1988 JEEP CHEROKEE Service Repair Manual

with fluid.
LOW-REVERSE (REAR) BAND ADJUSTMENT









\









\









\









\









\









\









\







Tighten Screw to Back Off
Application INCH Lbs. (N.m) Screw\
Model 727 ................. 41 (4.6 N.m.) .................... 2 Turns\
Model 904 ................. 41 (4.6 N.m.) .................... 7 Turns\
Model 999 ................. 41 (4.6 N.m.) .................... 4 Turns\









\









\









\









\









\









\









\







TRANSMISSION THROTTLE CABLE/LINKAGE
NOTE: A special Idle Speed Actuator (ISA) Exerciser Box Tool is
required to initially set ISA motor and adjust transmission
throttle linkage on vehicles with transmission model 999
with 4-cylinder engines.
727 Transmission with 6-Cylinder Engines
1) Disconnect throttle control rod spring. Use spring to
hold transmission throttle control lever forward, against stop. Block
choke open and release fast idle cam.
2) On carburetors equipped with throttle operated solenoid
valve, turn key to "ON" position to energize solenoid. Open throttle
halfway to allow solenoid to lock. Return throttle to idle position.
3) Loosen retaining bolt on throttle control adjusting link.
DO NOT remove spring clip or nylon washer. Pull on end of link to
eliminate lash. Tighten link retaining bolt. Reconnect throttle
control rod spring.
727 Transmission with V8 engines
1) Disconnect throttle control rod spring. Use spring to
hold transmission throttle valve control lever against forward stop.
Block choke open and release fast idle cam.
2) On carburetors equipped with throttle operated solenoid
valve, turn key to "ON" position to energize solenoid. Open throttle
halfway to allow solenoid to lock. Return throttle to idle position.
3) Loosen retaining bolt on throttle control rod adjusting
link. Remove spring clip and slide nylon washer to rear of link. Push
on end of link to eliminate lash and tighten retaining bolt. Install
nylon washer and spring clip. Reconnect throttle control rod spring.
904 Transmission with 6-Cylinder Engines
1) Remove air cleaner. Hold throttle control lever rearward
against its stop. Block choke plate open and set carburetor linkage
completely off fast idle cam.
2) Unlock throttle control cable by lifting "T" shaped
adjuster clamp with small screwdriver. Move cable outer sheath
forward to remove any cable load on throttle cable bellcrank.
3) Adjust cable by moving cable and sheath rearward until
there is no lash between cable and throttle linkage. Lock cable by
pressing "T" shaped clamp downward until clamp snaps into place.
Install and reconnect any parts removed and/or disconnected.
999 Transmission with 4-Cylinder Engines
1) Raise vehicle. Using a spring, hook one end on throttle
control lever and other end on torque converter housing. Lower
vehicle.
2) Disconnect the ISA motor and connect Exerciser Box to
ISA. Adjustment light should turn off and ready light should turn on.
Press retrack button. Wait until ISA adjusts, ready light goes off
and adjust light goes on.

