Page 1065 of 1378

NOTE: All other models are not adjustable.
BALL JOINTS
Jeep, Truck & Wagoneer
1) Raise vehicle and remove front wheels. Disconnect
steering damper and connecting rod. Remove cotter pin from right side
tie rod retaining nut. Rotate steering knuckles through complete arc
several times.
2) Place torque wrench on right side tie rod retaining nut.
Torque to turn knuckles through complete arc should not be more than
25 ft. lbs. (34 N.m).
3) If turning effort is excessive, disconnect tie rod ends
at knuckles. Measure turning effort of right and left side knuckles.
Individual turning effort should not be more than 10 ft. lbs. (14
N.m).
4) If individual turning effort is more than specified,
replace upper ball joint split ring seat. If turning effort is more
than 10 ft. lbs. (14 N.m) after split ring seat replacement, ball
joints will have to be replaced.
TURNING ANGLE
Truck & Wagoneer
1) Turning angle stop screws are located at rear of steering
knuckle, just above axle centerline. To adjust, loosen lock nut on
turning angle stop screw. Jeep turning angle is not adjustable.
2) Using turntable to measure angle, adjust stop screw to
obtain specified angle. Tighten lock nut without changing setting.
TURN ANGLE ADJUSTMENT
TURNING ANGLE ADJUSTMENT TABLE \
\
\
\
\
\
\
Application Left Right
Wheel Wheel
Jeep
Cherokee,
Comanche,
& Wrangler .......... ( 1) 32-33
................. ( 1) 32-33
Wagoneer ................. 36-37 ....................... 36-37
(1) - Angle stops are not adjustable. Parts must be replaced if
angle is incorrect.
\
\
\
\
\
\
\
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE \
\
\
\
\
\
\
Application Ft. Lbs.(N.m)\
Ball Joint Type
Lower Ball Joint Nut
Jeep .................................................. 100 (136)\
Upper Ball Joint Nut
Jeep .................................................. 100 (136)\
Upper Ball Joint Split Retaining Seat
Jeep ..................................................... 50 (68)\
\
\
\
\
\
\
\
Page 1066 of 1378
Fig. 2: Exploded View of Ball Joint Type Steering Knuckle
Assembly
Page 1067 of 1378

STE ER IN G L IN KAG E
1988 J e ep C hero ke e
1988 STEERING
Jeep Steering Linkage
All Models
STEERING SERVICE PRECAUTIONS
All steering component fasteners are made of special quality
materials. Replacement fasteners must be of same part number or
equivalent. Tighten all fasteners to specification. Always use new
cotter pins. DO NOT back off castle nuts to align cotter pin hole.
Tighten nut to next slot that lines up with hole.
DO NOT hammer on ball studs. If threads are not clean and
smooth, ball studs may turn in joint when nuts are tightened. Sleeve
clamps must always be positioned as specified before tightening bolts.
TROUBLE SHOOTING
Refer to TROUBLE SHOOTING - BASIC PROCEDURES article in the
GENERAL TROUBLE SHOOTING section.
REMOVAL & INSTALLATION
TIE ROD REPLACEMENT
Removal & Installation
1) Remove cotter pins and retaining nuts at both ends of tie
rod and connecting rod ball joints. Disconnect steering damper from
tie rod. Using puller and appropriate adapters from Ball Joint Tool
Kit (J-34503), remove tie rod ends from steering arms and connecting
rod.
2) Loosen clamp bolts. Remove tie rod ends from adjusting
sleeve noting the number of turns. To install, thread new tie rod ends
into adjusting sleeve. Attach tie rod ends to steering arms and
connecting rod. Tighten nuts.
3) Install new cotter pins. Attach steering damper. Check and
adjust toe-in. See WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES
article in WHEEL ALIGNMENT section. Tighten clamp bolts.
Fig. 1: Cherokee, Comanche, Wagoneer & Wrangler Steering Linkage
STEERING DAMPER REPLACEMENT
Removal & Installation
Page 1068 of 1378
1) Place front wheels in straight-ahead position. Remove lock
nuts and washers from damper ends. Remove damper assembly and rubber
bushings.
2) To install, place rubber bushings in damper eyelets. On
Grand Wagoneer models, secure eyelet at push rod end to stud on tie
rod bracket. Install rubber bushings in damper body eyelet. On
Cherokee, Comanche, Wagoneer and Wrangler, install stud at push rod
end into hole on tie rod.
3) On all models, attach opposite end of damper with bolt and
lock nut (Cherokee, Comanche, Wagoneer and Wrangler) or with a lock
nut (Grand Wagoneer). Tighten lock nuts.
Fig. 2: Grand Wagoneer Steering Linkage
WHEEL ALIGNMENT
Page 1069 of 1378

