2009 Hyundai Santa Fe Owner's Manual - RHD (UK, Australia)

1FEATURES OF YOUR HYUNDAI
94HEADLIGHT LEVELLING DEVICE SYSTEM
B340G01Y-DAT (If installed) To adjust the headlight beam level ac- cording to the number of the passen-gers and the loading weight in the lug- gage area, turn the beam levelling switch.The higher the number of the switch position, the lower the headlight beam level. Always keep the headlight beamat the proper levelling position, or head- lights may dazzle other road users. Listed below are the examples of recommeneded switch settings. For loading conditions other than those listed below, adjust the switch position sothat the beam level may be the nearest as the condition obtained according to the list.
Switch position0 0 1 2 3
Loading condition Driver only Driver + front passengerFull passengers (including driver) Full passengers (includ-ing driver) + full luggage loading (or light trailer loading)
Driver + full luggage
loading (or maximum
trailer loading)
OCM051028R
CRUISE CONTROL
B660A02S-GAT (If Installed) The cruise control system provides automatic speed control for your com- fort when driving on freeways, toll roads,or other noncongested highways. This is designed to function above approxi- mately 40 km/h (25 mph). NOTE: Cruise control is not recommended for city driving, winding roads, slip- pery roads, heavy rain, or other bad weather conditions.
CM-aust-1a.p65 5/21/2008, 2:10 PM
94

1
FEATURES OF YOUR HYUNDAI
95
NOTE: If the vehicle speed decreases more than 15 km/h (9 mph) below the set speed or decreases below 40 km/h(25 mph), the cruise control system will automatically cancel the set speed.
B660C01NF-DAT To Cancel the Cruise Speed To disengage the cruise control sys- tem, push the control switch "CAN- CEL".
OCM051031L
B660B01NF-GAT To Set the Cruise Speed
1. Push the cruise control ON/OFF
switch. The "CRUISE" indicator light in the instrument cluster will illumi- nate. This turns the system on.
2. Accelerate to desired cruising speed above 40 km/h (25 mph). 3. Push the "SET" (COAST) switch
after you have set the vehicle speed at the desired speed. If the "SET (COAST)" switch is se- lected, the cruise "SET" indicatorlight in the instrument cluster will illuminate.
4. Remove your foot from the accelera- tor pedal and the desired speed willautomatically be maintained.
5. To increase speed, temporarily de- press the accelerator pedal enoughfor the vehicle to exceed the preset speed. When you remove your footfrom the accelerator pedal, the ve- hicle will return to the speed you have set.
OCM051029L
OCM051030L
CM-aust-1a.p65 5/21/2008, 2:10 PM
95

1FEATURES OF YOUR HYUNDAI
96
B660D01NF-GAT To Resume the Preset Speed The vehicle will automatically resume the speed set prior to cancellation whenyou push the control switch "RESUME (ACCEL)" and release it to return (when travelling above 40 km/h).If the control switch "RESUME (ACCEL)" is selected, the cruise "SET" indicator in the instrument cluster willilluminate.
OCM051032L
Additionally, the following actions will disengage the system:
o Depress the brake pedal.
o Depress the clutch pedal (Manual
transaxle).
o Shift the selector lever to "N" posi-
tion (Automatic transaxle) not at high-way speeds.
o Decrease the vehicle speed lower
than the memory speed by 15 km/h(9 mph).
o Decrease the vehicle speed to less
than 40 km/h (25 mph).
o Release the cruise control ON/OFF switch. B660E01NF-GAT To Reset at a Faster Speed
1. Push the control switch "RESUME
(ACCEL)" and hold it. If the control switch "RESUME (ACCEL)" is selected, the cruise "SET" indicator in the instrumentcluster will illuminate.
2. Accelerate to desired speed and re-
lease the control switch. While thecontrol switch is held, the vehicle will gradually gain speed.
CM-aust-1a.p65 5/21/2008, 2:10 PM
96

1
FEATURES OF YOUR HYUNDAI
97
o Use the cruise control system only
when traveling on open highways in good weather.
o Do not use the cruise control when
it may not be safe to keep the carat a constant speed, for instance, driving in heavy or varying traffic, or on slippery (rainy, icy or snow-covered) or winding roads or over 6% up-hill or down-hill roads.
o Pay particular attention to the driv-
ing conditions whenever using thecruise control system.
o During cruise-control driving with a manual transaxle vehicle, do not shift into neutral without depress-ing the clutch pedal, since the engine will be overrevved. If this happens, depress the clutch pedalor release the cruise control ON/ OFF switch.
o During normal cruise control op-
eration, when the "SET" switch isactivated or reactivated after ap- plying the brakes, the cruise con-trol will energize after approxi- mately 3 seconds. This delay is normal.
!WARNING:
o Keep the cruise control ON/OFF switch off when not using the cruise control.
B660F01NF-GAT To Reset at a Slower Speed
1. Push the control switch "SET (COAST)" and hold it. While the con- trol switch is pushed, the vehicle speed will gradually decrease. If the "SET(COAST)" switch is se-lected, the cruise "SET" indicator light in the instrument cluster will illuminate.
2. When the desired speed is obtained, release the control switch.
OCM051030L
AUDIO REMOTE CONTROL SWITCH
B610A01L-GAT (If Installed) The steering wheel audio remote con- trol switch is installed to promote safedriving. NOTE: Do not operate audio remote control switches simultaneously. OCM052141
CM-aust-1a.p65
5/21/2008, 2:10 PM
97

1FEATURES OF YOUR HYUNDAI
98
Press the SEEK switch 1 sec. or more.
1. RADIO mode When the SEEK (
) is pressed, the unit
will automatically tune to the next higher frequency and when the SEEK (
)
switch is pressed, it will automatically tune to the next lower frequency.

