2001 NISSAN PICK-UP Repair Manual

Wiring Diagram Ð CHARGE Ð/Diesel Engine
GEL368A
CHARGING SYSTEM
EL-3018

Wiring Diagram Ð CHARGE Ð (KA engine)
GEL238A
CHARGING SYSTEM
EL-3019

Construction
SEL544V
MEL704P
CHARGING SYSTEM
EL-3020

Service Data and Specifications (SDS)
ALTERNATOR
TypeA5TA5271 A7TA8471 A5TA5372 A3TB0699 LR160-745 LR160-728E
MITSUBISHI HITACHI
Applied model KA24DEZ24
YD25 ZD30 TD27, QD32
Standard Option*
Nominal rating V-A 12-70 12-35 12-70 12-90 12-60
Ground polarityNegative
Minimum revolution under no-
load
(When 13.5V is applied) rpmLess than 1,300 Less than 1,000
Hot output current
(When 13.5V is applied) A/rpmMore than
14/1,300
More than
54/2,500More than
27/2,500More than
18/1,300
More than
51/2,500More than
29/1,300
More than
76/2,500
More than
88/5,000More than
17/1,300
More than
48/2,500
More than
57/5,000
Regulated output voltage V 14.1 - 14.7
Minimum length of brush
mm (in)5.0 (0.20) 6.0 (0.236)
Brush spring pressure
N (g, oz)4.8 - 6.0 (487 - 612, 17.25 - 21.59) 1.0 - 3.43 (102 - 350, 3.60 - 12.34)
Slip ring minimum outer diameter
mm (in)22.1 (0.870) 26.0 (1.024)
Rotor (Field coil) resistanceW2.5 - 2.9 2.7 - 3.2 2.5 - 2.9 2.1 - 2.5 2.6 2.58
*: Models with power steering and air conditioner
CHARGING SYSTEM
EL-3022

Wiring Diagram Ð H/LAMP Ð/LHD Models
GEL239A
HEADLAMP Ð Conventional Type Ð
EL-3023

GEL240A
HEADLAMP Ð Conventional Type Ð
Wiring Diagram Ð H/LAMP Ð/LHD Models
(Cont'd)
EL-3024

Wiring Diagram Ð H/LAMP Ð/RHD Models
GEL369A
HEADLAMP Ð Conventional Type Ð
EL-3025
