2007 TOYOTA TUNDRA Owners Manual

4962007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS40003a
Connecting point for 5.7 L V8 (3URFE)
engine
Do not connect the cable to or near
any part that moves when the engine
is cranked.
CAUTION
When making the connections, to
avoid serious injury, do not lean over
the battery or accidentally let the
jumper cables or clamps touch any-
thing except the correct battery termi-
nals or the ground.
5. Charge the discharged battery with thejumper cables connected for approxi-
mately 5 minutes. At this time, run the
engine in the vehicle with the booster
battery at about 2000 rpm with the ac-
celerator pedal lightly depressed.
6. Start your engine in the normal way. After starting, run it at about 2000 rpm
for several minutes with the accelerator
pedal lightly depressed.
7. Carefully disconnect the cables in the exact reverse order: the negative cable
and then the positive cable.
8. Carefully dispose of the battery cover cloths—they may now contain sulfuric
acid.
9. If removed, replace all the battery vent plugs.
If the cause of your battery discharging is
not apparent (for example, lights left on),
you should have it checked at your Toyota
dealer. If the first start attempt is not success-
ful...
Check that the clamp on the jumper
cables are tight. Recharge the discharged
battery with the jumper cables connected
for several minutes and restart your en-
gine in the normal way.
If another attempt is not successful, the
battery may be depleted. Have it checked
at your Toyota dealer.

4972007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If your engine stalls while driving...1. Reduce your speed gradually, keeping a straight line. Move cautiously off the
road to a safe place.
2. Turn on your emergency flashers.
3. Turn the ignition switch to the “ACC” or “LOCK” position, and try starting the
engine again.
If the engine will not start, see “If your
vehicle will not start” on page 493 in this
Section.
CAUTION
If the engine is not running, the pow-
er assist for the brakes and steering
will not work so steering and braking
will be much harder than usual.
If engine speed does not increase when
the accelerator pedal is depressed, there
may be a problem somewhere in the elec-
tronic throttle control system.
At this time, vibration may occur. Howev-
er, if you depress the accelerator pedal
more firmly and slowly, you can drive your
vehicle at low speeds. Have your vehicle
checked by your Toyota dealer as soon as
possible.
Even if the abnormality of the electronic
throttle control system is corrected during
low speed driving, the system may not be
recovered until the engine is stopped and
the ignition switch is turned to the “ACC”
or “LOCK” position.
CAUTION
Be especially careful to prevent erro-
neous pedal operation.
If your engine coolant temperature
gauge indicates overheating, if you ex-
perience a loss of power, or if you hear
a loud knocking or pinging noise, the
engine has probably overheated. You
should follow this procedure... 1. Pull safely off the road, stop the ve- hicle and turn on your emergency
flashers. Put the transmission in “P”
and apply the parking brake. Turn off
the air conditioning if it is being used.
2. If coolant or steam is boiling out of the radiator or reservoir, stop the engine.
Wait until the steam subsides before
opening the hood. If there is no coolant
boiling over or steam, leave the engine
running.
CAUTION
To help avoid personal injury, keep
the hood closed until there is no
steam. Escaping steam or coolant is
a sign of very high pressure.
If your engine stalls while
driving If you cannot incr
ease engine
speed If your vehicle overheats

4982007 TUNDRA from Jul. ’07 Prod. (OM34463U)
3. Visually check to see if the enginedrive belt (fan belt) is broken or loose.
Look for obvious coolant leaks from the
radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has
been used.
CAUTION
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.
4. If the engine drive belt is broken or thecoolant is leaking, stop the engine im-
mediately. Call a Toyota dealer for as-
sistance.
5. If the engine drive belt is O.K. and there are no obvious leaks, you may
help the engine cool down more quickly
by running it at about 1500 rpm for a
few minutes with the accelerator pedal
lightly depressed.
6. Check the coolant reservoir. If it is dry, add coolant to the reservoir while the
engine is running. Fill it about half full.
For the coolant type, See “Coolant type
selection” on page 546 in Section 7 −2.
CAUTION
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure.
7. After the engine coolant temperature
has cooled to normal, again check the
coolant level in the reservoir. If neces-
sary, bring it up to half full again. Seri-
ous coolant loss indicates a leak in the
system. You should have it checked as
soon as possible at your Toyota dealer.
1. Reduce your speed gradually, keeping a straight line. Move cau-
tiously off the road to a safe place
well away from the traffic. Avoid
stopping on the center divider of
a highway. Park on a level spot
with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. With the transmission in “P” firmly set the parking brake.
4. Have everyone get out of the ve- hicle on the side away from traffic.
5. Read the following instructions thoroughly.
If you have a flat tire—