3) Loosen bolt on throttle control link. Pull on link end to
eliminate lash. Tighten adjusting bolt. Press extend button on
Exerciser Box. When ISA retracts, release button and disconnect
Exerciser Box. Connect ISA wiring and remove spring from throttle
control lever. Install and reconnect any parts removed and/or
disconnected.
999 Transmission with 6-Cylinder Engines
1) Disconnect throttle control rod spring. Use spring to
hold adjusting link in forward position, against nylon washer. Block
choke open and release fast idle cam.
2) Raise vehicle. Loosen both retaining bolts on adjusting
link clamp. DO NOT remove spring clip or nylon washer. Use a spare
spring to hold transmission throttle lever against forward stop.
3) Push adjusting link to eliminate lash and pull clamp to
rear so that bolt in rod bottoms in rear of slot in rod. Tighten
forward clamp retaining bolt.
4) Pull throttle control rod to the rear so that bolt in
rod bottoms in front of slot and tighten rear retaining bolt. Remove
spare spring. Lower vehicle and reconnect throttle control rod spring.
AW-4 Transmission with All Engines
1) With ignition off, retract cable self-adjusting mechanism
fully. Press cable button down and push cable plunger inward.
2) Rotate throttle lever to wide open throttle position.
While holding throttle lever in position, allow cable plunger to
extend. When plunger is fully extended, release throttle lever. Cable
is now adjusted.
SHIFT LINKAGE
Cable Linkage
1) Place gearshift lever in "P" position and raise vehicle.
Using a small screwdriver, unlock shift control cable by releasing
U-shaped cable adjuster clamp. Remove cable from mounting bracket.
2) Move transmission shift lever rearward until fully
seated into "P" detent. Ensure that driveshaft cannot be rotated.
Snap control cable into cable mounting bracket and replace U-shaped
cable adjuster clamp.
3) Lower vehicle and verify engine starting. Engine should
start only with shifter in "P" or "N" position.
Rod Linkage
1) Loosen shift rod trunnion jam nuts at transmission lever.
Remove shift rod-to-bellcrank lock pin. Disengage trunnion and shift
rod. Place selector lever in "P" position and lock steering column.
Move transmission shift lever to full rear Park position.
2) Adjust shift rod trunnion to obtain free pin fit in
bellcrank arm. Tighten jam nuts. On vehicles with shift lever on
column, make sure linkage lash is eliminated by pulling down on shift
rod and pushing up on outer bellcrank when tightening jam nuts.
3) Check steering column lock for ease of operation. Ensure
engine starts in "N" or "P", only. If starter engages in any drive
gear, or does not work in "N" or "P", check for proper shift linkage
adjustment or faulty neutral safety switch.
NEUTRAL SAFETY SWITCH
1) Switch combines functions of neutral safety switch and
back-up light switch. With transmission linkage properly adjusted,
switch should allow starter operation in "P" and "N" only.
2) To test switch, remove wire connector and test for
continuity between center pin of switch and case. Continuity should

only exist when transmission is in "P" or "N".
3) Check for continuity between 2 outer pins. Continuity
should exist with transmission in "R" only. There should be no
continuity between either outer pin and transmission case. If any of
these conditions are not met, the switch should be replaced.
4) To replace switch, unscrew from case. Move selector lever
to "P" and "N" positions and check that switch operating fingers are
centered in switch opening. Install switch and new seal in case.
Check fluid level and add as needed.

\003
TR AN SM IS SIO N S ER VIC IN G - M /T

1988 J e ep C hero ke e
1988 MANUAL TRANSMISSION SERVICING
Jeep
Cherokee, Comanche, Grand Wagoneer, Pickup, Wagoneer,
Wrangler
LUBRICATION
SERVICE INTERVALS
Transmission
Under normal driving conditions, check fluid level every 5000
miles or when serviced. Under severe driving conditions, check fluid
level every 3000 miles. Transmission lubricant should be changed at
27,500 mile intervals.
Transfer Case
Check transfer case fluid every 12,000 miles and replace
fluid every 30,000 miles.
CHECKING FLUID LEVEL
Transmission
Check lubricant level at transmission filler plug hole.
Lubricant should be level with bottom of hole. Add lubricant as
needed.
Transfer Case
Remove fill plug. Check oil level. If level is not up to fill
plug opening, add lubricant until it is.
RECOMMENDED FLUID
Transmission
Recommended lubricant for Jeep with manual transmission is
AMC/Jeep Manual Transmission Fluid (89 83 000 000) or 75W-90 GL-5 gear\
lubricant.
Transfer Cases
Transfer cases use DEXRON-II ATF.
FLUID CAPACITY
NOTE: Capacities given are approximate. Correct fluid level should
be determined by level at filler plug hole.
TRANSMISSION REFILL CAPACITIES









\









\









\









\









\





Application Quantity
4-Speed
AX4 .......................... 7.4 pts. (3.5L)
T176 ......................... 3.5 pts. (1.7L)
5-Speed
AX5 .......................... 7.0 pts. (3.3L)
BA 10/5 ...................... 3.5 pts. (1.6L)









\









\









\









\









\





TRANSFER CASE REFILL CAPACITIES

\









\









\









\









\





Application Quantity
Model 207 ...................... 5.0 pts. (2.1L)
Model 208 ...................... 6.0 pts. (2.8L)
Model 228 ...................... 7.0 pts. (3.3L)
Model 229 ...................... 6.0 pts. (2.8L)









\









\









\









\









\





ADJUSTMENTS
SHIFT LINKAGE
NOTE: All Jeep models use transmission shift linkage that does not
require external adjustments.

