2009 Hyundai Santa Fe Owner's Manual - RHD (UK, Australia)

F9
1. Passenger's
Airbag............................................... 1-36
2. Rear Air Conditioning Sw itch (If installed) ............1-116
3. Front Window Demister Switch........................... 1-115
4. Digital Clock .......................................................... 1-68
5. Rear Window Demi ster Switch .............................. 1-67
6. Hazard Warning Light Switch................................ 1-67
7. Windshield W iper/Washer Switch ..........................1-63
8. Instrument Cluster ................................................ 1-54
9. Horn and Driver' s Airbag ............................... 1-92, 1-36
10. Steering Wheel ..................................................... 1-93
11. Audio System (If installed) .................................. 1-120
12. Glove Box ............................................................. 1-78
CAUTION:
When installing a container of liquid air freshener inside the vehicle, do not place it near the instrument cluster nor on the instrument panel surface. If there is any leakagefrom the air freshener onto these areas (Instrument cluster, instrument panel or airventilator), it may damage these parts. If the liquid from the air freshener does leakonto these areas, wash them with water immediately.
! 13. Ashtray
............................................................. 1-71
14. Power Outlet ..................................................... 1-70
15. Shift Lever (If installed) ...................................... 2-9
16. Centre Console Box .......................................... 1-78
17. Cigarette Lighter ................................................ 1-69
18 Parking Brake Pedal (If installed) ...................... 1-83
19. Heating/Air Conditioning Control Panel (If installed)
....................................................................... 1-107
20. Ignition Switch ................................................... 1-6
21. Bonnet Release Lever ....................................... 1-90
22. Multi-Function Light Switch ............................... 1-60
CM-aust-00.p65 5/19/2008, 6:25 PM
9

YOUR VEHICLE AT A GLANCE
F10B255A01CM-DAT INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER
* More detailed explanations of these items will be found beginning on page 1-48.
4WD System Warning Light
Malfunction Indicator Light
SRS (Airbag) Service Reminder Indicator (SRI)
Tail Gate Open Warning Light
Low Fuel Level Warning Light Door Ajar Warning Light
ABS Service Reminder Indicator
Turn Signal Indicator Lights
High Beam Indicator Light Low Oil Pressure Warning Light Parking Brake/Brake Fluid Level Warning Light Charging System Warning Light
Immobiliser Warning Light
4WD Lock Indicator Light
Electronic Stability Program Indicator Lights (If Installed)
Cruise SET Indicator Light (If Installed)
Door/Tail Gate Open Display (If installed)
Cruise Indicator Light (If Installed)
Low Windshield Washer Fluid Level Warning LightSeat Belt Warning Light
Diesel Preheat Indicator Light
Fuel Filter Warning Light (Diesel Engine)
CM-aust-00.p65 5/19/2008, 6:25 PM
10

F11
AUSTRALIAN DESIGN RULES
The compliance plate shows that your vehicle has been tested and found to comply with all relevant Australian Design Rules (ADR's) applicable at its date of manufac- ture. Any part, that is subject to these ADR's, must not be removed or altered and is to bemaintained in good order at all times for the vehicle to be roadworthy and re- registerable by all registerable authorities. Consult an Authorised Hyundai Motors Dealer before conducting any repairs thatmay affect these areas or if requiring further classification on design rules or safety features. Failure to observe the above warning may render the vehicle compliance invalid and result in personal injury which may have otherwise been avoided.
A100A01JM-DAT
CM-aust-00.p65
5/19/2008, 6:25 PM
11

Fuel Recommendations ................................................ 1-2
Running In Your New Hyundai ..................................... 1-4
Immobiliser System ...................................................... 1-4
Door Locks ................................................................... 1-6
Theft-Alarm System ...................................................... 1-9Power Windows........................................................... 1-14
Seats ........................................................................... 1-15
Seat Belts .................................................................... 1-24
Child Restraint System ................................................ 1-28
Supplemental Restraint (AIRBAG ) System................. 1-35
Instrument Cluster and Indicator Lights .......................1-44
Warning and Indicator Lights....................................... 1-48
Trip Computer .............................................................. 1-57
Multi-function Light Switch ........................................... 1-60
Windshield Wiper/Washer Switch ................................1-63
Sunroof ........................................................................ 1-73
Mirror ........................................................................... 1-79
Bonnet Release ........................................................... 1-90
Cruise Co ntrol.............................................................. 1-94
Heating and Cooling Control .......... ..............................1-99
Antenna ..................................................................... 1-118
Stereo Sound System ............................................... 1-119
Audio System ............................................................ 1-122
FEATURES OF YOUR HYUNDAI
1
1
CM-aust-1a.p65
5/21/2008, 2:04 PM
1

