2007 TOYOTA TUNDRA Owners Manual

2002007 TUNDRA from Jul. ’07 Prod. (OM34463U)
(a) Brake System Warning Light andbuzzer
This light comes on in the following cases
when the ignition switch is in the “ON”
position.
When the parking brake is applied...
This light comes on for a few seconds
when the ignition switch is turned to the
“ON” position even after the parking brake
is released.
When the brake fluid level is low...
CAUTION
It is dangerous to continue driving
normally when the brake fluid level is
low.
Have your vehicle checked at your
Toyota dealer in the following case:
The light does not come on even if the
parking brake is applied when the igni-
tion switch is in the “ON” position.
The light does not come on even if the
ignition switch is turned on with the
parking brake released.
A warning light turning on briefly during
operation does not indicate a problem.
CAUTION
If either of the following conditions
occurs, immediately stop your vehicle
at a safe place and contact your
Toyota dealer.
The light does not turn off even
after the parking brake is released
while the engine is running.
In this case, the brakes may not
work properly and your stopping
distance will become longer. De-
press the brake pedal firmly and
bring the vehicle to an immediate
stop.
The brake system warning light re-
mains on together with the “ABS”
warning light.
In this case, not only the antilock
brake system will fail but also the
vehicle will become extremely un-
stable during braking.
(b) Driver’s Seat Belt Reminder Light and Buzzer
The light and buzzer act as a reminder to
buckle up the driver’s seat belt.
Once the ignition switch is turned to “ON”
or “START”, the reminder light flashes and
buzzer sounds if the driver ’s seat belt is
not fastened. Unless the driver fastens the
belt, the light continues flashing and the
buzzer stops after about 4 to 8 seconds.
If the vehicle speed rises above 20 km/h
(12 mph) with the seat belt unfastened,
the buzzer will sound for about 10 sec-
onds. Then, if the seat belt is still unfas-
tened, the buzzer will sound in a different
tone for 20 seconds. Even if the vehicle
speed drops below 20 km/h (12 mph), the
buzzer will continue to sound. To stop the
buzzer, fasten the seat belt. If the buzzer
still sounds, make sure the front passen-
ger ’s seat belt is fastened.

2012007 TUNDRA from Jul. ’07 Prod. (OM34463U)
(c) Front Passenger ’s Seat Belt Re-minder Light and Buzzer
The light and buzzer act as a reminder to
have the front passenger buckle up the
seat belt.
Once the ignition switch is turned to the
“ON” position, the reminder light flashes if
a passenger sits in the right front passen-
ger seat and does not fasten the seat
belt.
If the vehicle speed rises above 20 km/h
(12 mph) with the seat belt unfastened,
the buzzer will sound for 10 seconds.
Then, if the seat belt is still unfastened,
the buzzer will sound in a different tone
for 20 seconds. Even if the vehicle speed
drops below 20 km/h (12 mph), the buzzer
will continue to sound. To stop the buzzer,
fasten the seat belt. If the buzzer still
sounds, make sure the driver ’s seat belt
is fastened.
The buzzer can be disabled. For details,
contact your Toyota dealer.
If luggage or other load is placed on the
front passenger seat, depending on its
weight, the reminder light to flash and
buzzer to sounds. (d) Charging System Warning Light
This warning light comes on when the
ignition switch is turned to the “ON” posi-
tion, and goes off when the engine is
started.
When there are problems in the charging
system while the engine is r
unning, the
warning light comes on.
NOTICE
When the charging system warning
light comes on while the engine is
running, malfunctions such as the en-
gine drive belt being broken may have
occurred. If the warning light comes
on, immediately stop the vehicle in a
safe place and contact your Toyota
dealer.
(e) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are
driving, pull off the road to a safe place
and stop the engine immediately. Call a
Toyota dealer or qualified repair shop for
assistance.
The light may occasionally flicker when
the engine is idling or it may come on
briefly after a hard stop. There is no
cause for concern if it then goes out when
the engine is accelerated slightly.
The light may come on when the oil level
is extremely low. It is not designed to
indicate low oil level, and the oil level
must be checked using the level dipstick.
NOTICE
Do not drive the vehicle with the
warning light on—even for one block.
It may ruin the engine.