\003
TR O UBLE S H O OTIN G - B ASIC P R O CED URES

1988 J e ep C hero ke e
GENERAL TROUBLE SHOOTING
* PLEASE READ THIS FIRST *
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
ACCESSORIES & ELECTRICAL
CHARGING SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC CHARGING SYSTEM TROUBLE SHOOTING CHART









\









\









\









\









\









\









\







CONDITION POSSIBLE CAUSE CORRECTION








\









\









\









\









\









\









\







Vehicle Will Not Dead battery Check battery cells,
Start alternator belt
tension and alternator
output
Loose or corroded battery Check all charging
connections system connections
Ignition circuit or switch Check and replace as
malfunction necessary









\









\









\









\









\









\









\







Alternator Light Loose or worn alternator Check alternator drive
Stays On With drive belt tension and
Engine Running condition, See Belt
Adjustment in TUNE-UP
article in the
TUNE-UP section
Loose alternator wiring Check all charging
connections system connections
Short in alternator light See Indicator Warning
wiring Lights in STANDARD
INSTRUMENTS in the
ACCESSORIES &
EQUIPMENT section
Defective alternator stator See Bench Tests in
or diodes ALTERNATOR article
Defective regulator See Regulator Check in

ALTERNATOR article








\









\









\









\









\









\









\







Alternator Blown fuse See WIRING DIAGRAMS
Light Stays Off
With Ignition
Switch ON
Defective alternator See Testing in
ALTERNATOR article
Defective indicator light See Indicator Warning
bulb or socket Lights in STANDARD
INSTRUMENTS in the
ACCESSORIES &
EQUIPMENT section









\









\









\









\









\









\









\







Alternator Short in alternator wiring See On-Vehicle Tests
Light Stays OFF in ALTERNATOR article
With Ignition
Switch ON
Defective rectifier bridge See Bench Tests in
ALTERNATOR article









\









\









\









\









\









\









\







Lights or Fuses Defective alternator wiring See On-Vehicle Tests
Burn Out in ALTERNATOR article
Frequently
Defective regulator See Regulator Check in
ALTERNATOR article
Defective battery Check and replace as
necessary









\









\









\









\









\









\









\







Ammeter Gauge Loose or worn drive belt Check alternator drive
Shows Discharge belt tension and
condition. See Belt
Adjustment in TUNE-UP
article in the
TUNE-UP section
Defective wiring Check all wires and
wire connections
Defective alternator or See Bench Tests and
regulator On-Vehicle Tests in
ALTERNATOR article
Defective ammeter, or See Testing in
improper ammeter wiring STANDARD INSTRUMENTS
connection in the ACCESSORIES &
EQUIPMENT section









\









\









\









\









\









\









\







Noisy Loose drive pulley Tighten drive pulley
Alternator attaching nut
Loose mounting bolts Tighten all alternator
mounting bolts
Worn or dirty bearings See Bearing
Replacement
ALTERNATOR article

Defective diodes or stator See Bench Test in
ALTERNATOR article









\









\









\









\









\









\









\







Battery Does Loose or worn drive belt Check alternator drive
Stay Charged belt tension and
condition. See
Belt Adjustment in
appropriate TUNE-UP
article in the
TUNE-UP section
Loose or corroded battery Check all charging
connections system connections
Loose alternator connections Check all charging
system connections
Defective alternator or See On-Vehicle Tests
battery and Bench Tests in
ALTERNATOR article
Add-on electrical accessories Install larger
exceeding alternator capacity alternator









\









\









\









\









\









\









\







Battery Defective battery Check alternator
Overcharged- output and repair as
Uses Too Much necessary
Water
Defective alternator See On-Vehicle Test and
Bench Tests in
ALTERNATOR article
Excessive alternator voltage Check alternator output
and repair as necessary









\









\









\









\









\









\









\







IGNITION SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
Ignition Secondary Trouble Shooting Chart








\









\









\









\









\









\





START: Visually inspect Spark Plug Wires, Coil Wires,

Plug Wire Boots, Rotor, and Distributor Cap for

signs of damage.










\









\









\









\









\









\



\b








\









\









\









\









\














\

OK   NOT OK




\b







\b








\









\









\
















\









\









* To test secondary ignition   * Repair or replace

system, modify a Spark Plug   damaged components

by attaching a ground wire   as necessary

to the body of the plug and









\









\





\b
