2006 SUBARU BAJA Owners Manual

6-40
Interior and exterior equipments
1. Before placing the crossbar on the roof rails, make
sure that the T-30 torx® head screw is fully loosened
from each end support.
2. Spread the inner clamp and the end support as far
apart as possible.
3. With the front direction arrow label on the top right
side of the crossbar pointing toward the front of the ve-
hicle, carefully place the cro
ssbar across the top of the
vehicle so that the crossbar end supports rest on the
top of the roof rails 7 inches (180 mm) rearward in the
front radius of the roof rail.
4. Move the end support and inner clamp to hook un-
der the end of the roof rail on both sides and loosely
assemble the T-30 torx® head screw with the tool pro- vided into the threaded insert in the inner clamp on
each end of the crossbar.
NOTE
It may be necessary to start the inner clamp and
end support at the center of the roof rail for easier
installation, then move the crossbar forward. Use
care not to cross-thread the screw in the insert if it
has been removed.
5. Adjust the alignment of the crossbar on the roof
rails, and if available, use a T-30 torx® bit and torque
wrench and tighten the T-30 torx® head screws to 30
to 35 lbf·in (3.4 to 4.0 N·m, 0.35 to 0.41 kgf·m) of
torque (or tighten securely with the torx® wrench pro-
7 in (180 mm)
UB6052BB
UB6053BA

6-41
Interior and exterior equipments
– CONTINUED –
vided).
Rear crossbar:
Install the rear crossbar in the same manner as the front crossbar.
NOTE yThe rear crossbar should be positioned just in
front of the rear radius in the roof rail. y Before each use of the roof crossbar, make sure
the four T-30 crossbar clamp screws have been
checked, and retightened if necessary to 35 lbf·in
(4.0 N·m, 0.41 kgf·m), as outlined in Step #5 above.
0 in
(0 mm)
UB6049BB
UB6050BA

6-42
Interior and exterior equipments
Sport activity lights (if equipped)
1) Indicator light
The sport activity lights will operate only when the
parking brake is engaged. Push the “SPORT LIGHTS”
switch to turn the sport activity lights on.
Press the switch agai n to turn them off.
The indicator light located on the switch will illuminate
when the sport activity lights are on.
NOTE y In most states, the sport activity lights must
have stone shields installed when the vehicle is operated on public roads. y
In most states, the sport activity lights may not
be operated when the vehicle is in motion on a
public road.
The sport activity lights mount to the vehicle front cross bar. The sport activi ty lights cross bar wire har-
ness connects to the roof wire harness and then to the
vehicle’s electrical system.
A tool is provided which will activate the sport activity
lights’ positioning to be modified, so that each lamp
can be aimed or rotated. The lamps can be mounted
in two positions, upright (normal) or forward (down-
ward). The lamps should be rotated to the forward
1
UB6041BB
UB3019AA

6-43
Interior and exterior equipments
– CONTINUED –
(downward) position when washing your vehicle. If you choose to remove sport activity lights, the follow-
ing sequence should be utilized:
1. Disconnect the roof harness from the cross bar har-
ness connector.
2. Attach the water proof connector cap to the roof
harness connector.
3. Care should be used when removing or installing
this electrical product.

7-1
7
Starting and operating
Fuel ................................................................ 7-2 Fuel requirements ............................................. 7-2
Fuel filler door and cap .................................... 7-4
State emission testing (U.S. only) ............... 7-6
Preparing to drive ......................................... 7-8
Starting the engine ....................................... 7-9 Manual transmission vehicle ........................... 7-9
Automatic transmission vehicle ...................... 7-10
Stopping the engine ..................................... 7-11
Manual transmission .................................... 7-12 Shifting speeds ................................................. 7-13
Driving tips ........................................................ 7-14
Automatic transmi ssion (Non-turbo
models) ...................................................... 7-14 Selector lever .................................................... 7-15
Driving tips ........................................................ 7-19
Shift lock release .............................................. 7-19
Automatic transmission (Turbo models) ... 7-21
Selector lever .................................................... 7-22
Selector lever reverse inhibiting function ...... 7-25
Selection of SPORTSHIFT mode (manual mode) ................................................ 7-26
Driving tips ........................................................ 7-29
Shift lock release .............................................. 7-29
Limited slip differential (LSD) ...................... 7-30
Power steering .............................................. 7-31
Braking .......................................................... 7-31 Braking tips ....................................................... 7-31
Brake system ..................................................... 7-32 Disc brake pad wear warning indicators ........ 7-32
ABS (Anti-lock Brake System) ..................... 7-33 ABS system self-check .................................... 7-33
ABS warning light ............................................. 7-34
Parking your vehicle ..................................... 7-35
Cruise control ................................................ 7-37 To set cruise control ........................................ 7-38
To temporarily cancel the cruise control ....... 7-39
To turn off the cruise control ........................... 7-39
To change the cruising speed ......................... 7-39
Cruise control set indicator light .................... 7-40

