1991 MITSUBISHI ECLIPSE Service Manual

BODY - Loose Panel
LOOSE PANEL
- REMOVAL AND INSTALLATION
, Frbnt
piI@ (LH),/
N22SAAK ,
-.
v trayFront deck
crossmember
+ADeck crossmember stay
/Front
I
‘-9-14 Nm7-10 ftlbs.slaememoer
mWaterproof plate\K?%--
(RH)
WA0471Headlight supportWA.0741
,
/
WA0463, Headlight support
/-c---x/
I IHood lock support
_Headlight supporte duct
MA0742
WA0472
e Dumper,18AO484

23-54BODY - Window Glass
WINDOW GLASS
N23LAAB
GENERALThe windshield and
liftgate window glass are attached by an urethane-base adhesive to the window frame.
This adhesive not only provides improved glass holding and sealing, but also permits use of body openings
having a greater
structural strength.
ADHESIVE, PRIMER AND RESERVE ITEMSItems
ApplicationsQuantityAdhesive, Primer
Adhesive:As required
3M Super Fast Urethan Part No.8609
or equivalent
Primer:As required
3M Super Fast Urethan Primer
Part
No.8608 or equivalentReserve items
Dispensing nozzleOne
Wire (dia. x length)for cutting adhesiveLir,“$c;s onfi wire(62 in.
x 3.3 ft.)
Adhesive gunfor adhesive application
OneIsopropyl alcoholfor cleaning jointing surfacesAs required
Wiping ragsAs required
Sealerfor prevention of water leaks andAs requiredgathering after adhesive applicationIsopropyl alcoholfor cleaning
As requiredGlass holderTwo
Spacers (Service Part)As required
Window moulding assembly
One(Service part)
Tectyl 506T (Valvoline Oil Company)As required

BODY - Window Glass23-55
WINDSHIELD INSTALLATION PROCEDURE
_-Body
--
+
e-eRemoval of moulding
(Wire)
IFinishing of adhesive
surfaceGlass-tIf reusing glass;
r --------- 1 ---s------ - -‘-,
IRemoval of adhesive and dam rL---------r---s---------- I
e-e _---mm,- __-_--_ 1,(Paint thinner)
II
IIIship ofglass tobody
IApplication of solvent
(Isopropyl alcohol)
III
-*I(Isopropyl alcohol)
(glass blackout primer)
pi&g(urethane adhesive)
-1 I- - -Installation of glass
_to body
ICleaning of attaching
surface
1If water leaks
--------------~
p%zG&pJ(Isopropyl alcohol)

23-56BODY - Window Glass
Recommended tool
Make the toolby
Windshield glass
Roof panel
scoop out
this portion.
iiiii- ,.:::i:::::::::::i.p:://jiiiig;iiiijjiiij
I&
::::::::::iiiiiii.::;QuarterQuarter
panelwindow
glass
WA0870Windshield
uppermoulding
Primer
Quarter
window
moulding
front---
---. Cuthere.
4%
>/yere.
MAO672-
REPLACEMENT OF MOULDING (WINDSHIELDUPPER
MOULDING AND QUARTER WINDOW p;MOULDING FRONT)
N22LABc -1. Remove the mouldings. (Refer to
P.23-58, 61.)
2.To cut the existing adhesive, make a tool such as the one
shown.3. Using the tool, scoop out the existing adhesive.
Caution
Take care not to remove more adhesive than neces-
sary, and not to scratch the glass or body.
4.Cut away part of the new moulding and provisionally attachthe moulding. Check to be sure that it fits closely to the
surface.
5.A coating of the specified primer should be applied to the
moulding.
Specified primer:
3M Super Fast Urethan Primer Part
No. 8808 or equivalent
Caution
Do not touch the surfaces that are coated with primer.

BODY - Window Glass23-57Windshield
uppermoulding
Additional
Quarter window
moulding front6. Apply a coating of the specified adhesive where shown in
the illustration, and then install the moulding before the
adhesive hardens.
Specified adhesive: 3M Super Fast Urethan PartNo. 8609 or equivalent
7. Scrape away excessive sealant forced out during installa-
tion of the moulding from the glass or body and wipe the
surfaces clean with MOPAR SUPER KLEEN or equivalent.8. After completion of installation, leave the moulding undis-
turbed until the adhesive hardens.
-.

