1991 MITSUBISHI ECLIPSE Service Manual

.-
BODY - Troubleshooting
AUTOMATIC SEAT BELT COMPONENTS LOCATION
WA0734
NameSymbolNameSymbolAutomatic seat belt control unit
CFasten switchAAutomatic seat belt motor
Automatic seat belt motor relay
Buckle switch
BuzzerDoor latch switch
EKey reminder switchI
DOuter switchF
GSeat belt warning lightJ
KRelease switchH
B--
A
P
(:0

23-30BODY - TroubleshootingAutomatic seat
belt control unit
Ovter switch
19A034(
IAutomatic seat
1680745
reminder switch

BODY - Service Adjustment Procedures23-31
16A0366
10A0370
SERVICE ADJUSTMENT PROCEDURES
HOOD ADJUSTMENTN23FAAK1. Loosen the hood mounting bolts, and then adjust the hood
by moving it so that the clearance is equal on all sides.
2. Turn the hood bumpers, adjust the height of the hood.
3. Loosen the food latch mounting bolts, and move the food
switch to adjust the attachment between the food switch
and food striker.
LIFTGATE ADJUSTMENTN23FCAE1. Loosen the
liftgate hinges mounting bolts, and then adjust
the liftgate by moving it so that the clearance is equal on all
sides.2. Loosen the
liftgate latch mounting bolts, and move the
liftgate latch to adjust the attachment between the liftgatelatch and
liftgate striker.
FUEL FILLER DOOR ADJUSTMENTN23FDAELoosen the fuel filler door mounting screw and adjust the fuel
filler door so that the clearance around the fuel filler door is evenwithout any height differences.

23-32BODY - Service Adjustment Procedures
‘C16A0711
18AO38t
DOOR ADJUSTMENTNZBFEAF1. Use the special tool to loosen the hinge mounting bolts on
Lc
the body side, and then adjust the clearance around the door_so that it is uniform on all sides.
CautionAttach protection tape to the fender
edges where the
hinge is installed.
2.When the hinge is replaced, loosen hinge mounting bolts ondoor side and adjust alignment of
fen,der panel with front
door panel.
3.Loosen door striker mounting screws to adjust alignment of
door panel.
4.Increase or decrease the number of shims and move strikerto adjust engagement of striker with door latch.
DOOR GLASS ADJUSTMENTNZSFFAK1. Remove the door trim and waterproof film. (Refer to
P.23-65.)
2. Loosen the installation bolt of the window regulator
,%assembly; then move the upper installation back and forth
-and adjust the tilted angle of the glass.
DOOR INSIDE HANDLE PLAY CHECKN23FQAH
If the door inside handle play does not conform to the standard
value, check the door inside handle or door latch assembly, and
replace if necessary.Standard value (A): 2.5-8.5 mm
(.09-.33 in.)
DOOR OUTSIDE HANDLE PLAY CHECKN23FHAH
If the door outside handle play does not conform to the standard
value check the door outside handle or door latch assembly, and
replace if necessary.Standard value
(B): 2.5-6.5 mm (.09-.25 in.)4

BODY - Service Adiistment Procedures23-33
Front floor pan18AO510
?ear floor pan
lOA
lW391
FLOOR PAN INSPECTIONN23FlACA common result of body leaks is a soaked floor mat pad or
carpet, and it’s not unusual to find that the water is getting in
through the floor pan to some other low point in the body. It is
possible however, for water to enter higher up and run
downward to soak the mat.
Since a soaked mat should be removed for drying, it’s a good
way to start your check. Of course, mat removal means you’ll
have to take off door sill plates and pull out seats or seat cushion.
But, this gives you a clear field for action so you can check bodyseam sealing and the plugs in the floor pan.
It’s usually not practical to water test for floor pan or
wheelhousing leaks unless a special underbody water spray
arrangement is available. As an alternate, the best way to locate
these leak points is to look for rusty seam edges or other traces
of leaks after the mats and cushions are removed. Traces of mudare an indication that the water is coming in from below.
WATER TESTN23FPABs1. Close roof lid tightly.
2.Hold hose upward and adjust water fountain to about 50 cm
(20 in.) high.
3. Pour water over the roof from about 30
cm (12 in.) above
roof for more than 5 minutes.
4. While pouring water, check for leak around roof lid.
5. In the event of leakage, check drain hose, weatherstrip
contact and others.

