2001 NISSAN PICK-UP Repair Manual

Special Service Tools (YD25DDTi engine)
Tool number
Tool nameDescription
ST0501S000
Engine stand assembly
1 ST05011000
Engine stand
2 ST05012000
Base
NT042
Disassembling and assembling
KV10106500
Engine stand shaft
NT028
KV11105900
Engine sub-attachment
NT799
KV10115900 has been replaced with
KV10106500.
KV10115600
Valve oil seal drift
NT603
Installing valve oil seal
Use side A.
Side A
a: 20 (0.79) dia.
b: 13 (0.51) dia.
c: 10.3 (0.406) dia.
d: 8 (0.31) dia.
e: 10.7 (0.421)
f: 5 (0.20)
Unit: mm (in)
KV10107902
Valve oil seal puller
1 KV10116100
Valve oil seal puller adapter
NT605
Removing valve oil seal
KV11103000
Injection pump drive gear
puller
NT676
Removing crankshaft pulley
PREPARATION
EM-3004

Tool number
Tool nameDescription
KV101056S0
Ring gear stopper
1 KV10105630
Adapter
2 KV10105610
Plate
NT617
Preventing crankshaft from rotating
a: 3 (0.12)
b: 6.4 (0.252)
c: 2.8 (0.110)
d: 6.6 (0.260)
e: 107 (4.21)
f: 14 (0.55)
g: 20 (0.79)
h: 14 (0.55) dia.
Unit: mm (in)
KV101151S0
Lifter stopper set
1 KV10115110
Camshaft pliers
2 KV10115120
Lifter stopper
NT041
Changing valve lifter shims
ST16610001
Pilot bushing puller
NT045
Removing crankshaft pilot bushing
KV10111100
Seal cutter
NT046
Removing steel oil pan and rear timing chain
case
WS39930000
Tube presser
NT052
Pressing the tube of liquid gasket
KV10112100
Angle wrench
NT014
Tightening bolts for bearing cap, cylinder head,
etc.
KV10109300
Pulley holder
NT628
a: 68 mm (2.68 in)
b: 8 mm (0.31 in) dia.
PREPARATION
Special Service Tools (YD25DDTi engine)
(Cont'd)
EM-3005

Tool number
Tool nameDescription
KV11106010
Hexagon wrench
NT801
a: 5 mm (0.20 in) (Face to face)
b: 20 mm (0.79 in)
KV11106020
Hexagon wrench
NT803
a: 6 mm (0.24 in) (Face to face)
b: 20 mm (0.79 in)
KV11106030
Positioning stopper pin
NT804
a: 6 mm (0.24 in) dia.
b: 80 mm (3.15 in)
KV11106040
TORX wrench
NT805
a: T70
b: 26 mm (1.02 in)
KV11106050
Hexagonal wrench
SBIA0224E
a: 6 mm (0.24 in) (Face to face)
b: 42 mm (1.65 in)
Removing and installing mounting bolts of fuel
injection pump sprocket
PREPARATION
Special Service Tools (YD25DDTi engine)
(Cont'd)
EM-3006

Commercial Service Tools (YD25DDTi
engine)
Tool name Description
Valve seat cutter set
NT048
Finishing valve seat dimensions
Piston ring compressor
NT044
Installing piston assembly into cylinder bore
Piston ring expander
NT030
Removing and installing piston ring
TORX socket
NT807
Standard Universal
NT808
PREPARATION
EM-3007

SEM881G
OUTER COMPONENT PARTSKA24DE
EM-3008

V1Spark plug
V2Ignition wire
V3Camshaft position sensor built
into distributor
V4Heated oxygen sensor 1 (front)
V5Exhaust manifold
V6Exhaust manifold cover
V7Water drain plug
V8TWC (manifold)
SEM882G
OUTER COMPONENT PARTSKA24DE
EM-3009

SEM883G
OUTER COMPONENT PARTSKA24DE
EM-3010

NVH Troubleshooting Ð Engine Noise
SEM862G
NOISE, VIBRATION, AND HARSHNESS (NVH)
TROUBLESHOOTINGYD25DDTi
EM-3011
