2007 FORD FIESTA Workshop Manual

206-06-3 Hydraulic Brake Actuation 206-06-3
DESCRIPTION. AND OPERATION
Hydraulic Brake Actuation - Vehicles Built Up To: 0112004
Brake pedal
I 1 I U-shaped profile of the brake pedal I
1 2 1 Latch I
1 3 1 Carrier plate I
The brake pedal is equipped with a safety device
which uncouples the brake pedal from the brake
master cylinder in the event of a severe frontal
collision to reduce injuries to the feet of the driver.
As a result, the pressure acting from the brake
master cylinder on the brake pedal is interrupted
and the brake pedal can be pushed to the floor.
The brake pedal is divided into
3 parts: a U-shaped
profile, a latch and a carrier plate within the brake
pedal.
2006.0 Fiesta 1212006 ~205541 en
procarmanuals.com

206-0614 Hydraulic Brake Actuation 206-06-4
DESCRIPTION AND OPERATION
Function
Item Description
I A I Fascialcrash padding mounting I
Connection point between the latch and
the pedal
1 2 1 Retaining pin (plastic) I
1 3 I Mounting bore I
1 4 1 Mounting for the brake servo actuation rod I
Item Description k
I A I Direction of motion of the latch I
I B I Direction of motion of the pedal I
I 1 I Sheared off retaining pin I
The latch is twisted around the mounting axis of
the pedal, and in the process the retaining pin is
cut through.
The connection point of the brake pedal is
released, and no more force can be transmitted.
The complete pedal unit is mounted via a bore in
The carrier plate ofthe pedal is uncoupled from
the carrier date. the U-shaped pedal and the pedal is left to swing I free.
The U-shaped profile of the brake pedal is held in
position by the latch at a connection point. It
is very important not to damage the retaining pin
when working on the pedal box.
In the event of a severe impact the entire pedal
box is pushed into the
footwell. As the pedal box
is pushed into the footwell, the latch on the upper
side of the brake pedal is pushed against the
mounting of the
fascialcrash padding.
2006.0 Fiesta 1~1200s ~205541 en
procarmanuals.com

206-06-5 Hydraulic Brake Actuation 206-06-5
DIAGNOSIS AND TESTING
Hydraulic Brake Actuation
REFER to Section 206-00 [Brake System -
General Information].
2006.0 Fiesta 1212006 GI 7506en
procarmanuals.com

206-06-6 Hydraulic Brake Actuation 206-06-6
REMOVAL AND INSTALLATION
Brake Pedal - RHD(12 333 0)
Removal
All vehicles
A WARNING:ln the event of a frontal impact
to a vehicle equipped with a decoupler
brake pedal in which damage to, or
significant movement of, the instrument
panel or the brake booster has occurred,
a new brake pedal must be installed.
Failure to follow this instruction may result
in personal injury.
1. Remove the instrument panel lower panel.
1. Remove the lower retaining screws.
2. Remove the upper retaining screws from the
stowage compartment.
3. Release the clip.
2. Detach the brake booster actuating rod from
the brake pedal (accelerator pedal shown
removed for clarity).
I. Depress the clip.
2. Remove the brake booster actuating rod pin.

Vehicles with manual transaxle 1.
3. N0TE:From 0212004 the brake pedal will not
be equipped with the brake pedal decoupler
mechanism.
Remove the brake pedal.
1. Remove the pivot shaft nut.
2. Slide out the pedal pivot shaft.
3. Remove the brake pedal.
4. Remove the brake pedal bushings. ( ,:
Vehicles with automatic transaxle
5. N0TE:From 0212004 the brake. pedal will not
be equipped with the brake pedal decoupler
mechanism.
Remove the brake pedal.
1. Remove the pivot shaft nut.
2. Slide out the pedal pivot shaft.
2006.0 Fiesta 1212006 G89190en
procarmanuals.com

206-06-7 Hydraulic Brake Actuation 206-06-7
REMOVAL AND INSTALLATION
3. Remove the brake pedal.
6. Remove the brake pedal bushings.
Installation
Im ACAUTION:D~ not drop or knock the brake
pedal. Failure to follow this instruction will
cause damage to the brake pedal decoupler
mechanism (if equipped).
To install, reverse the removal procedure.
2006.0 Fiesta 1212006 G89190en
procarmanuals.com

206-06-8 Hydraulic Brake Actuation 206-06-8
REMOVAL AND INSTALLATION
Brake Master Cylinder - RHD(12 343 0)
Removal 4. Tighten the bleed nipple. \,
All vehicles
CAUTI0N:lf brake fluid is spilt on the
paintwork, the affected area must be
immediately washed down with cold water.
I. Disconnect the brake vacuum pipe from the
brake booster.
I. Unclip the brake vacuum pipe.
2. Disconnect the brake vacuum pipe.
6. Install the brake fluid reservoir cap.
7m &AUTION:C~~ the brake tubes to prevent
fluid loss or dirt ingress.
Disconnect the brake tubes from the brake
master cylinder.
2. Disconnect the battery ground cable. For
additional information, refer to
Section
414-01 [Battery, Mounting and
Cables].
3. Remove the windshield wiper motor
assembly. For additional information, refer
to Section
501 -1 6 [Wipers and Washers].
4m &AUTION:T~~ brake fluid reservoir cap
must not become contaminated.
Vehicles with anti-lock brakes
Remove the brake fluid reservoir cap.
5. N0TE:lt will be necessary to carry out this 8m &AUTION:C~~ the brake tubes to prevent
fluid loss or dirt ingress.
step on both sides in order to completely
drain the brake fluid reservoir.
Drain the brake fluid reservoir.
1. Connect one end of a suitable piece of clear
plastic pipe to the bleed nipple and place the
other end into a suitable container.
2. Loosen the bleed nipple.
3. Depress the brake pedal until all the fluid is
drained from the brake fluid reservoir.
2006.0 Fiesta 1212006 ~89191 en
procarmanuals.com

206-0619 Hydraulic Brake Actuation 206-0619
REMOVAL AND INSTALLATION
Disconnect the brake tubes from the brake 11. Disconnect the low brake fluid warning
master cylinder. indicator switch electrical connector.
I
All vehicles
9m &AUTION:C~~ the clutch master cylinder
feed hose to prevent fluid loss or dirt
ingress.
Disconnect the clutch master cylinder feed
hose from the brake fluid reservoir.
12. Remove the brake master cylinder and
brake fluid reservoir assembly.
Installation
A CAUTI0N:Make sure the brake master
cylinder vacuum seal is correctly
positioned before installation.
I. To install, reverse the removal procedure.
2. Bleed the brake system. For additional
information, refer to Section
206-00 [Brake
System
- General Information].
10. Detach the brake master cylinder from the
brake booster.
2006.0 Fiesta 1212006 G89191 en
