2007 TOYOTA TUNDRA Owners Manual

2402007 TUNDRA from Jul. ’07 Prod. (OM34463U)
The A.D.D. can be engaged or disen-
gaged by the shifting operations de-
scribed in “(c) Shifting procedure”.
You should drive in four−wheel drive for
at least 16 km (10 miles) each month.
This will assure that the front drive com-
ponents are lubricated. SHIFTING BETWEEN “2WD” AND “4H”
To shift from “2WD” to “4H”,
reduce the
vehicle speed to less than 100 km/h (62
mph) and turn the front drive control
switch knob fully clockwise.
When the ambient temperature is −15 C
(5.0 F) or lower, shifting can be performed
with the vehicle speed below 70 km/h (43
mph).
If the “4HI” (high speed four −wheel drive)
indicator light continues to blink when you
operate the front drive control switch knob
from the “2WD” to the “4H” position, this
reminds you that the transfer mode is not
securely in “4H” mode. Drive straight
ahead while accelerating or decelerating.
If the “4HI” (high speed four −wheel drive)
indicator light continues to blink and the
buzzer sounds when you operate the front
drive control switch knob from the “2WD”
to the “4H” position, this reminds you that
the transfer mode is not in “4H” mode.
Stop the vehicle or reduce the vehicle
speed to less than 100 km/h (62 mph).
(When the ambient temperature is −15 C
(5.0 F) or lower, it needs to be reduced
to below 70 km/h (43 mph).) Operate the
switch knob again.CAUTION
Never operate the front drive control
switch knob if the wheels are slip-
ping. Stop the slipping or spinning
before operating.
To shift from “4H” to “2WD”, reduce the
vehicle speed to less than 100 km/h (62
mph) and turn the front drive control
switch knob fully counterclockwise.
When you operate the front drive control
switch knob from “4H” to “2WD” with the
vehicle speed at 100 km/h (62 mph) or
higher, the “4HI” indicator light continues
to blink and buzzer sounds. When the
switch knob is returned from “2WD” to
“4H”, the indicator light turns off and the
buzzer stops sounding.
If the “4HI” (high speed four −wheel drive)
indicator light continues to blink when you
operate the front drive control switch knob
from the “4H” to the “2WD” position, this
reminds you that the transfer mode is not
securely in “2WD” mode. Drive straight
ahead while accelerating or decelerating,
or drive forward or backward in a short
distance.
(b) A.D.D. (automatic
disconnecting differential) (c) Shifting procedure

2412007 TUNDRA from Jul. ’07 Prod. (OM34463U)
If there is any malfunction within the
brake system, “4HI” or “4LO” indicator
light blinks and the transfer mode may not
be able to be shifted from “4H” to “2WD”.
If the indicator light continues to blink
even if doing so, contact your Toyota
dealer as soon as possible. There may be
a trouble in the four−wheel drive system.
CAUTION
Never operate the front drive control
switch knob if the wheels are slip-
ping. Stop the slipping or spinning
before operating.
SHIFTING BETWEEN “4H” AND “4L”
To shift between “4H” and “4L”
1. Bring the vehicle to a complete stop with the brake pedal held down.
2. Shift the automatic transmission selec- tor lever into “N”.
3. To shift from “4H” to “4L”, push and turn the front drive control switch knob
fully clockwise.
To shift from “4L” to “4H”, turn the
front drive control switch knob counter-
clockwise. 4. Maintain this condition until the “4LO”
or “4HI” indicator light comes on.
If the “4LO” indicator light continues to
blink...
If this indicator light continues to blink
when you operate the front drive control
switch knob to the “4H” or “4L” position,
stop the vehicle completely, shift the auto-
matic transmission selector lever securely
into “N” and operate the switch knob
again.
INFORMATION
 If the engine coolant temperature is
too low the transfer mode may not
be able to be shifted. When the en-
gine is warmer operate the switch
knob again.
 If the automatic transmission selec-
tor lever is moved before the indi-
cator comes on, the transfer mode
may not be shifted completely. In
this case, stop the vehicle com-
pletely, return the automatic trans-
mission selector lever to “N” and
operate the switch knob again.
If there is any malfunction in the brake
system or the engine, “4HI” or “4LO” indi-
cator light blinks and the transfer mode
may not be able to be shifted from “4H”
to “4L”.
If the indicator continues to blink even if
doing so, contact your Toyota dealer as
soon as possible. There may be a trouble
in the four −wheel drive system.