MODE Switch Press the MODE switch to select Ra- dio, Tape, CD (Compact Disc) and CDC (Compact Disc Changer).Each press of the switch changes the display as follows:
RADIO (FM1 FM2 AM) TAPE CD CDC
SEEK ( / ) Switch 2. TAPE mode
o Pressing the SEEK (
) will play the
beginning of the next music seg- ment.
o Pressing the SEEK (
) will start
replay at the beginning of the music just listened to.
3. CD (Compact Disc)/CDC (Compact Disc Changer) mode
o Press the SEEK (
) once to skip
forward to the beginning of the next track.
o Press the SEEK (
) once to skip
back to the beginning of the track.
MUTE Switch
o Press the MUTE switch to disappear the sound.
o Press the MUTE switch again to
reproduce the sound.
VOL (
/ ) Switch
o Press the VOL (
) switch to in-
crease volume.
o Press the VOL (
) switch to de-
cease volume.
B700A01CM-GAT (If Installed) If your vehicle has an aux and/or USB(universal serial bus) port or iPod port, you can use an aux port to connectaudio devices and an USB port to plug in an USB and also an iPod port to plug in an iPod. ❈ iPod is a trademark of Apple Inc.
NOTE: When using a portable audio device connected to the power outlet, noise may occur during playback. If thishappens, use the power source of the portable audio device.
OCM029134
AUX, USB AND iPod
CM-aust-1a.p65
5/21/2008, 2:10 PM
98

1
FEATURES OF YOUR HYUNDAI
99HEATING AND COOLING CONTROL
B710A01TB-DAT (If installed)
1. Side Demister Nozzle
2. Side Ventilator
3. Windshield Demister Nozzle
4. Centre Ventilator B710B02O-DAT CENTRE VENTILATOR The centre ventilators are located in the middle of the dashboard. To change the direction of the air flow, move the knobin the centre of the vent up-and-down and side-to-side. The vents are opened when the vent knob is moved to " "position. The vents are closed when the vent knob is moved to " ". Keep these vents clear of any obstructions.
B710C01HP-DAT SIDE VENTILATOR The side ventilators are located on each side of the dashboard. To change the direction of the air flow, move the knob in the centre of the vent up-and-down and side-to-side. The vents are opened when the vent knob is moved to " " position. The vents are closedwhen the vent knob is moved to " ". Keep these vents clear of any obstruc- tions.
OCM052147R
CM-aust-1a.p65 5/21/2008, 2:10 PM
99

1FEATURES OF YOUR HYUNDAI
100HEATING AND VENTILATION
B670A03O-AAT There are three controls and two switches for the heating and coolingsystem. They are:
1. Air intake control switch
2. Air conditioning switch
3. Air flow control
4. Fan speed control
5. Temperature control B670B01CM-GAT Fan Speed Control (Blower Control)
The fan speed control knob allows you to control the fan speed of the airflowing from the ventilation system. To change the fan speed, turn the knob to the right for higher speed or left for lowerspeed. To turn off the fan, turn the knob to the off (0) position.
OCM051048R
OCM052153
OCM028153
Type A Type B
The ignition switch must be in the ON position for fan operation.
CM-aust-1a.p65 5/21/2008, 2:10 PM
100

1
FEATURES OF YOUR HYUNDAI
101
B670D01L-DAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, dashboardoutlets, or windshield. Five symbols are used to represent Face, Bi-Level, Floor, Floor-Demist and Demist air po-sition.
With the "Fresh" mode selected, airenters the vehicle from the outside andis heated or cooled according to the function selected. With the "Recirculation" mode selected, air from within the passenger compart- ment will be drawn through the heatingsystem and heated or cooled according to the function selected. NOTE: It should be noted that prolonged operation of the heating system in "Recirculation" mode (

) will give
rise to fogging of the windshield and side windows and the air within thepassenger compartment will become stale. In addition prolonged use of the air conditioning with the "Recir- culation" mode (
) selected may
result in the air within the passenger compartment becoming excessively dry.
OCM052156R
B670C03E-AAT Air Intake Control SwitchOCM052154
This is used to select fresh outside air or recirculate inside air. To change the air intake control mode,(Fresh mode, Recirculation mode) push the control button. FRESH MODE (
) : The indicator
light on the button is illuminated when the air intake control is in fresh mode. RECIRCULATION MODE (
) : The
indicator light on the button is illumi- nated when the air intake control is in recirculation mode.
