SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-281
STEP 12. Check rear combination lamp (RH) connector
F-03 for loose, corroded or damaged terminals, or
terminals pushed back in the connector.
Q: Is rear combination lamp (RH) connector F-03 in good
condition?
YES : Go to Step 14.
NO : Repair or replace the damaged component(s). Refer
to GROUP 00E, Harness Connector Inspection
P.00E-2. Check that the taillamp (RH) illuminates
normally.
STEP 13. Check the stop/taillamp bulb (RH).
(1) Remove the stop/taillamp bulb (RH).
(2) Verify that the stop/taillamp bulb (RH) is not damaged or
burned out.
Q: Is the stop/taillamp bulb (RH) in good condition?
YES : Go to Step 14.
NO : Replace the stop/taillamp bulb (RH). Verify that the
taillamp (RH) illuminates normally.
STEP 14. Check the ground circuit to the rear combination
lamp (RH). Measure the resistance at rear combination
lamp (RH) connector F-03.
(1) Disconnect rear lamp (RH) connector F-03 and measure
the resistance available at the wiring harness side of the
connector.
(2) Measure the resistance value between terminal 2 and
ground.
The resistance should be 2 ohms or less.
Q: Is the measured resistance 2 ohms or less?
YES : Go to Step 17.
NO : Go to Step 16.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-282
STEP 15. Check the wiring harness between rear
combination lamp (RH) connector F-03 (terminal 2) and
ground.
Q: Is the wiring harness between rear combination lamp
(RH) connector F-03 (terminal 2) and ground in good
condition?
YES : Replace the rear combination lamp socket (RH).
Verify that the taillamp (RH) illuminates normally.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. Verify that
the taillamp (RH) illuminates normally.
STEP 16. Check intermediate connector C-25 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.
Q: Is intermediate connector C-25 in good condition?
YES : Go to Step 17.
NO : Repair or replace the damaged component(s). Refer
to GROUP 00E, Harness Connector Inspection
P.00E-2. Check that the taillamp (RH) illuminates
normally.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-283
STEP 17. Check the wiring harness between rear
combination lamp (RH) connector F-03 (terminal 4) and
intermediate connector C-25 (terminal 8).
NOTE: Check intermediate connector C-25 for loose, corroded,
or damaged terminals, or terminals pushed back in the connec-
tor. If intermediate connector C-25 is damaged, repair or
replace the damaged component(s) as described in GROUP
00E, Harness Connector Inspection P.00E-2.
Q: Is the wiring harness between rear combination lamp
(RH) connector F-03 (terminal 4) and intermediate
connector C-25 (terminal 8) in good condition?
YES : Replace the rear combination lamp socket (RH).
Verify that the taillamp (RH) illuminates normally.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. Verify that
the taillamp (RH) illuminates normally.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-284
STEP 18. Check front combination lamp (LH) connector
A-20 for loose, corroded or damaged terminals, or
terminals pushed back in the connector.
Q: Is front combination lamp (LH) connector A-20 in good
condition?
YES : Go to Step 19.
NO : Repair or replace the damaged component(s). Refer
to GROUP 00E, Harness Connector Inspection
P.00E-2. Check that the front park lamp (LH)
illuminates normally.
STEP 19. Check the front park lamp bulb (LH).
(1) Remove the front park lamp bulb (LH).
(2) Verify that the front park lamp bulb (LH) is not damaged or
burned out.
Q: Is the front park lamp bulb (LH) in good condition?
YES : Go to Step 20.
NO : Replace the front park lamp bulb (LH). Verify that the
front park lamp (LH) illuminates normally.
STEP 20. Check the ground circuit to the front parking
lamp (LH). Measure the resistance at front combination
lamp (LH) connector A-20.
(1) Disconnect front combination lamp (LH) connector A-20
and measure the resistance available at the wiring harness
side of the connector.
(2) Measure the resistance value between terminal 5 and
ground.
The resistance should be 2 ohms or less.
Q: Is the measured resistance 2 ohms or less?
YES : Go to Step 22.
NO : Go to Step 21.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-285
STEP 21. Check the wiring harness between front
combination lamp (LH) connector A-20 (terminal 5) and
ground.
