2009 Hyundai Santa Fe Owner's Manual - RHD (UK, Australia)

1FEATURES OF YOUR HYUNDAI
110
B980B01Y-AAT Fan Speed Control The fan speed can be set to the desired speed by pressing the appropriate fanspeed control button. The higher the fan speed is, the more air is delivered. Pressing the "OFF" button turns off thefan. B670C03Y-DAT Air Intake Control Switch (Without A.Q.S) This is used to select fresh outside air or recirculation inside air.To change the air intake control mode, push the control button.
B980A01Y-AAT Manual Operation The heating and cooling system can be controlled manually as well as by push-ing buttons other than the "AUTO" but- ton. In this state, the system sequen- tially works according to the order ofbuttons selected. The function of the buttons which are not selected will be controlled automati-cally. Press the "AUTO" button in order to convert to automatic control of the sys-tem.
OCM052097
OCM052110L
FRESH MODE (
) : The indicator
light on the button comes on when the air intake control is fresh mode.
CM-aust-1a.p65 5/21/2008, 2:11 PM
110

1
FEATURES OF YOUR HYUNDAI
111
OCM052109L
RECIRCULATION MODE (
) : The
indicator light on the button is illumi- nated when the air intake control is recirculation mode. With the "Fresh" mode selected, air enters the vehicle from the outside and is heated or cooled according to thefunction selected. With the "Recirculation" mode selected, and air from within the passenger com- partment will be drawn through the heat- ing system and heated or cooled ac-cording to the function selected. NOTE: It should be noted that prolonged operation of the heating system in "recirculation" mode will give rise tofogging of the windshield and side windows and the air within the pas- senger compartment will becomestale. In addition, prolonged use of the air conditioning with the "Recir- culation" mode selected may resultin the air within the passenger com- partment becoming excessively dry.
B980C02JM-GAT Air Intake Control Switch (With A.Q.S) (If installed) This is used to select fresh outside air or recirculate inside air automatically.
:OFF
: ON Fresh Mode :
Air enters the vehicle from the outside and is heated or cooled according to the function selected.
Recirculation Mode :
Air from within the passenger compart- ment will be drawn through the heating system and heated or cooled according to the function selected.
OCM052109
CM-aust-1a.p65 5/21/2008, 2:11 PM
111

1FEATURES OF YOUR HYUNDAI
112
B740A01S-AAT Air Conditioning Switch The air conditioning is turned on or off by pushing the A/C button on the heat-ing/air conditioning control panel.
OCM052103
!
Exhaust Gas Cutoff Mode :
Air enters the vehicle from the outside. But if exhaust gas enters the vehicle from the outside, the exhaust gas cut- off mode ( ) is automaticallyconverted to the ( ) mode, to prevent exhaust gas from entering the vehicle.CAUTION:
If the windows fog up with the Recir- culation or A.Q.S mode selected, set the air intake control to the Fresh airposition or A.Q.S control to "OFF".
OCM052110 NOTE: It should be noted that prolonged operation of the heating system in recirculation mode (
) will give
rise to fogging of the windshield and side windows and the air within the passenger compartment will becomestale. In addition, prolonged use of the air conditioning with the recircu- lation mode (
) selected may
result in the air within the passenger compartment becoming excessively dry.
CM-aust-1a.p65 5/21/2008, 2:11 PM
112

1
FEATURES OF YOUR HYUNDAI
113
B980D01Y-AAT Heating and Cooling System Off B980E01L-DATAir Flow Control (Manual A/C Mode) This is used to direct the flow of air. Air can be directed to the floor, dashboardoutlets, or windshield. Four symbols are used to represent Face, Bi-Level, Floor and Floor-Demist position.
Press the "OFF" button to stop theoperation of the heating and coolingsystem.
OCM052099
OCM052104
B985A01CM-GAT Dual Temperature Control Selection Switch Adjusting the driver and passenger side temperature individually Press the DUAL button or turn the pussenger side "TEMP" knob to oper- ate the driver and passenger side tem- perature individually (The indicator lighton the button is illuminated). Adjusting the driver and passenger side temperature equally Press the DUAL button again to deac- tivate DUAL mode (The indicator light on the button goes off). The passenger side temperature will be set to the sameas the driver side temperature. OCM052148
CM-aust-1a.p65
5/21/2008, 2:11 PM
113

