2007 TOYOTA TUNDRA Owners Manual

3922007 TUNDRA from Jul. ’07 Prod. (OM34463U)
Ventilation
For best results, set controls to:
For automatic operation—Press in the “AUTO” button.
Temperature— Towards low temperature
Air intake—FRESH (outside air)
Air conditioning—OFF
For manual operation—
Fan speed— To the desired fan speed
Temperature— Towards blue zone
Air intake—FRESH (outside air)
Air flow—PANEL
Air conditioning—OFF
Defogging and defrosting
—The inside of the windshield
For best results, set controls to:
For automatic operation—
Temperature— Towards high temperature
to heat; low temperature
to cool
Air intake—FRESH (outside air)
Air flow—WINDSHIELD
For manual operation—
Fan speed— To the desired fan speed
Temperature— Towards high temperature
to heat; low temperature
to cool
Air intake—FRESH (outside air)
Air flow—WINDSHIELD
Pressing the windshield button turns on
the defroster −linked air conditioning. At
this time, the air conditioning turns on
regardless of the “A/C” button indicator
comes on or goes off. This is not a mal-
function. This is to clean up the front view
more quickly.
On humid days, do not blow cold air
on the windshield—the difference be-
tween the outside and inside tempera-
tures could make the fogging worse.
—The outside of the windshield
For best results, set controls to:
For automatic operation—
Temperature— Towards high temperature
Air intake—FRESH (outside air)
Air flow—WINDSHIELD
For manual operation—
Fan speed— To the desired fan speed
Temperature— Towards high temperature
Air intake—FRESH (outside air)
Air flow—WINDSHIELD
Pressing the windshield button turns on
the defroster −linked air conditioning. At
this time, the air conditioning turns on
regardless of the “A/C” button indicator
comes on or goes off. This is not a mal-
function. This is to clean up the front view
more quickly.

3932007 TUNDRA from Jul. ’07 Prod. (OM34463U)
To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.
XS19024
OpenCloseOpenClose
Side and center vents
XS19023a
Open
Close
Rear vents (Crew Max models)
If air flow control is not satisfactory, check
the instrument panel and rear vents. The
instrument panel and rear vents may be
opened or closed as shown.
Instrument panel and rear
vents

3942007 TUNDRA from Jul. ’07 Prod. (OM34463U)
Air conditioning filter—
XS19017
The air conditioning filter information
label is placed inside of the glove box
as shown and indicates that a filter has
been installed.
The air conditioning filter prevents dust
from entering the vehicle through the air
conditioning vent.
XS19007
The air conditioning filter is behind the
glove box.The air conditioning filter may clog af-
ter long use. The filter may need to be
replaced if the air flow of the air condi-
tioning and heater experiences extreme
reductions in operating efficiency, or if
the windows begin to fog up easily.
To maintain the air conditioning efficiency,
inspect and replace the air conditioning
filter according to the maintenance
schedule. In dusty areas or areas with
heavy traffic flow, such as inner city or
desert areas, early replacement may be
required. (For scheduled maintenance
information, please refer to the “Scheduled
Maintenance Guide” or “Owner ’s Manual
Supplement.”)
—Checking and replacing the
air conditioning filter

3952007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS19008
1. Open the glove box, and slide offthe damper as shown.
XS19009c
2. Push in each side of the glove boxto disconnect the claws.
XS19010a
3. Remove the filter cover while push-ing in both ends of the cover.

3962007 TUNDRA from Jul. ’07 Prod. (OM34463U)
XS19011a
4. Pull the filter out of the filter outlet.Inspect the filter on the surface.
If it is dirty, it should be replaced.
XS19012
When installing the filter in the filter
outlet, keep the arrow pointing up.
INFORMATION
The air filter should be installed prop-
erly in position. The use of air condi-
tioning with the air filter removed
may cause deteriorated dustproof per-
formance and then affect air condi-
tioning performance.

3972007 TUNDRA from Jul. ’07 Prod. (OM34463U)
OPERATION OF INSTRUMENTS AND
CONTROLS
Other equipment
Accessory meter398
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Intuitive parking assist 402
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Compass 407
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
Cigarette lighter and ashtray 411
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlets (12 VDC) 412
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
.
Power outlet (115 VAC) 414
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. .
Glove boxes 416
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
Garage door opener 416
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
Auxiliary boxes 420
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Sunglass holder 421
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Card holder 422
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Map holder 423
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Pen holder 425
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . .
Tissue pocket 425
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Center console box 426
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Front cup holders 428
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .
Rear cup holders 429
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . .
Bottle holders 430
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Storage box 431
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Seatback table 432
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . .
Deck hooks 432
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Grocery bag/cargo net hooks 433
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 433
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . .
SECTION 1 10

3982007 TUNDRA from Jul. ’07 Prod. (OM34463U)
Accessory meter—
1. Outside temperature and cruise infor-mation display or outside temperature
display
2. Clock
3. “H” button
4. “M” button
5. “INFO” button (with cruise information)
6. “SELECT RESET” button (with cruise information)
7. “SETUP US/M” button
XS10001c

3992007 TUNDRA from Jul. ’07 Prod. (OM34463U)
Operate the accessory meter with the
ignition switch on.
When the ignition switch is turned to
“ON”, the last previously used mode dis-
played just before the ignition switch is
turned off will appear.
When the instrument panel lights are
turned on, the brightness of the display
will be reduced.
CAUTION
Do not adjust the display while the
vehicle is moving. Be sure to adjust
the display only when the vehicle is
stopped.
SELECTING UNIT
You can select the unit between En-
glish/U.S. customary system and metric
unit.
To select the unit A (English/U.S. custom-
ary system) or unit B (metric unit), push
“SETUP US/M” button.
The unit variations are as follows:Information
Unit AUnit B
Average fuel
consumption and
Instantaneous
fuel consumption
MPGL/100 km
Driving rangeMILESkm
Outside
temperatureFC
XS10003b
The displayed temperature ranges from
− 40 C ( −40 F) up to 50 C (122 F).
The ignition switch must be in the “ON”
position.
If an abnormality exists in the connection
of the outside air temperature sensor,
“ −−− C” (“ −−−F”) will appear on the dis-
play. If “ −−−C” (“ −−−F”) appears on the
display, contact your Toyota dealer.
There may be a case that “−−− C”
(“−−− F”) appears momentarily when the
ignition switch is quickly turned to “ON”.
It is normal if it goes out soon.
—Before using the accessory
meter —Outside temperature display
(without cruise information)
