EN G IN E R EM OVA L - 4 -C YL

1988 J e ep C hero ke e
1988 ENGINES
Jeep - Engine Removal - 4-Cylinder
Cherokee, Comanche, Wrangler
4-CYLINDER ENGINES
2.5L
1) Disconnect negative battery cable. Drain cooling system.
Remove air cleaner, lower radiator hose, fan shroud, and engine
compartment light from hood. Scribe hinge locations and remove hood.
Disconnect automatic transmission cooler lines at radiator (if
equipped).
2) Remove upper radiator hose, fan assembly and coolant
recovery hose. Remove radiator and A/C condenser (if equipped). Hold
fan pulley to water pump flange using 5/16" x 1/2" SAE capscrew.
Disconnect heater hoses, throttle linkages, cruise control cable (if
equipped) and Throttle valve rod.
3) Disconnect wires from starter and separate CEC system
wiring harness connector. Disconnect fuel pipe from fuel pump and fuel
return hose from fuel filter. Disconnect hoses from A/C compressor and
power steering pump (if equipped). Drain power steering pump
reservoir. Cap all fittings and hose ends.
4) Remove vacuum check valve from brake booster (if
equipped). Tag and remove all wiring and vacuum lines connected to
engine or accessories. Raise vehicle and remove starter. Disconnect
exhaust pipe from manifold.
5) Remove converter/flywheel housing cover. Remove engine
mount nuts at bracket side. On automatic transmission models, index
mark drive plate and torque converter. Remove drive plate-to-converter
bolts.
6) Remove upper and loosen lower bellhousing-to-engine bolts.
Attach lifting equipment to engine. Raise engine off front mounts,
Place support under bellhousing. Remove remaining bellhousing-to-
engine bolts. Lift engine out of engine compartment.
NOTE: Engine mount pads may be removed from engine brackets to
align engine and transmission during installation.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE








\









\









\









\









\









\






Application Ft. Lbs. (N.m)
Clutch Housing-to-Block Bolts .................... 55 (75)
Drive Plate-to-Converter ......................... 26 (35)
Flywheel Bolts ............................... ( 1) 50 (68)
Front Support Bracket-to-Block ................... 45 (61)
Front Support Cushion-to-Crossmember ............. 33 (45)
Rear Support Bracket-to-Transmission ............. 33 (45)
Rear Support Cushion-to-Bracket .................. 30 (41)
Starter Motor-to-Block ........................... 33 (45)
( 1) - Tighten an additional 60 degrees.









\









\









\









\









\









\

\003
EN G IN E R EM OVA L - 6 -C YL

1988 J e ep C hero ke e
1988 ENGINES
Jeep - Engine Removal - 6-Cylinder
Cherokee, Comanche, Wagoneer, Wrangler
6-CYLINDER ENGINES
4.0L
1) Scribe hinge locations, remove engine compartment light
(if equipped) and remove hood. Disconnect battery cables and remove
battery. Drain cooling system.
2) Disconnect wire connectors from alternator, ignition coil
and distributor. Disconnect oil pressure sender wire, starter wires
and fuel injector wiring harness (if equipped). Detach 2 fuel pipe
quick connect couplings at left inner fender panel. Disconnect engine
ground strap and remove air cleaner.
3) Disconnect the vacuum purge hose at fuel vapor canister
tee. Disconnect wire from idle speed actuator and oxygen sensor.
Detach throttle cable from bracket and disconnect throttle valve rod
at bellcrank. Remove upper and lower radiator hoses.
4) On automatic transmission models, disconnect the
transmission fluid cooler tubing. On all models, remove fan shroud and
radiator. Remove fan and spacer or Tempatrol fan assembly. Hold fan
pulley to water pump flange using 5/16" x 1/2" SAE capscrew while
crankshaft is rotated.
5) Disconnect cruise control cable (if equipped). Disconnect\
wires from starter motor solenoid and disconnect CEC system harness.
Remove power brake vacuum check valve from booster (if equipped).
6) Disconnect power steering hoses from steering gear (if
equipped). Drain power steering pump reservoir and plug end of hoses.
Cap all fittings on steering gear and hoses. Raise and support
vehicle. Remove starter. Remove flywheel housing access cover.
7) Remove upper and loosen lower bellhousing-to-engine bolts.
Attach lifting equipment to engine. Raise engine off front mounts.
Place support under bellhousing. Remove remaining bellhousing-to-
engine bolts. Lift engine out of engine compartment.
4.2L
1) Remove battery and drain cooling system. Remove air
cleaner and engine compartment light from hood. Scribe hinge location
and remove hood. Disconnect and plug front fuel line at pump and fuel
return line at frame.
2) Disconnect heater hoses at heater. Label and disconnect
all wiring, lines, linkage and hoses at engine. Remove vacuum switch
assembly bracket from cylinder head cover. Remove both radiator hoses
and automatic transmission oil lines (if equipped) at radiator. Remove\
radiator and shroud.
3) Remove fan and spacer. Use 5/16" x 1/2" SAE bolt to hold
fan pulley to water pump flange. Remove starter and disconnect engine
ground strap. Remove engine mount-to-bracket nuts. Disconnect exhaust
pipe at manifold.
4) Discharge A/C system (if equipped). Disconnect and plug
hose or port openings at compressor. Disconnect hoses at power
steering gear and drain reservoir. Remove power brake vacuum check
valve. Remove bracket bolt for automatic transmission filler tube (if
equipped).
5) Lift and support vehicle. On models with automatic

