Page 433 of 1378

JEEP CHEROKEE 1988 Service Repair Manual 9) If difficulty is encountered when making these
adjustments, horizontal alignment should be checked. Even though
vertical alignment is correct, horizontal alignment can be badly out
of adju

Page 434 of 1378

JEEP CHEROKEE 1988 Service Repair Manual framing squares to align straightedge with side rails.
12) Measure distance "X" at each side. If both measurements
are not within 1/16" (1.6 mm) of each other, transmission flange is
horizont

Page 435 of 1378

$JEEP CHEROKEE 1988 Service Repair Manual \003 * D RIV ETR AIN S YSTE M S U NIF O RM IN SPEC TIO N G UID ELIN ES * 1988 Jeep Cherokee GENERAL INFORMATION Drivetrain/Transmission Motorist Assurance Program Stan$

Page 436 of 1378

JEEP CHEROKEE 1988 Service Repair Manual FLANGES
FLEX PLATES
FLUID LEVEL INDICATORS
FLUIDS AND LUBRICANTS
FLYWHEELS
FORCE MOTORS
GUIDES
HALF SHAFTS
HOSE

Page 437 of 1378

JEEP CHEROKEE 1988 Service Repair Manual VEHICLE SPEED SENSORS
VENTS
VIBRATION DAMPERS
WHEEL ATTACHMENT HARDWARE
WHEEL SPEED SENSORS
WIRING HARNESSES AND CONNECTORS
YOKES A

VEHICLE SPEED SENSORS
VENTS
VIBRATION DAMPERS
WHEEL ATTACHMENT HARDWARE
WHEEL SPEED SENSORS
WIRING HARNESSES AND CONNECTORS
YOKES AND SLIP YOKES
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
(1) a Pledge of Assurance to their Customers and (2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection were recently published.
Further, revisions to all of these inspection communication standards
are continually republished. In addition to these, standards for Drive
Train and Transmissions have recently been promulgated. Participating
shops utilize these Uniform Inspection & Communication Standards as
part of the inspection process and for communicating their findings to
their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method

Page 438 of 1378

JEEP CHEROKEE 1988 Service Repair Manual has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and you

has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
required because the part in question is no longer providing the
function for which it is intended, does not meet a vehicle
manufacturer's design specification or is missing.
Example:
An exhaust pipe has corroded severely and has a hole
in it through which exhaust gases are leaking. Replacement
of the exhaust pipe in this case is required due to
functional failure.
Example:
A brake rotor has been worn to the point where it measures
less than the vehicle manufacturer's discard specifications.
Replacement of the rotor is required because it does not meet
design specifications.
Some conditions indicate that a service or part replacement
is suggested because the part is close to the end of its useful life
or addresses a customer's need, convenience or request. If a
customer's vehicle has one of these conditions, the procedure may be
only to suggest service.

Page 439 of 1378

JEEP CHEROKEE 1988 Service Repair Manual Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the p

Example:
An exhaust pipe is rusted, corroded or weak, but no leaks are
present. In this case, the exhaust pipe has not failed.
However, there is evidence that the pipe may need replacement
in the near future. Replacement of the pipe may be suggested
for the customer's convenience in avoiding a future problem.
Example:
The customer desires improved ride and/or handling, but the
vehicle's shocks or struts have not failed. In this case,
replacement may be suggested to satisfy the customer's
wishes. In this case, replacement of the shocks or struts may
not be sold as a requirement.
A customer, of course, has the choice of whether or not a
shop will service his or her vehicle. He or she may decide not to
follow some of your suggestions. When a repair is required, a MAP shop
must refuse partial service on that system if, in the judgment of the
service provider, proceeding with the work could create or continue an
unsafe condition. When a procedure states that required or suggested
repair or replacement is recommended, the customer must be informed of
the generally acceptable repair/replacement options whether or not
performed by the shop.
When presenting suggested repairs to the customer, you must
present the facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
The following reasons may be used for required and suggested
services. These codes are shown in the "Code" column of the MAP
Uniform Inspection & Communications Standards that follow:
Reasons to Require Repair or Replacement
A - Part no longer performs intended purpose
B - Part does not meet a design specification (regardless of
performance)
C - Part is missing
NOTE: When a repair is required, the shop must refuse partial
service to the system in question, if the repair creates
or continues an unsafe condition.
Reasons to Suggest Repair or Replacement
1 - Part is close to the end of its useful life (just above
discard specifications, or weak; failure likely to occur
soon, etc.)
2 - To address a customer need, convenience, or request (to
stiffen ride, enhance performance, eliminate noise, etc.)
3 - To comply with maintenance recommended by the vehicle's
Original Equipment Manufacturer (OEM)
4 - Technician's recommendation based on substantial and
informed experience
NOTE: Suggested services are always optional. When presenting
suggested repairs to the customer, you must present the
facts, allowing the customer to draw their own conclusions
and make an informed decision about how to proceed.
DRIVE/POWER TRAIN ASSEMBLIES
SERVICE PROCEDURES REQUIRED AND SUGGESTED FOR PROPER
VEHICLE OPERATION

Page 440 of 1378

JEEP CHEROKEE 1988 Service Repair Manual NOTE: Whenever transmission or drivetrain service is performed
that affects the suspension alignment, for example,
removing the engine cradle, it is required that the
ali

NOTE: Whenever transmission or drivetrain service is performed
that affects the suspension alignment, for example,
removing the engine cradle, it is required that the
alignment be checked and corrected if necessary.
AUTOMATIC TRANSMISSION/TRANSAXLE ASSEMBLIES
AUTOMATIC TRANSMISSION/TRANSAXLE ASSEMBLY INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Any internal component
failure that requires
removal of the assembly
from the vehicle for
service. ( 1) ........... A ........... ( 2) Require repair or
replacement of the automatic
transmission/transaxle
assembly.
( 1) - It is Required that the torque converter and all other
failure related components be inspected for cause and
condition.
( 2) - For components not requiring removal of the assembly,
refer to the component listing in this document.
\
\
\
\
\
\
\

DIFFERENTIAL AND FINAL DRIVE ASSEMBLIES
NOTE: Does not include half shafts.
DIFFERENTIAL AND FINAL DRIVE ASSEMBLY INSPECTION
\
\
\
\
\
\
\

Condition Code Procedure
Any internal component
failure that requires
removal of the assembly
from the vehicle for
service. ( 1) ........... A ... Require repair or replacement
of the differential assembly.
( 1) - For components not requiring removal of the assembly,
refer to the component listing in this document.
\
\
\
\
\
\
\

MANUAL TRANSMISSION/TRANSAXLE ASSEMBLIES
MANUAL TRANSMISSION/TRANSAXLE ASSEMBLY INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Any internal component
failure that requires
removal of the assembly
from the vehicle for
service. ( 1) ........... A ... Require repair or replacement
of the manual
transmission/transaxle
assembly.
( 1) - For components not requiring removal of the assembly,

Load next 8 pages

Page: < prev 1-10 ... 401-408 409-416 417-424 425-432 433-440 441-448 449-456 457-464 465-472 ... 1384 next >

wiper fluid adblue headrest open bonnet child seat high beam
