2006 SUBARU BAJA Owners Manual

4-6
Climate control
NOTE
When the dial is placed in the “ ” or “ ” po-
sition, the air conditioner compressor operates
automatically regardless of the position of the air
conditioner button to defog the windshield quick-
ly. At the same time, the air inlet selection is auto-
matically set to “Outside air” mode.
In this state, you cannot select “recirculation”
mode by manually pressing the air inlet selectionbutton. T
Air conditioner button
The air conditioner operates only when the engine is
running. Push the air conditioner button while the fan is in op-
eration to turn on the air conditioner. The indicator light
will come on.
Push it again to turn off the air conditioner. T
Air inlet selection button
Continued operation in the ON position may fog
up the windows. Switch to the OFF position as
soon as the outside dusty condition clears.
UG4507BA
UB4041BA

4-7
Climate control
– CONTINUED –
ON position (Recirculation): Interior air is recirculat-
ed inside the vehicle. Push the air inlet selection but-
ton to the ON position. The indicator light will come on.
Push the air inlet selectio n button to the ON position
for fast cooling with the air conditioner or when driving
on a dusty road.
OFF position (Outside Air): Outside air is drawn into
the passenger compartment. Push the air inlet selec-
tion button again to the OFF position. The indicator
light will go off.
Push the air inlet selection button to the OFF position
when the interior has cooled to a comfortable temper-
ature and the road is no longer dusty. „
Heater operation
T Defrosting or defogging the windshield
To direct warm air to the windshield and front door win-
dows:
1. Set the air flow control dial to “ ”.
2. Turn the temperature control dial all the way to the right.
3. Set the fan speed control dial to the highest speed.
NOTE
Warm air also comes out from the right and left air
outlets. To stop warm ai r flow from these outlets,
turn the corresponding thumb-wheel to the
UB5011AA

4-8
Climate control
“”
posit io n.
T Heating and defrosting
To direct warm air toward the floor and the windshield:
1. Set the air flow control dial to “ ”.
2. Set the temperature control dial to the desired tem-
perature level.
3. Set the fan speed control dial to the desired speed.
NOTE
Warm air also comes out from the right and left air
outlets. To stop warm ai r flow from these outlets,
turn the corresponding thumb-wheel to the
“” posit io n. T
Heating
To direct warm air toward the floor:
1. Set the air inlet selection button to the “OFF” posi- tion.
2. Set the air flow control dial to “ ”.
3. Set the temperature control dial to the desired tem- perature level.
4. Set the fan speed control dial to the desired speed.NOTE
Warm air also comes out from the right and left air
outlets. To stop warm air flow from these outlets,
turn the corresponding thumb-wheel to the
“ ” position.
UB5012AA
UB5013AA

4-9
Climate control
– CONTINUED –
TBi-level heating
This setting allows you to direct air of different temper-
atures from the instrument panel and foot outlets. The
air from the foot outlets is slightly warmer than from the
instrument panel outlets.
1. Set the air inlet selection button to the “OFF” posi- tion.
2. Set the air flow control dial to “ ”.
3. Set the temperature control dial to the desired tem- perature level.
4. Set the fan speed control dial to the desired speed.
Setting the temperat ure control dial fully turned to the
red area or blue area decr eases the temperature dif- ference between the air from the instrument panel out- lets and the air from
the foot outlets.
T Ventilation
To force outside air through the instrument panel out-lets:
1. Set the air inlet selection button to the “OFF” posi-
tion.
2. Set the air flow control dial to “ ”.
3. Set the temperature control dial all the way left.
4. Set the fan speed control dial to the desired speed.
When driving on a dusty road, set the air inlet control
button to the “ON” position.
UB5014AA
UB5015AA

4-10
Climate control
Continued operation with the air inlet selection
button in the ON
position may fog up the win-
dows. Switch to the OFF position as soon as
the outside dusty condition clears.
„ Air conditioner operation
T Cooling or dehumidifying
1) ON position
For cooling and dehumidification of the passenger compartment, performing the following steps will allow
air to flow through the instrument panel outlets:
1. Set the air inlet selection button to the “OFF” posi- tion.
2. Set the air flow control dial to “ ”.
3. Set the air conditioner bu
tton to the “ON” position.
4. Set the temperature contro l dial to the blue area.
5. Set the fan speed control dial at the desired speed. T Defrosting or defogging
1) ON position
To direct warm air to the windshield and front door win-
dows:
1. Set the air outlet control dial to “ ”.
1UB5016BB
1UB5011BB

4-11
Climate control
– CONTINUED –
2. Set the temperature control dial to the red area.
3. Set the fan speed control dial at the highest speed. Operating tips for heater and air con-
ditioner T
Cleaning ventilator grille
Always keep the front ventilator inlet grille free of
snow, leaves, or other obstructions to ensure efficient
heating and defrosting. Since the condenser is located
in front of the radiator, th is area should be kept clean
because cooling performance is impaired by any ac-
cumulation of insects and leaves on the condenser. T Efficient cooling after parking in direct sunlight
After parking in direct sunlight, drive with the windows
UB4037BA

4-12
Climate control
open for a few minutes to allow outside air to circulate
into the heated interior. This results in quicker cooling
by the air conditioner. Keep the windows closed during
the operation of the air conditioner for maximum cool- ing efficiency. T
Lubrication oil circulation in the refrigerant cir-
cuit
Operate the air conditioner compressor at a low en-
gine speed (at idle or low driving speeds) a few min-
utes each month during the off-season to circulate its
oil. T Checking air conditioning system before sum-
mer season
Check the air conditioner unit for refrigerant leaks,
hose conditions, and pro per operation each spring.
This check is best performed by your SUBARU dealer. T Cooling and dehumidifying in high humidity
and low temperature weather condition
Under certain weather conditions (high relative humid-
ity, low temperatures, etc. ) a small amount of water
vapor emission from the ai r outlets may be noticed.
This condition is normal and does not indicate any
problem with the air conditioning system. T
Air conditioner compressor shut-off when en-
gine is heavily loaded
To improve acceleration and gas mileage, the air con-
ditioner compressor is designed to temporarily shut off
during air conditioner operation whenever the acceler-
ator is fully depressed such as during rapid accelera-
tion or when driving on a steep upgrade. T Refrigerant for your climate control system
Your air conditioner uses ozone friendly refrigerant
HFC134a. Therefore, the me thod of adding, changing
or checking the refrigerant is different from the method
for CFC12 (freon). Consult your SUBARU dealer for
service. Repairs needed as a result of using the wrong
refrigerant are not covered under warranty.

4-13
Climate control
– CONTINUED –
Air filtration system (if equipped)
If your vehicle’s air conditioning system is equipped
with a optional air filtration system, replace the filter el-
ement according to the replacement schedule shown
in the following. This schedule should be followed to
maintain the filter’s dust collection ability. Under ex-
tremely dusty conditions, t he filter should be replaced
more frequently. Have your filter checked or replaced
by your SUBARU dealer.
Replacement schedule:
Every 12 months or 9,300 miles (15,000 km) whichev-
er comes first
NOTE The filter can influence th e air conditioning, heat-
ing and defroster performance if not properly
maintained.