transmission, remove converter housing cover. Index mark converter and
driven plate for reassembly. Remove driven plate-to-converter bolts,
rotating crankshaft to access each bolt. Remove oil pan bolts holding
automatic transmission oil lines. On Wrangler models, remove exhaust
pipe support brace at converter housing.
6) On manual transmission models, remove flywheel housing
cover. Remove inner support bolts for clutch release arm. Disconnect
springs and remove clutch release arm. Remove outer bracket retainer
for release lever rod. On all models, remove upper and loosen lower
bellhousing bolts.
7) Lower vehicle. Support transmission. If A/C equipped,
remove idler pulley and mounting bracket. Attach lifting equipment to
engine. Raise engine off front mounts and support transmission. Remove
lower bellhousing bolts. Lift engine from compartment while pulling
forward.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE








\









\









\









\









\









\






Application Ft. Lbs. (N.m)
Automatic Transmission-to-Block .................. 28 (38)
Clutch Housing-to-Block
Top ............................................ 27 (37)
Bottom ......................................... 43 (58)
Drive Plate-to-Converter ......................... 22 (30)
Drive Plate/Flywheel-to-Crankshaft ............. 105 (143)
Front Support Bracket-to-Block ................... 35 (47)
Front Support Cushion-to-Bracket ................. 33 (45)
Front Support Cushion-to-Crossmember ............. 37 (50)
Rear Support Bracket-to-Transmission ............. 33 (45)
Rear Support Cushion-to-Bracket .................. 30 (41)
Starter Motor-to-Converter Housing ............... 18 (24)