1FEATURES OF YOUR HYUNDAI
2
OCM051001R
Unleaded petrol with a Pump Octane Rating of 87 (Research Octane Num-ber 91) or higher must be used in your Hyundai. If leaded petrol is used, it will cause the catalytic converter to become ineffec- tive and the emission control system tomalfunction. This can also result in increased maintenance expense. To avoid accidental use of leaded fuel,the larger nozzle used with leaded petrol at service stations cannot be inserted into the fuel tank opening of your Hyundai.
B010A02CM-DAT Use Unleaded Petrol
FUEL RECOMMENDATIONS
UNLEADED FUEL ONLY
!
Use Diesel Diesel fuel Diesel engine must be operated only on commercially available diesel fuel that complies with EN 590 or comparablestandard. (EN stands for "European Norm"). Do not use marine diesel fuel, heating oils, or non-approved fuel addi-tives, as this will increase wear and cause damage to the engine and fuel system. The use of non-approved fuelsand / or fuel additives will result in a limitation of your warranty rights. Diesel fuel of 52 to 54 cetane is thecorrect rating to use in your Hyundai. If two types of diesel fuel are available, use summer or winter fuel properlyaccording to the following temperature conditions.
o Above -5°C (23°F) ... Summer type
diesel fuel.
o Below -5°C (23°F) ... Winter type diesel fuel.
Watch the fuel level in the tank very carefully : If the engine stops through fuel failure, the circuits must be com- pletely purged to permit restarting. CAUTION:
o Do not let any petrol or water enter the tank. This would make it nec- essary to drain it out and to bleed the lines to avoid jamming theinjection pump and damaging the engine.
o In winter, in order to cut down
incidents due to freezing, paraffinoil may be added to the fuel if the temperature drops to below -10°C.Never use more than 20% paraffin oil.
Biodiesel Commercially supplied biodiesel blends of no more than 5% biodiesel, com- monly known as "B5 biodiesel" may be used in your vehicle if it meets EN14214 or equivalent specifications. (EN stands for "European Norm"). The use of biofuels made from rapeseed methylester (RME), fatty acid methyl ester (FAME), vegetable oil methyl ester (VME) etc. or mixing diesel withbiodiesel will cause increased wear or damage to the engine and fuel system.
CM-aust-1a.p65 5/21/2008, 2:04 PM
2

1
FEATURES OF YOUR HYUNDAI
3
B010E01A-DAT Petrol for Cleaner Air To help contribute to cleaner air, Hyundai recommends that you use petrol treatedwith detergent additives, which help prevent deposit formation in the engine. This petrol will help the engine runcleaner and enhance performance of the Emission Control System.
B010D01A-DAT Do not Use Methanol Fuels containing methanol (wood alco- hol) should not be used in your Hyundai.This type of fuel can reduce vehicle performance and damage components of the fuel system.
! B010F01A-AAT Operation in Foreign Countries If you are going to drive your Hyundai in another country, be sure to:
o Observe all regulations regarding
registration and insurance.
o Determine that acceptable fuel is
available.
CAUTION:
Hyundai Warranty Policy will not cover the damage of the fuel system and performance problems that are caused by the use of methanol orfuels containing methanol. B010B01A-DAT What About Gasohol [E-10]? Gasohol (a mixture of 90% unleaded gasoline and 10% ethanol or grain alco-hol) may be used in your Hyundai. However, if your engine develops drive ability problems, the use of 100% un-leaded petrol is recommended. Fuels with unspecified quantities of alcohol, or alcohols other than ethanol, shouldnot be used.
Repair or replacement of worn or dam-aged components due to the use of nonapproved fuels will not be covered by the manufactures warranty.
CAUTION:
o Never use any fuel, whether diesel or B5 biodiesel that fails to meet the latest petroleum industry speci-fication.
o Never use any fuel additives or
treatments that are not recom- mended or approved by the ve- hicle manufacturer.
!
CM-aust-1a.p65 5/21/2008, 2:04 PM
3