2422007 TUNDRA from Jul. ’07 Prod. (OM34463U)
The traction control system automatical-
ly helps prevent the spinning of rear
wheels (twowheel drive models) or 4
wheels (fourwheel drive models) when
the vehicle is started or accelerated on
slippery road surfaces.
When the ignition switch is turned to the
“ON” position, the system automatically
turns on.
CAUTION
Under certain slippery road condi-
tions, full traction of the vehicle and
power to the rear wheels (twowheel
drive models) or 4 wheels (fourwheel
drive models) cannot be maintained,
even though the traction control sys-
tem is in operation. Do not drive the
vehicle under any speed or maneuver-
ing conditions which may cause the
vehicle to lose traction control. In si-
tuations where the road surface is
covered with ice or snow, your ve-
hicle should be fitted with snow tires
or tire chains. Always drive at an ap-
propriate and cautious speed for the
present road conditions.
XS17004a
Ty p e A
XS17005a
Ty p e B
NORMAL DRIVING MODE
Leave the system on during the ordi-
nary driving so that it can operate
when needed.
You may hear a sound in the engine
compartment for a few seconds when the
engine is started or just after the vehicle
begins to move. This means that the trac-
tion control system is in the self−check
mode, but does not indicate a malfunction.
When the traction control system is oper-
ating, the following conditions occur:
The system controls the spinning of the
rear wheels (two −wheel drive models)
or 4 wheels (four −wheel drive models).
At this time, the slip indicator light
blinks.
You may feel vibration or noise in your
vehicle, caused by operation of the
brakes. This indicates the system is
functioning properly.
The slip indicator light comes on for a few
seconds when the ignition switch is turned
to the “ON” position. If the indicator light
does not come on when the ignition is
turned on, contact your Toyota dealer.
Traction control system

2432007 TUNDRA from Jul. ’07 Prod. (OM34463U)
The brake actuator temperature increases
during continuous operation of the follow-
ing systems under conditions such as on
slippery roads.
Traction control system
“AUTO LSD” system
If the brake actuator temperature becomes
too high while any of the systems is oper-
ating, a buzzer will start to sound intermit-
tently to indicate that the traction control
system can no l onger operate. In this
case, immediately stop your vehicle at a
safe place.
If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At the time, the slip indicator light will
come on and the traction control system
temporarily stops operating in order to
protect the brake actuator. (Although the
traction control system does not operate,
it is no problem to continue driving.) The
system will be automatically restored after
a short time and the slip indicator light
goes off.XS17010a
TRACTION CONTROL OFF MODE
(twowheel drive mode only)
When getting the vehicle out of mud or
newly fallen snow, etc., it may be bene-
ficial to turn off the traction control
system. This system that controls en-
gine performance interferes with the
process of freeing rear wheels.
To turn off: Briefly push the “VSC OFF”
switch.
The “AUTO LSD” and slip indicator lights
will come on.
The vehicle stability control system is al-
ways activated, even if the traction control
system is turned off. To turn on: Briefly push the “VSC OFF”
switch once again.
The “AUTO LSD” and slip indicator lights
will go off.
If the engine is turned off while the
“AUTO LSD” and slip indicator lights are
on and then restarted, the indicator lights
will turn off automatically.
When you push and hold the “VSC OFF”
switch for 3 seconds or more with the
vehicle stopped, turn off the vehicle stabil-
ity control system. See “Vehicle stability
control system” on page 248 in this Sec-
tion.
“AUTO LSD” and slip indicator lights come
on for a few seconds when the ignition
switch is turned to the “ON” position. If
the indicator lights do not come on when
the ignition switch is turned to the “ON”
position, contact your Toyota dealer.
CAUTION
Do not drive with the traction control
system continuously turned off.

