2009 Hyundai Santa Fe Owner's Manual - RHD (UK, Australia)

6DO-IT-YOURSELF MAINTENANCE
10
Ambient
temperature °C (°F)
-15 (5)
-25 (-13) -35 (-31)-45 (-49) Engine coolant concentration
Antifreezesolution
Water
65% 60%50%40%
35%40%50%60%
G050C01CM-AAT
To Check the Coolant Level
The coolant level can be seen on the
side of the plastic coolant reservoir.
G050B01A-AAT Recommended Engine Coolant Use a high quality ethylene-glycol cool- ant in a 50/50 mix with water. The engine coolant should be compatiblewith aluminum engine parts. Additional corrosion inhibitors or additives should not be used. The cooling system mustbe maintained with the correct concen- tration and type of engine coolant to prevent freezing and corrosion. Neverallow the concentration of antifreeze to exceed the 60% level or go below the 35% level, otherwise damage to thecooling system may result. For proper concentration when adding or replac- ing the engine coolant, refer to thefollowing table.
NOTE: It is recommended that the engine coolant should be changed by anauthorised Hyundai dealer.
OCM055004
Diesel Engine
OCM055004L
Petrol Engine
The level of the coolant should be between the "L" and "F" lines on thereservoir when the engine is cool. If the level is below the "L" mark, add coolant to bring it up between "L" and"F". If the level is low, inspect for coolant leaks and recheck the fluid level frequently. If the level drops again,visit your Hyundai dealer for an in- spection and diagnosis of the reason.
CM-aust-6.p65
5/19/2008, 6:38 PM
10

6
DO-IT-YOURSELF MAINTENANCE
11
!
!
CHANGING THE AIR CLEANER FILTER
G070A03Y-AAT The replacement of air filter is per-
formed in the following manner.
1. Unsnap the clips around the cover.
2. When this is done, the cover can be lifted off, the old filter removed and the new filter put in its place.
Genuine Hyundai replacement parts
are recommended.
WARNING:
The cooling fan is controlled byengine coolant temperature and may sometimes operate even when the engine is not running. Use extremecaution when working near the blades of the cooling fan so that you are not injured by a rotating fanblade. As the engine coolant tem- perature decreases, the fan will au- tomatically shut off. This is a nor-mal condition.
WARNING:
Remove the radiator cap when the
radiator is cool.
OCM055005OCM055007R
CM-aust-6.p65 5/19/2008, 6:38 PM
11

6DO-IT-YOURSELF MAINTENANCE
12
!
CAUTION:
o Operating your vehicle without a proper air cleaner filter in place can result in excessive enginewear.
o When removing the air cleaner filter, be careful that dust or dirt does not enter the air intake. These may result in damage to the aircleaner filter.!
WINDSHIELD WIPER BLADES
G080A02A-DAT
The wiper blades should be carefully
inspected from time to time and cleaned to remove accumulations ofroad film or other debris. To clean the wiper blades and arms, use a clean sponge or cloth with a mild soap ordetergent and water. If the wipers con- tinue to streak or smear the glass, replace them with genuine Hyundaireplacement parts or their equivalent. CAUTION:
o Do not operate the wipers on dry glass. This can result in morerapid wear of the wiper bladesand may scratch the glass.
o Keep the blade rubber out of con-
tact with petroleum products suchas engine oil, petrol, etc.
OCM055005R
CM-aust-6.p65 5/19/2008, 6:38 PM
12

6
DO-IT-YOURSELF MAINTENANCE
13
1. Put a new wiper blade onto the wiper arm and lower the wiper blade at the level of the wiper arm asshown in the drawing.
2. Raise the wiper blade lightly and
pull up it. HHR5049
HHR5050
G080B01HR-GAT
Replacing the Wiper Blades
To replace the wiper blades, raise the wiper to the vertical.
To remove the wiper blade
1. Push down the wiper blade with the locking clip (1) pressed to detach it from the wiper arm. HHR5048
(1) To install the wiper blade
CM-aust-6.p65
5/19/2008, 6:38 PM
13