After performing appropriate service procedures, refer to
WHEEL ALIGNMENT SPECIFICATIONS & PROCEDURES article in the WHEEL
ALIGNMENT section.
CONNECTING ROD REPLACEMENT
Removal & Installation
Remove cotter pins and nuts from both ends of connecting rod.
Using a separator, remove connecting rod. To install, place wheels in
straight-ahead position. Center pitman arm. Install connecting rod.
Tighten lock nuts. Install new cotter pins.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE \
\
\
\
\
\
Application Ft.Lbs. (N.m)
Clamp Bolt
Grand Wagoneer ................................. 30 (41)
All Others ..................................... 14 (19)
Connecting Rod Nut
5/8" ........................................... 70 (95)
9/16" .......................................... 60 (82)
Pitman Arm-to-Shaft Nut ........................ 185 (251)
Steering Damper Lock Nut
Wrangler ....................................... 53 (71)
All Others ..................................... 30 (41)
Tie Rod End Stud Nuts
Grand Wagoneer ................................. 60 (82)
All Others ..................................... 35 (47)
\
\
\
\
\
\
Page 1070 of 1378

\003
* S TE ER IN G U NIF O RM IN SPEC TIO N G UID ELIN ES *
1 988 J e ep C hero ke e
GENERAL INFORMATION
Steering, Suspension, Wheel Alignment, Wheels and Tires
Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Steering and Suspension
AIR RIDE SUSPENSION
AIR RIDE SUSPENSION - AIR SHOCKS AND AIR STRUTS
AIR RIDE SUSPENSION - AIR SPRING VALVES
AIR RIDE SUSPENSION - AIR SPRINGS
AIR RIDE SUSPENSION - COMPRESSORS
AIR RIDE SUSPENSION - HEIGHT SENSORS
AIR RIDE SUSPENSION - MODULES
AIR RIDE SUSPENSION - RELAYS (COMPRESSOR)
AIR RIDE SUSPENSION - SWITCHES (ON/OFF)
AIR RIDE SUSPENSION - TORSION SPRINGS (COUNTER BALANCING)
AIR RIDE SUSPENSION - TUBING
AIR RIDE SUSPENSION - WARNING LAMPS
AIR RIDE SUSPENSION - WIRING HARNESSES
BALL JOINTS
BUSHINGS
CENTER LINKS
CONTROL ARM SHAFTS
CONTROL ARMS
DRAG LINKS
ELECTRONIC RIDE CONTROL SHOCKS AND STRUTS
IDLER ARMS
KING PINS
PITMAN ARMS
POWER STEERING HOSES
POWER STEERING (HYDRAULIC) PUMPS
RADIUS ARMS
RELAY RODS
SHOCK ABSORBERS, STRUT CARTRIDGES AND STRUT ASSEMBLIES
SPINDLES
SPRINGS - COIL, LEAF AND TORSION BAR
STEEL POWER STEERING LINES
STEERING ARMS
STEERING DAMPERS
STEERING GEARS (EXCEPT RACK AND PINION)
STEERING GEARS - RACK AND PINION
STEERING KNUCKLES
STRIKE OUT BUMPERS
STRUT RODS
STRUT UPPER BEARING PLATE ASSEMBLIES
SWAY BAR LINKS
SWAY BARS
Page 1071 of 1378