2022007 TUNDRA from Jul. ’07 Prod. (OM34463U)
(f) Malfunction Indicator Lamp
This lamp comes on when the ignition
switch is turned to the “ON” position
and goes off after the engine starts.
This means that the warning light sys-
tem is operating properly.
If the lamp remains on, or the lamp
comes on while driving, first check the
followings.
Empty fuel tank
If the fuel tank is empty, refuel immedi-
ately.
Loose fuel tank cap
If the fuel tank cap is loose, securely
tighten it.
These cases are temporary malfunctions.
The malfunction indicator lamp will go off
after taking several driving trips.
If the lamp does not go off even after
several trips, contact your Toyota dealer
as soon as possible.
If the fuel tank is not empty or the fuel
tank cap is not loose...
There is a problem somewhere in the
engine, emission control system, elec-
tronic throttle control system, automatic
transmission electrical system or warn-
ing light system itself. Contact your Toyota dealer as soon as
possible to service the vehicle.
If engine speed does not increase when
the accelerator pedal is depressed, there
may be a problem somewhere in the elec-
tronic throttle control system.
At this time, vibration may occur. Howev-
er, if you depress the accelerator pedal
more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle
checked by your Toyota dealer as soon as
possible.
Even if the abnormality of the electronic
throttle control system is corrected during
low speed driving, the system may not be
recovered until the engine is stopped and
the ignition switch is turned to the “ACC”
or “LOCK” position.
CAUTION
Be especially careful to prevent erro-
neous pedal operation.
Emissions Inspection and Maintenance
(I/M) programs
Your vehicle may not pass a state
emission inspection if the malfunction
indicator lamp remains on. Contact your
Toyota dealer to check your vehicle’s
emission control system and OBD
(On
−Board Diagnostics) system before
taking your vehicle for the inspection.
For details, see “Emissions Inspection and
Maintenance (I/M) programs” in Section 6.
(g) Engine Oil Replacement Reminder Light (for vehicles sold in U.S.A.)
This light acts as a reminder to replace
the engine oil.
This light will come on when the ignition
switch is turned to the “ON” position and
will go off after about a few seconds.
When you drive for about 7200 km (4500
miles) after the engine oil replacement,
this light illuminates for about 3 seconds
and then flashes for about 12 seconds
with the ignition switch turned to the “ON”
position. If you continue driving without
replacing the engine oil, and if the
distance driven exceeds 8000 km (5000
miles), the light will come on after the
ignition switch is turned to “ON” position.
The light will remain on thereafter.

