-EA-16L_Edition1.indb 362016/12/12 10:06:32

5–37
Interior Features
Audio Set [Type A (non-touchscreen)]
Component Parts
Microphone
Talk button, Pick-up button and Hang-up button
Microphone Audio unit
Talk button
Hang-up button
Pick-up button

Microphone (hands-free)
The microphone is used for speaking voice commands or when making a Hand\
s-free call.
Talk button
Activates the voice recognition. In addition, it skips the voice guidanc\
e.
Pick-up button
Responds to incoming calls. In addition, after selecting a contact or di\
aling a number, it
places the call when the button is pressed.
Hang-up button
Ends the call or refuses an incoming call. In addition, it ends the voic\
e recognition
operation.
Volume adjustment
The power/volume dial of the audio unit is used to adjust the volume. Turn the dial to the
right to increase volume, to the left to decrease it.
The volume can also be adjusted using the volume button on the steering \
wheel.
NOTE
If the volume is lower compared to other audio modes, increase the volume from the device
side.

CX-5_8FN1-EA-16L_Edition1.indb 372016/12/12 10:06:32

5–38
Interior Features
Audio Set [Type A (non-touchscreen)]
Bluetooth ® Preparation
Bluetooth ® Hands-Free
Preparation
Pairing code setting
The 4-digit pairing code setting for
registration of your cell phone (pairing)
can be set beforehand.
NOTE
The initial setting value is “0000”.
1. Press the pick-up button or talk button
with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Pairing options”
5. Prompt: “Select one of the following: Pair, Edit, Delete, List, or Set Pairing
Code.”
6. Say: [Beep] “Set pairing code”
7. Prompt: “Your current pairing code is XXXX. Do you want to change it to a
different pairing code?”
8. Say: [Beep] “Yes”
9. Prompt: “Please say a 4-digit pairing code.”
10. Say: [Beep] “YYYY”
11. Prompt: “YYYY is this correct?”
12. Say: [Beep] “Yes” or “No”
13. If “Yes”, go to Step 14. If “No”, the procedure returns to Step 9.
14. Prompt: “Your new pairing code is YYYY. Use this pairing code when
pairing devices to the Hands free
system. Do you want to pair a device
now?”
15. Say: [Beep] “Yes” or “No” 16. If “Yes”, the system switches to the
device registration mode. If “No”, the
system returns to standby status.

Device pairing (Bluetooth ® Hands-
Free)
To use Bluetooth ® Hands-Free, the device
equipped with Bluetooth ® has to be paired
to the Bluetooth ® unit using the following
procedure.
A maximum of seven devices including
hands-free mobile phones and Bluetooth
®
audio devices can be paired to one vehicle.
NOTE
If a Bluetooth ® device has already been
paired to the vehicle as a Bluetooth ® audio
device, it does not need to be paired again
when using the device as a hands-free
mobile phone. Conversely, it does not need
to be paired again as a Bluetooth
® audio
device if it has already been paired as a
hands-free mobile phone.

1. Activate the Bluetooth ® application of
the device.
NOTE
For the operation of the device, refer to its
instruction manual.

2. Press the pick-up button or talk button with a short press.
3. Say: [Beep] “Setup”
4. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
5. Say: [Beep] “Pairing options”
6. Prompt: “Select one of the following: Pair, Edit, Delete, List, or Set Pairing
Code.”
7. Say: [Beep] “Pair”
CX-5_8FN1-EA-16L_Edition1.indb 382016/12/12 10:06:32

5–39
Interior Features
Audio Set [Type A (non-touchscreen)]
8. Prompt: “Start the pairing process on your Bluetooth ® device. Your pairing
code is 0000 (XXXX). Input this on
your Bluetooth
® device when prompted
on the device. See device manual for
instructions.”
9. Using the device, perform a search for the Bluetooth
® device (Peripheral
device).
NOTE
For the operation of the device, refer to its
instruction manual.

