2007 TOYOTA TUNDRA Owners Manual

1922007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS16013d
Normal display
XS16014c
Zoom display
This meter displays the odometer and
two trip meters.
Selecting the zoom display of the
odometer and trip meter when the
cruise information is displayed causes
the odometer and one of the trip me-
ters to be displayed simultaneously.1. Odometer—Shows the total distance the vehicle has been driven.
2. Two trip meters—Show two different distances independently driven since
the last time each trip meter was set
to zero.
You can use one trip meter to calculate
the fuel economy and the other to
measure the distance on each trip. All
trip meter data is cancelled if the elec-
trical power source is disconnected.
3. Trip meter reset knob—Resets the two trip meters to zero, and also changes
the meter display.
To change the meter display, quickly
push and release the knob. The meter
display changes in the order from the
odometer to trip meter A to trip meter
B, then back to the odometer each
time you push. To reset the trip meter A to zero, dis-
play the meter A reading, then push
and hold the knob until the meter is
set to zero. The same process can be
applied for resetting the trip meter B.
—Odometer and two trip
meters

1932007 TUNDRA from Jul. ’07 Prod. (OM34463U)
MessageStatusAction
(a)Parking brake is not released.Release parking brake.
(b)Engine coolant temperature is too high.Stop your vehicle and allow engine to cool.
(c)Any of doors are opened.Close doors completely.
—Warning messages

1942007 TUNDRA from Jul. ’07 Prod. (OM34463U)
MessageStatusAction
(d)Fuel in tank becomes nearly empty.Fill up tank.
(e)Automatic transmission fluid temperature is
too high.Stop and check.
(f)Oil change is nearly due.Check engine oil.
(g)Oil change is due.Replace engine oil.
(h)Washer fluid level is low.Add washer fluid.

1952007 TUNDRA from Jul. ’07 Prod. (OM34463U)
(a)
This message is to warn the driver that
the parking brake is not completely re-
leased at the vehicle speed of 5 km/h
(3 mph) or more.
Stop the vehicle and release the park-
ing brake fully.
The message appears with the master
warning light flashes, brake system warn-
ing light and a warning tone sounds.
(b)
This message is to warn the driver that
the engine coolant temperature is too
high.
Stop the vehicle and allow the engine
to cool.
The message appears with the master
warning light flashes and a warning tone
sounds.
NOTICE
Do not continue driving with an over-
heated engine. See “If your vehicle
overheats” on page 497 in Section 4.
(c)
This message is to remind the driver
that any of the doors are opened.
Close the door securely.
The message appears with the master
warning light flashes, open door warning
light and a warning tone sounds when the
vehicle speed rises above 5 km/h (3
mph).
(d)
This message is to remind the driver
that the fuel level in the tank becomes
nearly empty.
If the message appears with the low fuel
level warning light comes on and a warn-
ing tone sounds, fill up the tank as soon
as possible.The message disappears by pressing
“SELECT RESET” button when the ignition
switch is in the “ON” position. However,
the low fuel level warning light remains
on.
(e)
This message is to warn the driver that
automatic transmission fluid tempera-
ture is too high.
If the automatic transmission fluid temper-
ature is too high, the message appears
with the automatic transmission fluid tem-
perature warning light comes on and a
warning tone sounds.
If this message appears while you are
driving, slow down and pull off the road.
Stop the vehicle at a safe place and put
the selector lever in “P”. With the engine
idling, wait until the message goes off. If
the message goes off, you may start the
vehicle again. If the message does not go
off, call a Toyota dealer or qualified repair
shop for assistance.

1962007 TUNDRA from Jul. ’07 Prod. (OM34463U)
NOTICE
Continue driving with the warning
message on may result in damage of
the automatic transmission.
(f) (U.S.A. only)
This message is to remind the driver to
change the engine oil. The message is
a prior notice.
Toyota recommends that the engine oil
be changed as soon as possible.
If the driving range after the previous oil
change reaches 7200 km (4500 miles), the
message appears for about 15 seconds
with the master warning light and a warn-
ing tone sounds.
The engine oil maintenance data must be
reset after the engine oil change. See
following “Resetting the engine oil
maintenance data”. (g)
(U.S.A. only)
This message is to remind the driver to
change the engine oil.
Change the engine oil as soon as pos-
sible.
If the driving range after the previous oil
change reaches 8000 km (5000 miles), the
message appears with the master warning
light and a warning tone sounds. The
message stays on with the ignition switch
is turned to the “ON” position.
The engine oil maintenance data must be
reset after the engine oil change. See
“Resetting the engine oil maintenance
data” below for the procedure to reset the
system.
Resetting the engine oil maintenance
data
The engine oil maintenance data must be
reset after replacement of the engine oil.
Reset the data by the following procedure: 1. Turn the ignition switch to the “ACC” or “LOCK” position with the trip meter
A reading shown. (For details, see
“Odometer and two trip meters” on
page 186 in this Section.) 2. Turn the ignition switch to the “ON”
position while holding down the trip
meter reset knob.
Hold down the knob for at least 5
seconds. The information display indicates
“MAINT REQD RESET MODE
COMPLETE”, the master warning light
turns on and the tone sounds.
If the system fails to reset, perform the
above procedure again.
(h)
This message appears when the washer
fluid level becomes very low.
Fill the tank as soon as possible.
The message appears with the master
warning light, low windshield washer fluid
level warning light and a warning tone
sounds.
If the message appears, fill the washer
tank as soon as possible. For instruc-
tions, see “Adding washer fluid” on
page 563 in Section 73.

1972007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If the indicator or buzzer comes on...Do this.
(a)
(indicator and buzzer)
orIf parking brake is off, stop immediately and contact Toyota dealer.
(b)
(indicator and buzzer)
Fasten driver ’s seat belt.
(c)
(indicator and buzzer)
Fasten front passenger ’s seat belt.
(d)Stop immediately and contact Toyota dealer.
(e)Stop and check.
(f)Take vehicle to Toyota dealer.
Service reminder indicators and warning buzzers

1982007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If the indicator or buzzer comes on...Do this.
(g)Replace engine oil.
(h)Fill up tank.
(i)orTake vehicle to Toyota dealer.
If brake system warning light is also on, stop immediately and contact Toyota dealer.
(j)If the light flashes, take vehicle to Toyota dealer.
(k)Close all doors.
(l)Take vehicle to Toyota dealer immediately.
(m)Adjust tire inflation pressure. If the warning light comes on after blinking for 1 minute,
contact Toyota dealer.

1992007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If the indicator or buzzer comes on...Do this.
(n)Stop and check.
(o)Read a warning message on multi−information display.
(p)Add washer fluid.
(q)Key reminder buzzerRemove key.
(r)Parking brake reminder buzzerRelease parking brake.
(s)Four −wheel drive system warning
buzzerShift the transfer mode correctly.
(t)Open moon roof reminder buzzerClose moon roof.