\









\









\









\









\









\

\003
* E N G IN E S YSTE M S U NIF O RM IN SPEC TIO N G UID ELIN ES *

1 988 J e ep C hero ke e
GENERAL INFORMATION
Engine Performance and Maintenance Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
Engine Assemblies
CYLINDER HEAD ASSEMBLIES
LONG BLOCK ASSEMBLIES
SHORT BLOCK ASSEMBLIES
Engine Components
ACCELERATOR PEDAL POSITION SENSORS
ACCESSORY BELTS
ACCESSORY PULLEYS
ACTUATORS
AIR CONDITIONING CYCLING SWITCHES
AIR CONDITIONING PRESSURE SENSORS
AIR DUCTS AND TUBES
AIR FILTER ELEMENTS
AIR FILTER GASKETS
AIR FILTER HOUSINGS AND GASKETS
AIR FUEL RATIO SENSORS
AIR INJECTION CONTROL SOLENOIDS
AIR PLENUMS
AIR PUMP BELTS
AIR PUMPS (ELECTRIC-DRIVEN)
AIR TUBES
ASPIRATOR, CHECK AND DECEL VALVES
BAFFLES
BALLAST PRIMARY SUPPLY RESISTOR WIRES
BALLAST RESISTORS AND PRIMARY SUPPLY RESISTOR WIRES
BAROMETRIC PRESSURE SENSORS
BATTERIES
BATTERY CABLES, WIRES AND CONNECTORS
BATTERY CONNECTORS
BATTERY TRAYS AND HOLD DOWN HARDWARE
BATTERY WIRES
BELT-DRIVEN AIR PUMPS
BELT IDLER ASSEMBLIES (ACCESSORY AND CAM BELTS)
BELT TENSIONERS (ACCESSORY AND CAM BELTS)
BOOST CONTROL MECHANISMS
CAMSHAFT POSITION SENSORS
CARBURETORS AND CHOKES
CASTING CORE PLUGS AND EXPANSION PLUGS
CHARGE AIR COOLERS "INTERCOOLERS" (CAC)
CHECK VALVES
CHOKES

CLUTCH PEDAL POSITION SWITCHES
COLD START INJECTORS
CONNECTORS
COOLANT
COOLANT RECOVERY TANKS
COOLING FAN MOTOR MODULES
COOLING FAN MOTOR RELAYS AND MODULES
COOLING FAN MOTOR RESISTORS
COOLING FAN MOTOR SENSORS AND SWITCHES
COOLING FAN MOTOR SWITCHES
COOLING FAN MOTORS
CRANKSHAFT POSITION SENSORS
DECEL VALVES
DEFLECTORS
DIP STICKS AND TUBES
DIP STICK TUBES
DISTRIBUTOR ADVANCES AND RETARDERS (MECHANICAL AND VACUUM)
DISTRIBUTOR BOOTS AND SHIELDS
DISTRIBUTOR CAPS
DISTRIBUTOR RETARDERS (MECHANICAL AND VACUUM)
DISTRIBUTOR ROTORS
DISTRIBUTOR SHIELDS
DISTRIBUTORS
EARLY FUEL EVAPORATION VALVES (HEAT RISER ASSEMBLIES)
EGR COOLERS
EGR EXHAUST MANIFOLD PASSAGES
EGR INTAKE AND EXHAUST MANIFOLD PASSAGES
EGR PLATES AND COOLERS
ELECTRONIC SPARK CONTROL MODULES
ELECTRONIC TRANSMISSION CONTROL DEVICES
ELECTRONIC TRANSMISSION FEEDBACK DEVICES
ENGINE COOLANT TEMPERATURE SENSORS
ENGINE COOLING SYSTEMS
ENGINE COVERS (OIL PAN, VALVE COVER, TIMING COVER)
ENGINE OIL
ENGINE OIL CANISTERS
ENGINE OIL COOLERS (EXTERNAL)
ENGINE OIL DRAIN PLUGS AND GASKETS
ENGINE OIL FILTERS AND CANISTERS
ENGINE OIL GASKETS
ENGINE OIL PRESSURE GAUGES (MECHANICAL)
EVAPORATIVE EMISSION (EVAP) CANISTER FILTERS
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE DEVICES
EVAPORATIVE EMISSION (EVAP) CANISTERS
EVAPORATIVE EMISSION (EVAP) FEEDBACK DEVICES
EXHAUST GAS RECIRCULATION DEVICES
EXHAUST GAS RECIRCULATION FEEDBACK DEVICES
EXPANSION PLUGS
FAN CONTROL SENSORS
FUEL
FUEL ACCUMULATORS AND DAMPERS
FUEL AND COLD START INJECTORS
FUEL DAMPERS
FUEL DELIVERY CHECK VALVES
FUEL DISTRIBUTORS (BOSCH CIS)
FUEL FILLER NECKS AND RESTRICTORS
FUEL FILTERS
FUEL INJECTORS
FUEL LEVEL SENDERS7
FUEL PRESSURE REGULATORS
FUEL PUMPS (IN-TANK AND EXTERNAL, ELECTRICAL OR MECHANICAL)
FUEL RAILS
FUEL RESTRICTORS

