2006 SUBARU BAJA Owners Manual

5-1
5
Audio
Antenna system ............................................ 5-2 Pillar mounted antenna (Non-turbo models) .. 5-2
Roof mounted antenna (Turbo models) ......... 5-2
FM reception ..................................................... 5-3
Installation of accessories ........................... 5-4
Audio set ........................................................ 5-4 Type A audio set ............................................... 5-4
Type B audio set ............................................... 5-5
In-dash 6 CD auto changer (Optional audio unit – if equipped) .......................................... 5-5
AM/FM radio with CD player ........................ 5-6 Radio operation ................................................ 5-6
Compact disc player operation ....................... 5-11
CD changer control (if optional in dash CD changer is connected) ................................... 5-13
Type B audio set (if equipped) ..................... 5-17 Radio operation ................................................ 5-17
Built-in CD changer operation ......................... 5-23
In-dash 6 CD auto changer (if equipped) .... 5-27
Precautions to observe when handling a compact disc .......................................... 5-30

5-2
Audio
AudioAntenna system „
Pillar mounted antenna (Non-turbo
models)
Pull the antenna out to extend it to its full length. „
Roof mounted antenna (Turbo models)
UB5070BA
UB5073BA
UB5074BA

5-3
Audio
– CONTINUED –
Stand the roof antenna up for use. You can detach the
roof antenna by turning it counterclockwise. When fit-
ting the roof antenna, turn it clockwise and tighten it securely.
When working on the cargo bed, be careful notto get poked in the eye by the roof antenna.
NOTE y Detach the roof antenna before putting the vehi-
cle in a garage and before washing it in an auto-
matic car wash.y After detaching the roof antenna, keep the
mounting hole free of dirt and dust. If any dirt or
dust sticks to the hole, remove it before attaching
the roof antenna. y When detaching the roof antenna, grasp and
turn the roof antenna at the base. y To avoid damaging the roof antenna, be careful
not to overtighten it when attaching it.
y Radio reception is not poss ible with the roof an-
tenna folded down. Also, reception deteriorates if
metallic objects are placed near the roof antenna. „
FM reception
Although FM is normally static free, reception can be
affected by the surroundi ng area, atmospheric condi-
tions, station strength and transmitter distance. Build-
ings or other obstructions may cause momentary stat-
ic, flutter or station interference. If reception continues
to be unsatisfactory, swit ch to a stronger station.

5-4
Audio
Installation of accessories
Always consult your SUBARU dealer before installing
a citizen band radio or other transmitting device in
your vehicle. Such devices may cause the electronic
control system to malfunction if they are incorrectly in-
stalled or if they are not suited for the vehicle.Audio set
Your SUBARU may be equipped with one of the fol-
lowing audio sets. See the pages indicated in this sec-
tion for operating details. „
Type A audio set
y Radio operation: refer to page 5-6
y CD (compact disc) player operation: refer to page 5-
11 y CD changer control: refer to page 5-13
UB5066AA

5-5
Audio
– CONTINUED –
„Type B audio set
y Radio operation: refer to page 5-17
y Built-in CD changer operation: refer to page 5-23 „
In-dash 6 CD auto changer (Optional
audio unit – if equipped)
y Inserting and removing a di sc or all discs: refer to
page 5-27
UB5075AA
HS5011AA

5-6
Audio
AM/FM radio wi
th CD player
The audio set will operate only when the ignition switch is in the “ACC” or
“ON” position. „ Radio operation
(1) (2)
(6) (5) (4) (3)
UB5067BB
(1) Power switch/Volume, Tone, Balance, Fader control dial
(2) BAND button
(3) Tuning buttons
(4) Preset buttons
(5) AUDIO button
(6) SCAN button

5-7
Audio
– CONTINUED –
TPower switch and volume/bass/treble/fader/
balance control
V Power switch and volume control (PWR/VOL)
The dial (1) is used for both power (ON/OFF) and vol-
ume control. The radio is turned ON and OFF by push-
ing the dial and the volume is controlled by turning the
dial. V Tone and balance control (AUDIO)
The volume control dial (1) normally functions as a vol-
ume control. This dial becomes a control for Bass,
Treble, Fader or Balance when you select the appro-
priate tone and balance control mode.
Choose desired volume level for each mode by turning
the volume control dial. The control function returns to
volume control mode after approximately 5 seconds.
To change control modes: Each brief press of the
“AUDIO” button (5) changes control modes in the fol-
lowing sequence starting from volume control mode.
(When the radio is first turned on, the control mode is
in the volume control.) The “AUDIO” button (5) is used for selecting the fol-
lowing control modes:
Volume Bass Treble Balance
Fader
