1988 JEEP CHEROKEE Service Repair Manual

Fig. 10: Chart 2-B - Ignition Switch On (Cont.)

Fig. 11: Chart 2-C - Ignition Switch On (Cont.)

Fig. 12: Chart 3 - Throttle Position Sensor Test

Fig. 13: Chart 4-A - System Operational Test

Fig. 14: Chart 4-B - System Operational Test (Cont.)

Fig. 15: Chart 4-C - System Operational Test (Cont.)

Fig. 16: Chart 4-D - System Operational Test (Cont.)

Fig. 17: Chart 4-E - System Operational Test (Cont.)