Q: Is the wiring harness between front combination lamp
(LH) connector A-20 (terminal 5) and ground in good
condition?
YES : Replace the front combination lamp socket (LH).
Verify that the front parking lamp (LH) illuminates
normally.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. Verify that
the front park lamp (LH) illuminates normally.
STEP 22. Check the wiring harness between front
combination lamp (LH) connector A-20 (terminal 2) and
front-ECU connector A-11X (terminal 4).
Q: Is the wiring harness between front combination lamp
(LH) connector A-20 (terminal 2) and front-ECU
connector A-11X (terminal 4) in good condition?
YES : No action is necessary and testing is complete.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. Verify that
the front park lamp (LH) illuminates normally.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-286
STEP 23. Check front combination lamp (RH) connector
A-32 for loose, corroded or damaged terminals, or
terminals pushed back in the connector.
Q: Is front combination lamp (RH) connector A-32 in good
condition?
YES : Go to Step 24.
NO : Repair or replace the damaged component(s). Refer
to GROUP 00E, Harness Connector Inspection
P.00E-2. Check that the front park lamp (RH)
illuminates normally.
STEP 24. Check the front parklamp bulb (RH).
(1) Remove the front park lamp bulb (RH).
(2) Verify that the front park lamp bulb (RH) is not damaged or
burned out.
Q: Is the front park lamp bulb (RH) in good condition?
YES : Go to Step 25.
NO : Replace the front park lamp bulb (RH). Verify that the
front park lamp (RH) illuminates normally.
STEP 25. Check the ground circuit to the front parking
lamp (RH). Measure the resistance at front combination
lamp (RH) connector A-32.
(1) Disconnect front combination lamp (RH) connector A-32,
and measure the resistance available at the harness side of
the connector.
(2) Measure the resistance value between terminal 5 and
ground.
The resistance should be 2 ohms or less.
Q: Is the measured resistance 2 ohms or less?
YES : Go to Step 27.
NO : Go to Step 26.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-287
STEP 26. Check the wiring harness between front
combination lamp (RH) connector A-32 (terminal 5) and
ground.
Q: Is the wiring harness between front combination lamp
(RH) connector A-32 (terminal 5) and ground in good
condition?
YES : Replace the front combination lamp socket (RH).
Verify that the front park lamp (RH) illuminates
normally.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. Verify that
the front park lamp (RH) illuminates normally.
STEP 27. Check the wiring harness between front
combination lamp (RH) connector A-32 (terminal 2) and
front-ECU connector A-11X (terminal 4).
Q: Is the wiring harness between front combination lamp
(RH) connector A-32 (terminal 2) and front-ECU
connector A-11X (terminal 4) in good condition?
YES : No action is necessary and testing is complete.
NO : The wiring harness may be damaged or the
connector(s) may have loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Repair the wiring harness as necessary. Verify that
the front parking lamp (RH) illuminates normally.

SYMPTOM PROCEDURES
SIMPLIFIED WIRING SYSTEM (SWS)54B-288
STEP 28. Check licence plate lamp connector F-06 for
loose, corroded or damaged terminals, or terminals
pushed back in the connector.
Q: Is licence plate lamp connector F-06 in good condition?
YES : Go to Step 29.
NO : Repair or replace the damaged component(s). Refer
to GROUP 00E, Harness Connector Inspection
P.00E-2. Check that the licence plate lamps
illuminate normally.
STEP 29. Check the licence plate lamp bulbs.
(1) Remove the licence plate lamp bulbs.
(2) Verify that both licence plate lamp bulbs are not damaged
or burned out.
Q: Are both licence plate lamp bulbs in good condition?
YES : Go to Step 30.
NO : Replace the licence plate lamp bulbs. Verify that the
licence plate lamps illuminate normally.
STEP 30. Check the ground circuit to the licence plate
lamp. Measure the resistance at licence plate lamp
connector F-06.
(1) Disconnect licence plate lamp connector F-06 and measure
the resistance available at the wiring harness side of the
connector.
(2) Measure the resistance value between terminal 1 and
ground.
The resistance should be 2 ohms or less.
Q: Is the measured resistance 2 ohms or less?
YES : Go to Step 32.
NO : Go to Step 31.