1FEATURES OF YOUR HYUNDAI
4IMMOBILISER SYSTEM
B880A01A-DAT The immobiliser system is an anti-theft device, designed to deter automobile theft. B880B03MC-DAT Keys All of the locks fitted to the vehicle are operated by the same key. However,since it is possible to lock the doors without the use of the key, care should be exercised to ensure that the keydoes not become locked inside the vehicle by mistake. NOTE: If you make your own duplicate key, you will not be able to cancel the system or start the engine.
B885B01JM
B020A01FC-DAT During the First 1,000 km (Diesel Engine) No formal running in period is required with your new Hyundai. However, youcan contribute to the economical opera- tion and durability of your Hyundai by observing the following recommenda-tions during the first 1000 km.
o While driving, keep your engine speed
or revolutions per minute within 3000 rpm.
o While driving, keep under three quar- ters of maximum speed.
o Use moderate acceleration. Don't use
full-throttle starts.
o For the first 300 km, try to avoid hard braking.
o Don't labouring the engine (in other words, don't drive so slowly in toohigh a gear that the engine hesitates: shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than 3
minutes at one time.
o Do not tow a trailer during the first
1000 km of operation.
RUNNING IN YOUR NEW HYUNDAI
B020A01S-DAT During the First 2,000 km (Petrol Engine) No formal running in period is required with your new Hyundai. However, youcan contribute to the economical opera- tion and durability of your Hyundai by observing the following recommenda-tions during the first 2000 km.
o Don't drive faster than 88 km/h.
o While driving, keep your engine speed
or revolutions per minute between2000 and 4000 rpm.
o Use moderate acceleration. Don't use full-throttle starts.
o For the first 300 km, try to avoid hard stops.
o Don't labour the engine (in other
words, don't drive so slowly in toohigh a gear that the engine jumps: shift to a lower gear).
o Whether going fast or slow, vary your speed from time to time.
o Don't let the engine idle longer than 3
minutes.
o Do not tow a trailer during the first 2000 km of operation.
CM-aust-1a.p65 5/21/2008, 2:04 PM
4

1
FEATURES OF YOUR HYUNDAI
5
B880C01NF-DAT Key Numbers The vehicle key number is recorded upon a number tag attached to the keyswhen the vehicle is first delivered to you. The key number should be recordedand kept in a safe place in case the need to order further keys arises. New keys are available from any Hyundaidealer by quoting the relevant key num- ber. In the interest of security, the numbertag attached to the keys which bears the key number should be removed from the key string after you receiveyour new vehicle. In addition, key num- bers cannot be provided by Hyundai for security reasons. If you need additional keys or if youshould lose your keys, your authorisedHyundai dealer can make new keys if you can supply the key number and master key.
B885D01CM-DAT Limp home procedures In case the immobiliser warning indica- tor blinks for five seconds when the ignition key is turned to "ON" position,this indicates that the immobiliser sys- tem is out of order. Should the immobiliser system be out of order,your vehicle will need to be towed to a Hyundai dealer for rectification.
HNF2011
Immobiliser warning indicator
OMC025002
!
CAUTION:
o When starting the engine, do not use the key with other immobiliser keys around. Otherwise the en-gine may not start or may stop soon after it starts. Keep each keys separately not tohave any malfunction after you receive your new vehicle.
o Do not install the metal accesso-
ries near the key or ignition switch.The engine may not start for the metal accessories may interruptthe transponder signal from nor- mally transmitting.
!WARNING:
In order to prevent theft of your ve- hicle, do not leave spare keys any-where in your vehicle. Your immobi- lizer password is a customer unique password and should be kept confi-dential. Do not leave this number anywhere in your vehicle.
CM-aust-1a.p65 5/21/2008, 2:04 PM
5