7-2
Starting and operating
Starting and operatingFuel
Use of a fuel which is low in quality or use of an
inappropriate fuel ad
ditive may cause engine
damage.
„ Fuel requirements
T Non-turbo models
The 2.5-liter engine is designed to operate using un-
leaded gasoline with an octane rating of 87 AKI or
higher. T Turbo models
The 2.5-liter turbo engine is designed to operate using
premium unleaded gasoline with an octane rating of
91 AKI or higher. If premium unleaded gasoline is not
available, regular unleaded gasoline with an octane
rating of 87 AKI or higher may be temporarily used.
For optimum engine performance and driveability, it is
required that you use premium grade unleaded gaso-
line. T
Fuel octane rating
This octane rating is the av erage of the Research Oc-
tane and Motor Octane numbers and is commonly re-
ferred to as the Anti Knock Index (AKI).
Using a gasoline with a lower octane rating can cause
persistent and heavy knocking, which can damage the
engine. Do not be concerned if your vehicle some-
times knocks lightly when you drive up a hill or when
you accelerate. See your dealer or a qualified service
technician if you use a fuel with the specified octane
rating and your vehicle kno cks heavily or persistently.
T Unleaded gasoline
The neck of the fuel filler pipe is designed to accept
only an unleaded gasoline filler nozzle. Under no cir-
cumstances should leaded gasoline be used because
it will damage the emission control system and may
impair driveability and fuel economy. T Gasoline for Califo rnia-certified LEV
Your vehicle was certified to California’s low emission
vehicle (LEV) standards as indicated on the under-
hood tune-up label, it is designed to optimize engine
and emission control system performance with gaso-
line that meets the clean bu rning low-sulfur California
gasoline specifications. If you live in any other state
than California, your vehicle will operate on gasoline
meeting Federal specifications. Gasoline sold outside

7-3
Starting and operating
– CONTINUED –
California is permitted to have higher sulfur levels,
which may affect the performance of your vehicle’s
catalytic converter and may produce a sulfur exhaust
odor or smell. SUBARU recommends that you try a
different brand of unleaded gasoline having lower sul-
fur to determine if the problem is fuel related before re-
turning your vehicle to an authorized dealer for ser-
vice. T MMT
Some gasoline contains an octane-enhancing additive
called MMT (Methylcyclopentadienyl Manganese Tri-
carbonyl). If you use such fuels, your emission control
system performance may de teriorate and the CHECK
ENGINE warning light/Malfunction indicator lamp may
turn on. If this happens, return to your authorized
SUBARU Dealer for service. If it is determined that the
condition is caused by the type of fuel used, repairs
may not be covered by your warranty. T Gasoline for cleaner air
Your use of gasoline with detergent additives will help
prevent deposits from forming in your engine and fuel
system. This helps keep yo ur engine in tune and your
emission control system work ing properly, and is a
way of doing your part for cleaner air. If you continu-
ously use a high quality fuel with the proper detergent
and other additives, you should never need to add any fuel system cleaning agents to your fuel tank.
Many gasolines are now blended with materials called
oxygenates. Use of these fuels can also help keep the
air cleaner. Oxygenated blend fuels, such as MTBE
(Methyl Tertiary Butyl ether) or ethanol (ethyl or grain
alcohol) may be used in your vehicle, but should con-
tain no more than 15% MTBE or 10% ethanol for the
proper operation of your SUBARU.
In addition, some gasoline suppliers are now produc-
ing reformulated gasoline, which is designed to reduce
vehicle emissions. SUBARU ap
proves the use of re-
formulated gasoline.
If you are not sure what the fuel contains, you should
ask your service station oper ators if their gasoline con-
tains detergents and oxy genates and if they have
been reformulated to reduce vehicle emissions.
As additional guidance, only use fuels suited for your
vehicle as explained in the following. y Fuel should be unleaded and have an octane rating
no lower than that specified in this manual. y Methanol (methyl or wood alcohol) is sometimes
mixed with unleaded gasoline. Methanol can be used
in your vehicle ONLY if it does not exceed 5% of the
fuel mixture AND if it is accomp anied by sufficient
quantities of the proper cosolvent and corrosion inhib-