6DO-IT-YOURSELF MAINTENANCE
14
!
FILLING THE WASHER RESERVOIR
G090A01CM-DAT The washer fluid reservoir supplies
fluid to the windshield washer system. A good quality washer fluid should beused to fill the washer reservoir. The fluid level should be checked more frequently during inclement weather orwhenever the washer system is in frequent use. The capacity of the washer reservoir is 4.6 litres.
2. Pull up the wiper blade until you
hear an audible "click" to engage in the end of the wiper arm.
NOTE: Do not allow the wiper arm to fall against the windshield. HHR5051
OCM055028LCAUTION:
o Radiator anti-freeze (engine cool- ant) should not be used in the washer system because it willdamage the car's finish.
o The washer should not be oper-
ated if the washer reservoir isempty. This can damage the washer fluid pump.
!
WARNING:
o Windshield washer fluid agents contain some amounts of alcohol and can be flammable under cer-tain circumstances. Do not allow sparks of flame to contact the washer fluid or the washer fluidreservoir. Damage to the vehicle or its occupants could occur.
o Windshield washer fluid is poi- sonous to humans and animals. Do not drink windshield washerfluid. Serious injury or death could occur.
CM-aust-6.p65 5/19/2008, 6:38 PM
14

6
DO-IT-YOURSELF MAINTENANCE
15
!
G110C01CM-GAT Transaxle Fluid Capacity See page 9-4.
WARNING:
The transaxle fluid level should be checked when the engine is at nor-mal operating temperature. This means that the engine, radiator, exhaust system etc., are very hot.Exercise great care not to burn your- self during this procedure.
G110B04A-AAT
Recommended Fluid
Your Hyundai automatic transaxle is specially designed to operate with Hyundai Genuine ATF SP-III, DIA- MOND ATF SP-III, SK ATF SP-III orother brands approved by Hyundai Motor Co., Damage caused by a nonspecified fluid is not covered byyour new vehicle limited warranty.
CHECKING THE TRANSAXLE FLUID (AUTOMATIC)
G110A02E-AAT Transaxle fluid in the automatic transaxle should be changed at those intervals specified in the vehicle main-tenance schedule in Section 5. NOTE: Automatic transaxle fluid is a red in color. As driving distance increases, the fluid color turns darkish redgradually. It is a normal condition and you should not judge the need to replace based upon the changingcolor.You must replace the automatictransaxle fluid in accordance withintervals specified in the vehicle maintenance schedule in section 5.
CM-aust-6.p65 5/19/2008, 6:38 PM
15

6DO-IT-YOURSELF MAINTENANCE
16
OCM055037L
G110D02CM-DAT
To Check the Transaxle Fluid Level Keep the vehicle on level ground with
the parking brake applied and check the fluid level according to the follow- ing procedure.
1. Place the shift lever in N(neutral)
position and confirm the engine is running at normal idle speed.
2. After the transaxle is warmed up
sufficiently [fluid temperature70~80°C (158~176°F)], for example by 10 minutes usual driving, move the shift lever through all positionsthen place the shift lever in N(neutral) or P(park) position.
The automatic transaxle fluid levelshould be checked regularly.
OCM055006 3. Confirm if the fluid level is in the
“75°C” range on the level gauge. If the fluid level is lower, add the specified fluid from the fill hole. Ifthe fluid level is higher, drain the fluid from the drain hole.
4. If the fluid level is checked in cold condition[fluid temperature 20~30°C (68~86°F)], add the fluid to the “25°C”line and then recheck the fluid level according to the above step 2.
Fluid level should be within 75°C range
CM-aust-6.p65
5/19/2008, 6:38 PM
16

6
DO-IT-YOURSELF MAINTENANCE
17
!WARNING:
The cooling fan is controlled by engine coolant temperature and may sometimes operate even when the engine is not running. Use extremecaution when working near the blades of the cooling fan, so that you are not injured by a rotating fanblade. As the engine coolant tem- perature decreases, the fan will au- tomatically shut off. This is a nor-mal condition.
CHECKING THE BRAKES
G120A01A-AAT
! CAUTION:
Because brakes are essential to the
safe operation of the car, it is sug- gested that they be checked andinspected by your Hyundai dealer. The brakes should be checked and inspected for wear at those intervalsspecified in the vehicle maintenance schedule in Section 5.!WARNING (DIESEL ONLY):
Never work on injection system with
engine running or within 30 sec- onds after shutting off engine. High pressure pump, rail, injectors andhigh pressure pipes are subject to high pressure even after the engine stopped. The fuel jet produced byfuel leaks may cause serious injury, if it touch the body. People using pacemakers should not move than30cm closer to the ECU or wiring harness within the engine room while engine is running, since the high currents in the Common Rail system produce considerable mag-netic fields.
