86ROOF RACK
B630A01CM-DAT (If installed)
➀ Roof rack
➁ Crossbar (If installed)
If your Hyundai has a roof rack, you can load things on top of your vehicle.Crossbars and fixing components to adapt the roof rack on your vehicle may be obtained from an authorised Hyundaidealer. To move the crossbars, pull the lock release lever and release it after thedesired position is achieved. OCM052135L
OCM054008
B545B01CM-GAT Luggage Under Tray There is a multipurpose receipt space under the luggage mat.Before use the luggage under tray, remove the luggage mat. Raise the luggage under tray cover withholding the grip.
B635A01CM-GAT To move the front crossbar (If installed) You can reposition the front crossbar more to the frontside of the vehicle to transport ski equipment or other goods.After removing the bumper molding
➀
and mounting bolt ➁, move the cross-
bar frontside of the vehicle and fix it upwith a bolt into the hole. And then reinstall the bumper molding. NOTE: When do not use the roof rack, to prevent severe noise of the wind while you driving, place the front crossbar at the extreme rearward. OCM052135L-D
CM-aust-1a.p65
5/21/2008, 2:09 PM
86

1
FEATURES OF YOUR HYUNDAI
87HIGH-MOUNTED REAR STOP LIGHT
B550A01A-DAT In addition to the lower-mounted rear stop lights on either side of the car, the high mounted rear stop light in the centre of the rear window also lights when the brakes are applied. OCM055027
!WARNING:
o The following specification is the maximum weight that can be loaded onto the roof rack. Distrib-ute the load as evenly as possible across the crossbars (if installed) and roof rack and secure the loadfirmly. o The vehicle centre of gravity will
be higher when items are loadedonto the roof rack. Avoid sudden starts, braking, sharp turns, abrupt manoeuvres or high speeds thatmay result in loss of vehicle con- trol or rollover causing an acci- dent.
CAUTION:
o The crossbars (if installed) should be placed in the proper load carry-ing positions prior to placing itemsonto the roof rack.
o If the vehicle is equipped with a
sunroof, be sure not to positioncargo onto the roof rack in such a way that it could interfere with sunroof operation.
o When carrying cargo on the roof rack, take the necessary precau-tions to make sure the cargo doesnot damage the roof of the vehicle.
o When carrying large objects on
the roof rack, make sure they donot exceed the overall roof length or width.
!
ROOF RACK 100 kg (220 lb) EVENLY DISTRIBUTED
o Always drive slowly and turn cor-
ners carefully when carrying items on the roof rack. Severe wind updrafts, caused by passing ve- hicles or natural causes, can causesudden upward pressure on items loaded on the roof rack. This is especially true when carryinglarge, flat items such as wood panels or mattresses. This could cause the items to fall off the roofrack and cause damage to your vehicle or those around you.
o To prevent damage or loss of cargo while driving, check frequently be-fore or while driving to make sure the items on the roof rack aresecurely fastened.
CM-aust-1a.p65 5/21/2008, 2:09 PM
87

1FEATURES OF YOUR HYUNDAI
88
!WARNING:
o Fuel vapours are dangerous. Be- fore refuelling, always stop the engine and never allow sparks or open flames near the filler area. Ifyou need to replace the filler cap, use a genuine Hyundai replace- ment part.If you open the fuel filler cap dur- ing high ambient temperatures, a slight "pressure sound" may beheard. This is normal and not a cause for concern. Whenever you open the fuel fillercap, turn it slowly.
REMOTE FUEL-FILLER LID RELEASE
B560A01CM-DAT The fuel-filler lid may be opened from inside the vehicle by pulling up on thefuel-filler lid opener located on the driver side door. NOTE: If the fuel-filler lid will not open be- cause ice has formed around it, tap lightly or push on the lid to break theice and release the lid. Do not pry on the lid. If necessary, spray around the lid with an approved de-icer fluid(do not use radiator anti-freeze) or move the vehicle to a warm place and allow the ice to melt. OCM052014R
OCM052015
o Automotive fuels are flammable/
explosive materials. When refuel- ling, please note the followingguidelines carefully. Failure to follow these guidelines may re- sult in severe personal injury, se-vere burns or death by fire or explosion.
- Before refuelling always note the
location of the Emergency Petrol Shut-Off, if available, at the petrol station facility.
- Before touching the fuel nozzle or fuel filler cap, you shouldeliminate potentially dangerousstatic electricity discharge by touching another metal part of the front of the vehicle, a safedistance away from the fuel filler neck, nozzle, or other flammable source.
- Do not get back into a vehicle once you have begun refuelling.Do not touch, rub or slide againstany item or fabric (polyester, satin, nylon, etc.) capable of pro- ducing static electricity. Staticelectricity discharge can ignite fuel vapours resulting in explo- sion.
CM-aust-1a.p65 5/21/2008, 2:09 PM
88

