1988 JEEP CHEROKEE Service Repair Manual

performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Wire lead burned ........ A .. Require repair or replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Malfunctioning includes inoperative, intermittent
operation, or failure to perform all functions.
( 3) - Make sure poor sound quality is not caused by
ignition/charging system or other forms of electrical
interference.









\









\









\









\









\









\









\


TRANSDUCERS
TRANSDUCER INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Drive mechanism damaged,
affecting performance .. A ........... ( 2) Require repair or
replacement.
Drive mechanism damaged,
not affecting
performance ............ 2 ........... ( 2) Suggest repair or
replacement.
Inoperative ............. A ........... ( 3) Require repair or
replacement.
Leaking
(vacuum/fluid/air) ..... A ............ Require replacement.
Linkage bent, affecting
performance ............ A ... Require repair or replacement
of linkage.
Linkage bent, not
affecting performance .. .. ........ No service suggested or
required.
Linkage binding, affecting
performance ............ A ... Require repair or replacement
of linkage.
Linkage binding, not
affecting performance .. 2 ... Suggest repair or replacement
of linkage.
Linkage broken .......... A ... Require repair or replacement

of linkage.
Linkage loose, affecting
performance ............ A ... Require repair or replacement
of linkage.
Linkage loose, not
affecting performance .. 1 ... Suggest repair or replacement
of linkage.
Linkage missing ......... C ............ Require replacement.
Linkage noisy ........... 2 .. Suggest repair or replacement.
Out of adjustment ....... B .......... (4) Further inspection
required.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Further inspection required to determine cause.
( 3) - Inoperative includes intermittent operation or out of
specification.
( 4) - Follow OEM recommended adjustment procedures. Repair
or replace if out of specification.









\









\









\









\









\









\









\


VACUUM ACCUMULATORS (RESERVOIRS)
VACUUM ACCUMULATOR (RESERVOIR) INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Leaking ................. A .. Require repair or replacement.









\









\









\









\









\









\









\


VACUUM RESERVOIRS
See VACUUM ACCUMULATORS (RESERVOIRS) .
VOLTAGE REGULATORS
VOLTAGE REGULATOR INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure

Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... (1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Inoperative ............. A ........ ( 2) Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - NOTE: Inoperative includes intermittent operation or
out of OEM specification.









\









\









\









\









\









\









\


WASHER FLUID LEVEL SENDERS
WASHER FLUID LEVEL SENDER INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Inoperative ............. A ........... ( 1) Require repair or
replacement.
Leaking ................. A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 2) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.

Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.
Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Inoperative includes intermittent operation or out of OEM
specification.
( 2) - Determine cause and correct prior to repair or
replacement of part.









\









\









\









\









\









\









\


WASHER PUMPS
WASHER PUMP INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Inoperative ............. A ........... ( 2) Require repair or
replacement.
Leaking externally ...... A .. Require repair or replacement.
Leaking internally ...... A .. Require repair or replacement.
Noisy ................... 2 .. Suggest repair or replacement.
Resistance out of
specification .......... B .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
Wire lead conductors
exposed ................ B .. Require repair or replacement.

Wire lead corroded ...... A .. Require repair or replacement.
Wire lead open .......... A .. Require repair or replacement.
Wire lead shorted ....... A .. Require repair or replacement.
(1) - Determine cause and correct prior to repair or
replacement of part.
( 2) - Inoperative includes intermittent operation.









\









\









\









\









\









\









\


WIPER ARMS AND BLADES
NOTE: Windshield coatings or waxes can cause blades to not
function as intended. Clean surface before making final
judgment about blade replacement.
WIPER ARM AND BLADE INSPECTION









\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Attaching socket
stripped ............... A ............ Require replacement.
Bent .................... A .. Require repair or replacement.
Loose ................... 2 .. Suggest repair or replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 .. Suggest repair or replacement.
Size incorrect .......... 2 ............ Suggest replacement.
Tension insufficient .... B .. Require repair or replacement.
Torn .................... A ............ Require replacement.
Worn, affecting
performance ............ A ............ Require replacement.
Worn, not affecting
performance ............ 1 ............ Suggest replacement.









\









\









\









\









\









\









\


WIPER BLADES
See WIPER ARMS AND BLADES .
WIPER HOSES AND NOZZLES
WIPER HOSE AND NOZZLE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Blocked ................. A .. Require repair or replacement.

Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.
Oil-soaked (spongy) ..... 1 ............ Suggest replacement.
Spray pattern incorrect . 2 .. Suggest repair or replacement.
Surface cracks (dry-
rotted) ................ 1 ............ Suggest replacement.









\









\









\









\









\









\









\


WIPER LINKAGES
WIPER LINKAGE INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Attaching stud stripped . A ............ Require replacement.
Bent .................... A .. Require repair or replacement.
Inoperative ............. A ........ ( 1) Require replacement.
Loose ................... 2 .. Suggest repair or replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 .. Suggest repair or replacement.
Tension insufficient .... B .. Require repair or replacement.
Worn, affecting
performance ............ A ............ Require replacement.
Worn, not affecting
performance ............ 1 ............ Suggest replacement.
( 1) - Inoperative includes intermittent operation.









\









\









\









\









\









\









\


WIPER NOZZLES
See WIPER HOSES AND NOZZLES .
WIPER PUMP RESERVOIRS
WIPER PUMP RESERVOIR INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Cap missing ............. C ............ Require replacement.
Leaking ................. A .. Require repair or replacement.
Missing ................. C ............ Require replacement.









\









\









\









\









\









\









\

WIRING HARNESSES AND CONNECTORS
WIRING HARNESS AND CONNECTOR INSPECTION








\









\









\









\









\









\









\


Condition Code Procedure
Application incorrect ... B .. Require repair or replacement.
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted ........ A ........... ( 1) Require repair or
replacement.
Connector missing ....... C ............ Require replacement.
Insulation damaged,
conductors exposed ..... A .. Require repair or replacement.
Insulation damaged,
conductors not exposed . 1 ............ Suggest replacement.
Open .................... A .. Require repair or replacement.
Protective shield
(conduit) melted ....... 2 ........... ( 1) Suggest repair or
replacement.
Protective shield
(conduit) missing ...... 2 .. Suggest repair or replacement.
Resistance (voltage drop)
out of specification ... A .. Require repair or replacement.
Routed incorrectly ...... B ................. Require repair.
Secured incorrectly ..... B ................. Require repair.
Shorted ................. A .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 2 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
Voltage drop out of
specification .......... A .. Require repair or replacement.
( 1) - Determine cause and correct prior to repair or
replacement of part.









\









\









\









\









\









\









\

\003
ELE C TR O STA TIC D IS C HAR G E W AR NIN G - B ASIC IN FO RM ATIO N
1988 J e ep C hero ke e
GENERAL INFORMATION
Electrostatic Discharge (ESD) Warning - Basic Information
All Makes amd Models
* PLEASE READ THIS FIRST *
NOTE: This article is intended for general information purposes
only.
INTRODUCTION
All Electrostatic Discharge (ESD) sensitive components
contain solid state circuits (transistors, diodes, semiconductors)
that may become damaged when contacted with an electrostatic charge.
The following information applies to all ESD sensitive devices. The
ESD symbol shown in Fig. 1 may be used on schematics to indicate which
components are ESD sensitive. See Fig. 1. Although different
manufactures may display different symbols to represent ESD sensitive
devices, the handling and measuring precautions and procedures are the
same.
Fig. 1: Sample ESD Symbol
HANDLING STATIC-SENSITIVE CIRCUITS/DEVICES