2032007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If the light is flashing, we recommend that
you replace the engine oil at an early
opportunity depending on the driving and
road conditions. If the light comes on,
replace it as soon as possible.
The system must be reset after the
engine oil replacement. Reset the system
by the following procedure:1. Turn the ignition switch to the “OFF” position with the trip meter A reading
shown. (For details, see “Odometer and
two trip meters” on page 186 in this
Section.)
2. Turn the ignition switch to the “ON” position while holding down the trip
meter reset knob.
Hold down the knob for at least 5
seconds. The trip meter A indicates
“000000” and the light goes off.
If the system fails to reset, the light will
continue flashing.
(h) Low Fuel Level Warning Light
This light comes on when the fuel level
in the tank becomes nearly empty. Fill up
the tank as soon as possible.
On inclines or curves, due to the move-
ment of fuel in the tank, the low fuel level
warning light may come on earlier than
usual. (i) “ABS” Warning Light
The light comes on when the ignition
switch is turned to the “ON” position. If
the anti
−lock brake system and the brake
assist system work properly, the light
turns off after a few seconds. Thereafter,
if either of the systems malfunctions, the
light comes on again.
When the “ABS” warning light is on (and
the brake system warning light is off), the
following systems do not operate, but the
brake system still operates conventionally.
Anti −lock brake system
Brake assist system
Traction control system
“AUTO LSD” system
Vehicle stability control system
When the “ABS” warning light is on (and
the brake system warning light is off), the
anti −lock brake system does not operate,
so that the wheels will lock up during a
sudden braking or braking on slippery
road surfaces.
If either of the following conditions oc-
curs, this indicates a malfunction some-
where in the components monitored by
the warning light system. Contact your
Toyota dealer as soon as possible to
service the vehicle.
The light does not come on when the
ignition switch is turned to the “ON”
position, or remains on.
The light comes on while you are dri-
ving.
A warning light turning on briefly during
operation does not indicate a problem.
CAUTION
If the “ABS” warning light remains on
together with the brake system warn-
ing light, immediately stop your ve-
hicle at a safe place and contact your
Toyota dealer.
In this case, not only the antilock
brake system will fail but also the
vehicle will become extremely unsta-
ble during braking.

2042007 TUNDRA from Jul. ’07 Prod. (OM34463U)
(j) “VSC OFF” warning light
The light flashing warns that there is a
problem somewhere in the following.
Vehicle stability control system
Traction control system
“AUTO LSD” system
The light will come on when the ignition
switch is turned to the “ON” position, and
will go off after a few seconds.
If the light flashes on while driving, the
above mentioned systems do not work.
However, as conventional braking operates
when applied, there is no problem to con-
tinue your driving.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition switch is turned to the
“ON” position.
The warning light remains on after the
ignition switch is turned to the “ON”
position.
The warning light flashes while driving. (k) Open Door Warning Light
This light remains on until all the doors
are completely closed.
The buzzer also sounds once when any
of the doors is not completely closed at
the vehicle speed 5 km/h (3 mph) or
more. Stop the vehicle and close all the
door completely.
(l) SRS Warning Light
This light will come on when the igni-
tion switch is turned to the “ON” posi-
tion. After about 6 seconds, the light
will go off. This means the systems of
the airbag and front seat belt preten-
sioners are operating properly.
This warning light system monitors the
airbag sensor assembly, front airbag sen-
sors, side and curtain shield airbag sen-
sors, curtain shield airbag sensors, driv-
er ’s seat position sensor, driver ’s seat belt
buckle switch, front passenger occupant
classification system
∗, passenger airbag
off switch, passenger airbag on −off indica-
tor light, seat belt pretensioner assem-
blies, inflators, “RSCA OFF” indicator light,
interconnecting wiring and power sources.
∗: The front passenger occupant classifica-
tion system includes the front passenger
occupant classification ECU, load sensor
and front passenger ’s seat belt buckle
switch.
If either of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.
The light does not come on when the
ignition switch is turned to the “ON”
position or remains on for more than
6 seconds.
The light comes on while driving.
(m) Tire Pressure Warning Light
This light warns that the tire inflation pres-
sure of one or more of your tires (except
for the temporary spare tire) is low. The
light comes on when the ignition switch is
turned to the “ON” position. It goes off
after a few seconds. This indicates that
the tire pressure warning system is func-
tioning properly.