FUEL TANKS
GAS CAPS
GASKETS
GROMMETS (VALVE COVER)
HARMONIC DAMPERS
HEATER CONTROL VALVES
HEATER CORES
HOSE AND TUBE COUPLERS, CONNECTORS AND CLAMPS
HOSE CLAMPS
HOSE CONNECTORS
HOSE COUPLERS
HOSES AND TUBES (FUEL LINES, RADIATOR, VACUUM, BY PASS,
HEATER, RECOVERY TANK AND OIL COOLERS)
HOUSINGS
IDLE AIR CONTROLS
IDLE SPEED CONTROL ACTUATORS
IGNITION BOOTS
IGNITION COIL TOWERS
IGNITION COILS
IGNITION CONTROL MODULES (ICM)
IGNITION SWITCHES
IGNITION TERMINALS
IGNITION WIRES, BOOTS, COIL TOWERS AND TERMINALS (SECONDARY)
IN-TANK FUEL STRAINERS
INERTIA FUEL SHUT-OFF SWITCHES
INTAKE AIR TEMPERATURE SENSORS
INTAKE MANIFOLDS
INTERCOOLERS
KNOCK SENSORS
LIQUID VAPOR SEPARATORS
MANIFOLD ABSOLUTE PRESSURE (MAP) SENSORS
MASS AIR FLOW (MAF) SENSORS
METAL AIR MANIFOLDS AND PIPES
METAL AIR PIPES
MIX CONTROL SOLENOIDS
MOTOR MOUNTS
O-RINGS, GASKETS, SEALS AND SPRING LOCKS
O2 SENSORS
OIL PRESSURE SENDING UNITS
OIL PUMP PICK-UP SCREENS
OIL PUMPS
PARK NEUTRAL POSITION SWITCHES
PCV BREATHER ELEMENTS
PCV ORIFICES
PCV VALVES
PICK-UP ASSEMBLIES (INCLUDES MAGNETIC, HALL EFFECT AND
OPTICAL)
POWER STEERING PRESSURE SENSORS
POWERTRAIN CONTROL MODULES (PCM) AND PROM
POWERTRAIN CONTROL PROM
PRESSURIZED EXPANSION TANK CAPS
RADIATOR CAPS AND PRESSURIZED EXPANSION TANK CAPS
RADIATOR FAN BLADES
RADIATOR FAN CLUTCHES
RADIATORS
ROLL OVER VALVES
SEALING COMPOUNDS
SEALS
SECONDARY AIR INJECTION SYSTEM MANAGEMENT DEVICES
SENSORS AND ACTUATORS
SHROUDS, BAFFLES AND DEFLECTORS
SPARK PLUGS
SPRING LOCKS

SUPER CHARGERS
SWITCHES
THERMAL VACUUM VALVES
THERMOSTATIC AIR DOOR ASSEMBLIES
THERMOSTATS AND HOUSINGS
THROTTLE BODIES
THROTTLE CABLES
THROTTLE LINKAGES AND CABLES
THROTTLE POSITION SENSORS
THROTTLE POSITION SWITCHES
TIMING BELT SPROCKETS
TIMING BELTS
TORQUE STRUTS
TRANSMISSION RANGE SWITCHES
TUBE CLAMPS
TUBE CONNECTORS
TUBE COUPLERS
TUBES
TURBO CHARGERS
VACUUM CONNECTIONS
VACUUM HOSES, TUBES AND CONNECTIONS (NON-METALLIC)
VACUUM REGULATOR SOLENOIDS
VACUUM TUBES
VEHICLE SPEED SENSORS
VOLUME AIR FLOW SENSORS
WASTE GATE CONTROL SOLENOIDS
WASTE GATES AND BOOST CONTROL MECHANISMS
WATER PUMPS (ELECTRIC)
WATER PUMPS (NON-ELECTRIC)
WIRING HARNESSES AND CONNECTORS
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
(1) a Pledge of Assurance to their Customers and (2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
