2001 NISSAN PICK-UP Repair Manual

Maintenance Schedule for Diesel Engines
(Annual Mileage < 30,000 km/year)
YD25DDTi ENGINE
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary, C = Clean D = Check filter and drain water
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Reference pages Perform on a kilometer basis, but
on an annual basis when driving
less than 20,000 km (12,000
miles) per year.km x 1,000
(miles x 1,000)
Months20
(12)
1240
(24)
2460
(36)
3680
(48)
48100
(60)
60120
(72)
72
Engine compartment and under vehicle
Engine oil (For 2WD or 4WD
appearance 2WD models, use
API CF-4 oil)HRRRRRR3012
Engine oil (For 4WD use API
CF-4 oil)HReplace every 10,000 km (6,000 miles) or 12 months 3012
Engine oil filter (Use Eco filter or
equivalent)HSee NOTE (1)RRRRRR3013
Drive beltsIIIIII3011
Cooling systemIIIIII3016
Engine anti-freeze coolant (Use
genuine NISSAN Anti-freeze
Coolant (L250) or equivalent)See NOTE
(2)I R 3014
Air cleaner filter (Viscous paper
type)HR R R 3019
Air cleaner filter (Dry paper
type)HCRCRCR3019
Cyclone pre-air cleanerHIIIIII3019
Intake & exhaust valve clear-
anceSee NOTE
(3)*1
Fuel lines I I I 3019
Injection nozzlesSee NOTE
(4)*2
Fuel filterHDRDRDR3018
NOTE: (1) Oil filter element assembly (Part No. 15208 AD200) and O-ring seal (Part No. 15226 AD200) are replacement parts.
(2) First replace at 100,000 km (60,000 miles)/60 months, then every 60,000 km (36,000 miles)/36 months. After first
replacement, perform ªIº (checking the mixture ratio and correcting the mixture ratio if necessary) at the middle
of replacement interval.
(3) If valve noise increases, check valve clearance.
(4) If engine power decreases, black exhaust smoke is emitted or engine noise increases, check injection nozzles and
if necessary, replace injection nozzle assembly.
HMaintenance items with ªHº should be performed more frequently according to ªMaintenance Under Severe Driv-
ing Conditionsº.
*1: ªValve Clearance Inspection and Adjustmentº in EM section
*2: ªInjection Tube and Injection Nozzleº in EC section
PERIODIC MAINTENANCE
MA-3003

Maintenance Under Severe Driving
Conditions (Annual Driving Distance < 30,000
km/year)
The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be
performed on the following items as shown in the table.
A Ð Driving in dusty conditions
B Ð Repeatedly driving short distances
C Ð Towing a trailer or caravan
D Ð Extensive idling
E Ð Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F Ð Repeated driving at high speeds and/or at high engine load
Driving condition Maintenance itemMaintenance
operationMaintenance intervalReference
pages
ABCD . .
Engine oil
Petrol models (KA engine) ReplaceEvery 7,500 km (4,500
miles) or 6 monthsÐ
Diesel models
(YD engine)2WD models or
4WD appearance 2WD modelsReplaceEvery 10,000 km (6,000
miles) or 6 months3012
4WD models ReplaceEvery 5,000 km (3,000
miles) or 6 months3012
.....FDiesel models
(YD engine)All 2WD and 4WD versionsCheck oil level,
correct if neces-
saryEvery 5,000 km (3,000
miles)Ð
ABCD . .Engine oil filter
Petrol models (KA engine) ReplaceEvery 7,500 km (4,500
miles) or 6 monthsÐ
Diesel models (YD engine) ReplaceEvery 10,000 km (6,000
miles) or 6 months3013
A.....Air cleaner filter (Viscous paper type)
Petrol models (KA engine) ReplaceEvery 30,000 km (18,000
miles) or 24 months3010
Diesel models (YD engine) ReplaceEvery 20,000 km (12,000
miles) or 12 months3019
A.....Air cleaner filter (Dry paper type)
Diesel models (YD engine)CleanEvery 10,000 km (6,000
miles) or 6 months3019
ReplaceEvery 20,000 km (12,000
miles) or 12 months3019
A.....Cyclone pre-air cleaner
Diesel models (YD engine) Inspect More frequently 3019
A.....Positive crankcase ventilation (PCV) filter
Petrol models (KA engine) ReplaceEvery 15,000 km (9,000
miles) or 12 months3010
A...E.Fuel filter
Petrol models (KA engine) ReplaceEvery 45,000 km (27,000
miles) or 36 monthsÐ
Diesel models (YD engine)ReplaceEvery 20,000 km (12,000
miles) or 12 months3018
Check & drain
waterEvery 10,000 km (6,000
miles) or 6 months3018
PERIODIC MAINTENANCE
MA-3004