2052007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If the light comes on, stop your vehicle in
a safe place as soon as possible and
check that the tire inflation pressure of all
four tires is as specified on the tire and
loading information label. (See “Checking
tire inflation pressure” on page 548 in
Section 7−2.) The light should go off 3 to
6 minutes after the tire inflation pressure
is adjusted.
If the warning light comes on after blink-
ing for 1 minute, the tire pressure warning
system may be malfunctioning. Contact
your Toyota dealer.
For details, see “Tire pressure warning
system” on page 251 in Section 1 −7.
(n) Automatic Transmission Fluid Tem- perature Warning Light
This light warns that the automatic trans-
mission fluid temperature is too high.
If this light comes on while you are driv-
ing, slow down and pull off the road. Stop
the vehicle at a safe place and put the
selector lever in “P”. With the engine id-
ling, wait until the light goes off. If the
light goes off, you may start the vehicle
again. If the light does not go off, call a
Toyota dealer or qualified repair shop for
assistance.NOTICE
Continued driving with the warning
light on may damage the automatic
transmission.
(o) Master Warning Light
If the master warning light comes on, a
message appears on the multi −information
display. Depending on the conditions a
warning tone may sound. (See “—Warning
messages” on page 193 in this Section for
instructions.)
(p) Low Windshield Washer Fluid Level Warning Light
The light warns that the windshield washer
fluid level is too low. Add washer fluid at
your earliest opportunity. (For instructions,
see “Adding washer fluid” on page 563 in
Section 7 −3.)
The light will come on when the ignition
switch is turned to the “ON” position and
will go off after a few seconds.
(q) Key Reminder Buzzer
This buzzer acts as a reminder to remove
the key when you open the driver’s door
with the ignition switch in the “ACC” or
“LOCK” position. (r) Parking Brake Reminder Buzzer
The buzzer acts once when the parking
brake is not completely released at the
vehicle speed of 5 km/h (3 mph) or more.
Stop the vehicle and release the parking
brake fully.
(s) Fourwheel Drive System Warning
Buzzer (fourwheel drive models)
This buzzer reminds you that the transfer
mode is not selected correctly.
If the buzzer sounds when you shift the
transfer from “2WD” to “4H”, “4L” to “4H”,
“4H” to “4L”, or “4L” to “2WD” mode, fol-
low the instructions in “Four −wheel drive
system” on page 239 in Section 1 −7.
(t) Open Moon Roof Reminder Buzzer
This buzzer acts as a reminder to close
the moon roof when you turn the ignition
switch off and open the driver ’s door.

2062007 TUNDRA from Jul. ’07 Prod. (OM34463U)
CHECKING SERVICE REMINDER
INDICATORS (except the low fuel level
warning light)
Without multi−information display—
1. Apply the parking brake.
2. Open one of the doors. The open door warning light should
come on.
3. Close the door. The open door warning light should go
off.
4. Turn the ignition switch to the “ON” position, but do not start the engine.
All the service reminder indicators ex-
cept the open door warning light should
come on.
The following service reminder indica-
tors go off after a few seconds:
Engine oil replacement reminder light
“ABS” warning light
“RSCA OFF” indicator light
“VSC OFF” indicator/warning light
“AUTO LSD” indicator light
Tire pressure warning light
Slip indicator light
Low windshield washer fluid level warn-
ing light The SRS warning light goes off after
about 6 seconds.
With multi −information display—
1. Apply the parking brake.
2. Open one of the doors. The open door warning light should
come on.
3. Close the door. The open door warning light should go
off.
4. Turn the ignition switch to the “ON” position, but do not start the engine.
All the service reminder indicators ex-
cept the open door warning light should
come on.
The following service reminder indica-
tors go off after a few seconds:
Engine oil replacement reminder light
“ABS” warning light
“RSCA OFF” indicator light
“VSC OFF” indicator/warning light
“AUTO LSD” indicator light
Tire pressure warning light
Slip indicator light
Master warning light
The SRS warning light goes off after
about 6 seconds. If any service reminder indicator or warn-
ing buzzer does not function as described
above, have it checked by your Toyota
dealer as soon as possible.

2072007 TUNDRA from Jul. ’07 Prod. (OM34463U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Ignition switch, Transmission and Parking brake
Ignition switch208
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Automatic transmission 209
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Four −wheel drive system 239
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Traction control system 242
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
”AUTO LSD” system 244
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Vehicle stability control system 248
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressure warning system 251
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking brake 258
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Cruise control 259
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
SECTION 1 7