10. Select “Mazda” from the device list searched by the device.
11. Input the 4-digit pairing code to the device.
12. Prompt: “Please say the name of the device after the beep.”
13. Say: [Beep] “XXXX - - -” (Say a “device tag”, an arbitrary name for the
device.) Example: “Stan's device.”
NOTE
Say a paired “device tag” within
10 seconds.
If more than two devices are to be paired,
they cannot be paired with the same or
similar “device tag”.

14. Prompt: “XXXXXX - - - (Ex. “Stan's device”) (Device tag). Is this correct?”
15. Say: [Beep] “Yes”
16. Prompt: “Pairing complete”


After a device is registered, the system
automatically identi fi es the device. By
activating Bluetooth
® Hands-Free again,
or by activating Bluetooth ® Hands-Free
fi rst after switching the ignition from
OFF to ACC, the system reads out a voice
guidance, “XXXXXX - - - (Ex. “Stan's
device”) (Device tag) is connected”.
NOTE
   When the pairing is completed, the
symbol is displayed.
   Some Bluetooth ® audio devices need a
certain amount of time before the

symbol is displayed.
   Device registration can also be done by
operating the audio unit.
  Depending on the device, the
registration status may be lost after a
certain period of time. If this occurs,
repeat the entire process from Step 1.

Registered device read-out
Bluetooth
® Hands-Free can read-out the
devices registered to its system.
NOTE
Do this function only when parked. It is
too distracting to attempt while driving
and you may make too many errors to be
effective.

1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Pairing options”
5. Prompt: “Select one of the following: Pair, Edit, Delete, List, or Set Pairing
Code”
6. Say: [Beep] “List”
CX-5_8FN1-EA-16L_Edition1.indb 392016/12/12 10:06:32

5–40
Interior Features
Audio Set [Type A (non-touchscreen)]
7. Prompt: “XXXXX..., XXXXX..., XXXXX... (Ex. Device A, device B,
device C)” (The voice guidance reads
out the device tags registered to the
hands-free system.)

Press the talk button with a short press during the read-out at the desired
device, and then say one of the
following voice commands to execute
it.
 “Select phone”: Selects device (Mobile phone) when the talk button
is short-pressed.
 “Select music player”: Selects device (Music player) when the talk button
is short-pressed.
 “Edit”: Edits device when the talk button is short-pressed.
 “Continue”: Continues the list readout.
 “Delete”: Deletes the registered device when the talk button is short-
pressed.
 “Previous”: Returns to the previous device in read-out when the talk
button is short-pressed.

8. Prompt: “End of list, would you like to start from the beginning?”
9. Say: [Beep] “No”
10. Prompt: “Returning to main menu.”

Device selection (Bluetooth ®
Hands-Free)
If several devices have been paired, the
Bluetooth ® unit links the device last
paired. If you would like to link a different
paired device, it is necessary to change the
link. The order of device priority after the
link has been changed is maintained even
when the ignition is switched off.
(Hands-free phone)
1. Press the pick-up button or talk button with a short press.
2. Say: [Beep] “Setup”
3. Prompt: “Select one of the following: Pairing options, con fi rmation prompts,
language, passcode, select phone or
select music player.”
4. Say: [Beep] “Select phone”
5. Prompt: “Please say the name of the device you would like to select.
Available devices are XXXXX... (Ex.
device A), XXXXX... (Ex. device B),
XXXXX... (Ex. device C). Which
device please?”
6. Say: [Beep] “XXXXX... (Ex. Device B)”
7. Prompt: “XXXXX... (Ex. Device B). Is this correct?”
8. Say: [Beep] “Yes” or “No”
9. If “Yes”, go to Step 10. If “No”, the procedure returns to Step 5.
10. Prompt: “XXXXX... (Ex. Device B) selected.”

CX-5_8FN1-EA-16L_Edition1.indb 402016/12/12 10:06:32