4992007 TUNDRA from Jul. ’07 Prod. (OM34463U)
CAUTION
When jacking, be sure to observe
the following to reduce the possi-
bility of death or serious injury:
Follow jacking instructions.
 Do not put any part of your
body under the vehicle sup-
ported by the jack. Otherwise,
personal injury may occur.
 Do not start or run the engine
while your vehicle is supported
by the jack.
 Stop the vehicle on a level firm
ground, firmly set the parking
brake and put the transmission
in “P”. Block the wheel diago-
nally opposite to the one being
changed if necessary.
Make sure to set the jack prop-
erly in the jack point. Raising
the vehicle with jack improper-
ly positioned will damage the
vehicle or may allow the ve-
hicle to fall off the jack and
cause death or serious injury.
 Never get under the vehicle
when the vehicle is supported
by the jack alone.
 Use the jack only for lifting
your vehicle during wheel
changing.
 Do not raise the vehicle with
someone in the vehicle.
 When raising the vehicle, do
not place any objects on top
of or underneath the jack.
 Raise the vehicle only high
enough to remove and change
the tire.NOTICE
Do not continue driving with a
deflated tire. Driving even a
short distance can damage a
tire and wheel beyond repair.

5002007 TUNDRA from Jul. ’07 Prod. (OM34463U)
The temporary spare tire is de-
signed for temporary emergency
use only.
See also the tire information on page
548 through 557 in Section 7−2 for
details on the treadwear indicators
and other service information.
CAUTION
 The temporary spare tire was
designed especially for your
Toyota. Do not use it on any
other vehicle.
 Do not use more than one tem-
porary spare tire at the same
time.
 The pressure for the temporary
spare tire must be 230 kPa (2.3
kgf/cm
2 or 2.3 bar, 33 psi).
 Do not exceed 80 km/h (50
mph) when driving with the
temporary spare tire.
Replace the temporary spare
tire with the standard tire as
soon as possible.
 Avoid sudden a cceleration,
sudden d eceleration and sharp
turns with the temporary spare
tire.
NOTICE
The temporary spare tire does
not have a tire pressure warn-
ing valves and transmitters. If
you replace one of the road
tires with the spare, the tire
pressure warning light may be
illuminated. Tire pr essure warn-
ing system should be operated
properly by reinstall the road
tire containing the tire pressure
warning valves and transmit-
ters.
XS40043
Regular cab models
(behind the right seatback)
—Temporary spare tire —Required tools and temporary
spare tire

5012007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS40009a
Double cab models
(under the right rear seats
without storage box)
XS40038a
Double cab models
(under the right rear seats with
storage box)
XS40044
Crew Max models
(behind the right rear seatback)

5022007 TUNDRA from Jul. ’07 Prod. (OM34463U)
1. Get the required tools and tem-porary spare tire.
1 Tool bag
2Jack
To prepare yourself for an emergency,
you should familiarize yourself with
the use of the jack, each of the tools
and their storage locations.
When storing the tool bag, make sure
it is securely by the tightening strap.
XS40037b
Storage box lid
Before getting the required tools
(Double cab models with the stor-
age box) 1. Remove the right storage box lid by following the procedure below:
1 Turn the knob to the open posi-
tion.
2 Lift the lid to an upright posi-
tion.
3 Slide the lid forward until it dis- engages from the box.
XS40036b
Jack cover
panel
2. Remove the jack cover panel as
shown in the illustration.

5032007 TUNDRA from Jul. ’07 Prod. (OM34463U)
LS40036
Turn the jack joint by hand.
To rem ov e: Tur n the joint in direction
1 until the jack is free.
To store: Turn the joint in direction 2
until the jack is fi rmly secured to pre-
vent it flying forward during a collision
or sudden braking.
XS40006
To remove the temporary spare tire:
1. Put a jack handle extension and jack handle end together as shown
in the illustration.
1 Jack handle extension No.1
2 Jack handle extension No.2
3 Wheel nut wrench
CAUTION
Make sure they are each securely
fixed.
XS40008
2. Insert the end of the jack handle
extension No.1 into the lowering
screw and turn it counterclock-
wise.
3. After the tire is lowered completely to the ground, remove the holding
bracket.
When storing the temporary spare
tire, put it in place with the outer side
of the wheel facing up. Then secure
the tire, taking care that the tire goes
straight up without catching on any
other part, to prevent it from flying for-
ward during a collision or sudden
braking.