TIE ROD ENDS (INNER AND OUTER)
TRACK BARS
TRAILING ARMS
WHEEL BEARINGS, RACES AND SEALS
Wheel Alignment
WHEEL ALIGNMENT
Wheels and Tires
TIRES
VALVE STEMS
WHEEL ATTACHMENT HARDWARE
WHEELS (RIMS)
MOTORIST ASSURANCE PROGRAM (MAP)
OVERVIEW
The Motorist Assurance Program is the consumer outreach
effort of the Automotive Maintenance and Repair Association, Inc.
(AMRA). Participation in the Motorist Assurance Program is drawn from
retailers, suppliers, independent repair facilities, vehicle
manufacturers and industry associations.
Our organization's mission is to strengthen the relationship
between the consumer and the auto repair industry. We produce
materials that give motorists the information and encouragement to
take greater responsibility for their vehicles-through proper,
manufacturer-recommended, maintenance. We encourage participating
service and repair shops (including franchisees and dealers) to adopt
1) a Pledge of Assurance to their Customers and 2) the Motorist
Assurance Program Standards of Service. All participating service
providers have agreed to subscribe to this Pledge and to adhere to the
promulgated Standards of Service demonstrating to their customers that
they are serious about customer satisfaction.
These Standards of Service require that an inspection of the
vehicle's (problem) system be made and the results communicated to the\
customer according to industry standards. Given that the industry did
not have such standards, the Motorist Assurance Program successfully
promulgated industry inspection communication standards in 1994-95 for
the following systems: Exhaust, Brakes, ABS, Steering and Suspension,
Engine Maintenance and Performance, HVAC, and Electrical Systems.
Further, revisions to all of these inspection communication standards
are continually re-published. In addition to these, standards for
Drive Train and Transmissions have recently been promulgated.
Participating shops utilize these Uniform Inspection & Communication
Standards as part of the inspection process and for communicating
their findings to their customers.
The Motorist Assurance Program continues to work
cooperatively and proactively with government agencies and consumer
groups toward solutions that both benefit the customer and are
mutually acceptable to both regulators and industry. We maintain the
belief that industry must retain control over how we conduct our
business, and we must be viewed as part of the solution and not part
of the problem. Meetings with state and other government officials
(and their representatives), concerned with auto repair and/or
consumer protection, are conducted. Feedback from these sessions is
brought back to the association, and the program adjusted as needed.
To assure auto repair customers recourse if they were not
satisfied with a repair transaction, the Motorist Assurance Program
offers mediation and arbitration through MAP/BBB-CARE and other non-
Page 1072 of 1378

profit organizations. MAP conducted pilot programs in twelve states
before announcing the program nationally in October, 1998. During the
pilots, participating repair shops demonstrated their adherence to the
Pledge and Standards and agreed to follow the UICS in communicating
the results of their inspection to their customers. To put some
"teeth" in the program, an accreditation requirement for shops was
initiated. The requirements are stringent, and a self-policing method
has been incorporated which includes the "mystery shopping" of
outlets.
We welcome you to join us as we continue our outreach... with
your support, both the automotive repair industry and your customers
will reap the benefits. Please visit MAP at our Internet site www.
motorist.org or contact us at:
1444 I Street, NW Suite 700
Washington, DC 20005
Phone (202) 712-9042 Fax (202) 216-9646
January 1999
MAP UNIFORM INSPECTION GENERAL GUIDELINES
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
It is MAP policy that all exhaust, brake, steering,
suspension, wheel alignment, drive-line, engine performance and
maintenance, and heating, ventilation and air conditioning, and
electrical services be offered and performed under the standards and
procedures specified in these sections.
Before any service is performed on a vehicle, an inspection
of the appropriate system must be performed. The results of this
inspection must be explained to the customer and documented on an
inspection form. The condition of the vehicle and its components will
indicate what services/part replacements may be "Required" or
"Suggested". In addition, suggestions may be made to satisfy the
requests expressed by the customer.
When a component is suggested or required to be repaired or
replaced, the decision to repair or replace must be made in the
customer's best interest, and at his or her choice given the options
available.
This section lists the various parts and conditions that
indicate a required or suggested service or part replacement.
Although this list is extensive, it is not fully inclusive. In
addition to this list, a technician may make a suggestion. However,
any suggestions must be based on substantial and informed experience,
or the vehicle manufacturer's recommended service interval and must be
documented.
Some conditions indicate that service or part replacement is
required because the part in question is no longer providing the
function for which it is intended, does not meet a vehicle
manufacturer's design specification or is missing.
Example:
An exhaust pipe has corroded severely and has a hole in it
through which exhaust gases are leaking. Replacement of the
exhaust pipe in this case is required due to functional
failure.
Example:
A brake rotor has been worn to the point where it measures
less than the vehicle manufacturer's discard specifications.
Replacement of the rotor is required because it does not meet
design specifications.
