JEEP CHEROKEE 1988 Service Repair Manual Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replaceme

Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Determine source of contamination, such as engine coolant,
fuel, metal particles, or water. Require repair or
replacement.
( 3) - Inoperative includes intermittent operation or out of
OEM specification. Some components may be serviceable;
check for accepted cleaning procedure.
\
\
\
\
\
\
\

VOLUME AIR FLOW SENSORS
VOLUME AIR FLOW SENSOR INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of hardware.
Attaching hardware
threads stripped
(threads missing) ...... A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Contaminated ............ A ........... ( 2) Require repair or
replacement.
Inoperative ............. B ........... ( 3) Require repair or
replacement. Further
inspection required.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Resistance out of
specification .......... B .. Require repair or replacement.
Restricted, affecting
performance ............ A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.

Page 754 of 1378

JEEP CHEROKEE 1988 Service Repair Manual Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repa

Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Determine source of contamination, such as engine coolant,
fuel, metal particles, or water. Require repair or
replacement.
( 3) - Inoperative includes intermittent operation or out of
OEM specification. Some components may be serviceable;
check for accepted cleaning procedure.
\
\
\
\
\
\
\

WASTE GATE CONTROL SOLENOIDS
WASTE GATE CONTROL SOLENOID INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware
threads damaged ........ A ... Require repair or replacement
of hardware.
Attaching hardware
threads stripped
(threads missing) ...... A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Contaminated ............ A ........... ( 2) Require repair or
replacement.
Inoperative ............. B ........... ( 3) Require repair or
replacement. Further
inspection required.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Resistance out of
specification .......... B .. Require repair or replacement.
Restricted, affecting
performance ............ A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.

Page 755 of 1378

JEEP CHEROKEE 1988 Service Repair Manual Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Wire lead conductors
exposed ...........

Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Determine source of contamination, such as engine coolant,
fuel, metal particles, or water. Require repair or
replacement.
( 3) - Inoperative includes intermittent operation or out of
OEM specification. Some components may be serviceable;
check for accepted cleaning procedure.
\
\
\
\
\
\
\

WASTE GATES AND BOOST CONTROL MECHANISMS
WASTE GATE AND BOOST CONTROL MECHANISM INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Boost pressure
incorrect .............. A ........... ( 1) Require repair or
replacement. Further
inspection required.
Leaking ................. A .. Require repair or replacement.
( 1) - Incorrect boost pressure includes intermittent operation
or out of OEM specification.
\
\
\
\
\
\
\

WATER PUMPS (ELECTRIC)
WATER PUMP (ELECTRIC) INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Inoperative ............. A ........ ( 2) Require replacement.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 ............ Suggest replacement.
Rotation incorrect for
application ............ B .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.

Page 756 of 1378

JEEP CHEROKEE 1988 Service Repair Manual Terminal burned, affecting
performance ............ A ........... (1) Require repair or
replacement.
Terminal burned, not
affecting performan

Terminal burned, affecting
performance ............ A ........... (1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Vibration ............... 1 ............ Suggest replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Check fan motor/controls. Inoperative includes
intermittent operation or out of OEM specification.
\
\
\
\
\
\
\

WATER PUMPS (NON-ELECTRIC)
WATER PUMP (NON-ELECTRIC) INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
corroded ............... A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Corrosion (internal) is
excessive, affecting
performance ............ A ............ Require replacement.
Corrosion (internal) is
excessive, not affecting
performance ............ 2 . Suggest cooling system service.
Inoperative ............. A ........ ( 1) Require replacement.
Leaking ................. A ............ Require replacement.
Noisy ................... A ............ Require replacement.
Rotation incorrect for
application ............ B .. Require repair or replacement.
Shaft bent .............. A ............ Require replacement.
( 1) - Inoperative includes intermittent operation or out of
OEM specification.
\
\
\
\
\
\
\

WIRING HARNESSES AND CONNECTORS

Page 757 of 1378

$JEEP CHEROKEE 1988 Service Repair Manual WIRING HARNESS AND CONNECTOR INSPECTION��\ ��\ ��\ ��\ ��\ ��\ ��\ �� Condition$

WIRING HARNESS AND CONNECTOR INSPECTION\
\
\
\
\
\
\

Condition Code Procedure
Application incorrect ... B .. Require repair or replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... (1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Insulation damaged,
conductors exposed ..... A .. Require repair or replacement.
Insulation damaged,
conductors not exposed . 1 ............ Suggest replacement.
Open .................... A .. Require repair or replacement.
Protective shield
(conduit) melted ....... 2 ........... ( 1) Suggest repair or
replacement.
Protective shield
(conduit) missing ...... 2 .. Suggest repair or replacement.
Resistance (voltage drop)
out of specification ... A .. Require repair or replacement.
Routed incorrectly ...... B ................. Require repair.
Secured incorrectly ..... B ................. Require repair.
Shorted ................. A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Voltage drop out of
specification .......... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
\
\
\
\
\
\
\

Page 758 of 1378

$JEEP CHEROKEE 1988 Service Repair Manual \003 A - E N G IN E/V IN ID 1988 J e ep C hero ke e 1984-89 ENGINE PERFORMANCE Chrysler Motors/Jeep VIN Code Identification Jeep; Cherokee, Wagoneer MODEL$

Page 759 of 1378

JEEP CHEROKEE 1988 Service Repair Manual S * 4-Speed Manual Floor Shift (2WD)
D * Auto Floor Shift (2WD)
W * 5-Speed Manual Shift (2WD)
5 - Car Line (1989)
J * Cherokee 4WD
N * Wagoneer 4WD
T * Cherokee 2WD
6 - B

Page 760 of 1378

JEEP CHEROKEE 1988 Service Repair Manual 12-17 - Sequential Serial Number
* Production Sequence

Load next 8 pages

Page: < prev 1-10 ... 721-728 729-736 737-744 745-752 753-760 761-768 769-776 777-784 785-792 ... 1384 next >

gas mileage fuel tank capacity navigation system child seat radiator cap keyless entry