Maintenance Schedule for Petrol Engines
(Annual Mileage > 30,000 km/year)
KA24DE ENGINE
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence
pages Perform on a kilometer basis only.km x 1,000
(miles x 1,000)15
(9)30
(18)45
(27)60
(36)75
(45)90
(54)105
(63)120
(72)
Engine compartment and under vehicle
Engine oil (Use SG, SH or SJ oil)HRRRRRRRRÐ
Engine oil filter (Use NISSAN genu-
ine part or equivalent)HRRRRRRRRÐ
Drive beltsIIIIIIIIÐ
Cooling systemIIIIÐ
Engine anti-freeze coolant (Use
genuine NISSAN Anti-Freeze Cool-
ant (L250) or equivalent)See NOTE (1) I R I Ð
Air cleaner filter (Viscous paper
type)HR R 3010
Positive crankcase ventilation (PCV)
filterHR R 3010
Intake & exhaust valve clearance See NOTE (2)Ð
Fuel and EVAP vapor lines I I Ð
Spark plugsRRRRÐ
Ignition wiresIÐ
Fuel filterHRÐ
NOTE: (1) First replace at 90,000 km (54,000 miles), then every 60,000 km (36,000 miles). Perform ªIº (checking the mixture
ratio and correcting the mixture ratio if necessary) at the middle of replacement interval.
(2) Periodic maintenance is not required. However, if valve noise increases, check valve clearance.
HMaintenance items with ªHº should be performed more frequently according to ªMaintenance Under Severe Driv-
ing Conditionsº.
PERIODIC MAINTENANCE
MA-3005

Maintenance Schedule for Diesel Engines
(Annual Mileage > 30,000 km/year)
YD25DDTi ENGINE
Abbreviations: R = Replace I = Inspect: Correct or replace if necessary, C = Clean D = Check filter and drain water
MAINTENANCE OPERATIONMAINTENANCE INTERVAL
Refer-
ence
pages Perform on a kilometer basis only.km x 1,000
(miles x 1,000)20
(12)40
(24)60
(36)80
(48)100
(60)120
(72)
Engine compartment and under vehicle
Engine oil (For 2WD models or
4WD appearance 2WD models,
use API CF-4 oil)HRRRRRR3012
Engine oil (For 4WD models, use
API CF-4 oil)HReplace every 10,000 km (6,000 miles) 3012
Engine oil filter (Use Eco filter or
equivalent)HSee NOTE (1)RRRRRR3013
Drive beltsIIIIII3011
Cooling systemIIIIII3016
Engine anti-freeze coolant (Use
genuine NISSAN Anti-Freeze Cool-
ant (L250) or equivalent)See NOTE (2) I R 3014
Air cleaner filter (Viscous paper
type)HR R 3019
Air cleaner filter (Dry paper type)HCRCRCR3019
Cyclone pre-air cleanerHIIIIII3019
Intake & exhaust valve clearance See NOTE (3)*1
Fuel linesI I 3019
Injection nozzles See NOTE (4)*2
Fuel filterHDDRDDR3018
NOTE: (1) Oil filter element assembly (Part No. 15208 AD200) and O-ring seal (Part No. 15226 AD200) are replacement parts.
(2) First replace at 100,000 km (60,000 miles), then every 60,000 km (36,000 miles). After first replacement, perform
ªIº (checking the mixture ratio and correcting the mixture ratio if necessary) at the middle of replacement inter-
val.
(3) If valve noise increases, check valve clearance.
(4) If engine power decreases, black exhaust smoke is emitted or engine noise increases, check injection nozzles and
if necessary, replace injection nozzle assembly.
HMaintenance items with ªHº should be performed more frequently according to ªMaintenance Under Severe Driv-
ing Conditionsº.
*1: ªValve Clearance Inspection and Adjustmentº in EM section
*2: ªInjection Tube and Injection Nozzleº in EC section
PERIODIC MAINTENANCE
MA-3006

Maintenance Under Severe Driving
Conditions (Annual Driving Distance > 30,000
km/year)
The maintenance intervals shown on the preceding pages are for normal operating conditions. If the vehicle
is mainly operated under severe driving conditions as shown below, more frequent maintenance must be
performed on the following items as shown in the table.
A Ð Driving in dusty conditions
B Ð Repeatedly driving short distances
C Ð Towing a trailer or caravan
D Ð Extensive idling
E Ð Driving in extremely adverse weather conditions or in areas where ambient temperatures are either
extremely low or extremely high
F Ð Repeated driving at high speeds and/or at high engine load
Driving condition Maintenance itemMaintenance
operationMaintenance intervalReference
pages
ABCD ..
Engine oil
Petrol models (KA engine) ReplaceEvery 7,500 km
(4,500 miles)Ð
Diesel models
(YD engine)2WD models or
4WD appearance 2WD modelsReplaceEvery 10,000 km
(6,000 miles)3012
4WD models ReplaceEvery 5,000 km
(3,000 miles)3012
.....FDiesel models
(YD engine)All 2WD and 4WD versionsCheck oil level,
correct if neces-
saryEvery 5,000 km
(3,000 miles)Ð
ABCD ..Engine oil filter
Petrol models (KA engine) ReplaceEvery 7,500 km
(4,500 miles)Ð
Diesel models (YD engine) ReplaceEvery 10,000 km
(6,000 miles)3013
A.....Air cleaner filter (Viscous paper type)
Petrol models (KA engine) ReplaceEvery 30,000 km
(18,000 miles)3010
Diesel models (YD engine) ReplaceEvery 30,000 km
(18,000 miles)3019
A.....Air cleaner filter (Dry paper type)
Diesel models (YD engine)CleanEvery 10,000 km
(6,000 miles)3019
ReplaceEvery 20,000 km
(12,000 miles)3019
A.....Cyclone pre-air cleaner
Diesel models (YD engine) Inspect More frequently 3019
A.....Positive crankcase ventilation (PCV) filter
Petrol models (KA engine) ReplaceEvery 30,000 km
(18,000 miles)3010
A...E.Fuel filter
Petrol models (KA engine) ReplaceEvery 45,000 km
(27,000 miles)Ð
Diesel modelsReplaceEvery 30,000 km
(18,000 miles)3018
Check & drain
waterEvery 10,000 km
(6,000 miles)3018
PERIODIC MAINTENANCE
MA-3007