1FEATURES OF YOUR HYUNDAI
114
Floor-Level
When selecting the "Floor-Level", the indicator light will come on and the airwill be discharged through the floor vents, windshield demister nozzle, side demister nozzle and side ventilator.
OCM052107R
Bi-Level
When selecting the "Bi-Level", the indi- cator light will come on and the air will be discharged through the face vents and the floor vents.
Face-Level
When selecting the "Face-Level", theindicator light will come on, causing airto be discharged through the face level vents.
OCM052106ROCM052105R
OCM052113OCM052113 This makes it possible to have cooler air from the dashboard vents and warmerair from the floor outlets at the same time.
CM-aust-1a.p65
5/21/2008, 2:12 PM
114

1
FEATURES OF YOUR HYUNDAI
115
B980F01O-DAT Demist Switch When the "Demist" button is pressed, the "
" mode will be automatically
selected and the air will be discharged through the windshield demister nozzle, side demister nozzle and side ventila- tor. To assist in demisting, the air con-ditioning will operate if ambient tem- perature is higher than 3.5°C and auto- matically turns off if the ambient tem-perature drops below 3.5°C.
Floor-Demist Level
When selecting the "Floor-Demist Level" mode, the indicator light will come on and the air will be discharged throughthe windshield demister nozzle, the floor vents, side demister nozzle and side ventilator.
OCM052108R
OCM052076R B740D01Y-AAT Operation Tips
o If the interior of the car is hot when
you first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air condition-
ing system, keep all windows closedto keep hot air out.
o When moving slowly, as in heavy
traffic, shift to a lower gear. Thisincreases engine speed, which in turn increases the speed of the air conditioning compressor.
o On steep grades, turn the air condi- tioning off to avoid the possibility ofthe engine overheating.
o During winter months or in periods when the air conditioning is not usedregularly, run the air conditioning onceevery month for a few minutes. This will help circulate the lubricants and keep your system in peak operatingcondition.
CM-aust-1a.p65 5/21/2008, 2:12 PM
115

1FEATURES OF YOUR HYUNDAI
116REAR AIR CONDITIONING SYSTEM
B770A02B-GAT Rear Air Conditioning Switch (If installed)
OCM052112R
You may select the rear air conditioning ON/OFF button in the front seat.When pushing the button, the indicator light will come on and the rear air con- ditioning will operate. NOTE: The rear air conditioning system can only be used when the front air con-ditioning system is operating.
4. Set the temperature control to warm
or cool. When the cool box is notused, turn the lever to its closed position. Turn the knob up (RED mark) when warm air is desired, ordown (BLUE mark) when cool air is desired.
B750A02CM-DAT (If installed) You can keep beverage cans or other items warm or cool using the open/close lever of the vent installed in the centre console box.
1. Turn on the fan control switch.
2. Set the air flow control to the face
(
) or bi-level ( ) position.
3. Turn the open/close lever of the vent installed in the centre console box to the open position.
➀ ON
➁ OFF
COOL BOX
(1)(2)
OCM052149
CM-aust-1a.p65
5/21/2008, 2:12 PM
116

1
FEATURES OF YOUR HYUNDAI
117
B770B01CM-DAT Rear Ventilator (If Installed) The rear ventilators are located in quar- ter trim. To change the direction of theair flow, move the knob in the centre of the vent side to side. The blower fan speed may be controlled by setting thecontrol lever to the desired position.
OCM052114
CLIMATE CONTROL AIR FIL- TER
B760A06A-DAT The climate control air filter is located in the passenger cabin in front of theevaporator unit behind the glove box. It functions to decrease the amount of pollutants entering the car.To replace the climate control air filter, refer to the page 6-19.
OMG075033
Inside air
Blower fan
Evaporator core Filter
Outside air
Heater core
Inside airCAUTION:
o Replace the filter every 15,000 km (10,000 miles) or once a year. If the car is being driven in severe conditions such as dusty, rough roads, more frequent climate con-trol air filter inspections and changes are required.
o When the air flow rate is decreased,
it must be checked at an authoriseddealer.!
CM-aust-1a.p65 5/21/2008, 2:12 PM