1
FEATURES OF YOUR HYUNDAI
89
B560B01CM-GAT Manual Fuel Filler Lid Release If the fuel filler lid does not open using the remote fuel filler lid release, you canopen it manually. Unsnap and remove the panel in the cargo area. Pull the handle outward.
OCM052017
If you must re-enter the vehicle, you should once again elimi- nate potentially dangerous staticelectricity discharge by touch- ing a metal part of the vehicle, away from the fuel filler neck,nozzle or other petrol source.
- When using a portable fuel con-
tainer be sure to place the con-tainer on the ground prior to refuelling. Static electricity dis- charge from the container canignite fuel vapours causing a fire. Once refuelling has begun, contact with the vehicle shouldbe maintained until the filling is complete. Use only portable fuel containers designed to carry andstore petrol.
- Do not use mobile phones
around a petrol station or whilerefuelling any vehicle. Electric current and/or electronic inter- ference from mobile phones canpotentially ignite fuel vapours causing a fire. If you must use your mobile phone use it in aplace away from the petrol sta- tion.- When refuelling always shut theengine off. Sparks produced by electrical components related tothe engine can ignite fuel vapours causing a fire. Always insure that the engine is OFF before andduring refuelling. Once refuel- ling is complete, check to make sure the fuel filler cap and doorare securely closed, before start- ing the engine.
- Do not light any fire around a petrol station. DO NOT usematches or a lighter and DO NOT SMOKE or leave a lit ciga-rette in your vehicle while at a petrol station especially during refuelling. Automotive fuel ishighly flammable and can, when ignited, result in explosion by flames.
- If a fire breaks out during refuel- ling, leave the vicinity of thevehicle, and immediately con-tact the manager of the petrol station or contact the police and local fire department. Followany safety instructions they pro- vide.
CM-aust-1a.p65 5/21/2008, 2:09 PM
89

1FEATURES OF YOUR HYUNDAI
90
!
BONNET RELEASE
B570A01HP-DAT
1. Pull the release knob to unlatch the bonnet.
2. Push the secondary latch lever side- ways and lift the bonnet.
3. Raise the bonnet by hand.
OCM052018R
OCM052019 When closing the bonnet, slowly close the bonnet and make sure it locks intoplace.
WARNING:
o Always double check to be sure that the bonnet is firmly latchedbefore driving away. If it is not latched, the bonnet could open while the vehicle is being driven,causing a total loss of visibility, which might result in an accident.
o Do not move the vehicle with the
bonnet in the raised position, asvision is obstructed and the bon- net could fall or be damaged.
OCM051026L
SUN VISOR
B580A01CM-GAT Your Hyundai is equipped with sun visors to give the driver and front pas- senger either frontal or sideward shade. To reduce glare or to shut out direct rays of the sun, turn the sun visor down.Vanity mirrors are provided on the back of the sun visor for the driver and front passenger. NOTE: The Supplemental Restraint System (SRS) label containing useful infor- mation can be found on the front ofeach sun visor. OCM052124R
CM-aust-1a.p65
5/21/2008, 2:10 PM
90

1
FEATURES OF YOUR HYUNDAI
91
B580C01LZ-AAT Ticket Holder (If installed) The ticket holder is provided on the front of the sun visor for holding a tollgate ticket.
OCM052125R
B580B01B-GAT Illuminated Vanity Mirror (If installed)
Opening the lid of the vanity mirror will automatically turn on the mirror light.
B580C01JM-AAT Sun Visor Extender (If installed)
Your vehicle is equipped with sun visor extenders that may be used when thevisor is in the side glass position.
OCM051201R
OCM052126R
!WARNING:
Do not place the sun visor in such a manner that it obscures visibility of the roadway, traffic or other objects.
CM-aust-1a.p65 5/21/2008, 2:10 PM
91

1FEATURES OF YOUR HYUNDAI
92
B620A01S-AAT (If installed) A red light comes on when the front door is opened. The purpose of this light is to assist when you get in or out, and alsoto warn passing vehicles.FRONT DOOR EDGE WARNING LIGHT
HORN
B610B01A-DAT Press the centre hub of the steering wheel to sound the horn.
OCM052052
REAR SEAT ARM REST
B611A01Y-DAT The rear seat arm rest is located in the centre of the rear seat back.
OCM052035
OCM051027R
CM-aust-1a.p65 5/21/2008, 2:10 PM
92

1
FEATURES OF YOUR HYUNDAI
93
!
CAUTION:
After adjusting the steering wheel, try moving it up and down to make sure it is locked in position.!
WARNING:
Do not attempt to adjust the steering wheel while driving as this may re-sult in loss of control of the vehicle and serious injury or death.
B600B01NF-GAT Tilt and telescopic type (If Installed)
To adjust the steering wheel:
1. Push the lever downward fully to
unlock.
2. Adjust upward or downward and for- ward or backward to set the steering wheel to the desired position.
3. After adjustment, securely tighten
the lever by pulling it upward. OCM052051R
STEERING WHEEL COLUMN
B600A01NF-GAT Tilt type
To adjust the steering wheel:
1. Pull the lever toward you and hold it to unlock.
2. Raise or lower the steering wheel to the desired position.
3. After adjustment, release the lever.
OCM052050R
CM-aust-1a.p65 5/21/2008, 2:10 PM