Fluids and Lubricants
Capacity (Approximate)
Recommended Fluids/Lubricants
LiterImp
measure
Engine oil (Refill)
With oil filter
Gasoline engine: API SG, SH or SJ*1
ILSAC grade GF-I or GF-II*1
Diesel engine: API CD, CE, CF, CF-4 for TD engine*1,
*5
ACEA B3-96, 98 or ACEA B3/E3 96, 98 for TD engine*4
API CF-4 for YD engine*1, *5
ACEA 98-B1 for YD engine KA24DE2WD 3.6
4WD 4.13-1/8 qt
3-5/8 qt
YD25DDTi2WD 5.6 *7
4WD 4.34-7/8 qt *7
3-3/4 qt
Without oil filter
KA24DE2WD 3.3
4WD 3.82-7/8 qt
3-3/8 qt
YD25DDTi2WD 5.3 *7
4WD 4.04-5/8 qt *7
3-1/2 qt
Cooling system (With reservoir)
KA24DE 6.9 6-1/8 qt
Genuine Nissan Anti-freeze Coolant (L250)
or equiva-
lent*6
YD25DDTi 8.6 7-5/8 qt
Manual transmission
gear oilFS5R30A2WD 2.8
4WD 5.14-7/8 pt
9pt
API GL-4, Viscosity SAE 75W-85 only
FS5W71C2WD 2.0
4WD 4.93-1/2 pt
8-5/8 pt
Transfer fluid TX10A 2.2 2 qt Genuine Nissan ATF or equivalent*2 or API GL-4*1
Differential gear oil
Front R180A 1.3 2-1/4 pt
Standard differential gear: API GL-5*1
Limited-slip differential (LSD) gear: Gear Oil Hypoid
LSD or equivalent*3 Rear C200 1.3 2-1/4 pt
Power steering fluid Ð Ð Type DEXRON
TMIII or equivalent
Brake and clutch fluid Ð Ð DOT 3 or DOT 4 (U.S. FMVSS No. 116)
Propeller shaft grease Ð Ð NLGI No. 2 (Lithium soap base)
Multi-purpose grease Ð Ð NLGI No. 2 (Lithium soap base)
*1: For further details, see ªSAE Viscosity Numberº.
*2: Contact a NISSAN dealership for more information regarding suitable fluid, including recommended brand(s) of DEXRONTMIII/MERCONTMAuto-
matic Transmission Fluid.
*3: API GL-5, SAE 140 and 10% volume of LSD Friction Modifier (Part No.: 38469-C6000) is an equivalent.
*4: If ACEA B3-96, 98 oils are not available, API CD, CE, CF, CF-4 oil may be used. However, ACEA oils are strongly recommended if at all possible.
*5: Never use CG-4 grade oil.
*6: Use Nissan Genuine Anti-freeze Coolant (L250), or equivalent in its quality,
in order to avoid possible aluminum corrosion within the engine cool-
ing system caused by the use of non-genuine engine coolant.
Note that any repairs for the incidents within the engine cooling system while using non-genuine engine coolant may not be covered by
the warranty even if such incidents occurred during the warranty period.
*7: Including 4WD appearance 2WD models.
RECOMMENDED FLUIDS AND LUBRICANTS
MA-3008

SAE Viscosity Number
+For warm and cold areas: 75W-90 for trans-
fer and 80W-90 for differential are prefer-
able.
+For hot areas: 90 is suitable for ambient
temperatures below 40ÉC (104ÉF).
+For extremely hot areas:
140 for differential is preferable.
SLIA0015E
RECOMMENDED FLUIDS AND LUBRICANTS
MA-3009

Changing Air Cleaner Filter
VISCOUS PAPER TYPE
The viscous paper type filter does not need cleaning
between renewals.
Changing Positive Crankcase Ventilation
(PCV) Filter
Remove air cleaner cover and take out PCV filter located inside
air cleaner cover. Then install new PCV filter.
SMA243C
SMA167D
ENGINE MAINTENANCEKA24DE
MA-3010