23-34BODY - Hood
HOOD
REMOVAL AND INSTALLATION
N23HAA8
1518AO751
18A0438
LRemoval5
1.Bumper
2.Hood weatherstrip
3.Heat protector4.Hood weatherstrip
5. Headlight hood protector
I)+ 6.Bumper7. Hood support rod
8.Bumper9. Hood switch theft-alarm system
>10.Bumper11.Bumper bracketl *I 12. Hood lock release handlel 13. Hood latch
NOTE
(1) Reverse the removal procedures to reinstall.(2) l 4 : Refer to “Service Points of Installation”.Hood lock release cable removal steps
l 12. Hood lock release handle
w 13. Hood latch
14. Protector15. Hood lock release cable
Hood removal steps
;f3: “,;n,yction for washer tube and nozzle
Hood hinge removal steps
17: ig?ction for washer tube and nozzle
Windshield wiper arms (Refer to GROUP
8-Windshield Wiper.)
18. Front deck garnish
,*I 19. Hood hinge
1
INSPECTIONHOOD SWITCH(I
1 Disconnect the hood switch connector.
(2) Check the continuity between the terminal.
WA0754lBRO665
)
NOTE
m indicates that there is continuity between the terminals.

BODY - Hood23-35
SERWCE POINTS OF INSTALLATION
19. APPLICATION OF GREASE TO HOOD HINGE/IS. HOODLATCH/12.
HOOD LOCK RELEASE HANDLEApply multipurpose grease to all moving parts.
Grease: MOPAR Multipurpose Grease Part No.
2932524 or equivalent
Front end upper bar
18AO3926. INSTALLATION OF BUMPER
Install the bumper so that the amount of projection from thefront end upper bar is as shown in the illustration.

23-36BODY - Liftgate
LIFTGATEN230AAT
REMOVAL AND INSTALLATION/
11-16 Nm
16
/9-14 Nm
’7-10 ft.lbs.
“‘/- -$j7-11 Nm
5-8
ft.lbs.
Removal
1. Bumper2.
Liftgate damper (upper)
3.
Liftgate outer weatherstrip
4.
Liftgate damper (lower)
5. Liftgate opening weatherstrip
Liftgate hinge removal steps
Headlining (Refer to P.23-89.16. Connection for rear washer tube
Center pillar trim (driver’s side) (Refer to
Quarter trim (driver’s side)
3P.23-85.)7. Connection for
liftgate wiring harness
8.
Liftgate9. Liftgate hinge
Liftgate removal steps
6. Connection for rear washer tube
Center pillar trim (driver’s side) (Refer to
Quarter trim (driver’s side)
1P.23-85.)7. Connection for
liftgate wiring harness
8.
Liftgate
Liftgate lock release cable removal steps
Rear seat (Refer to P.23-93.)Scuff plate (driver’s side)
Quarter trim (driver’s side) (Referto
Rear end trim
1P.23-85.)Rear side trim
l a 11. Liftgate latch
15. Release handle cover
l + 16. Liftgate lock release handle17. Liftaate lock release cable
WA0743
Liftgate lock release handle removal steps
Scuff plate (driver’s side)
(Refer to P.23-85.)15. Release handle cover
w 16. Liftgate lock release handle
Liftgate latch removal steps
Rear end trim (Refer to P.23-85.)10. Liftgate switch connector ,4 1 1. Liftgate latch
Liftgate lock cylinder removal steps
Rear end trim (Refer to P.23-85.112. Liftgate unlock switch theft-alarm system >
13. Retainer14. Liftgate lock cylinder
Liftgate striker removal stepsLiftgate
trim (Refer to P.23-86.)18. Liftgate striker
Liftgate stopper removal steps
Rear side trim (Refer to P.23-85.)
c*19. Liftgate stopper
NOTE
(1) Reverse the removal procedures to reinstall.(2) 4* : Refer to “Service Points of Removal”.(3) l * : Refer to “Service Points of Installation”.