2442007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS17006a
Ty p e A
XS17007a
Ty p e B
“VSC OFF” warning light
The light flashing warns that there is a
problem somewhere in the following.
Traction control system
Vehicle stability control system
“AUTO LSD” system
When the system is normal and the igni-
tion switch is turned to the “ON” position,
the light will come on and will go off after
a few seconds.
If the “VSC OFF” warning light flashes
while driving, the traction control system
does not work. However, if the brakes
operate normally when applied, it is no
problem to continue your driving.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition switch is turned to the
“ON” position.
The warning light remains on after the
ignition switch is turned to the “ON”
position.
The warning light flashes while driving
XS17009
The “AUTO LSD” system aids traction
by using the traction control system to
control engine performance and braking
when one of the rear wheels begins to
spin.
This system should be used only when
wheel spinning occurs in a ditch or
rough surface.
This system is effective in case one of
the rear wheels is spinning.
“AUTO LSD” system

2452007 TUNDRA from Jul. ’07 Prod. (OM34463U)
CAUTION
Do not use the “AUTO LSD” system
in conditions other than the above. A
much greater steering effort and more
careful cornering control will be re-
quired.
XS17010a
To turn on the system, briefly push the
“VSC OFF” switch.
The “AUTO LSD” is activated under the
following condition. At this time, the
“AUTO LSD” and slip indicator lights
will come on.
The driving mode is set in the two−
wheel drive mode (In the four −wheel
drive mode, the system does not
work.)
Driving at a speed under 100 km/h (62
mph)
To turn off the system, briefly push the
“VSC OFF” switch again and the “AUTO
LSD” and slip indicator lights will go off. If the engine is turned off while the
“AUTO LSD” and slip indicator lights are
on and then restarted, the indicator light
will turn off automatically.
When you push and hold the “VSC OFF”
switch for 3 seconds or more with the
vehicle stopped, turn off the vehicle stabil-
ity control system. See “Vehicle stability
control system” on page 248 in this Sec-
tion.

2462007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS17011a
Ty p e A
XS17012a
Ty p e B
Make sure the “AUTO LSD” and slip indi-
cator lights come on under the above con-
dition when you use the “AUTO LSD” sys-
tem.
The slip indicator light blinks when the
system is controlling the spinning of the
rear wheels.
The “AUTO LSD” and slip indicator lights
come on for a few seconds when the
ignition switch is turned to the “ON” posi-
tion. If the indicator lights does not come
on when the ignition switch is turned to
the “ON” position, contact your Toyota
dealer.
The brake actuator temperature increases
during continuous operation of the follow-
ing systems under conditions such as on
slippery roads.
“AUTO LSD” system
Traction control system
If the brake actuator temperature becomes
too high while any of the systems is oper-
ating, a buzzer will start to sound intermit-
tently to indicate that the “AUTO LSD”
system can no l onger operate. In this
case, immediately stop your vehicle at a
safe place. If the system continues to operate, the
buzzer sound changes from intermittent to
continuous. (The continuous buzzer
sounds for about 3 seconds.)
At the time the slip indicator light will
come on and the “AUTO LSD” system
temporarily stops operating in order to
protect the brake actuator. (Although the
“AUTO LSD” system does not operate, it
is no problem to continue driving.) The
system will be automatically restored after
a short time.

2472007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS17006a
Ty p e A
XS17007a
Ty p e B
“VSC OFF” warning light
The light flashing warns that there is a
problem somewhere in the following.
“AUTO LSD” system
Traction control system
Vehicle stability control system
When the system is normal and the igni-
tion switch is turned to the “ON” position,
the light will come on and will go off after
a few seconds.
If the “VSC OFF” warning light flashes
while driving, the “AUTO LSD” system
does not work. However, as the brakes
operate normally when applied, it is no
problem to continue your driving.
In the following cases, contact your Toyota
dealer:
The warning light does not come on
after the ignition switch is turned to the
“ON” position.
The warning light remains on after the
ignition switch is turned to the “ON”
position.
The warning light flashes while driving.
CAUTION
Do not drive with the “AUTO LSD”
system continuously turned on.