23-58BODY - Windshield
WINDSHIELD
REMOVAL AND INSTALLATION
ISA0466
Pre-removal Operation0 Removal of Hood
(Refer to P.23-34.)0 Removal of Wiper Arm
(Refer to GROUP &WindshieldWiper)
l Removal of Front Deck Garnish
(Refer to
P.23-47.)0 Removal of Front Headlining Trim
(Refer to P.23-89.)0 Removal of Drip Moulding
(Refer to P.23-72.)
Post-installation Operation0 Installation of Drip Moulding
(Refer to P.23-72.)0 Installation of Front Headlining
Trim
(Refer to
P.23-89.)l Installation of Front Deck Garnish
(Refer to
P.23-47.)l installation of Front Wiper Arm(Refer to GROUP 8-WindshieldWiper)
0 Installation of Hood
(Refer to P.23-34.)
NZBLBAR
,
Removal steps1. Inside rear view mirror
2. Windshield upper moulding
a*3. Windshield glass
4. Windshield glass spacer
Installation steps4. Windshield glass spacer
l 2. Windshield upper moulding
+a 3. Windshield glass
1. Inside rear view mirror
NOTE(1 I Reverse the removal procedures to reinstall.(2) +* : Refer to “Service Points of Removal”.(3) l + : Refer to “Service Points of Installation”.(4) H : Non-reusable parts
SERVICE POINTS OF REMOVAL3. REMOVAL OF WINDSHIELD GLASS
(1) Using a sharp-pointed drill, make a hold in the adhesivearea of the windshield.
From inside the vehicle, insert one end of wire through
adhesive material applied to the upper edge of
windshield.
(2) Insert the other end of wire from inside the vehicle
through adhesive material applied to the lower edge of
windshield.
(3) Secure each end of wire to a piece of wood or similar
object.
(4) Carefully cut through adhesive by pulling wire along the
windshield from outsi,de the vehicle in a sawing motion.
Caution
In order to protect the body from damage, apply cloth
tape to all body areas around the installed glass beforecutting the adhesive.

BODY - Windshield
Glass holders
,(5) Make mating marks on the glass and body if the glass
is to be reinstalled.
NOTEUse chalk or equivalent to make mating marks on the
glass and body.
(6) Take out the glass with glass holders.
NOTE
If the glass being removed is to be reinstalled, place it ona protected bench or holding fixture.
SERVICE POINTS OF INSTALLATION2. INSTALLATION OF WINDSHIELD UPPER MOULDING/
3. WINDSHIELD GLASS
(1) Thoroughly remove the adhesive deposited on the
windshield glass and clean applying surface with
isopropyl alcohol.
Allow to dry for at least three minutes.
(2) Apply the specified primer to the entire bonding surfaceof the glass, both to the inside surface and the edge of
the glass.
Allow to dry for five minutes.
Specified primer:
3M Super Fast Urethan Primer
CautionPart No.8608 or equivalent
Use care to avoid spilling primer solution on trim or apainted surface. Wipe away any spilled solution
immediately, because the primer will damage trim orpainted surfaces. Do not touch the primer coated
surface.(3) Use a cutter knife to cut away adhesive so that the
thickness is within 2 mm
(.08 in.) around the entire
circumference of the body flange.
Finish the flange surfaces so that they are smooth.
Caution
Be careful not to remove more adhesive than
necessary, and also not to damage the paintwork onthe body surface with the knife. If the paintwork is
damaged, repair the damaged area with touch-up
paint or Tectyl.
(4) Degrease the bonding surface of the body with isopropyl
alcohol.Allow to dry for at least three minutes.
(5) Attach the windshield upper moulding to the windshield
glass.

23-60BODY - Windshield
SECT. B-B
SECT. A-A(Other areas not illustrated are
the same as those in cross aec-tion A-A.)
Approx.ISA0520 iSAo522&jSECT. C-C(Other areas not illustrated are the same
as those in cross section A-A.1
Nozzle tip
G QApprox 7
I 28)
Approx12
t.47
1.3~0523 mm (in.) 181988
(6) Using the adhesive gun, coat the specified adhesive onthe windshield glass mounting surface of the body
flange.FiSpecified adhesive:
3M Super Fast Urethan Part -No. 8609 or equivalent
NOTECut the nozzle tip into a
V shape to facilitate adhesive
application. Adhesive material begins to cure after fifteenminutes’ when exposure to air.
(7) Using a glass holder, place the glass on the body
opening.
(8) Press the glass gently so that no adhesive appears.
Caution
1.Do not move the glass after installing them to the
body.
2. Place the glass in the previously marked position.3. Use care not to close the water groove
(in the
lower corner of the pinch weld
flange) with
adhesive.4. Wipe off any excessive adhesive that overflows.
(9) Perform the water-test for the windshield.
Use cold water spray, being careful not to direct a
powerful stream of water on the new adhesive material.Allow water to spill over the edges of the glass. If there
are leaks, apply sealant at the leak point(s).
~
Cautions/
If it is necessary to move the vehicle, move it slowly.
(10)Using a clean, lint-free cloth liberally dampened iso-
propyl alcohol, wipe away dirt from the glass perimeter
and the body.
INSTALLATION OF WINDSHIELD WITH NEW ADHESIVE
ONLYThis method is recommended if there is a considerable loss of
adhesion between the old adhesive material and the body
opening, or body opening requires repair. All adhesive materialmust be removed from the pinch-weld flanges.
1. Using a knife or similar tool, remove the old adhesive
material from the pinch weld flanges.
2.Using tape or some other suitable means, mark the bondedareas of the body and the glass at several positions.
3. Using a clean, lint-free cloth liberally dampened with
isopropyl alcohol, prime the pinch-weld flange.
4. If the pinch-weld flange has been repainted, prime it with a
paint finish primer.
Caution1. Do not use blackout glass primer on the pinch-weld
q
flange.2. If the pinch-weld flanges require painting, use a bake-
Lon type paint.
5. For the rest of the service procedure, refer to Installation of
WINDSHIELD on
P.23-59.
